500DA2Q-HD Dual HD Reclocking Distribution Amplifier
TABLE OF CONTENTS
Revision 1.1
Frame Manual
Advertisement
Table of Contents
Related Manuals for evertz exponent 500DA2Q-HD
Summary of Contents for evertz exponent 500DA2Q-HD
-
Page 1: Table Of Contents
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION........................... 3 SPECIFICATIONS..........................4 3.1. SERIAL VIDEO INPUT ....................... 4 3.2. SERIAL VIDEO OUTPUTS......................4 3.3. ELECTRICAL ..........................4 3.4. PHYSICAL ..........................4 STATUS LEDS ............................ 5 4.1. - Page 2 Mar 03 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
-
Page 3: Overview
500DA2Q-HD Dual HD Reclocking Distribution Amplifier OVERVIEW The Evertz 500DA2Q-HD Dual HD Reclocking Distribution Amplifier provides the highest density DA in the industry allowing up to 32 HD or SDI Distribution amplifiers in a 3RU space. It provides inexpensive distribution of your SMPTE 292M (1.5 Gb/s), SMPTE 259M (143 to 360 Mb/s), SMPTE 344M (540 Mb/s), DVB-ASI or SMPTE 310M (19.4 Mb/s) or any other SDI signal within the 143 Mb/s to 1.5 Gb/s range. -
Page 4: Figure 1: 500Da2Q-Hd Block Diagram
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier Reclocker 1.5G Locked Cable Drivers Serial Input (143Mb/s to 1.5Gb/s) Serial Output 143Mb/s to 1.5Gb/s 143Mb/s-1.5Gb/s Equalizer (SMPTE 259M, 344M or Reclocker 292M) Reclocker Bypass Carrier Present Reclocker Control & Bypassed Indicators Reclocker Locked 1.5G... -
Page 5: Installation
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier INSTALLATION The 500DA2Q-HD comes with a companion rear panel overlay that can be placed over the rear panel BNC connectors to identify their function. For information on inserting the module into the frame see the 500FR chapter section 3. -
Page 6: Specifications
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier SPECIFICATIONS 3.1. SERIAL VIDEO INPUT Standards: Reclocked: SMPTE 292M (1.5 Gb/s). SMPTE 259M (143 to 360 Mb/s). SMPTE 344M (540 Mb/s) DVB-ASI Non-reclocked: SMPTE 310M (19.4 Mb/s) Any SDI signal in the143Mb/s to 1.5 Gb/s range Connectors: 2 BNC per IEC 169-8 Equalization:... -
Page 7: Status Leds
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier STATUS LEDS The 500DA2Q-HD has thirteen LED Status indicators on the front card edge to show operational status of the card at a glance. Error! Reference source not found. shows the location of the LEDs. Two large LEDs on the front of the board indicate the general health of the module STATUS: This Red LED indicates poor module health and will be On during the absence of a... -
Page 8: Input 2 Indicators
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier 4.2. INPUT 2 INDICATORS There are three small LEDs at the bottom of the module that indicate the status of equalizer for input 2 and the reclocker 2 rate. CARRIER PRESENT: This Green LED will be On when cable equalizer 2 detects that there is a signal present at input 2. -
Page 9: Selecting Whether Local Faults Will Be Monitored By The Global Frame Status
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier 5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED BY THE GLOBAL FRAME STATUS The FRAME STATUS jumper J1, located at the front of the module determines whether local faults (as shown by the Local Fault indicator) will be connected to the 500FR frame's global status bus. FRAME STATUS: To monitor faults on this module with the frame status indicators (on the power supply’s FRAME STATUS LED's and on the Frame's Fault Tally output) install this... -
Page 10: Selecting The Reclocking Rate
Frame Manual 500DA2Q-HD Dual HD Reclocking Distribution Amplifier 5.4. SELECTING THE RECLOCKING RATE Two jumpers located near the front of the module, determine whether the each half of the module will operate as a reclocking distribution amplifier SMPTE 292M (1.5 Gb/s), SMPTE 259M (143 to 360 Mb/s) or SMPTE 344M (540 Mb/s) or DVB-ASI video signals.
