5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Model: H137 series Humidity Holding Hot Cabinet
BUC-EE'S PROGRAMMING REVISION J-08

ELECTRICAL SPECIFICATIONS:

Model No.
H137WSUA5DMFBC
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Volts Watts
120 2000

HOW TO INSTALL UNIT:

1. Place cabinet on level floor, in a well ventilated area.
2. Unpack and install inner pan slides parts.
3. Plug cord end into proper wall outlet.
HOW TO CHANGE FROM °C TO °F (if needed)
1. Push the switch on; the light will come on.
2. Push and hold the "SET" button and the button in
the lower left hand corner together for 5 seconds.
You are now entered into the menu.
3. Scroll over the"Unit" and change it to "C" , then
scroll to the "END".
WARNING
Air is VERY HOT when door is opened.

FIRST TIME OPERATION:

NOTE: A new cabinet needs to "burn off"
manufacturing oils and excess adhesive
before its first use. Do NOT load food into
cabinet until this has been done!
1. Push the switch on; the light will come on.
NOTE: The letters "LOTPR" (Low Temperature)
will show on the control panel until it
reaches 80°F (26°C).
2. Push and hold knob for 5 seconds, then turn to
show 220°F. Push the knob to set the temperature.
Run the unit for one (1) hour.
3. Push the switch off the unit off and let cool.
4. Wipe the inside clean with detergent and hot water.
Insulated
Hot Cabinets
Rev. 2 (12/20)
Amps Hertz Phase
16.7 60 1
FL-2355-BC
Page 1 of 8
NEMA
5-20P
