Summary of Contents for TDRFORCE 540E
- Page 1 RV/MARINE WATER PRESSURE PUMP INSTRUCTION 5 4 0 E 5 3 0 E 5 4 0 F 5 3 0 F with Warranty Card...
- Page 2 Cautions 1.After unpacking the pump, please check if it has been damaged during transport. If so, please contact TDRFORCE online services at the first time. 2.Make sure that the main voltage corresponds to the voltage specified on the instruction manual.
-
Page 3: Technical Specifics
Pressure Pressure FLOW CERTIFICATIO CONTINUOUS MODEL VOLTS CHAMBERS H-MAX POWER MOTOR LIFE (PSI) (BAR) RATE WORKING TIME more than 110V 540E 170FT 2400rpm 172.5W 1500 40mins hours more than 540F 12V DC 5 GPM 157FT 2300rpm 180W 1500 40mins hours... -
Page 4: General Information
GENERAL INFORMATION The patent has been designed for delivering smooth and consistent flow at all ranges of operation while drawing low current. The balanced motor design incorporates with precision ball bearings for long life, and is equipped with an integral thermal breaker. Full corrosion-resistant shell and environmental thermoplastic construction ensure less prone to mechanical failure. - Page 6 Component Pressure switch Pump head Valve plate assembly Diaphragm/ Drive assembly Motor...
-
Page 7: Troubleshooting
Troubleshooting TYPE OF DEFECT CAUSE SOLUTION - Make sure the power cord is - False electric connections accurately plugged The motor does not start - Low inlet water pressure - Increase water flow of inlet - Ensure that the power source is - The operating voltage is unstable in accord with the instructions - The water inlet pipe is bent or... - Page 8 rubber sealing ring to shrink, expand, oxidize and become non-sealing. - Connect proper screw and seal - Thread damage of the screw with Teflon tape Pump starts and stops - Diaphragm broken - Disposal frequently - Adjust the pressure screw - The pump is over-pressure counterclockwise to release the pressure...
- Page 9 - Restart the pump until it's - Overheat protection starts cooling Pump suddenly quit - Power off - Turn on again working - Motor burns out - Disposal - Switch burns out - Disposal Pump vibrates and - Fix the inlet leakage and make - Air in the water inlet pipe operates noisily the pipes firmly connected...
- Page 10 - Pressure setting too high, overloaded - Adjust the pressure screw operation counterclockwise to release pressure Pump supplies insufficient - The diaphragm is jammed or blocked - Disposal flow - The inlet flow rate is too small - Increase the inlet water flow...
- Page 11 Customer contact, please keep it properly. Dear customer: Thank you for choosing products of TDRFORCE. In order to provide you with more satisfactory service and better protect your rights, please read this regulation carefully and keep the warranty card properly.
-
Page 12: Warranty Card
Warranty Card Buyer’s Name: Tel: E-mail: Order ID: Return Address: Product Problem Description:...
