Page 3
Quick Operation Guide For detailed operating method read the corresponding content on the instruction manual. Switch on the appliance Press the Power switch button to switch on the appliance, Open the door. Compartment A: For each wash cycle. Compartment B: Fill the detergent dispenser For programs with pre-wash only.
Read this Manual 1) Safety Information...........1 2) Disposal............2 Dear Customer, 3) Operation Instruction........3 Please carefully read this manual before using the dishwasher, it will help you to use and maintain the Control Panel..........3-1 dishwasher properly. Dishwasher Features ........3-1 Keep it for reference in future. Pass it on to any subsequent owner of the appliance.
Page 5
When using your dishwasher, WARNING! follow the precautions listed below: EARTHING INSTRUCTIONS This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of an electric shock by providing a path of least resistance of electric current.
2.Disposal This appliance's packaging materials are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. It is prohibited to dispose of this appliance as household waste.Correct Disposal of this product: this symbol on the product or in its packing indicates that this product may not be treated as household waste.
3.Operation Instruction IMPORTANT before using it for the first time. Control Panel Start/Pause Button: Press this button to start or pause the dishwasher. Display screen: To show the reminding time Washing Program Selector: Press the button and the state(running state, delay time etc ) to select wash cycles.
Prior using for the first time A. Rinse Aid Dispenser Rinse Aid Dispenser Function of Rinse Aid Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak free help the drying. Attention! When to Refill the Rinse Aid Dispenser "...
Adjusting Rinse Aid Dispenser Adjust lever (Rinse) NOTE: Increase the dose if there are drops of water or lime spots on the dishes after washing. Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or knife blades.
Page 12
Adding detergent to dispenser Push latch to open NOTE: If the lid is closed: push the latch to open. Always add the detergent just before starting each wash cycle. Only use branded detergent and rinse aid for dishwasher. WARNING! Proper Use of Detergent Use only detergent specifically made for use in dishwashers.
5.Loading the Dishwasher Baskets Recommendation Suitability of use in the dishwasher Not suitable for use Limited suitability Some types of glasses can become Cutlery with wooden, horn china or dull after a large number of washes. mother-of-pearl handles. Plastic items that are not heat resistant. Silver and aluminium parts have a Older cutlery with glued parts that is not tendency to discolour during washing.
Loading the Basket Position the dishes and cookware so that they do not get moved by the spray of water. Cups Saucers Dessert dishes Glasses Dinner plates Soup plates Cutlery basket Cutlery Basket Cutlery should be placed into the cutlery basket with handles at the bottom. Soup spoons 2 Forks Knives...
6.Starting a washing programme Wash Cycle Table Detergent Cycle Selection Running Description Water Energy Rinse Program pre/main Information time(min) of Cycle (Kwh) Pre-wash(50℃) Wash (55℃) For heaviest soiled crockery, Rinse and normally soiled pots、 0.85 /17.5g Rinse pans、dishes etc with dried (1or2 pieces) Intensive Rinse(70℃)
Change the Program Premise: You can modify the washing program, If the dishwasher just runs for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. In this case, the detergent dispenser must be refilled (see the section entitled "Detergent "...
Page 17
7.Maintenance and Cleaning Filtering System The filter prevent larger remnants of food or other objects from getting inside the pump. and a micro filter (fine filter). Main filter Food and soil particles trapped by this filter are pulverized by a special jet on the spray arm and washed down to drain.
Remarks: - Inspect the filters for blocking after every time the dishwasher has been used. - By unscrewing the coarse filter, you can remove the filter system.Remove any food remnants and clean the filters under running water. NOTE: The entire filter assembly should be cleaned once a week. Cleaning The Filter To clean the coarse filter and the fine filter, use a cleaning brush.
Cleaning the Spray Arms How to Keep Your Dishwasher in Shape After Every Wash When not in use for an extended period of time Remove the Plug Before cleaning or performing maintenance, always remove the plug from the socket. If the appliance must be moved, try to keep it in the vertical position.
Positioning the Appliance and drain hoses that can be positioned to the right or the left to facilitate proper installation. About Power Connection WARNING! For personal safety: Do not use an extension cord or an adapter plug with this appliance. Do not under any circumstance, cut or remove the earthing connection from the power cord.
Connection of drain hoses Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it run into the sink, making sure to avoid bending or crimping it. The free end of the hose must be at a height lower than 30 cm and must not be immersed into water to avoid the backflow of it.
Page 22
How to Drain Excess Water From Hoses If the sink is more than 300mm higher than the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink.
9.Troubleshooting Tips Before Calling for Service Review the charts on the following pages may save you from calling for service. Problem Possible Causes Dishwasher doesn t Fuse blown, or the Replace fuse or reset circuit breaker. Remove any other circuit breaker tripped. appliances sharing the same circuit with the dishwasher start Power supply is not...
Problem Possible Causes The dishes The dishes were not See notes in " Loading the Dishwasher Baskets ". loaded correctly. are not clean The program was not powerful enough. Not enough detergent Use more detergent, or change your detergent. was dispensed. Items are blocking Rearrange the items so that the sprayer can rotate freely.
Technical Information Height : 438mm Width : 550mm Depth : 500mm Voltage connected Load : see rating label Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 6 Place settings...
