Satechi THUNDERBOLT 4 MULTIMEDIA PRO DOCK Quick Manual

1
Connect the included power adapter to the Thunderbolt 4
Multimedia Pro Dock.
3
USB 3.2 10G USB 2.0
Using the included Thunderbolt cable, connect the dock to your
host device from its Thunderbolt 4 or USB-C Port.
Made for Thunderbolt 3/4 and USB4 devices. Using USB-C
devices will limit the docking station to the host device capabilities.
5
UP TO
4K/60Hz
Use HDMI cables to connect up to two HDMI-enabled monitors.
Dual Display supported at 4K/60Hz on M1/M2 Pro/Max and Intel
based Macs
Q U I C K G U I D E
THUNDERBOLT 4
MULTIMEDIA PRO DOCK
Displayport Displayport
HDMI 2.1 HDMI 2.1
DC 20V
2
USB 3.2 10G USB 2.0
The Pro Dock can be laid flat horizontally on the supported rubber
feet or vertically using the included Desktop Stand.
4
USB 3.2 10G USB 2.0
After connecting the dock, press the power button on the front of
the dock to turn it on.
The power LED will change from white to green once fully connected
to host device
6
UP TO
USB 3.2 10G
4K/60Hz
Use DisplayPort cables to connect up to two DisplayPort-enabled
monitors.
Dual Display supported at 4K/60Hz on M1/M2 Pro/Max and Intel
based Macs
Displayport Displayport
HDMI 2.1 HDMI 2.1
DC 20V
USB 3.2
