sescom SES-ADDA1 Quick Start Manual

SES-ADDA1 Bidirectional Coax/TOSLINK Audio Converter
1 2
1 USB POWER: Connect to any powered USB port with a mini-USB cable or AC adapter to mini-USB
2 INPUT SWITCH SELECTOR: Select TOSLINK or COAX input
3 TOSLINK/ OPTICAL IN: Connect to an optical digital audio source
4 COAXIAL IN: Connect to a coaxial digital audio source
5 DC 5V: Plug the power supply into the converter
6 LED: Indicates power connection
7 COAXIAL OUTPUT: Connect to he Coaxial input port of audio amplifier or receiver
8 OPTICAL OUTPUT: Connect to the TOSLINK (optical fiber) input port of audio amplifier or receiver
NOTE: Use USB or DC/5V Power Inputs but NOT BOTH.
SPECIFICATIONS
Operating Temperature
Sampling Frequencies
Certification
Power Consumption
Dimensions
Weight
Includes
3 4
32°F-104°F
Up to 192kHz
CE, RoHS
1W
2.6 x 2.16 x 0.78 in
1.41 oz
5V/1A Power Adapter
FEATURES
 Bidirectional Conversion Coax/TOSLINK
 S/PDIF Amplification
 Extends Transmission Distance
 LED Power Indicator
 TOSLINK or Coax Input
 1 Year Warranty
