Honda RUCKUS NPS50 2022 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
2022
2022
NPS50

Advertisement

Table of Contents
loading

Related Manuals for Honda RUCKUS NPS50 2022

Summary of Contents for Honda RUCKUS NPS50 2022

  • Page 1 Owner’s Manual 2022 2022 NPS50...
  • Page 2 This publication includes the latest production information available before printing. Honda Motor Co., Ltd. reserves the right to make changes at any time without notice and without incurring any obligation.
  • Page 3 Welcome Congratulations on your purchase of a new When service is required, remember that Honda vehicle. Your selection of a Honda your Honda dealer knows your vehicle best. makes you part of a worldwide family of If you have the required mechanical “know- satisfied customers who appreciate Honda's how”...
  • Page 4 A Few Words About Safety DANGER Your safety, and the safety of others, is very important. Operating this vehicle safely is an You WILL be KILLED or SERIOUSLY important responsibility. HURT if you don’t follow instructions. To help you make informed decisions about WARNING safety, we have provided operating procedures and other information on safety...

  • Page 5: Table Of Contents

    Contents Vehicle Safety P. 2 Operation Guide P. 16 Maintenance P. 34 Troubleshooting P. 65 Information P. 73 Specifications P. 98...

  • Page 6: Vehicle Safety

    Vehicle Safety This section contains important information for safe riding of your vehicle. Please read this section carefully. Safety Guidelines ..........P. 3 Safety Labels............P. 7 Safety Precautions..........P. 9 Riding Precautions ..........P. 10 Accessories & Modifications......P. 13 Loading ..............

  • Page 7: Safety Guidelines

    Safety Guidelines Safety Guidelines Before Riding Make sure that you are physically fit, mentally Follow these guidelines to enhance your safety: focused and free of alcohol and drugs. Check Perform all routine and regular inspections ● that you are wearing an approved helmet and specified in this manual.
  • Page 8 Safety Guidelines We recommend that all riders take a certified Make Yourself Easy to See course approved by the Motorcycle Safety Make yourself more visible, especially at night, Foundation (MSF) or a state approved training by wearing bright reflective clothing, positioning course.
  • Page 9 Safety Guidelines Keep Your Honda in Safe Condition If You are Involved in a Crash It's important to keep your vehicle properly Personal safety is your first priority. If you or maintained and in safe riding condition. anyone else has been injured, take time to...
  • Page 10 Safety Guidelines WARNING Carbon Monoxide Hazard Exhaust contains poisonous carbon monoxide, a Running the engine of your vehicle colorless, odorless gas. Breathing carbon while in an enclosed or even partially monoxide can cause loss of consciousness and enclosed area can cause a rapid build- may lead to death.

  • Page 11: Safety Labels

    Safety Labels Safety Labels serious injury. Read these labels carefully and don't remove them. Safety and information labels on your vehicle If a label comes off or becomes hard to read, provide important safety information and may contact your dealer for a replacement. warn you of potential hazards that could cause Continued...
  • Page 12 Safety Labels...

  • Page 13: Safety Precautions

    Safety Precautions Safety Precautions Look for a DOT (Department of Transportation) certification label on any helmet Ride cautiously and keep your hands on the you buy. ● handlebar and feet on the floor. Always consider the safety of other drivers ●...

  • Page 14: Riding Precautions

    Riding Precautions Riding Precautions Boots or Riding Shoes Sturdy boots with non-slip soles and ankle protection Break-in Period Jacket and Pants During the first 60 miles (100 km) of running, follow these guidelines to ensure your vehicle's Protective, highly visible, long-sleeved jacket future reliability and performance.
  • Page 15 Riding Precautions Exercise caution on low traction surfaces. Parking ● The tires slip more easily on such Park on a firm, level surface. ● surfaces and braking distances are If you must park on a slight incline or loose ● longer.
  • Page 16 Riding Precautions Parking with the Center Stand Refueling and Fuel Guidelines Stop the engine. Follow these guidelines to protect the engine, To lower the center stand, stand on the left fuel system and catalytic converter: side of the vehicle. Use only unleaded gasoline. ●...

  • Page 17: Accessories & Modifications

    We strongly advise that you do not add any seriously hurt or killed. accessories that were not specifically designed or approved for your vehicle by Honda or make Follow all instructions in this owner's modifications to your vehicle from its original manual regarding accessories and design.

  • Page 18: Loading

    Loading Loading WARNING Carrying extra weight affects your vehicle's ● Overloading, improper loading or handling, braking and stability. carrying a passenger can cause a crash Always ride at a safe speed for the load you and you can be seriously hurt or killed. are carrying.

  • Page 20: Operation Guide

    Basic Operation Flow Pre-ride Inspection (P.41) Acceleration Carefully inspect your vehicle to (P.28) make sure that it is safe to ride. Apply throttle gradually. Obey the speed limit. Starting the Engine (P.25) Start and warm the engine. Avoid revving the engine. Starting the Vehicle (P.28)
  • Page 21 Parking Braking Close the throttle and apply the (P.11) (P.29) front and rear brakes together. Park on a firm level surface. Use the stand and lock the The brake light will indicate steering. that you have applied the brakes. Stopping If pulling off the road, signal early enough to show traffic that you are pulling over, and pull over smoothly.
  • Page 22 Parts Location Owner’s manual storage (P.33) Throttle grip (P.64) Front brake lever (P.59) Ignition switch (P.22) Battery (P.52) Fuse box (P.72) Fuel fill cap (P.30) Engine oil fill cap/dipstick (P.55) Coolant reserve tank (P.57)
  • Page 23 Rear brake lock lever (P.24) Rear brake lever (P.59) Helmet holder (P.32) Kickstarter (P.26) Center stand (P.12)
  • Page 24 Instruments Speedometer Shows riding speed in miles (USA) or kilometers (Canada) per hour. Odometer Shows the total miles (USA) or kilometers (Canada) ridden.
  • Page 25 Indicators If one of these indicators does not come on when it should, have your dealer check for problems. Turn signal indicator High coolant temperature indicator If it comes on while riding: (P.67) Fuel reserve indicator When this indicator comes on while riding, fuel reserved in the tank about: 0.32 US gal (1.2 liters) High beam indicator...
  • Page 26 Switches Ignition Switch Switches the electrical system on/off, locks the Turns electrical system on for steering. starting/riding. Key can be removed when in the OFF or LOCK position. Turns engine off. LOCK Locks steering. Engine stop switch Should normally remain in the (Run) position.
  • Page 27 Steering Lock Locking Turn the handlebar all the way to the left. Lock the steering when parking to help Push the key down, and turn the ignition prevent theft. switch to the LOCK position. A U-shaped wheel lock or similar device is Jiggle the handlebar if the lock is difficult also recommended.
  • Page 28 Rear Brake Lock Be sure the rear brake lock is applied while starting and warming up the engine. Rear brake lever Locking Rear brake Squeeze the rear brake lever and set the rear lock lever brake lock lever. The rear brake lock will not function if the rear brake is not adjusted properly.
  • Page 29 Starting the Engine Start your engine using the following Place the vehicle on its center stand. Lock the rear brake. procedure, regardless of whether the engine The starter motor will only work when is cold or warm. the brake lever is pulled in. Make sure the engine stop switch is in the NOTICE (Run) position.
  • Page 30 Starting the Engine (Continued) To Start the Engine with Electric Starter To Start the Engine with Kickstarter With the throttle closed, operate the Press the start button with the throttle kickstarter with a rapid, continuous motion. completely closed. Release the start button Allowing the kickstarter to snap back as soon as the engine starts.
  • Page 31 If the engine does not start: Open the throttle slightly (about 1/8 in (3 mm), without freeplay) while starting the engine. About 1/8 in (3 mm), without freeplay If Engine Will Not Start (P.66)
  • Page 32 Riding Starting the Vehicle Acceleration and deceleration To accelerate: Open the throttle slowly. Push the vehicle forward off the center stand. To decelerate: Close the throttle. Lock the rear brake lock. Open Keep throttle closed. Close (Accelerate) Get on the vehicle. (Decelerate) Mount the vehicle from the left side, keeping at least one foot on the ground.
  • Page 33 Braking Close the throttle and apply the front and rear brake levers together. Do not apply the brake lock while riding. It may cause the wheel to lock, reducing control of the vehicle. Rear brake lever Front brake lever...
  • Page 34 Refueling Fuel type: Unleaded gasoline only Lower edge of Recommended fuel octane number: Fuel tank lid filler neck Pump Octane Number (PON) 86 or higher. Tank capacity: 1.32 US gal (5.0 L) Refueling and Fuel Guidelines (P.12) Opening the Fuel Fill Cap Pull the tab and open the fuel tank lid.
  • Page 35 Closing the Fuel Fill Cap WARNING Install and tighten the fuel fill cap by turning Gasoline is highly flammable and it clockwise. explosive. You can be burned or Make sure that the arrow marks on the seriously injured when handling fuel. cap and fuel tank are aligned.
  • Page 36 Storage Equipment Helmet Holder Locking The helmet holder is located at the left seat Hang your helmet on the holder pin and rail. push it in to lock. Remove the key. Helmet holder Use the helmet holder only when parked. WARNING Riding with a helmet attached to the holder can interfere with the rear wheel...
  • Page 37 Document Bag Seat The document bag is in the owner’s manual storage compartment on the underside of the seat. Document bag Seat hook Screw To open the seat Push the seat hook and lift the seat. To close the seat Lower the seat.

  • Page 38: Maintenance

    Maintenance Please read “Importance of Maintenance” and “Maintenance Fundamentals” carefully before attempting any maintenance. Refer to “Specifications” for service data. Importance of Maintenance ......P. 35 Maintenance Schedule........P. 37 Maintenance Record......... P. 40 Maintenance Fundamentals ......P. 41 Removing & Installing Body Components.. P. 52 Battery ..............

  • Page 39: Importance Of Maintenance

    Importance of Maintenance For information about the exhaust emission and Importance of Maintenance noise emission requirements of the U.S. Keeping your vehicle well-maintained is Environmental Protection Agency (EPA), and the absolutely essential to your safety and to Environment and Climate Change Canada protect your investment, obtain maximum (ECCC).
  • Page 40 Importance of Maintenance Follow these guidelines when performing Maintenance Safety maintenance. Always read the maintenance instructions Stop the engine and remove the key. ● before you begin each task, and make sure that Place your vehicle on a firm, level surface ●...

  • Page 41: Maintenance Schedule

    Maintenance work should be performed in owner. accordance with Honda's standards and specifications by properly trained and equipped technicians. Your dealer meets all of these requirements. All scheduled maintenance is considered a normal owner operating cost and will be charged to you by your dealer.
  • Page 42 Inspect (clean, adjust, lubricate, or replace, if necessary) dealer, unless you have the necessary tools and are Replace mechanically skilled. Clean Procedures are provided in an official Honda Service Manual (2 P. 90). : Technical. In the interest of safety, have your vehicle serviced by your dealer.
  • Page 43 Maintenance Schedule Frequency Odometer Reading × 1,000 mi Refer to page Items × 1,000 km Brake Shoes Wear Brake System Brake Lock Operation 24, 60 Headlight Aim – Clutch Shoes Wear – Suspension – Nuts, Bolts, Fasteners – Wheels/Tires Steering Head Bearings –...

  • Page 44: Maintenance Record

    Maintenance Record Distance Odometer Date Performed By: Notes 600 miles (1,000 km) 4,000 miles (6,400 km) 8,000 miles (12,800 km) 12,000 miles (19,200 km) 16,000 miles (25,600 km) 20,000 miles (32,000 km) 24,000 miles (38,400 km) 28,000 miles (44,800 km) 32,000 miles (51,200 km) 36,000 miles (57,600 km) 40,000 miles (64,000 km)

  • Page 45: Maintenance Fundamentals

    Maintenance Fundamentals Check the following items after you get on your Pre-ride Inspection vehicle: To ensure safety, it is your responsibility to Throttle action moves smoothly without ● perform a pre-ride inspection and make sure binding. P. 64 that any problem you find is corrected. A pre- Brake levers operate normally.
  • Page 46 Maintenance Fundamentals Periodic Checks You should also perform other periodic maintenance checks at least once a month regardless of how often you ride, or more often if you ride frequently. Also, check the odometer reading against the Maintenance Schedule and perform all maintenance that is due.
  • Page 47 Maintenance Fundamentals Replacing Parts Always use Honda Genuine Parts or their equivalents to ensure reliability and safety. When ordering colored components, specify the model name, color, and code mentioned on the color label. When ordering colored components, specify the model name, color, and code mentioned on the color label.
  • Page 48 Maintenance Fundamentals Electrolyte splashes onto your skin: Battery ● Remove affected clothing and wash your Your vehicle has a maintenance-free type skin thoroughly using water. battery. You do not have to check the battery Electrolyte splashes into your mouth: ● electrolyte level or add distilled water.
  • Page 49 30 days using a charger designed specifically for If the terminals are heavily corroded, clean your Honda, which can be purchased from your and polish the terminals with a wire brush or dealer. Read the information that came with sandpaper.
  • Page 50 Bump starting is also not ratings, see “Specifications.” P. 99 recommended. NOTICE Blown fuse Installing non-Honda electrical accessories can overload the electrical system, discharging the battery and possibly damaging the system. Fuses Fuses protect the electrical circuits on your NOTICE vehicle.
  • Page 51 Use SG or higher oils, excluding oils marked as “Energy If you use non-Honda engine oil, check the Conserving” or “Resource Conserving” on the label to make sure that the oil satisfies all of the circular API service symbol.
  • Page 52 Maintenance Fundamentals Recommended Coolant Crankcase Breather Pro Honda HP Coolant is a pre-mixed solution Service more frequently when riding in rain, at of antifreeze and distilled water. full throttle, or after the vehicle is washed or overturned. Service if the deposit level can be...
  • Page 53 Maintenance Fundamentals Inspecting for Damage Inspecting Tread Depth Inspect the tread wear indicators. If they Inspect the tires for become visible, replace the tires immediately. cuts, slits, or cracks that exposes fabric or cords, or nails or other foreign objects or TWI embedded in the side of the tire or the tread.
  • Page 54 Maintenance Fundamentals Have your tires replaced by your dealer. WARNING For recommended tires and air pressure, see Installing improper tires on your vehicle “Specifications.” P. 99 can adversely affect handling and Follow these guidelines whenever you replace stability, and can cause a crash in which tires.
  • Page 55 Maintenance Fundamentals Tire Identification Number (TIN) Tire Service Life The tire identification number (TIN) is a group The service life of your tires is dependent on of numbers and letters located on the sidewall many factors, including, but not limited to, of the tire.

  • Page 56: Removing & Installing Body Components

    Removing & Installing Body Components Battery Battery holder Fuse box cover Bolt Battery Battery Removal Make sure the ignition switch is in the OFF position. Remove the inner cover. P. 54 Disconnect the negative - terminal from the battery. Negative terminal Positive terminal Release the tab, then remove the fuse box cover.
  • Page 57 Removing & Installing Body Components Battery Remove the battery holder by removing the bolt. Remove the battery taking care not to drop the terminal nuts. Installation Install the parts in the reverse order of removal. Always connect the positive + terminal first.

  • Page 58: Inner Cover

    Removing & Installing Body Components Inner Cover Inner Cover Removal Remove the screws. Screws Release the tabs, then remove the inner cover. Installation Install the parts in the reverse order of removal. Inner cover Tabs...

  • Page 59: Engine Oil

    Engine Oil Checking the Engine Oil Upper level If the engine is cold, idle the engine for 3 to 5 minutes. Turn the ignition switch to the OFF Lower position and wait for 2 to 3 minutes. level Place your vehicle on its center stand on a firm, level surface.
  • Page 60 Engine Oil Adding Engine Oil Adding Engine Oil Securely reinstall the oil fill cap/dipstick. NOTICE If the engine oil is below or near the lower Overfilling with oil or operating with insufficient level mark, add the recommended engine oil. oil can cause damage to your engine. Do not mix P.

  • Page 61: Coolant

    Coolant Checking the Coolant If the coolant level is dropping noticeably or the reserve tank is empty, you likely have a serious leak. Have your vehicle inspected by Check the coolant level in the reserve tank your dealer. while the engine is cold. Place your vehicle on its center stand on a firm, level surface.
  • Page 62 Coolant Adding Coolant Adding Coolant Remove the reserve tank cap and add fluid while monitoring the coolant level. Do not overfill above the UPPER level If the coolant level is below the LOWER level mark. mark, add the recommended coolant Make sure no foreign objects enter the P.

  • Page 63: Brakes

    Brakes Inspecting the Brake Lever Check the brake cable for kinks or signs of wear. If necessary have it replaced by your Freeplay dealer. Lubricate the brake cable with a Place your vehicle on its center stand on a commercially available cable lubricant to firm, level surface.
  • Page 64 Brakes Adjusting the Rear Brake Lever Freeplay Adjusting the Rear Brake Lever Adjust by turning the rear brake adjusting nut a half-turn at a time. Freeplay Adjusting Adjust the freeplay of the brake lever with the front wheel pointed straight ahead. Make sure the cut-out on the adjusting nut is seated on the brake arm pin when adjusting the freeplay.
  • Page 65 Brakes Adjusting the Front Brake Lever Freeplay Adjusting the Front Brake Lever Push the brake arm to confirm that there is a gap between the rear brake adjusting Freeplay nut and brake arm pin. Adjust the freeplay of the brake lever with the Brake arm front wheel pointed straight ahead.
  • Page 66 Brakes Adjusting the Front Brake Lever Freeplay Adjust by turning the front brake Brake arm adjusting nut a half-turn at a time. Push Adjusting Brake arm pin Adjusting nut After adjustment, confirm the freeplay of the Increase brake lever. Brake Freeplay Make sure the brake arm, spring and fastener arm pin...
  • Page 67 Brake with the reference mark on full application of the brake, the brake shoes must be replaced. See your dealer for this service. When the brake service is necessary, see your dealer. Use only Honda Genuine Parts or its equivalent.

  • Page 68: Throttle

    Throttle Checking the Throttle Adjusting the Throttle Freeplay With the engine off, check that the throttle Slide the rubber dust cover. rotates smoothly from fully closed to fully Loosen the lock nut. open in all steering positions and throttle Turn the adjuster until the freeplay is 1/16 freeplay is correct.

  • Page 69: Troubleshooting

    Troubleshooting Engine Will Not Start........P. 66 Overheating (High coolant temperature indicator is on) ..........P. 67 Tire Puncture ............P. 68 Electrical Trouble ..........P. 69 Battery Goes Dead ..........P. 69 Burned-out Light Bulb........P. 69 Blown Fuse ............P. 72...

  • Page 70: Engine Will Not Start

    Engine Will Not Start Starter Motor Operates But Starter Motor Does Not Engine Does Not Start Operate Check the following items: Check the following items: Check the correct engine starting Check the correct engine starting ● ● sequence. P. 25 sequence.

  • Page 71: Overheating (High Coolant Temperature Indicator Is On)

    Overheating (High coolant temperature indicator is on) The engine is overheating when the following Stop the engine using the ignition switch. occurs: Allow the engine to cool with the ignition High coolant temperature indicator switch in the OFF position. ● comes on.

  • Page 72: Tire Puncture

    Tire Puncture WARNING Repairing a puncture or removing a wheel requires special tools and technical expertise. Riding your vehicle with a temporary We recommend you have this type of service tire repair can be risky. If the temporary performed by your dealer. repair fails, you can crash and be After an emergency repair, always have the seriously injured or killed.

  • Page 73: Electrical Trouble

    Electrical Trouble Battery Goes Dead Burned-out Light Bulb Charge the battery using a motorcycle Follow the procedure below to replace a battery charger. burned-out light bulb. Remove the battery from the vehicle before Turn the ignition switch to the OFF or LOCK charging.
  • Page 74 Electrical Trouble Burned-out Light Bulb Headlight Bulb Disconnect the connector by pressing the tabs. Bulb Remove the dust cover. Dust Unhook the pin and remove the bulb. cover Headlight Install a new bulb and parts in the reverse order of removal. mark Install the dust cover with its TOP mark facing up.
  • Page 75 Electrical Trouble Burned-out Light Bulb Brake/Taillight Bulb Front/Rear Turn Signal Bulb Lens packing Screw Turn signal lens Taillight lens Bulb Lens packing Screws Bulb Remove the taillight lens by removing the Remove the turn signal lens by removing screws. the screw. Slightly press the bulb in and turn it Slightly press the bulb and turn it counterclockwise.

  • Page 76: Blown Fuse

    Electrical Trouble Blown Fuse Blown Fuse Remove the inner cover. P. 54 Remove the fuse box cover by pressing the tab. Before handling fuses, see “Inspecting and Pull the main fuse and circuit fuses out Replacing Fuses.” P. 46 one by one and check for a blown fuse. Fuse Box Fuses Always replace a blown fuse with a spare fuse of the same rating.

  • Page 77: Information

    Vehicle Identification Number....... P. 81 Emission Control Systems ....... P. 82 Catalytic Converter ........... P. 87 High Altitude Carburetor Adjustment ..P. 88 Oxygenated Fuels..........P. 89 Authorized Manuals ......... P. 90 Warranty Coverage and Service ....P. 91 Honda Contacts ..........P. 94...

  • Page 78: Keys

    Keys Keys Ignition Key Be sure to record the key number provided with the original keys. Store the spare key and key number in a safe location. To make a duplicate, take the spare key or the key number to your dealer. If you lose all ignition keys and the key number, the ignition switch assembly will probably have to be removed by your dealer to determine the...

  • Page 79: Instruments, Controls, & Other Features

    Instruments, Controls, & Other Features Instruments, Controls, & Odometer Other Features The odometer returns to 0 when the read-out exceeds 99,999.9. Ignition Switch Document Bag Leaving the ignition switch in the ON position The owner’s manual, registration, and insurance with the engine stopped will drain the battery. information can be stored in the plastic Do not turn the key while riding.

  • Page 80: Caring For Your Vehicle

    Frequent cleaning and polishing is important to After the vehicle dries, lubricate any moving ensure the life of your Honda. A clean vehicle parts. makes it easier to spot potential problems.
  • Page 81 Caring for Your Vehicle Washing Precautions Do not direct water near the headlight: ● The headlight's inside lens may fog Follow these guidelines when washing: Do not use high-pressure washers: temporarily after washing or while riding ● High-pressure water cleaners can in the rain.
  • Page 82 Caring for Your Vehicle Aluminum Components Exhaust Pipe and Muffler Aluminum will corrode from contact with dirt, When the exhaust pipe and muffler are painted, mud, or road salt. Clean aluminum parts do not use a commercially available abrasive regularly and follow these guidelines to avoid kitchen cleaning compound.

  • Page 83: Storing Your Vehicle

    For more information about storage, Canada Place your vehicle on its center stand and visit our website at www.honda.ca and look up ● position a block so that both tires are off the “Storage Tips” under the “Honda Warranty” in ground.

  • Page 84: Transporting Your Vehicle

    Transporting Your Vehicle Transporting Your Vehicle You & the Environment If your vehicle needs to be transported, it Owning and riding a vehicle can be enjoyable, should be carried on a motorcycle trailer or a but you must do your part to protect the flatbed truck or trailer that has a loading ramp environment.

  • Page 85: Vehicle Identification Number

    Vehicle Identification Number Vehicle Identification Number The VIN and engine serial number uniquely identify your vehicle and are required in order to register your vehicle. They may also be required when ordering replacement parts. The VIN is stamped on the left side of the frame and also appears on the Safety Certification Label attached to the left side of the frame.

  • Page 86: Emission Control Systems

    Emission Control Systems Emission Control Systems Your vehicle engine emits combustion byproducts, including carbon monoxide (CO), oxides of nitrogen (NOx), and hydrocarbons (HC). Gasoline evaporation also emits hydrocarbons. Controlling the production of NOx, CO, and HC is important for the environment.
  • Page 87 Compliance with the terms of the The EPA requires that vehicles built after Distributor's Warranties for Honda Scooter January 1, 1983 comply with applicable noise emission standards for one year or 3,730 miles Emission Control Systems is necessary in order (6,000 km) after the time of purchase when to maintain a valid emissions system warranty.
  • Page 88 Emission Control Systems Exhaust Emission Control System Crankcase Emissions Control System The exhaust emission control system consists of The engine is equipped with a closed crankcase appropriate carburetor settings, and no system to prevent discharging crankcase adjustment should be made except idle speed emissions into the atmosphere.
  • Page 89 Emission Control Systems Fuel Permeation Emission Control Noise Emission Control System The fuel tank, fuel hoses, and fuel vapor charge TAMPERING WITH THE NOISE CONTROL hoses use fuel permeation control technologies SYSTEM IS PROHIBITED: to prevent fuel vapor emissions. Tampering with U.
  • Page 90 Emission Control Systems AMONG THOSE ACTS PRESUMED TO Problems Affecting Vehicle Exhaust CONSTITUTE TAMPERING ARE THE Emissions FOLLOWING ACTS: Have your vehicle inspected and repaired by Removal of, or puncturing the muffler, ● your dealer if you experience any of the baffles, header pipes or any other following symptoms: component which conducts exhaust gases.

  • Page 91: Catalytic Converter

    A defective catalytic converter contributes to air riding and turn off the engine. Have your pollution and can impair your engine's vehicle serviced as soon as possible. performance. A replacement unit must be an original Honda part or equivalent.

  • Page 92: High Altitude Carburetor Adjustment

    High Altitude Carburetor Adjustment High Altitude Carburetor Adjustment Your engine's air-fuel mixture becomes overly rich when operated at high altitudes. Above 6,500 ft (2,000 m), a rich mixture can cause driveability problems, reduce engine performance, and increase fuel consumption. To compensate, you can have the carburetor adjusted for high altitude riding.

  • Page 93: Oxygenated Fuels

    Oxygenated Fuels Oxygenated Fuels If you accidentally fill your fuel tank with an oxygenated fuel containing higher percentages, Some conventional fuels blended with alcohol you may experience performance problems. To or an ether compound are available in some resolve the problem, have your dealer drain the locales to help reduce emissions to meet clean fuel tank and replace with the correct fuel.

  • Page 94: Authorized Manuals

    Authorized Manuals Authorized Manuals These Honda manuals are written for the professional technician. However, if you possess The Service Manual used by your the proper tools, observe the safety standards, authorized dealer is available from your Honda and are mechanically capable, you should find dealer or Helm, Inc.

  • Page 95: Warranty Coverage And Service

    Service workmanship of your Honda. Your warranty coverage does not apply to the normal wear Coverage and deterioration associated with use of the Your new Honda is covered by the following vehicle. warranties: Vehicle Limited Warranty ● Your warranty coverage is not voided if you Emission Control System Warranty ●...
  • Page 96 Warranty Coverage and Service performed by a person other than an Statement on Warranty Coverage for authorized service provider caused damage to Aftermarket and Recycled Parts another part of the vehicle otherwise covered New Jersey under warranty before denying warranty The Magnuson-Moss Warranty Act, 15 U.S.C.
  • Page 97 If you believe you have a problem with your dealership or their designated representative. vehicle, call the service department of your Honda dealer. Make an appointment for an inspection and diagnosis. You will be asked to authorize that inspection, and your dealer will return the results of the inspection.

  • Page 98: Honda Contacts

    P.O. Box 2200, Torrance, CA 90509-2200 Product model, year, and VIN ● Mailstop: 100-4W-5F Date of purchase ● Dealer name and address ● Telephone: (866) 784-1870 We will likely ask your Honda dealer to respond, or possibly acknowledge your comments directly. Website: https://powersports.honda.com/ contact-us...
  • Page 99 Your Honda Dealer HondaCare Protection Plan to extend almost ® The service department of your Honda dealer all of your warranty coverage. offers trained personnel to perform regular maintenance and unexpected repairs. It has the Your Honda dealer can also supply information...
  • Page 100 However, NHTSA cannot become involved in individual problems between you, your dealer, or American Honda Motor Co., Inc.
  • Page 101 However, Transport Canada cannot become involved in individual problems between you, your dealer, or Honda Canada Inc.

  • Page 102: Specifications

    Specifications Main Components ■ Displacement 3.0 cu-in (49 cm Overall length 73.2 in (1,860 mm) Bore x stroke 1.49 x 1.73 in (37.8 x 44.0 mm) Overall width 28.9 in (735 mm) Compression ratio 11.9:1 Unleaded gasoline Overall height 40.4 in (1,025 mm) Fuel Recommended: 86 PON or higher Wheelbase...
  • Page 103 API service label, SAE Fuses ■ engine oil 10W-30, JASO T 903 standard MA, Pro Honda GN4 4-stroke oil (USA & Canada) or Honda 4- Main fuse 20 A stroke oil, or an equivalent motorcycle oil Other fuse...
  • Page 104 Information Record Engine No. Color Label & Code Owner's Name Address City/State Phone Dealer's Name Address City/State Phone Service Manager...
  • Page 105 California Proposition 65 Warning WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm.
  • Page 106 31GGA720 00X31-GGA-7200 PRINTED IN USA...
