6. Technical Specifications

Description
Nominal voltage
Battery input
voltage
Rated current
Max. PV voltage
Temperature
compensation
coefficient
Self-consumption
Charge circuit
voltage drop
Discharge circuit
voltage drop
Operating
environment
temperature
Related humidity
Enclosure
Grounding
Dimensions (mm)
Mounting
dimensions (mm)
Mounting hole size
Terminals
Net Weight
*Controller performance might drop slightly at increased ambient temperature
PWM Pro 10A PWM Pro 20A
10 A
12 V battery: 22 V PVmax / 24 V battery: 50 V PVmax
132x84.6x39.7 149x94.1x461
120x56
4 mm²
0,18 kg
PWM Pro 30A
12/24 V DC Auto
9~32V
20 A
-3 mV / ℃ / 2V (25℃)
≤8.1mA(12V);≤6.5mA(24V)
≤0.29 V
≤0.16 V
-25℃～+55℃*
≤95% (N.C.)
IP 30
COMMON POSITIVE
177.5x106.6x46
137x60 165.5x70
Φ4.5mm
10 mm² 16 mm²
0,26 kg 0,33 kg
— 21 —
PWM Pro 45A
30 A 45 A
194x118.4x63.8
185x90
16 mm²
0,76 kg
