Summary of Contents for Award DWC316S
- Page 1 Dishwasher Instruction Instruction Manual Instruction Instruction Manual Manual Manual...
-
Page 2: Table Of Contents
CONTENTS • T • • Recycling • • Recommendations • • • W • W • W • • • • • • . 17 • . 22 • Programme Selection and Operating the Machine . 23 • Operating the Machine •... - Page 3 Worktop Rating plate Upper basket with racks Control Panel Upper spray arm Detergent and rinse-aid dispenser Lower basket Cutlery basket Lower spray arm Upper basket track latch Filters Active Drying Unit: This system provides better drying performance for your dishes.
-
Page 4: Technical Specifications
European Community. 2004/108/EC, 2006/95/EC,IEC 436/DIN 44990,AS/NZS 2007.1/2:2005 Important Note for User:For softcopy of this user manual, please contact following address: "service@award.co.nz”.In your e-mail, please provide the model name and serial number (20 digits) which you can find on the appliance door. -
Page 5: Recycling
SAFETY INFORMATION AND RECOMMENDATIONS Recycling • Certain components and the packaging of your machine have been produced from recyclable materials. • Plastic parts are marked with international abbreviations: (>PE< , >PS< , >POM<, >PP<, ) • Cardboard parts have been produced from recycled paper and they should be disposed of into waste paper collection containers for recycling. - Page 6 • Check whether the indoor electrical fuse system is connected according to the regulations. • All electrical connections must match the values indicated on the rating plate. • Pay special attention and be sure that the machine does not stand on the electricity supply cable. •...
- Page 7 • Due to danger of explosion, do not put into the machine’s washing section any chemical dissolving agents such as solvents. • Check whether plastic items are heat-resistant before washing them in the machine. • Children shall not play with the appliance.Cleaning and user maintenance shall not be made by children without supervision.
-
Page 8: Recommendations
• If EnergySave option is selected as "Yes", The door will be opened at the end of the program. Do not force to close the door to avoid damaging the auto door mechanism. The door must be open during 30 minutes to get effective drying.( in models with auto door opening system ) Warning: Do not stand in front of the door after the signal sounds belonging auto-open. - Page 9 • Use the pre-wash programme only whenever necessary. • Place such hollow items as bowls, glasses and pots into the machine in such a way that they will face down. • You are recommended not to load into your machine any dishes different or more than indicated.
-
Page 10: W S
Do not put your machine in any location where there is the probability for the room temperature to fall below 0°C. Before positioning, take the machine out of its packaging by following the warnings located on the package. Position the machine close to a water tap or drain. You need to site your machine, taking into consideration that its connections will not be altered once they are made. -
Page 11: W E
Water inlet hose Do not use the water inlet hose of your old machine,if any. Use the new water inlet hose supplied with your machine instead. If you are going to connect a new or long - unused water inlet hose to your machine ,run water through it for a while before making the connection. -
Page 12: W E
Water outlet hose The water drain hose can be connected either directly to the water drain hole or to the sink outlet spigot. Using a special bent pipe (if available), the water can be drained directly into the sink via hooking the bent pipe over the edge of the sink. -
Page 13: Electrical Connection
Electrical connection The earthed plug of your machine should be connected to an earthed outlet supplied by suitable voltage and current. If there is no earthing installation, have a competent electrician carry out an earthing installation. In case of usage without earthing installed, our company will not be responsible for any loss of usage that might occur. - Page 14 Fitting the machine undercounter If you wish to fit your machine undercounter, check whether you have sufficient space under your countertop and whether the wiring-plumbing is suitable to do so.1 If you decide that the space under the countertop is suitable for fitting your machine, remove the worktop as shown in the illustration.
- Page 15 Adjust the machine feet according to the slope of the floor.3 Fit your machine by pushing it undercounter without letting the hoses get crushed or bent.4 Product Without Insulation With Insulation All Product For 2nd Basket For 3rd Basket Height 820 mm 830mm 835 mm Warning: After removal of worktop, the machine should be placed in such a closed place of which dimensions are shown at fig.
-
Page 16: Preparing The Machine For Use
Prior to using the machine for the first time Check whether the electricity and supply water specifications match the values indicated by • the installation instructions for the machine. Remove all packaging materials inside the machine. • Set the water softener. •... - Page 17 ENGLISH Points to consider when using this type of products: Always make sure to check the specifications of the product you will use or whether or not • it is a combined product. Check if the detergent used is appropriate for the hardness of mains water that machine is •...
-
Page 18: Loading Your Dishwasher
The rinse aid level adjuster can be set to a position between 1 and 6. Factory setting for rinse aid is the position 3. You need to increase the degree of the adjuster if water stains form on your dishes after a wash, whereas you need to decrease the degree if a blue stain is left when wiped by hand.3 Warning: Use only those rinse aid materials which are allowed for use in the machine. - Page 19 Spoon rack It allows your long-stemmed goblets to be washed safely as well as it is a part to provide your spoons and forks put easily to spoon rack. Do not lean your long-stemmed goblets and glasses against each other but spoon rack, thus during the washing it is ensured your glasses and goblets stay in place and a safe washing by preventing...
- Page 20 Top basket height adjustment Top basket of your machine is in upper position. When it is in this position, you can place big items such as pans, etc. on lower basket. When you take top basket to lower position, you can place and wash big sized plates on the top basket.
- Page 21 Alternative basket loads Lower Basket Top basket...
- Page 22 Faulty loads Important Note for Test Laboratories For detailed information on performance tests, please contact following address: "dishwasher@standardtest.info” . In your email, please provide the model name and serial number (20 digits) which you can find on the appliance door. ...
-
Page 24: Programme Selection And Operating The Machine
Programme Selection and Operating the Machine 1. Remaining Time Indicator city and water (see programme listing Remaining Time Indicator shows the du- p 22) Note: If you have used any extra func- ration of the programmes and the rema- ining time during the programme flow. tion (such as the delay or half load) in Besides, you can put off the programme the washing programme that you last... - Page 25 6. Rinse Aid Missing Warning Indica- Check the rinse aid missing warning in- dicator light on the display to have an idea whether the amount of the rinse aid in your machine is enough. When rinse aid missing warning indicator is lit, fill the rinse aid compartment.
-
Page 26: Operating The Machine
Operating the Machine When the programme is started the light on the Start/Pause goes off and Washing light is lit. 1.By rotating the programme selection button, energise the machine and select the suitable programme. After rotating the programme selection button and energising 2.Start the programme by the machine, the light on the pressing the Start/Pause key. -
Page 27: Cancelling The Programme
Cancelling the Programme If you would like cancel a programme while a washing programme is running on: Press and hold the Start/ Pause key for 3 seconds. After 3 seconds, programme cancellation step starts and the water inside the machine is discharged for 30 seconds. -
Page 28: Filters
MAINTENANCE AND CLEANING Cleaning the machine in regular intervals prolongs the machine’s service life. Oil and lime may accumulate in the machine’s washing section. In case of such accumulation; -Fill the detergent compartment without loading any dishes into the machine, select a programme that runs at high temperature, and start the machine. - Page 29 ENGLISH Spray arms Check whether or not the holes for the upper and lower spray arms are clogged. If there is any clogging, remove the spray arms and clean them under water. You can remove the lower spray arm by pulling it upwards, while the upper spray arm nut can be removed by turning the nut to the left.
- Page 30 FAILURE CODES AND WHAT TO DO IN CASE OF FAILURE FAILURE FAILURE DEFINITION CONTROL CODE Make sure that the water inlet faucet is completely turned on and the water is not cut off. Turn off the water inlet faucet and clean the filter on the connecting terminal of the hose Water inlet is inadequate.
- Page 31 ENGLISH If one of program monitor lights is on and start/Pause light is on and off, Your machine’s door is open, shut the door. If the programme won’t start Check if the plug is connected. • Check your indoor fuses. •...
-
Page 32: Practical And Useful Information
ENGLISH If there are whitish stains on the dishes A very small amount of detergent is being used. • Rinse aid dosage setting at a very low level. • Water softener system setting is at a very low level. • If the dishes won't dry up A programme without a dry operation selected. - Page 33 Award Appliances Po Box 6269 Upper Riccarton Christchurch New Zealand Ph 03-3480556 sales@award.co.nz www.awardappliances.co.nz 52162676 R22...
