Summary of Contents for TDRFORCE BW1000A
- Page 1 INSTRUCTION MANUAL with Warranty Card...
- Page 2 Models BW1000A BW1020A BW2000 (Original Style with Single (Original Style with Double (Original Style with Single Inlet Tube) Inlet Tubes) Inlet Tube and Screw Switch) BW4003A BW4020A BW6000A (New Style with Single (New Style with Double (Upgraded Model with Inlet Tube)
- Page 3 Specifics Input 110V AC AMPS 0.25 AMP Power Annual Power consumption 106 kW · h Flow 1 GPM Max head 13 ft Max pressure 40 psi Plug 3-way standard US plug Cord 4.4 ft Inlet tube 1.8 ft Outlet hose 20 ft Material Weight...
-
Page 4: Installation
Installation... - Page 7 Cautions 1.After unpacking the pump, please check if it has been damaged during transport. If so, please contact TDRFORCE online services at the first time. 2.Make sure that the main voltage corresponds to the voltage specified on the instruction manual.
-
Page 8: How The System Works
How the System Works... -
Page 10: Troubleshooting
Trouble-shooting TYPE OF DEFECT CAUSE SOLUTION -The dispenser doesn’t -Power failure. -Check the power. pump water -Long time unused. Air in -Keep the power on and the pipes. fill some water manually from the inlet pipe. Try several times until it start pumping. -
Page 11: Warranty Card
Customer contact, please keep it properly. Dear customer: Thank you for choosing products of TDRFORCE. In order to provide you with more satisfactory service and better protect your rights, please read this regulation carefully and keep the warranty card properly.
Need help?
Do you have a question about the BW1000A and is the answer not in the manual?
Questions and answers
how do I test the pump to see if it is functioning?
To test if the TDRFORCE BW1000A pump is functioning:
1. Check power – Ensure the pump is connected to a power source.
2. Turn on the faucet – Open and close the faucet to check if the pressure switch activates the pump.
3. Listen for pump operation – If the pump does not start, check for air in the pipes and fill water manually through the inlet pipe. Try several times.
4. Inspect float switch – Make sure the float switch in the water bottle is correctly positioned and not stuck.
5. Check for leaks – Look for leaks at the tubes, tube fittings, and other connections; fix any found.
These steps help verify if the pump powers on, cycles correctly, and responds to water demand.
