AMiO VM-207 User Manual

EN
1
2
9
4
5
6
10
EN - USER MANUAL
BLUETOOTH FM TRANSMITER VM-207
Thank you for choosing VM-207
Transmitter. This product is designed and built with
high-performance Bluetooth module and audio
decoding chip. Not only it can connect the music from
the mobile phone to the car stereo through Bluetooth,
it can also play music files in U disk/ and transmit it to
the car stereo wirelessly. Built in hands-free phone call
system switches between music and incoming calls
seamlessly and enables you talk on the phone freely
during your driving. This product works by means of
wireless transmissions, so you can keep the original
classic setting of your car and still enjoy music on the
road.
DESCRIPTIONS
1. LED Display
2. LED Status Indicating Light
3. USB Charging Port Output 5V-2.4A
4. Left/Right Adjustment Button
5. Phone Answering Button
6. U Disk Port
7. 3.5mm AUX Port
8. Car Charging Adapter
9. Microphone
10. 0.5m 3.5mm Aux In Cable
SAFETY GUIDE
1. Do not drop, puncture or disassemble this product
2. This product is not waterproof, please do no expose
it to rain or water splashing
3. For safety, do not prolong exposure to direct sunlight
7 8
3
MEIDI+
Bluetooth FM
4. Do not place this product in an open flame that may
cause an explosion
5. Clean with a clean soft cloth and do not use any cor-
rosive cleaning agent
6. Drive safely. Do not operate this product while dri-
ving
FEATURES
1. This device has a car battery voltage display func-
tion.
2. Supports Bluetooth hands-free calling, built-in mi-
crophone.
3. Supports mobile phone A2DP function, directly
plays high quality music after connecting to Blue-
tooth.
4. Automatically enters the pairing state and connects
with your phone after power-on.
5. Supports U disk to play MP3/WMA/WAV/ FLAC/APE
format music.
6. After the car is turned off, the device records the
parking position and has a car searching function.
7. Equipped with car charger, output 5V-2.4A.
USE OF "MEIDI+" APP
Download the "Meidi+" APP in the Apple store or
Google Play. You can set the FM frequency, locate your
car and monitor car battery voltage on the "Meidi+"
APP. Upgrade the APP when there is a new update for
better using experience.
INSTRUCTIONS
1. Insert the product into the car cigarette lighter and
start the car engine, it will be powered on automa-
tically.
2. Press and hold the answer button to enter the
frequency setting interface. The left and right ad-
justment buttons can be used to set the frequency.
You can also set through the APP.
3. Turn on your car's FM radio stations and adjust the
frequency to match with the frequency on the trans-
mitter which supports 199 frequencies between
88.1MHz-107.9MHz.
4. Enable Bluetooth on your smartphone and search
for available Bluetooth devices, select "VM-207" and
connect. The Bluetooth indicating light changes
from flashing to long on when the Bluetooth is con-
nected, then go to the "Smart FM+" on your phone and
choose "Connect Bluetooth".
Note: For the FIRST TIME Bluetooth connection only,
when searching for available Bluetooth devices, make
sure you choose both "VM-207" and "VM-207-BLE"
manually and have them both connected at the same
time.
When AUX/U Disk is inserted, the mode will
automatically switch to it. Long Press Adjustment
Button to switch between Bluetooth, AUX, U Disk.
P/N: 02252
