SERVICE MANUAL
LCD Color Television
32DL66Ps
This model is classified as a
green product
This Service Manual describes replacement parts for the green product. When repairing this
green product, use the part(s) described in this manual and
GREEN PRODUCT PROCUREMENT
For (*1) and (*2), refer to
SOLDER.
© TOSHIBA CORPORATION
Ver. 1
(*1), as indicated by the underlined serial number.
lead-free solder
(*2).
LEAD-FREE
and

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 32DL66Ps

Summary of Contents for Toshiba 32DL66Ps

  • Page 1 This Service Manual describes replacement parts for the green product. When repairing this green product, use the part(s) described in this manual and lead-free solder (*2). GREEN PRODUCT PROCUREMENT LEAD-FREE For (*1) and (*2), refer to SOLDER. © TOSHIBA CORPORATION...

  • Page 2: Important Notice

    WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.
  • Page 3 IMPORTANT NOTICE User Guide Autodesk® DWF™ Viewer is necessary to view drawings and to activate the functions of this system. Please download and install. When Windows XP SP2 is used, pop-up windows are limited by the enhanced security function and this sample may not work. In that case, perform the Internet Explorer setting using the following procedure to restore normal operation.

  • Page 4: Operating Environment

    Operating Environment : Pentium III or higher recommended Monitor : 1024 x 768 or higher resolution recommended...
  • Page 5 Mouse : A mouse with wheel recommended : Microsoft Windows 2000/XP Browser Microsoft Internet Explorer 6.0 or later Drawing viewer : Autodesk DWF Viewer 6.0 * Use the software following respective license terms and conditions. Note: In case of using this service manual with network connection, allocate its folder to the client PCs as network drive to avoid any possible malfunction.
  • Page 6 Layer Display Changing Function When any of the color buttons on the toolbar is clicked, it can be selected to display desired layer in its color or not to display each layer. This allows you to see the pattern layer only by setting other layers to "non-display".
  • Page 7 Through WEB, ver. 6.5 has been released but with it, the linking function in this manual may not work properly. If ver. 6.5 has been installed, uninstall it and reinstall ver. 6.0. To get ver. 6.0, click the icon, or contact to the nearest Toshiba Service Centre for further assistance. Freezing windows opened (Cannot close the open windows) This may happen occasionally.
  • Page 8 Continue to use by operating the windows. Precaution when opening the diagrams While opening the diagrams, the menu in the left frame changes its color to GRAY. This is an indication that the viewer is processing. With this condition, the menu indication color may stick to the GRAY color or Windows may freeze if clicking other menu.

  • Page 9: Green Product Procurement

    Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.

  • Page 10: Lead-Free Solder

    LEAD-FREE SOLDER This product is manufactured using lead-free solder as a part of a movement within the consumer products industry at large to be environmentally responsible. Lead-free solder must be used in the servicing and repair of this product. WARNING: This product is manufactured using lead free solder.

  • Page 11: Safety Instruction

    SAFETY INSTRUCTION WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" INSTRUCTIONS BELOW. Safety Precaution WARNING: SERVICING SHOULD NOT BE ATTEMPTED BY ANYONE UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER. THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED BEFORE SERVICING THIS CHASSIS.
  • Page 12 inflammability, voltage resistance, etc. therefore, use only replacement parts that have these same characteristics. Use only the specified parts when the mark is indicated in the circuit diagram or parts list. 7. Parts mounting and routing dressing of wirings should be the same as that used originally.
  • Page 13 Resistance values in orms ( ). V: Voltmeter or oscilloscope (r.m.s. or peak reading) Input resistance : Input capacitance : 200 pF Frequency range : 15 Hz to 1 MHz and d.c. respectively Note: Appropriate measures should be taken to obtain the correct value in case of non sinusoidal waveforms.

  • Page 14: Product Safety Notice

    Product Safety Notice Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in this manual and its supplements;...

  • Page 15: Precautions For Handling The Lcd Module

    SAFETY INSTRUCTION Handling the LCD Module Safety Precaution In the event that the screen is damaged or the liquid crystal (fluid) leaks, do not breathe in or drink this fluid. Also, never touch this fluid. Such actions could cause toxicity or skin irritation. If this fluid should enter the mouth, rinse the mouth thoroughly with water.
  • Page 16 3. If the panel surface becomes soiled, wipe with cotton or a soft cloth. If this does not remove the soiling, breathe on the surface and then wipe again. If the panel surface is extremely solied, use a CRT cleaner as a cleaner. Wipe off the panel surface by drop the cleaner on the cloth.
  • Page 17 6. CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static electricity. When handling the module, use a wrist ground or anchor ground. 7. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for an extended period of time.
  • Page 18 10. When transporting the LCD module, do not use packing containing epoxy resin (amine) or silicon resin (alcohol or oxim). The gas generated by these materials can cause loss of polarity.
  • Page 20 Digital receiving board SIGNAL BOARD AV BOARD PANEL DDR RAM FLI8548 CORTEZ Plus w HDMI VBI Data Processor PANEL I/F DCDi Video Input Analog MADi Decoder Terminal Front Scaling (Audio) (16port) LVDS CVBS(L/R) S-VIDEO(L/R) YCbCr(L/R) Channel Standby Process uCON Digital Input A EEPROM PC_IN(L/R)

  • Page 21: Schematic Diagram

    SCHEMATIC DIAGRAM Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
  • Page 22 All capacitors are ceramic 50 V, unless otherwise noted as the following marks. = Electrolytic capacitor = Mylar capacitor 3. The parts indicated with " " have special characteristics, and should be replaced with identical parts only. 4. Voltages read with DIGITAL MULTI-METER from point indicated to chassis ground, using a color bar signal with all controls at normal, line voltage at nominal AC volts.

  • Page 77: Entering To Service Mode

    ADJUSTMENT Service Mode Entering to Service Mode 1. Set VOLUME to minimum and press button once on remote control. ↓ 2. Press button again and hold button down. ↓ Service Mode display 3. While holding the button, press MENU button on TV set.
  • Page 78 Displaying the Adjustment Menu Press MENU button on TV. Service Mode Press ↑ ↓ Press Adjustment Mode Key Function in the Service Mode The following key entry during display of adjustment menu provides special functions. CAUTION: Never try to perform initialization unless you have changed the memory IC.

  • Page 79: Setting & Adjusting Data

    Test signal selection Selection of the adjustment items (on TV or remote control) Change of the data value Volume +/- (on TV or remote control) Adjustment menu mode ON/OFF MENU button (on TV) CALL + CH button on TV ( Initialization of the memory (QA02) Reset the count of operating CALL + CH button on TV (...

  • Page 80: Exit From Service Mode

    Item Name of adjustment Preset Data RCUT R CUT OFF ← GCUT G CUT OFF ← BCUT B CUT OFF ← RDRV R DRIVE ← GDRV G DRIVE ← BDRV B DRIVE ← BRTC BRIGHTNESS CENTER ← COLC COLOR CENTER ←...

  • Page 81: Test Signal Selection

    After replacing QA02, the following initialization is required. CAUTION: Never attempt to initialize the data unless QA02 has been replaced. 1. Enter the service mode, then select any register item. 2. Press and hold the CALL button on the remote control, then press the CH button on the TV.

  • Page 82: Self-Diagnostic Function

    All Black All White Self Diagnostic Function 1. Press "9" button on remote control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC's is executed properly. 2. During diagnosis, the following displays are shown. (1) Firmware : Version information of microprocessor In case of file name : WL66_EU and Version : 0326 indicates [WL66_EU_0326].
  • Page 83 SDA-GND (Red indication) : SDA-GND short circuit SCL-SDA (Red indication) : SCL-SDA short circuit (4) Bus cont : --- "OK" is normal. NG is abnormal (Red indication). When the abnormal status is detected, type name of semiconductor is indicated in in red colour. (5) Block : TV reception mode V1 - V9 : VIDEO 1-9 input mode...
  • Page 84 The version of main MPU will be checked. 2. During Version Check, the following displays are shown. (1) MAIN MPU : Version information of microprocessor In case of file name : WL66_EU, Version 0326 for Code Program Version and (E01) for OSD Version indicates [WL66_EU_0326 (E01)] (2) EEPROM : Version information of EEPROM : Display 1 byte data.
  • Page 85 (8) A/D Adjust A/D adjustment item. --COMP : Component input --PC : PC input --PAL : PAL (50 Hz) SD signal (composite input) --NTSC : NTSC (60 Hz) SD signal (composite input) --OK : A/D adjustment set correctly. --NG : A/D adjustment set incorrect. (9) LCD Panel Vender information display The following Panel Vender and screen size are displayed.

  • Page 86: Screen Size

    (1) MAIN : Main source information : Display RF position number (0 - 99) on the main screen, or Input Source (EXT1/2/3/HDMI etc.) (2) MAIN FORMAT : Display Video and PC format information (3) MAIN PLL : Main PLL information : Display 1 byte data at five. (4) SUB : Sub source information : Display RF position number (0 - 99) on the Sub screen, or Input Source...

  • Page 87: Setting Hotel Mode

    Super Live 2 Cinema 2 Super Live 1 Cinema 1 Subtitle 14:9 (8) OTHER STATUS : Other status information : Display three numbers of 2 byte data. Setting Hotel Mode Enter to service mode and select Hotel Mode menu by pressing P or P .

  • Page 88: Led Indications

    (tuning adjustment etc.) D1 (bit1) SETUP MENU Disable Enable D0 (bit0) HOTEL Mode On (Enable the setting of D1 Off (Normal) to D7) LED Indications The Green and Red LEDs on the TV (at the bottom center of the TV) indicate the TV's status, as described below.

  • Page 89: Parts List

    PARTS LIST Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
  • Page 90 : Electrolytic : Metal Film : Fusible Resistor All CD and PF capacitors are ±5 %, 50 V and all resistor, ±5 %, 1/6 W unless otherwise noted.
  • Page 91 U01A POWER (PE0117) Location Parts No. Description U01A 75003771 PC BOARD ASSY, PE0117C1, POWER C801 76503507 CAPACITOR, PLASTIC FILM, AC275V 0.22UF K C802 76503507 CAPACITOR, PLASTIC FILM, AC275V 0.22UF K C803 76503169 CAPACITOR, PLASTIC FILM, 630V 0.1UF J C804 76214103 CAPACITOR, CERAMIC DISC, 500V B 0.01UF K C805 76092281...
  • Page 92 CE43 76567104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J CE82 76676470 CAPACITOR, ELECTROLYTIC, 100V 47UF M CE85 76073178 CAPACITOR, ELECTROLYTIC, 25V 3300UF M D801 23362200 DIODE, D5SB60, 7009F07 D801B 23717240 SCREW, BITTB3X10SZN D805 23357850 DIODE, ZENER, MTZJ9.1A D806 23357893 DIODE, ZENER, MTZJ27C D809 23357905 DIODE, ZENER, MTZJ36C...
  • Page 93 L801 23217847 TRANSFORMER, CHOKE, TPW2082AS L804 23103304 FERRITE CHOKE, TEM2011AA L805 23103304 FERRITE CHOKE, TEM2011AA L806 23248417 COIL, CHOKE, TLN3481AH L807 23248417 COIL, CHOKE, TLN3481AH L874 23103304 FERRITE CHOKE, TEM2011AA L875 23103304 FERRITE CHOKE, TEM2011AA L876 23103304 FERRITE CHOKE, TEM2011AA L878 23103304 FERRITE CHOKE, TEM2011AA...
  • Page 94 R821 76322689 RESISTOR, OXIDE METAL FILM, 1W 6.8 OHM J R827 76383103 RESISTOR, OXIDE METAL FILM, 2W 10K OHM J R828 76383103 RESISTOR, OXIDE METAL FILM, 2W 10K OHM J R853 76011103 RESISTOR, CHIP, 1/20W 10K OHM J R854 76011102 RESISTOR, CHIP, 1/20W 1K OHM J R869 76011472...
  • Page 95 U01B LOW_B (PE0117) Location Parts No. Description U01B 75003772 PC BOARD ASSY, PE0117C2, LOW_B C851 76092538 CAPACITOR, CERAMIC CHIP, 10V F 1UF Z C852 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CE40 76073183 CAPACITOR, ELECTROLYTIC, 35V 220UF M CE42 76539104 CAPACITOR, PLASTIC FILM, 50V 0.1UF J CE47...
  • Page 96 P810A 23713814 SOCKET, 127301109K2 PG02 23165495 EARTH TERMINAL, MET31-0332 Q853 23205443 TRANSISTOR, 2SA1162-Y(F) Q854 23205446 TRANSISTOR, 2SC2412K, Q T146 Q855 23205446 TRANSISTOR, 2SC2412K, Q T146 Q856 23205327 TRANSISTOR, RN1406(F) Q860 23205292 TRANSISTOR, 2SD2396 Q860B 23717240 SCREW, BITTB3X10SZN QE40 75003051 IC, SI-8050W-TL QE47 75001881 IC, CE-1059...
  • Page 97 RE32 76011223 RESISTOR, CHIP, 1/20W 22K OHM J RE33 76011473 RESISTOR, CHIP, 1/20W 47K OHM J RE34 76011104 RESISTOR, CHIP, 1/20W 100K OHM J RE51 76000445 CHIP JUMPER, 1608TYPE RE52 76011151 RESISTOR, CHIP, 1/20W 150 OHM J RE53 76871222 RESISTOR, CHIP, 1/8W 2.2K OHM J RE54 76871222 RESISTOR, CHIP, 1/8W 2.2K OHM J...
  • Page 98 U02B FRONT_AV (PE0118) Location Parts No. Description U02B 75003054 PC BOARD ASSY, PE0118A2, FRONT_AV C604 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K C605 76109103 CAPACITOR, CERAMIC CHIP, 50V B 0.01UF K CC11 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K CC12 76109102 CAPACITOR, CERAMIC CHIP, 50V B 1000PF K...
  • Page 99 U02C LED (PE0118) Location Parts No. Description U02C 75003055 PC BOARD ASSY, PE0118A3, LED CB02 76202221 CAPACITOR, ELECTROLYTIC, 10V 220UF M CB03 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z CB04 76100104 CAPACITOR, CERAMIC CHIP, 25V F 0.1UF Z CB05 76202221 CAPACITOR, ELECTROLYTIC, 10V 220UF M DB01...
  • Page 100 U02D KEY (PE0118) Location Parts No. Description U02D 75003056 PC BOARD ASSY, PE0118A4, KEY DA01 23362042 DIODE, ZENER, UDZS6.8B DA06 23362042 DIODE, ZENER, UDZS6.8B DA07 23362042 DIODE, ZENER, UDZS6.8B RA71 76011683 RESISTOR, CHIP, 1/20W 68K OHM J RA72 76011223 RESISTOR, CHIP, 1/20W 22K OHM J RA73 76011103 RESISTOR, CHIP, 1/20W 10K OHM J...
  • Page 101 U02E DB_DOWNLOAD (PE0118) Location Parts No. Description U02E 75003057 PC BOARD ASSY, PE0118A5, DB_DOWNLOAD GR60 76000445 CHIP JUMPER, 1608TYPE PL05A 23713754 PLUG, 3P 2.5MM G, B3B-EH-F1-TV4 PL05B 23713776 PLUG, 3P 2.5MM W, S3B-EH...
  • Page 102 U03AS SIGNAL (PE0119) Location Parts No. Description U03AS 75004631 PC BOARD ASSY, PE0119A1, SIGNAL C311 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C312 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C313 V03GD0000559 CHIP CERAMIC CAPACITOR (1608) C321 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C322 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C327 V03GD0000719 CHIP CERAMIC CAPACITOR (1608) C360...
  • Page 103 C435 V03GD0000591 CHIP CERAMIC CAPACITOR (1608) C436 V03GD0000574 CHIP CERAMIC CAPACITOR (1608) C438 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C439 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C440 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C441 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C442 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C451 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C453...
  • Page 104 C872 V03GD0001138 CHIP CERAMIC CAPACITOR (1608) C873 V03GD0001138 CHIP CERAMIC CAPACITOR (1608) C874 V03GD0000558 CHIP CERAMIC CAPACITOR (1608) C912 V03GD0001126 CHIP CERAMIC CAPACITOR (1608) C913 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C914 V03GD0000589 CHIP CERAMIC CAPACITOR (1608) C915 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C919 V03GD0000719 CHIP CERAMIC CAPACITOR (1608) C923...
  • Page 105 C3416 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3417 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3418 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3419 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3420 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3421 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3446 V03GD0000719 CHIP CERAMIC CAPACITOR (1608) C7900 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7901...
  • Page 106 C7934 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7935 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7936 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7937 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7938 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7939 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7940 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7941 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7942...
  • Page 107 C7976 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7977 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7978 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7979 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7980 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7981 V03GD0000719 CHIP CERAMIC CAPACITOR (1608) C7982 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7983 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7984...
  • Page 108 D201 V42GD0000208 ZENER DIODE D202 V42GD0000208 ZENER DIODE D203 V42GD0000208 ZENER DIODE D204 V42GD0000208 ZENER DIODE D205 V42GD0000208 ZENER DIODE D206 V42GD0000208 ZENER DIODE D207 V42GD0000208 ZENER DIODE D208 V42GD0000208 ZENER DIODE D209 V42GD0000208 ZENER DIODE D210 V42GD0000208 ZENER DIODE D211 V42GD0000208 ZENER DIODE D212...
  • Page 109 IC924 V45GD0000462 2 INPUT AND GATE L344 V05GD0000502 CHIP INDUCTOR(3225) L430 V05GD0000598 CHIP POWER INDUCTOR L431 V05GD0000599 CHIP POWER INDUCTOR L922 V13GD0000343 CHIP BEADS INDUCTOR (1608) L923 V13GD0000343 CHIP BEADS INDUCTOR (1608) N001 23961276 SOLDER, M705-GRN360-K2V C N002 23961260 SOLDER, M708E-3.0 (PB-FRE N003 23961257 SOLDER, M708E BAR (PB-FRE...
  • Page 110 R322 V01GD0000896 CHIP RESISTOR (1608) R323 V01GD0000896 CHIP RESISTOR (1608) R324 V01GD0000896 CHIP RESISTOR (1608) R325 V01GD0000896 CHIP RESISTOR (1608) R326 V01GD0000896 CHIP RESISTOR (1608) R327 V01GD0000896 CHIP RESISTOR (1608) R328 V01GD0000896 CHIP RESISTOR (1608) R329 V01GD0000896 CHIP RESISTOR (1608) R380 V01GD0000924 CHIP RESISTOR (1608) R381...
  • Page 111 R453 V01GD0000894 CHIP RESISTOR (1608) R454 V01GD0000894 CHIP RESISTOR (1608) R455 V01GD0001006 CHIP RESISTOR (1608) R456 V01GD0000894 CHIP RESISTOR (1608) R457 V01GD0001006 CHIP RESISTOR (1608) R458 V01GD0000903 CHIP RESISTOR (1608) R464 V01GD0000908 CHIP RESISTOR (1608) R465 V01GD0000894 CHIP RESISTOR (1608) R466 V01GD0001029 CHIP RESISTOR (1608) R467...
  • Page 112 R745 V01GD0001006 CHIP RESISTOR (1608) R746 V01GD0001006 CHIP RESISTOR (1608) R748 V01GD0000903 CHIP RESISTOR (1608) R913 V01GD0001667 CHIP RESISTOR (1608) R914 V01GD0001667 CHIP RESISTOR (1608) R915 V01GD0001702 CHIP JUMPER 1608TYPE R917 V01GD0001667 CHIP RESISTOR (1608) R920 V01GD0002075 CHIP RESISTOR (1608) R921 V01GD0002075 CHIP RESISTOR (1608) R922...
  • Page 113 R3232 V01GD0000895 CHIP RESISTOR (1608) R3233 V01GD0000895 CHIP RESISTOR (1608) R3242 V01GD0000894 CHIP RESISTOR (1608) R3244 V01GD0000894 CHIP RESISTOR (1608) R3250 V01GD0000915 CHIP RESISTOR (1608) R3251 V01GD0000895 CHIP RESISTOR (1608) R3252 V01GD0000909 CHIP RESISTOR (1608) R3253 V01GD0002069 CHIP RESISTOR (1608) R3254 V01GD0000894 CHIP RESISTOR (1608) R3255...
  • Page 114 R4241 V01GD0002075 CHIP RESISTOR (1608) R4251 V01GD0002075 CHIP RESISTOR (1608) R4261 V01GD0002075 CHIP RESISTOR (1608) R9208 V01GD0000895 CHIP RESISTOR (1608) R9209 V01GD0001667 CHIP RESISTOR (1608) R9211 V01GD0000894 CHIP RESISTOR (1608) R9212 V01GD0000914 CHIP RESISTOR (1608) R9242 V01GD0000894 CHIP RESISTOR (1608) R9243 V01GD0000894 CHIP RESISTOR (1608) R9246...
  • Page 115 W232 V01GD0001702 CHIP JUMPER 1608TYPE W233 V01GD0001702 CHIP JUMPER 1608TYPE W320 V01GD0001702 CHIP JUMPER 1608TYPE W400 V01GD0001702 CHIP JUMPER 1608TYPE W402 V01GD0001702 CHIP JUMPER 1608TYPE W403 V01GD0001702 CHIP JUMPER 1608TYPE W406 V01GD0001702 CHIP JUMPER 1608TYPE W409 V01GD0001702 CHIP JUMPER 1608TYPE W410 V01GD0001702 CHIP JUMPER 1608TYPE W411...
  • Page 116 W9143 V01GD0001702 CHIP JUMPER 1608TYPE W9160 V01GD0001702 CHIP JUMPER 1608TYPE W9998 V01GD0001702 CHIP JUMPER 1608TYPE X700 V10GD0000236 CHIP CRYSTAL RESONATOR...
  • Page 117 Miscellaneous Location Parts No. Description B001 75003768 LCD PANEL, G6LPL32-0RT, LC320W01-SL17 H001 23321543 TUNER, ENG37A13GF P801 23372353 POWER CORD, UK 250V3A FL/FUSE13 P801 23372297 POWER CORD, CEE PJ22B 75002683 CONNECTOR, 1MM PITCH B TO B, 237702150K4 PP01 23845859 HOLDER, WIRE, PVC-C0AT, L=70MM PP08 23974994 BAND, KESSOKU...
  • Page 118 Accessory Location Parts No. Description Y101 75001977 OWNERS MANUAL, ENGLISH Y101E 75001979 OWNERS MANUAL, EURO Y110 75001978 QUICK REFERENCE MANUAL, SET UP GUIDE Y114 75003440 SCHEMATIC DIAGRAM Y130 75001967 REMOCON HAND UNIT, CT-865 Y170 23845800 HOLDER, WIRE, NYLON66 D6.8...
  • Page 119 Cabinet Location Parts No. Description A201 75003666 FRONT BEZEL ASSY A320 75001971 PIECE, FRONT AV ASSY A330 75001968 PIECE, AC PAL A340 75001920 PIECE, BUTTON 7 KEY A380 23717240 SCREW, BITTB3X10SZN A401 75001970 BACK COVER A410 23717219 SCREW, PP3X8+SW+W SBN A411 23717267 SCREW, BITTB4X16 SBN...
  • Page 120 Packing Location Parts No. Description A701 75001973 CARTON BOX A702A 75001974 PACKING, TOP PAD A702B 75001975 PACKING, BOTTOM PAD...

  • Page 121: Function And Operation

    FUNCTION AND OPERATION The Remote Control Simple at-a-glance reference of your remote control. Inserting Battery and Effective Range of the Remote...
  • Page 122 Remove the back cover to reveal the battery compartment and make sure the batteries are inserted the right way round. Suitable battery types for this remote are AAA, IEC R03 1.5V. Do not combine a used, old battery with a new one or mix battery types. Remove dead batteries immediately to prevent acid from leaking into the battery compartment.
  • Page 123 FUNCTION AND OPERATION Control and Input Connection A wide variety of external equipment can be connected to the input sockets on the side of the television. Whilst all the necessary adjustments and controls for the television are made using the remote control, the buttons on the television may be used for some functions.
  • Page 124 Using the Control and Connection...
  • Page 126 FUNCTION AND OPERATION Tuning the Television Using Quick Setup, Sorting Programme Position Before switching on the television put your decoder and media recorder to Standby if they are connected. To set up the television use the buttons on the remote control.

  • Page 129: Manual Tune

    FUNCTION AND OPERATION Manual Tune The television can be tuned-in manually using Manual tuning. For example: if the television cannot be connected to a media recorder/decoder with a SCART lead or to tune-in a station on another System. Use left and right to move across the screen and select any of these Manual Tune options. Programme : The number to be pressed on the remote control.
  • Page 134 FUNCTION AND OPERATION Programme Skip...
  • Page 137 FUNCTION AND OPERATION Auto Tune, General Control, Sound Control Using Auto Tuning...
  • Page 138 Selecting Programme Position...
  • Page 140 FUNCTION AND OPERATION Auto Tune, General Control, Sound Control Using Auto Tuning...
  • Page 141 Selecting Programme Position...
  • Page 143 FUNCTION AND OPERATION Auto Tune, General Control, Sound Control Using Auto Tuning...
  • Page 144 Selecting Programme Position...

  • Page 146: Specification

    SPECIFICATION...
