- Page 1 ASSEMBLY INSTRUCTIONS FIREPLACE SURROUND...
- Page 2 FIREPLACE SURROUND BEFORE FIRST USE, READ THE OPERATING AND INSTALLATION INSTRUCTIONS Manufacturer: The Hitze brand is owned by STALKO Spółka z ograniczoną odpowiedzialnością sp. k. ul. Solec 24/253, 00-403 Warszawa OFFICE / WAREHOUSE: 32 Gdyńska Street, 26-600 Radom Hotline: +48 800 880 030...
- Page 3 Thank you for purchasing a product from the Hitze range! Warmth from Nature - these words perfectly illustrate the Hitze brand philosophy. In line with this, we manufacture fireplaces and cookers, Thanks to modern technology, we have created innovative solutions that are characterised by a modern design and high heating efficiency.
- Page 4 U W A G A 1. DANGER OF BURNS! THE GLASS AND PARTS OF THE FIREPLACE SURROUND MAY BE VERY HOT. 2. DO NOT TOUCH THE APPLIANCE AND THE HOUSING UNTIL THEY HAVE COOLED DOWN COMPLETELY. 3. NEVER LEAVE CHILDREN OR PETS UNATTENDED IN FRONT OF A BURNING OR JUST EXTINGUISHED FIREPLACE.
-
Page 5: Table Of Contents
This manual is protected by copyright. All rights reserved. The manufacturer reserves the right to make corrections and amendments to the manual without any notification to anyone. The version of the manual should be verified with the version on www.hitze.pl. -
Page 6: General Information
GENERAL INFORMATION Important: Keep these instructions! ■ The rigidity of the structure and its individual components should be checked to verify that it has no damage; ■ Any fitted appliance is subject to periodic chimney sweeping. The appliance must be inspected or serviced by a qualified chimney sweep/sweep. - Page 7 ■ leave flammable materials within 1.5m of the fireplace; ■ light fires with flammable materials and burn waste; Hitze is exempt from civil and criminal liability in the event of: ■ if the insert is not used in accordance with the Operating and Installation Instructions;...
-
Page 8: Installation
X - indicates the size of the case Y - indicates panel number Example: 8.1 means that it is a panel from the CALMA 80x50 model numbered 1 A description of the individual cut-outs follows. 6. - CALMA 65x80 8. - CALMA 80x50 1. - CALMA 120x50 .3 and .2 - designation of universal panels used for all types of enclosures... -
Page 9: Montage
MONTAGE The appliance must be assembled in accordance with the step-by-step diagram below without omitting any of the points. Skipping one of the steps may lead to weakening of the structure, resulting in damage during operation or even life and health hazards. - Page 10 Step 3. Mount the door frame connector (8) on both sides using M5x6 screws (7). Fasten the right and left side connector (9) with 4 M5x6 screws ( 7) to the flat in the back part of the insert so that the mounting holes for screwing the back support (10) are at the top and outside (do not tighten them!).
- Page 11 Step 5. In this step, the two panels numbered .2 and .3 are to be found. The lower left and right panels (13) a r e assembled by sliding them over the protruding parts of the bracket (4) shown in the close-up B, then pushing them down and tightening them with 2 DIN 912 M5x10 screws (14).
- Page 12 Step 7. In this step, find the two panels marked with the cut-out numbers .5 and .6. Screw on the corner connector (15) with the M5x6 screws (7) and then screw in the DIN 912 M5x10 screw (14) with the head towards the centre (projection A). The left and right panels (16) are assembled by sliding them over the projections of the door frame catch (8-"Step 3"), then pushing them together and screwing them in with 2 DIN 912 M5x10 screws (14) (projection B).
- Page 13 Step 9. In this step, find two small side panels .10 and .11 with 4 cutouts on the shorter sides (18). The panels are assembled by sliding them over the protruding heads of the DIN 912 M5x10 screws (14) at both the top of the panel and the bottom. "10"...
- Page 14 After screwing the element together, place the whole onto the pre-built enclosure in such a way that t h e holes in the lower part of the panels go into the hooks, and then move the whole towards the back of the enclosure until the elements interlock. "DL"...
- Page 15 After screwing the element together, place the entire assembly on the pre-built enclosure so that t h e hooks on the bottom of the panels enter the holes on the enclosure, and then slide the entire assembly towards the rear of the enclosure until the elements interlock.
- Page 16 Step 12. Fitting left bottom back (26) and right bottom back (27) by fitting the bracket projections (24) and the lower slat into the holes located on the back elements. Step 13. The final step is to attach the top covers of the housing, the left cover (28) and the right cover (29).
-
Page 17: Conservation
E n c l o s e d unit. CONSERVATION All maintenance must only be carried out on an extinguished and cooled appliance. ■ Carry out periodic and timely maintenance - at least once a year an inspection of the fireplace by a specified service. ■... - Page 20 www.hitze.pl...
