Satechi TRIPLE 4K DISPLAY DOCKING STATION Quick Manual

TRIPLE 4K DISPLAY DOCKING STATION
1
Connect the included power adapter to the Dock.
Once connected, the dock will automatically turn on. To turn the
dock o you must press the power button located on top of the
dock.
3
Download and Install DisplayLink Software on your host device.
DisplayLink software must be installed in order for HDMI and DisplayPorts in Display 2 & 3 groups to output video.
4
USB 3.1
USB 3.1 USB 3.0
Use the USB-A and USB-C 3.1 ports for fast charging and transfers
– up to 10Gbps.
Does not support CD readers, including Apple SuperDrive.
Q U I C K G U I D E
UP TO
10Gbps
2
Connect the included USB-C cable to your host device.
Cable can be connected to host device with USB-A port by using
USB-C to USB-A adapter attached.
DISPLAY 3 DISPLAY 2
5
USB 3.1
USB 3.1 USB 3.0
Use the USB-C data port – up to 5Gbps.
Does not support charging or CD readers, including Apple
SuperDrive.
DISPLAY 1
UP TO
5Gbps
