Summary of Contents for Parkmate ClearView 7
- Page 1 User Manual 7.0" Smart Screen Monitor With 2-Channel Dash Camera ™ YOUR SAFETY COMES FIRST ClearView 7 PM-72W...
-
Page 2: Table Of Contents
CONTENTS Cautions Warning Micro SD card warning Introduction Package contents Product overview Micro SD card installation Product installation Windscreen suction mount ....10 3M adhesive suction mount ....12 Rear camera installation Rear camera wiring ......16 Rear camera connection ......16 Rear camera features ......17 Power connection Auto power on/off ........18 Micro SD card... - Page 3 Home screen Dash camera ........22 Apple CarPlay ........24 9.2.1 iPhone set-up ........24 Android Auto ........26 9.3.1 Android Auto set-up ......27 10.0 Audio output 10.1 PM-72W Speakers .......29 10.2 Car Audio ..........30 10.3 FM Transmitter ........32 10.3.1 FM Transmitter set-up ......33 10.4 AUX .............33 11.0...
-
Page 4: Cautions
CAUTIONS • Please ensure you are using your Dash Camera within your country's road laws. • Please make sure you are familiar with your local road legislation before use. • The time and date need to be set before you start recording. -
Page 5: Warning
WARNING • Always power this product using the supplied charger. • Never dismantle this product. • Do not dispose of this product in fire. • Disposal of this product should observe local regulations. MICRO SD CARD WARNING • This product can only be used with Micro SD Cards, Class 10 or above with 32GB to 256GB storage capacity. -
Page 6: Introduction
INTRODUCTION Thank you for purchasing a Parkmate ClearView 7 Wireless Smart Monitor with Dual Channel Dash Camera. This product enables your smartphone to be seamlessly connected via Bluetooth and Wi-Fi for hands-free operation while driving. It also comprises a built-in front Dash Camera and a rear camera to facilitate hassle-free driving and navigation. -
Page 7: Product Overview
PRODUCT OVERVIEW... - Page 8 1. Display screen 2. AUX input 3. Micro SD card slot 4. Rear camera input 5. Microphone 6. Type-C connector (for power supply) 7. Front camera lens 8. 3M adhesive/magnetic mount 9. Speaker vent 10. Reset button - Press this button to restart the device.
-
Page 9: Micro Sd Card Installation
MICRO SD CARD INSTALLATION Please insert the memory card into the Micro SD Card slot with the chip contact surface facing up. Insert it until you hear a click sound. -
Page 10: Product Installation
2. 3M adhesive mount WINDSCREEN SUCTION MOUNT Figure: 1 • Insert the magnetic mount holder at the back of the ClearView 7. • Clean the windscreen area where the suction mount is to be mounted. • Unlock the mount. • Press the suction mount on the windscreen and... - Page 11 4. Pull the suction cup lever up to release suction. 5. Press the suction mount on the windscreen and lock it by pressing the suction cup lever down until it snaps into place. 6. Snap the ClearView 7 onto the magnetic mount holder.
-
Page 12: Adhesive Suction Mount
3M ADHESIVE SUCTION MOUNT Figure: 2 • Insert the magnetic mount holder at the back of the ClearView 7. • Clean the area on the dashboard where the mount is to be placed. • Remove the 3M tape at the bottom of the mount. - Page 13 4. Place the mount on the cleaned surface and press it firmly for two minutes. 5. Snap the ClearView 7 on to the magnetic mount holder. 6. Adjust the height and view angle of the ClearView 7 using the knob at the back of the 3M adhesive mount.
-
Page 14: Rear Camera Installation
MOUNTING NOTES • Make sure the camera lens is within the range of the windscreen wiper so that there is a clear line of view when it rains. • Do not touch the camera lens. Fingerprints on the lens will result in unclear videos or photos. If your photos or videos are blurred, this may be rectified by cleaning the lens gently with a microfibre cloth. - Page 15 5. Mark a position suitable for the second screw and drill a small hole. 6. Fasten the second screw and tighten both screws securely. Figure: 3...
-
Page 16: Rear Camera Wiring
REAR CAMERA WIRING Figure: 4 To enable the Smart Monitor to display the Rear Camera view when the vehicle is engaged in reverse gear, the red Reversing Light Wire must be connected to the reverse light circuit. Otherwise, the Rear Camera will not work in conjunction with reverse gear. -
Page 17: Rear Camera Features
REAR CAMERA FEATURES After successfully installing and connecting the rear camera to the main front unit, the rear camera images will be displayed on the ClearView 7 display screen. Both front and rear camera images will now be displayed on the ClearView 7 display screen... -
Page 18: Power Connection
POWER CONNECTION • Only use the supplied 12/24V power adaptor to power the ClearView 7. • Once the ClearView 7 is securely installed on the windscreen or dashboard, plug the 12/24V power adaptor cable into the vehicle’s 12/24V power port. -
Page 19: Micro Sd Card
NOTE: • The ClearView 7 is designed to be powered only by the supplied DC power plug. Its internal battery is NOT designed for primary use. MICRO SD CARD FORMATTING INSERTED MICRO SD CARD It is highly recommended to format the Micro SD card before use. - Page 20 12:30 Tuesday Apple Carplay Android 12 June 2023. To format the Micro SD card, please follow the steps below: 1. Press the Settings button Screen Audio Output PM-72W 12:30 Tuesday Apple Carplay Android Auto 12 June 2023. Screen Off Audio Output PM-72W 2.
-
Page 21: Home Screen
HOME SCREEN 10 11 12 13 12:30 Tuesday Apple Carplay Android Auto 12 June 2023. Screen Off Audio Output PM-72W 1. Brightness button: Touch to adjust screen brightness. 2. Volume button: Touch to adjust the volume. 3. Dash Camera: Touch to enter into the video recording interface. -
Page 22: Dash Camera
8. Display button: Touch to turn off the screen, and touch anywhere on the screen again to wake up the screen. 9. Video Recording Indicator 10. Micro SD Card Indicator 11. Wi-Fi Connection Indicator 12. Bluetooth Connection Indicator 13. Home Button: Touch to return to Home Screen. DASH CAMERA After the Micro SD card is successfully inserted and... - Page 23 12:30 Tuesday, 12 June 2023. 1. Record: Touch to stop recording. A blinking red button indicates that recording is in progress. 2. Lock file: Touch to lock the one-minute recorded video file and protect it from being overwritten. 3. Camera: Touch to take photo. 4.
-
Page 24: Apple Carplay
APPLE CARPLAY FOR FIRST-TIME CONNECTION Touch the Apply CarPlay icon to show the connecting instructions. After first connection, it will show "Connected" and display the Apple CarPlay menu. 9.2.1 IPHONE SET-UP 1. Touch the Apple CarPlay icon on the display screen. 12:30 2. - Page 25 Android Auto • Please turn on Bluetooth and Wi-Fi on your iPhone. ndroid Auto • Pair your iPhone with the Smart Monitor. • After successful Bluetooth pairing, Wi-Fi will automatically connect between the ClearView 7 and your iPhone. Screen Off...
-
Page 26: Android Auto
From now on, connection between the ClearView 7 and your iPhone will be automatic each time the ClearView 7 is powered on when your iPhone is within close proximity. Press Exit to return to the ClearView 7 Menu. ANDROID AUTO... -
Page 27: Android Auto Set-Up
9.3.1 ANDROID AUTO SET-UP Please ensure that you have downloaded the latest Android 12:30 Auto app from the Google Play Store to your smartphone. Tuesday Apple Carplay Android Auto 12 June 2023. Use Bluetooth to pair your Android phone with the Smart Monitor. - Page 28 From now on, connection between the ClearView 7 and your Android phone will be automatic each time the ClearView 7 is powered on when your Android phone is within close proximity. Press Exit to return to the ClearView 7 Menu.
-
Page 29: Audio Output
10.0 AUDIO OUTPUT 10.1 PM-72W SPEAKERS Select "PM-72W" to play audio through the device's built-in speaker. -
Page 30: Car Audio
10.2 CAR AUDIO Select "Car Audio" to play audio either through your smartphone speaker or the car stereo speakers if your smartphone is connected via Bluetooth to the device. This selection only needs to be done once to maintain the same selection. - Page 31 ClearView 7 on your smartphone, it is suggested to disable the "Media Audio" so that the default audio is via the ClearView 7 built-in speaker when connected to your smartphone. This only applies to Android Auto mode.
-
Page 32: Fm Transmitter
ClearView 7 to your vehicle’s built-in stereo speakers. When you turn on the FM Transmitter, the ClearView 7 will be muted. You will have to match the frequency of the FM Transmitter to a free frequency channel on the vehicle head unit to hear... -
Page 33: Fm Transmitter Set-Up
10.3.1 FM TRANSMITTER SET-UP 1. Turn on the FM Transmitter. The ClearView 7 built-in speaker is now muted. 2. Turn on the vehicle's radio and select a free frequency channel. 3. On your ClearView 7, select the frequency you have chosen on your radio. -
Page 34: Vehicles With Bluetooth Functionality
Android phone system or vehicle’s audio vehicle’s audio is connected to ClearView 7 system system vehicle’s Bluetooth Played Played and ClearView 7 through through vehicle’s audio vehicle’s audio system via system via ClearView 7 ClearView 7 FM Transmitter Played Played... - Page 35 'Hey Google' or 'OK Google' and 'Hey Siri'. ClearView 7 will use your smartphone data for all CarPlay and Android services. • Not all apps on your smartphone are accessible via the ClearView 7. It will depend on iOS and Android terms and conditions.
-
Page 36: Settings
12.0 SETTINGS SETTING OPTION DEFAULT Camera Resolution 1080P Front +1080P Rear 1080P Front + 720P Front +720P Rear 1080P Rear Loop recording 1min/3min/5min 1min Audio recording On/Off G-Sensor Off/Low/Mid/High Date and time 12hr/24hr 12hr Auto LCD off Always on/1 min/5mins Always on Auto-dimming On/Off... -
Page 37: Reversing Guidelines Settings
13.0 REVERSING GUIDELINES SETTINGS Touch on the Reversing Guidelines button to enter into settings and calibration. Touch On or Off to switch guidelines on or off. When guide lines are turned off, they will not show on the display screen when the vehicle is in reverse gear. To adjust the guidelines, touch [Calibration] to enter into calibration mode. -
Page 38: Parking Monitor
14.0 PARKING MONITOR This function is designed to monitor and record any incident that may occur when your car is parked. The ClearView 7 must be hardwired to your vehicle's electrical circuit for the function to be used. Recording in Parking Monitor* mode can be done in time lapse mode to save memory space on the Micro SD Card. -
Page 39: Troubleshooting
15.0 TROUBLESHOOTING PROBLEM SOLUTION Unable to start the Check whether the DC head of the 12V power device. cord is damaged or worn. Check whether the fuse of the power plug is disconnected or damaged. No touch control Touch control is invalid during powering up of response the device. -
Page 40: Warranty
16.0 WARRANTY WARRANTY TERMS AND CONDITIONS Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. - Page 41 Parkmate and its subsidiaries and affiliates, relating to or arising out of your breach of any provision of these terms, your misuse of Parkmate products or its services, or your unauthorised modification or alteration of products or software.
- Page 42 WARRANTY AND WARRANTY DISCLAIMER Parkmate has a limited warranty on whereby Parkmate warrants to you and only to you that Parkmate products will be free from defects in materials and workmanship for one (1) year from the date of your purchase (unless a longer warranty period is required by law).
- Page 43 Parkmate. In the event of any loss, damage or injury, you will not look to Parkmate to compensate you or anyone else. You release and waive for yourself and your insurer all subrogation and other rights to recover against Parkmate arising as a result of the payment of any claim for loss, damage or injury.
- Page 44 Because some jurisdictions do not permit the exclusion of implied warranties, the last sentence of this section may not apply to you. Parkmate hereby further expressly disclaims all liability for any claims for service failures that are due to...
- Page 45 Parkmate. Any liability for negligence is limited to direct losses usually and typically foreseeable in such case. Should the...
- Page 46 Some states and countries do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. Additionally, this provision is not intended to limit Parkmate’s liability in the event of Parkmate’s wilful or intentional misconduct.
- Page 48 V1.0 ™ YOUR SAFETY COMES FIRST www.parkmate.com.au | www.parkmatehd.co.nz All Images, Information and Content are Copyright © 2023 www.directed.com.au Directed Electronics Australia Pty Ltd. All Rights Reserved. www.directed.co.nz...
Need help?
Do you have a question about the ClearView 7 and is the answer not in the manual?
Questions and answers
Primate clear 7 pls help me I cannot connect android auto or apple airplay
To connect Apple CarPlay or Android Auto to the Parkmate ClearView 7 system:
For Apple CarPlay:
1. Ensure your iPhone is running iOS 13.0 or higher.
2. Turn on Bluetooth and Wi-Fi on your iPhone.
3. On the ClearView 7 screen, touch the Apple CarPlay icon.
4. Pair your iPhone with the device (PM-72W-XXXX) via Bluetooth.
5. After pairing, Wi-Fi will automatically connect.
6. The system will display "Connected" and show the Apple CarPlay menu.
7. Future connections will be automatic.
For Android Auto:
1. Download and install the Android Auto app from the Google Play Store.
2. Turn on Bluetooth and Wi-Fi on your Android phone.
3. Pair your phone with the ClearView 7 system.
4. Once paired, Android Auto will connect and function through the vehicle's audio system via the ClearView 7.
Note: Android users cannot initiate data calls (e.g., WhatsApp) via the vehicle's audio system.
This answer is automatically generated
I cannot pair my android to pakmate, have done factory reset, I get it o. M y phone but no pairing on unit
To pair your Android phone with the Parkmate ClearView 7 after a factory reset, follow these steps:
1. Ensure your Android phone is running Android 11.0 or higher.
2. Turn on Bluetooth and Wi-Fi on your phone.
3. Power on the ClearView 7.
4. Follow the on-screen instructions to connect your phone.
5. The first-time connection may take slightly longer.
6. Once paired, future connections will be automatic when the ClearView 7 is powered on.
These steps need to be done only once after a factory reset.
This answer is automatically generated
hi have the parkmate all installed in car what do i do to get hand free call to work
To enable hands-free calling on the Parkmate ClearView 7, follow these steps:
1. Pair Your Smartphone via Bluetooth
- Ensure Bluetooth is enabled on your smartphone.
- Follow the pairing instructions on the ClearView 7 Smart Monitor to connect your smartphone via Bluetooth.
2. Connect to Wi-Fi (for iPhone users)
- After successful Bluetooth pairing, the ClearView 7 will automatically connect to your iPhone via Wi-Fi.
3. Use Voice Commands
- For Android smartphones, install the Android Auto app from the Google Play Store.
- Use voice commands like "Hey Google" or "OK Google" for Android Auto.
- For iPhones, use "Hey Siri" to initiate calls and navigation.
This setup allows hands-free operation while driving.
This answer is automatically generated
the 3 colour line display safe distance options
