Cres Cor Hand-Lift Cabinet H-339214 Operating And Maintenance Instructions

5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
For INSULATED HAND-LIFT CABINET; MODEL H-339214
ELECTRICAL SPECIFICATIONS:
MODEL
H-339214
THERMOSTAT
DOOR
VENT
HOW TO INSTALL UNIT:
1. Plug cord into 20-amp wall outlet.
2. Place cabinet in a well ventilated area.
3. Push the switch on, turn the thermostat to No. 10
and run the unit for one hour.
NOTE: DO NOT PUT IN FOOD!
This step is to burn off manufacturing oils and
excessive adhesive.
4. Let the cabinet cool and wipe inside clean with
detergent and hot water before use.
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Volts Watts
120 1800
SWITCH LIGHT
"ON-OFF"
FIGURE 1
Amps Hertz
15 60
THERMOMETER
HOW TO OPERATE UNIT: (Figure 1)
1. Push switch "ON". Yellow light will come on.
2. Turn thermostat to the temperature you need.
NOTE: No. 7½ setting will give you about 180° F.
Proper food holding temperature is 140° F or
higher.
3. Preheat cabinet for 45 minutes
4. Put food into cabinet.
5. Turn the wing nut on the door vent to open the vent
when less humidity is needed.
To Turn Off Unit:
Push switch "OFF". The yellow light will go off.
NOTE: Thermometer gives the inside cabinet
temperature.
Insulated
FL-0520-12
Hand-lift Cabinet
Rev. 3 (1/09) Page 1 of 4
Phase NEMA
1 5-20
