- Page 1 Instruction Manual Instruction Manual Instruction Instruction Manual Manual DWT21BIW DWT21BIS...
-
Page 2: Table Of Contents
CONTENTS Technical specifications …………………………………………………….. • Conformity with the standards and Test data …………………………….. • Safety information and Recommendations………………………………….. Recycling ..………………………............• Safety information …………………………………………………………… • Recommendations …...……………………………………………………… • Items not suitable for dishwashing ………………………………………… • Installing the machine ………………………………………………………….. Positioning the machine …………………………………………………….. •... - Page 3 Loading your dishwasher .……………………………………………………. Alternative basket loads …………………………………………………... • Programme descriptions .…………………………………………………….. Programme items ………………………………………………………….. • Getting familiar with your machine …………………………………………… 26 Switching on the machine and selecting a programme……………..Switching on the machine…………………………………………………. • Programme follow-up ……………………………………………………… • Changing a programme ……………………………………………………...
-
Page 5: Technical Specifications
Technical specifications Capacity 15 place settings Height 820 mm-870 mm/870 mm-920 mm Width 598 mm Depth 570 mm Net Weight 43 kg Electricity input 220-240 V, 50 Hz Total Power 1900 W Heating Power 1800 W Pump Power 100 W Drain Pump Power 30 W Water supply pressure 0.03 MPa... -
Page 6: Safety Information And Recommendations
• Check for any damage to your machine or to its packaging. Never start a machine damaged in any way, make sure to contact an Award authorised service centre. • Unwrap the packaging materials as indicated and dispose of them in accordance with the rules. - Page 7 As Award will not beresponsible for any damage this may cause to your machine. • The water in the machine's washing section is no drinking water do not drink it.
- Page 8 • Place knives and other sharp-ended objects in the cutlery basket in blade-down position. • If the supply cord is damaged, it must be replaced by an Award authorisied service. persons in order to avoid a hazard. •This appliance is not intended for use by persons who are unable to operate the machine in a safe manner.
-
Page 9: Recommendations
Award authorised service centre Any repair work performed by anyone other than an Award authorised service centre with forfeit the warranty. • Prior to any repair work on the machine, be sure that the machine is cut off from the mains.Switch off the fuse or unplug the machine.Do not pull by the cable when unplugging. -
Page 10: Items Not Suitable For Dishwashing
Items not suitable for dishwashing: • Cigarette ashes, candle leftovers, polish, paint, chemical substances, iron-alloy materials; • Forks, spoons and knives with wooden or bone, or ivory or nacre-coated handles; glued items,items soiled with abrasive, acidic or base chemicals. • Plastic items that are not heat-resistant, copper or tin-coated containers. -
Page 11: Water Connections
Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. Do not grip the machine by its door or panel in order to move Take care to leave a clearance on all sides of the machine so that you can comfortably move it back and forth during cleaning. -
Page 12: Water Inlet Hose
Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection. -
Page 13: Water Outlet Hose
50 cm and at a maximum of 110 cm from the floor plane. Warning: When a drain hose longer than 4 m is used, the dishes might remain dirty. In that case, Award will not accept responsibility. -
Page 14: Electrical Connection
In case of usage without earthing installed, Award will not be responsible for any loss of usage that might occur. The indoor fuse current value should be 10-16 A. - Page 17 Follow the list of instructions as provided with the kit.
-
Page 18: Preparing The Machine For Use
PREPARING THE MACHINE FOR USE Prior to using the machine for the first time • Check whether the electricity and supply water specifications match the values indicated by the installation instructions for the machine. • Remove all packaging materials inside the machine. •... -
Page 19: Filling With Rinse Aid And Making The Setting
Observe the instructions on packagings when using such products. • If such detergents are in the form of tablets, never put them into the interior section or the • cutlery basket of the dishwasher. Always put the tablets into the detergent compartment in the detergent dispenser. -
Page 20: Loading Your Dishwasher
Warning: Use only those rinse aid materials which are allowed for use in the machine. As rinse aid residues left as a result of overflowing will create extremely high amounts of foam and thus reduce the washing performance, remove the excess amount of rinse aid by wiping it with a rag. LOADING YOUR DISHWASHER If you properly place your dishes into the machine, you will be using it in the best way in terms of energy consumption, washing and drying performance. - Page 21 Top basket height adjustment while it is full Basket height adjustment mechanism on the top basket of your machine is designed to let you adjust the height of your top basket upwards or downwards, without removing it from your machine when it is full, and create large spaces at the top or bottom area of your machine as needed.
- Page 22 Upper Cutlery Basket The upper cutlery basket is designed for you to place forks, spoons and knives, long dippers and small items. Because it can easily be taken out of the machine, it allows your dishes to be taken out of the machine along with the basket after washing.
- Page 23 Lower Basket Folding Racks Folding racks consisting of four parts that are located on the lower basket of your machine are designed in order to let you place big items easier such as pots, pans, etc. If requested, each part can be folded separately, or all of them can be folded and larger spaces can be obtained. You can use folding racks by raising them upwards, or by folding.
-
Page 24: Alternative Basket Loads
Alternative basket loads Lower Basket Top basket... - Page 25 Faulty loads ...
-
Page 26: Programme Descriptions
PROGRAM DESCRIPTIONS Program items Name of Program Prewash Quick 30 min. Economic 50°C Super 50 min. Daily Auto Auto Auto Delicate Intensive Washing Temperature 30-50 50-60 60-70 Type of Food Fragment Fresh coffee, milk, Normally Tarried soup, sauce, Fresh coffee, milk, Detects contamination level of dishes and sets Fresh less dirty, temperature and amount of washing water and... -
Page 27: Getting Familiar With Your Machine
GETTING FAMILIAR WITH YOUR MACHINE 1.) ON/OFF Button When one presses the on/off button, the machine is energized and the light on Start/Standby button goes on. 2.) Extra Rinse / Dry Button You can add extra rinsing or drying functions into the selected program by using extra button. - Page 28 Thus, washing up shall be done only on the lower basket of your machine. In using this feature,make sure that there are no dishes in the upper basket. Note : If you have used an extra feature on the latest washing program, this feature will remain active also on the next washing program.
-
Page 29: Switching On The Machine And Selecting A Programme
SWITCHING ON THE MACHINE AND SELECTING A PROGRAMME Switching on the machine The lamp on Program Start/Pause key goes off once the Program starts and the washing lamp is highlighted. Press the Power On/Off key. Select the program suiting your dishes via the Program Selector button. -
Page 30: Changing A Programme With Resetting
Changing a programme with resetting If you would like to cancel a program while a washing program is resumed. Hold Start/Pause button pressed for approx. 3 sec. until Finish light blinks. Once Finish light comes on, it means that the cycle has been cancelled. -
Page 31: Maintenance And Cleaning
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. -
Page 32: Spray Arms
Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left. -
Page 33: Failure Codes And What To Do In Case Of Failure
Close the water input tap, separate the water input hose from the tap and clean the filter at • the connection end of the hose. Restart your machine, contact an authorised Award service person if the error resumes. • Close the tap. - Page 34 If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. • Be sure that the water inlet tap is turned on.
-
Page 35: Practical And Useful Information
• Unhealthy mains grounding. • Call an Award authorised service centre if the problem still persists or in case of any malfunction not described above. PRACTICAL AND USEFUL INFORMATION 1. Wheneveryour machine is left unused for an extended period of time. - Page 36 Award Appliances (NZ) Limited E-mail: sales@award.co.nz www.awardappliances.co.nz 52XXXXXX R23...
