Cres Cor Tri-Powered Series Operating And Maintenance Instruction Manual

Hot cabinets
Hide thumbs

Advertisement

Quick Links

Download this manual
5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Models: HC-UA-11 Tri-Powered Series Hot Cabinets
Cabinet model number:
Cabinet serial number:
Authorized Service Agency:
Ph:
Keep this manual for future reference.
Fax:
HC-UA-11
IMPROPER INSTALLATION, SERVICE,
ADJUSTMENTS, ALTERATIONS CAN
CAUSE PROPERTY DAMAGE, INJURY
OR DEATH. READ THE INSTALLATION
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING
THIS EQUIPMENT.
Holding Cabinet
Rev. 4 (10/13)
Page 1 of 12
WARNING
FL-2361

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tri-Powered Series and is the answer not in the manual?

Questions and answers

Related Manuals for Cres Cor Tri-Powered Series

Summary of Contents for Cres Cor Tri-Powered Series

  • Page 1 FL-2361 Holding Cabinet Rev. 4 (10/13) Page 1 of 12 5925 Heisley Road • Mentor, OH 44060-1833 OPERATING and MAINTENANCE INSTRUCTIONS Models: HC-UA-11 Tri-Powered Series Hot Cabinets HC-UA-11 WARNING Cabinet model number: IMPROPER INSTALLATION, SERVICE, Cabinet serial number: ADJUSTMENTS, ALTERATIONS CAN...

  • Page 2: Table Of Contents

    FL-2361 Holding Cabinet Rev. 4 (10/13) Page 2 of 12 5925 Heisley Road • Mentor, OH 44060-1833 TABLE OF CONTENTS SUBJECT PAGE INSTALLATION INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 OPERATING INSTRUCTIONS .

  • Page 3: Installation Instructions

    FL-2361 Holding Cabinet Rev. 4 (10/13) Page 3 of 12 5925 Heisley Road • Mentor, OH 44060-1833 INSTALLATION INSTRUCTIONS INSTRUCTIONS TO INSTALLER BEFORE CONNECTING TO GAS AND ELECTRIC SUPPLIES 1 . Retain this manual for further use . 2 . Post in a prominent place the following instructions: FOR YOUR SAFETY IF YOU SMELL GAS: FOR YOUR SAFETY...
  • Page 4 FL-2361 Holding Cabinet Rev. 4 (10/13) Page 4 of 12 5925 Heisley Road • Mentor, OH 44060-1833 INSTALLATION INSTRUCTIONS HC-UA-11 FOR PROPANE CYLINDER INSTALLATION: This cabinet is not intended for use with natural gas. WARNING It is not user-convertible to natural gas. 1 .
  • Page 5 FL-2361 Holding Cabinet Rev. 4 (10/13) Page 5 of 12 5925 Heisley Road • Mentor, OH 44060-1833 INSTALLATION INSTRUCTIONS GENERAL INSTALLATION: FOR PROPANE GAS OPERATION: Specifications: (Propane) 8,700 BTU 1 . Remove all paper and packing materials from the inside of the cabinet and install angles into posts . Connect a propane tank (per Propane Installation 2 .

  • Page 6: Operating Instructions

    FL-2361 Holding Cabinet Rev. 4 (10/13) Page 6 of 12 5925 Heisley Road • Mentor, OH 44060-1833 OPERATING INSTRUCTIONS TEMPERATURE "ON-OFF" SWITCH CONTROL BATTERY INDICATOR RESET LIGHT Figure 1: CONTROL PANEL CONTROL PANEL HOW TO HOLD FOOD: Air is VERY HOT HOW TO HOLD: WARNING when door is opened.

  • Page 7: Maintenance Instructions

    FL-2361 Holding Cabinet Rev. 4 (10/13) Page 7 of 12 5925 Heisley Road • Mentor, OH 44060-1833 MAINTENANCE INSTRUCTIONS Cleaning hints: WARNING 1 . Wipe up spills as soon as possible . 2 . Clean cabinet daily to avoid heavy dirt build-up. BEFORE cleaning the cabinet: 3 .

  • Page 8: Trouble Shooting Guide

    FL-2361 Holding Cabinet Rev. 4 (10/13) Page 8 of 12 5925 Heisley Road • Mentor, OH 44060-1833 TROUBLE-SHOOTING FAILURE POSSIBLE CAUSE 1 . Unit does not turn on (electric mode) . 1a . Power cord is not plugged in . 1b .
  • Page 9 FL-2361 Holding Cabinet Rev. 4 (10/13) Page 9 of 12 5925 Heisley Road • Mentor, OH 44060-1833 REPLACEMENT PARTS Include all information on nameplate when ordering parts 23 24 Cabinet Assembly: ITEM DESCRIPTION 120V Door Assembly 1221-596-K Hinge (2 per kit) 0519-110-K Latch 1006-143-K...
  • Page 10 FL-2361 Holding Cabinet Rev. 4 (10/13) Page 10 of 12 5925 Heisley Road • Mentor, OH 44060-1833 REPLACEMENT PARTS Include all information on nameplate when ordering parts CONTROL PANEL ASSEMBLY Control Panel Assembly: ITEM DESCRIPTION 120V 10 Power Switch 0808-126 11 Temperature Control 0848-075-CC 12 Battery Indicator...

  • Page 11: Wiring Diagram

    FL-2361 Holding Cabinet Rev. 4 (10/13) Page 11 of 12 5925 Heisley Road • Mentor, OH 44060-1833 WIRING DIAGRAM VALVE CONTROL MODULE BATTERY PROPANE TANK HOOK-UPAREA 8100-015 BURNER ASSEMBLY Burner Assembly: ITEM DESCRIPTION 120V 26 Terminal Block 0852-093 27 Relay DPDT 0857-130 28 Battery 7037-003...
  • Page 12 INPUT DC-DC CONVERTER 12V -> 6V blue brwn...
