Promation Engineering PX1 Series Installation & Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation & Operation
This IOM is for the following
ProMation Engineering Products:
PX1-24N7+ACDC
PX1-24N7+DC
Division System
CAN/CSA-C22.2 No. 0-10, CSA C22.2 No. 30-M1986, CSA C22.2 No. 25-17, FM
3600, FM 3615, FM 3616
Class I Division 1 Groups C,D T4
Ambient Temperature - 30 °C to + 70 °C ( - 22 °F to + 158 °F )
Class II Division 1 Groups E,F,G T130°C
Ambient Temperature - 30 °C to + 70 °C ( - 22 °F to + 158 °F )
Zone System
CAN/CSA-C22.2 No. 0-10, CAN/CSA-C22.2 No. 60079-0, CAN/CSA-C22.2 No.
60079-1,
CAN/CSA-C22.2 No. 60079-31, UL 60079-0, UL 60079-1, UL 60079-31
Class I, Zone 1, AEx db IIB Gb T4
Class II Zone 21, AEx tb IIIC T130°C
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PX1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Promation Engineering PX1 Series

Summary of Contents for Promation Engineering PX1 Series

  • Page 1 Installation & Operation Manual This IOM is for the following ProMation Engineering Products: PX1-24N7+ACDC PX1-24N7+DC Division System CAN/CSA-C22.2 No. 0-10, CSA C22.2 No. 30-M1986, CSA C22.2 No. 25-17, FM 3600, FM 3615, FM 3616 Class I Division 1 Groups C,D T4 Ambient Temperature - 30 °C to + 70 °C ( - 22 °F to + 158 °F )
  • Page 2 This page intentionally left blank...

  • Page 3: Table Of Contents

    Field Manual PX1- Series LV On/Off/Jog Control ISO5211 F03/05 8P14 Table of Contents 2 . . . . . . . . . . . . . . . . . . . Product Specifications Contents 3 .

  • Page 4: Product Specifications

    Product Specifications Actuator Specifi cations Torque “lb/Nm 300”lbs/35Nm Supply Voltage 12vac/dc 24vac/dc Max Inrush Current 2.0A 2.8/1.8A Running Current 1.9A 1.6/1.4A Motor DC Brush Type Runtime (90°@60Hz/vdc) 15 sec Runtime (90 @50Hz) 15 sec Duty Cycle Motor Starts 1200 per hour Weight 5lbs/3kg Mechanical Connections...
  • Page 5 • The handling shall follow the safety and warning instructions contained in this manual. • The user should read and follow instructions contained in this operation manual. Failure to do this may result in damages and void warranty. ProMation Engineering is not liable for damages due to operator negligence or misuse.
  • Page 6 Hazardous Location Information (Continued) • Do not touch any components on the PCB with metal tools or bare hands to avoid functional failure caused by static electricity discharge. • Do not parallel wire multiple actuators together without using isolation relay(s). • Use proper techniques when installing conduit and properly seal the connection.

  • Page 7: Shipping And Handling

    All terminals accept 14-18AWG solid/stranded wire. • Do NOT parallel wire multiple actuators together without utilizing isolation relays! If this is your intention, please contact ProMation Engineering for a multiple actuator parallel wiring diagram. Page 5 of 11 P1 HV Series...

  • Page 8: Wiring Diagram

    Wiring Diagram Actuator Specifi cations 300”lbs/35Nm Torque “lb/Nm On/Off/Jog Control Supply Voltage 24vac 24vdc Max Inrush Current 3.0A 1.6A Running Current 2.8A 1.3A Motor DC Brush Type Runtime (90°@60Hz/vdc) 15 sec Runtime (90 @50Hz) 15 sec Duty Cycle 75% maximum Motor Starts 1200 per hour Weight...

  • Page 9: Check End Of Travel Settings

    Check End of Travel Settings The actuators are tested, calibrated and shipped in the Full CW position and End of Travel cams are set at 90 degrees from each other. A. Set the control device (valve or damper) to the closed position. B.

  • Page 10: Adjusting The Actuator Auxiliary Switches

    Adjusting the actuator Auxiliary Switches Remove power from this device BEFORE making any End of Travel cam adjustments. Cam 3 Adjustment 1. The third cam is Cam 3, the CCW auxiliary switch adjustment. Drive the actuator to its CCW position. Then use a 2.5mm hex key to free up the cam set screw.

  • Page 11: Mechanical Data

    1/6/2020 Checked By Last Checked: Dwg. Name PX1 F0305 8P14 DimData.idw 1/7/2020 This Document is the property of ProMation Engineering, Inc. Distribution of this document without the written Material Finish Rev. consent of the owner is Strictly forbidden. Failure to comply will incur a liability for Damages.
  • Page 12 Mechanical Data P1 Series Exploded View (P1-120N4 unit is shown) Position indicator viewport Aluminum Casting NEMA 4X Protection Heavy Duty Drive Motor NEMA 4X Cover Seal Easily distinguishable yellow/red position indicator Switch Card Easily accessible switch stack Anti-Condensation Heater Adjustable End of Travel cams (2) 1/2”...
  • Page 13 Commissioning This procedure will assume that the actuator is installed correctly both mechanically and electrically with correct power. 1. Apply the correct supply power to the actuator. • NOTE - Power is measured at terminals marked 1 & 7 on the actuator. NORMAL OPERATION Power applied to terminals marked 1 &...
