F 800 GS special vehicle
MAKE LIFE A RIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F 800 GS special vehicle and is the answer not in the manual?

Questions and answers

Related Manuals for BMW Motorrad F 800 GS special vehicle

Summary of Contents for BMW Motorrad F 800 GS special vehicle

  • Page 1 MOTORRAD RIDER'S MANUAL F 800 GS special vehicle MAKE LIFE A RIDE...
  • Page 2 Vehicle data Model Vehicle Identification Number Colour code Date of first registration Registration number Dealership details Person to contact in Service department Ms/Mr Phone number Dealership address/phone number (company stamp)
  • Page 3 YOUR BMW. We congratulate you on your choice of a vehicle from BMW Motorrad and welcome you to the community of BMW riders. Familiarise yourself with your new vehicle so that you can ride it safely and confidently in all traffic situations.
  • Page 4 GENERAL STATUS INSTRUCTIONS INDICATORS Quick & easy reference Indicator and warning Abbreviations and sym- lights bols Pure Ride view Equipment Menu view Technical data Rev. counter Currency Recommendation to Additional sources of upshift information Warning indicators Certificates and operat- ing licences INSTRUMENT Data memory CLUSTER...
  • Page 5 Run-on special func- Running in Shifting gear tions Off-road use Intelligent emergency Brakes call Parking your motor- Lighting cycle Light signals Refuelling Sound signals Securing motorcycle Authority-vehicle for transportation speedometer Traction control (DTC) ENGINEERING DE- Electronic Suspension TAILS Adjustment (D-ESA) Riding mode General notes Cruise control...
  • Page 6 Two-way radio box sound signals Topcase Function-button as- Navigation system signment Special functions CARE SERVICE Care products Washing the vehicle Reporting safety-rel- Cleaning easily dam- evant defects aged components Recycling Care of paintwork BMW Motorrad Paint preservation Service Laying up motorcycle...
  • Page 7 BMW Motorrad service history BMW Motorrad mo- bility services Maintenance work Maintenance sched- BMW Motorrad run- ning-in check Maintenance confirm- ations Service confirmations APPENDIX Declaration of Con- formity Radio equipment TFT instrument cluster Radio equipment tyre pressure control (RDC) Keyless Ride ECU...
  • Page 8 GENERAL INSTRUCTIONS...
  • Page 9 QUICK & EASY REFERENCE ABBREVIATIONS AND SYMBOLS EQUIPMENT TECHNICAL DATA CURRENCY ADDITIONAL SOURCES OF INFORMATION CERTIFICATES AND OPERATING LICENCES DATA MEMORY INTELLIGENT EMERGENCY CALL SYSTEM...
  • Page 10 GENERAL INSTRUCTIONS DANGER High-risk haz- QUICK & EASY REFERENCE ard. Non-avoidance leads An important aspect of this to fatal or severe injury. rider's manual is that it can be ATTENTION Special notes used for quick and easy refer- and precautionary meas- ence.
  • Page 11 Optional equipment. EQUIPMENT The vehicles are When you ordered your assembled com- BMW Motorrad, you chose plete with all the various items of custom BMW Motorrad equipment. This rider's manual optional equipment describes optional equipment originally ordered. (OE) and selected optional Optional accessories.
  • Page 12 Your authorised tration documents, or can be BMW Motorrad retailer obtained from your authorised will be happy to answer any BMW Motorrad retailer or an- questions you may have. other qualified service partner or specialist workshop. The Internet specifications in the vehicle...
  • Page 13 The vehicle owner can also re- process personal data. quest that a BMW Motorrad...
  • Page 14 GENERAL INSTRUCTIONS retailer or another qualified Environmental conditions, for service partner or specialist example temperature workshop read out the data The data is only processed in that is stored in the vehicle for the vehicle itself and is gener- a charge. ally non-permanent.
  • Page 15 BMW Motorrad retailer or an- this technical information can other qualified service partner be read out of the vehicle to- or specialist workshop.
  • Page 16 GENERAL INSTRUCTIONS Multimedia data, such as mu- formation is transferred to the sic for playback mobile device. Depending on Contacts data for use in con- the type of integration, this in- nection with a communication cludes, for example, position system or an integrated navig- data and additional general ation system vehicle information.
  • Page 17 Services of the vehicle has no influence on the con- manufacturer tent that is exchanged in this instance. Information on the For online services of the type, scope and purpose of the vehicle manufacturer, the data capture and use of per- individual functions are sonal data as part of the ser- described at suitable points,...
  • Page 18 GENERAL INSTRUCTIONS Protection of personal data: press permission of the per- Directive 95/46/EC of the son affected by the data pro- European Parliament and of cessing, for example the vehicle the Council. owner. Protection of personal data: SIM card Directive 2002/58/EC of the The intelligent emergency call European Parliament and of system operates via the mobile...
  • Page 19 card installed in a particular tions centre by the statutory vehicle. emergency call system eCall. In addition, the intelligent Log data of emergency calls emergency call system sends The log data of emergency the following additional calls is stored in a memory of information to an emergency the vehicle.
  • Page 20 GENERAL INSTRUCTIONS lysed. After this, the voice re- cordings are deleted. The voice recordings of the employee of the emergency call centre are stored for 24 hours for quality assurance purposes. Information on personal data The data that is processed as part of the intelligent emer- gency call is processed exclus- ively to carry out the emer-...
  • Page 22 GENERAL VIEWS...

  • Page 23: Table Of Contents

    GENERAL VIEW, LEFT SIDE GENERAL VIEW, RIGHT SIDE UNDER THE RIDER'S SEAT MULTIFUNCTION SWITCH, LEFT MULTIFUNCTION SWITCH, RIGHT MULTIFUNCTION SWITCH, RIGHT INSTRUMENT CLUSTER...

  • Page 24: General View, Left Side

    GENERAL VIEWS GENERAL VIEW, LEFT SIDE Power socket ( 216) Cases ( 218) Case for special vehicle USB charging interface 221) 217) 10 Fire extinguisher in the Microphone ( 104) case ( 222) Speaker ( 104) 11 Adjusting damping for Radio communication unit rear wheel ( 128)

  • Page 25: General View, Right Side

    GENERAL VIEW, RIGHT SIDE 360° marker strobe with additional head- light LED auxiliary headlights. Two-way radio box 222) Coolant level indicator Brake-fluid reservoir, front (behind the side trim pan- 179) el) ( 182) Vehicle identification Brake-fluid reservoir, rear number, type plate (on 180) steering head) 10 Adjusting spring preload...

  • Page 26: Under The Rider's Seat

    GENERAL VIEWS UNDER THE RIDER'S SEAT Toolkit ( 173) Tool for adjusting spring preload ( 127) Diagnostic connector 212) Battery ( 204) Fuses ( 211) Main fuse ( 210)

  • Page 27: Multifunction Switch, Left

    MULTIFUNCTION SWITCH, LEFT High-beam headlight and Hailing system ( 102) headlight flasher ( Sound 3 and sound 4 Siren ( 103) Manual daytime riding light ( 10 Turn indicators ( Cruise control ( 112) 11 Function buttons (codable, depending on equipment Hazard warning lights fitted and customer re- quest: see the section...
  • Page 28 GENERAL VIEWS 13 MENU rocker button 14 Multi-Controller (...

  • Page 29: Multifunction Switch, Right

    MULTIFUNCTION SWITCH, RIGHT with intelligent emergency call Operating heated handle- Function buttons (codable, bar grips ( 118) depending on equipment fitted and customer re- Select the riding mode quest: see the section 110) headed "Technical data" Emergency-off switch (kill for details of coding for switch) ( function buttons) Starter button (...
  • Page 30 GENERAL VIEWS STOP signal, rear 100) LED flashing beacon, front LED 360° marker strobe SOS button Intelligent emergency call Rear fog light ( Light deactivation 101)

  • Page 31: Multifunction Switch, Right

    MULTIFUNCTION SWITCH, RIGHT Operating heated handle- Function buttons (codable, bar grips ( 118) depending on equipment fitted and customer re- Select the riding mode quest: see the section 110) headed "Technical data" Emergency-off switch (kill for details of coding for switch) ( function buttons) Starter button (...
  • Page 32 GENERAL VIEWS STOP signal, rear 100) LED flashing beacon, front LED 360° marker strobe Rear fog light ( Light deactivation 101)

  • Page 33: Instrument Cluster

    INSTRUMENT CLUSTER Indicator and warning lights ( Instrument cluster 31) ( DWA light-emitting diode 115) with Keyless Ride Indicator light for the ra- dio-operated key ( Photosensor (for adapting the brightness of the in- strument lighting)
  • Page 34 STATUS INDICATORS...
  • Page 35 INDICATOR AND WARNING LIGHTS PURE RIDE VIEW MENU VIEW REV. COUNTER RECOMMENDATION TO UPSHIFT WARNING INDICATORS...

  • Page 36: Indicator And Warning Lights

    STATUS INDICATORS INDICATOR AND WARNING LIGHTS Turn indicators, left with additional head- light LED auxiliary headlights. High-beam headlight General warning light Turn indicators, right Warning light, drive mal- function ( DTC ( ABS ( Manual daytime riding light (...

  • Page 37: Pure Ride View

    PURE RIDE VIEW Change of operating fo- 13 Operating help cus ( 14 Heating stages, handlebar Rev. counter ( grips ( 118) Status line ( 15 Automatic daytime riding light ( Speedometer 16 Outside temperature Riding mode ( 109) warning ( Recommendation to up- 17 Ambient temperature shift (...

  • Page 38: Menu View

    STATUS INDICATORS MENU VIEW Speedometer 13 Automatic daytime riding light ( Cruise control ( 112) 14 Outside temperature Speed Limit Info ( warning ( Riding mode ( 109) 15 Ambient temperature Status line ( 16 Menu section Recommendation to up- shift ( Gear indicator Clock (...

  • Page 39: Rev. Counter

    REV. COUNTER Scale Engine speed range Upper/red engine speed range Needle Secondary indicator Unit for engine speed display: 1000 revolutions per minute...

  • Page 40: Recommendation To Upshift

    STATUS INDICATORS RECOMMENDATION TO UP- SHIFT Check Control display The messages differ in how they show on the display. Dif- The recommendation to upshift ferent colours and symbols are in the status line 1 or in the used depending on priority: Pure Ride view 2 indicates the Green CHECK OK 1: No mes- best time to upshift economic-...
  • Page 41 or has reached a certain speed. Dashes are displayed as place- holders for as long as a meas- ured value cannot be displayed because the preconditions for measurement have still to be met. If there are no valid meas- ured values, there will be no assessment in the form of a Values display coloured symbol.
  • Page 42 STATUS INDICATORS 66). The message can be called up again as long as the fault persists.
  • Page 43 Warnings, overview Indicator and Display text Meaning warning lights Outside tempe- is displayed. rature warning Radio-operated lights up yel- Remote key not in key out of range low. range. Keyless Ride lights up yel- Keyless Ride failed ( low. failure Replacing battery lights up yel- Remote key bat-...
  • Page 44 STATUS INDICATORS Indicator and Display text Meaning warning lights Anti-theft alarm Alarm system battery flat battery empty. DWA failed Alarm system failure Engine tempera- lights up yel- Engine temp. ture high ( low. high! Engine over- lights up red. Engine overheat- heated ( ing! Drive malfunction...
  • Page 45 Indicator and Display text Meaning warning lights Tyre pressure flashes red. is displayed in red. outside permitted tolerance ( Tyre pressure does not match setpoint Tyre press. con- trol. Loss of pressure. Transmission fault " " Sensor faulty lights up yel- "...
  • Page 46 STATUS INDICATORS Indicator and Display text Meaning warning lights ABS self-dia- flashes. gnosis not com- pleted ( ABS fault ( lights up yel- Limited ABS low. availability! lights up. ABS failed lights up yel- ABS failure! low. lights up. ABS Pro failed lights up yel- ABS Pro failure! low.
  • Page 47 Indicator and Display text Meaning warning lights DTC fault ( lights up yel- Traction control low. failure! lights up. D-ESA fault lights up yel- Spring strut ad- low. justment faulty! Fuel down to re- Fuel reserve reached. serve ( Go to a filling station soon Gear not taught flashes.
  • Page 48 STATUS INDICATORS Ambient temperature The outside temperature is dis- WARNING played in the status line of the Risk of black ice forming TFT display. even when temperature is When the vehicle is at a stand- above approx. 3 °C still, the heat of the electrical Risk of accident machine can falsify the ambi- Always take extra care when...
  • Page 49 The integral battery in the ra- Have the faulty radio-operated dio-operated key has lost a key replaced by an authorised BMW Motorrad retailer. significant proportion of its original capacity. There is no Keyless Ride failed assurance of how long the ra-...
  • Page 50 Switch off non-essential con- cialist workshop, preferably an sumers or disconnect them authorised BMW Motorrad re- from the vehicle's electrical tailer. system. If the fault persists or occurs Voltage of the vehicle...
  • Page 51 Have the fault rectified as dicator faulty! quickly as possible by a spe- Rear right turn indic- cialist workshop, preferably an ator faulty! authorised BMW Motorrad re- Number plate light tailer. faulty! Bulb faulty Have it checked by a lights up yellow.
  • Page 52 This error message is dis- quickly as possible by a spe- played briefly only after cialist workshop, preferably an the Pre-Ride-Check completes. authorised BMW Motorrad re- Possible cause: tailer. The integral battery in the anti- Anti-theft alarm battery weak theft alarm (DWA) has lost its with anti-theft alarm (DWA) entire original capacity.
  • Page 53 Possible cause: Consult a specialist work- shop, preferably an authorised The coolant level is too low. BMW Motorrad retailer. Check the coolant level. 182) DWA failed If the coolant level is too low: with anti-theft alarm (DWA) Allow the motor to cool down.
  • Page 54 If the coolant level is too low: preferably an authorised Allow the motor to cool BMW Motorrad retailer. down. Top up the coolant. You can continue riding; pol- Have the cooling system lutant emissions are higher checked by a specialist than the threshold values.
  • Page 55 BMW Motorrad re- tailer. WARNING It is possible to continue to Unusual ride characterist- ride but not recommended. ics when engine running in Engine control failed emergency-operation mode lights up yellow. Risk of accident Avoid accelerating sharply lights up.
  • Page 56 The sensors do not cialist workshop, preferably an start transmitting measured authorised BMW Motorrad re- tyre pressure signals until the tailer. first time the vehicle acceler- ates to more than the minimum...
  • Page 57 RDC sensor is not active ible tolerance range. min 30 km/h (The RDC For further information about sensor does not transmit its BMW Motorrad RDC, see the signal to the vehicle until a section entitled "Engineering certain minimum speed has details" ( 165).
  • Page 58 Have the tyre checked for acteristics. damage by a specialist work- Adapt your style of riding shop, preferably an authorised accordingly. BMW Motorrad retailer. If you are unsure whether the vehicle can be ridden with the tyre in its present condition:...
  • Page 59 Increase speed above this preferably an authorised threshold and observe the BMW Motorrad retailer. RDC readings. Assume that Sensor faulty or system fault a permanent fault has not oc- with tyre pressure control curred unless the 'General'...
  • Page 60 Have the fault rectified Tyre pressure check by a specialist workshop, failure! Function preferably an authorised limited. Have it checked BMW Motorrad retailer. by a specialist work- Battery for tyre pressure shop. sensor weak Possible cause: with tyre pressure control...
  • Page 61 Make an Consult a specialist work- appointment at a spe- shop, preferably an authorised cialist workshop. BMW Motorrad retailer. Possible cause: Malfunction, side stand The emergency call cannot be monitor made automatically or cannot lights up yellow.
  • Page 62 157). Have the fault rectified as flashes. quickly as possible by a spe- cialist workshop, preferably an Possible cause: authorised BMW Motorrad re- The ABS function is not avail- tailer. able, because self-diagnosis did ABS failed not complete. The motorcycle has to move forward a few lights up yellow.
  • Page 63 (The motorcycle has to reach cialist workshop, preferably an a defined minimum speed authorised BMW Motorrad re- with the engine running for tailer. the wheel-speed sensors to DTC intervention be checked: min 5 km/h) quick-flashes.
  • Page 64 Possible cause: quickly as possible by a spe- The engine control unit has de- cialist workshop, preferably an tected a DTC fault. authorised BMW Motorrad re- tailer. DTC fault lights up yellow. lights up. Traction control failure! Onward...
  • Page 65 You can continue to ride. cialist workshop, preferably an Bear in mind the more authorised BMW Motorrad re- detailed information on tailer. situations that can lead to a Fuel down to reserve DTC fault ( 160).
  • Page 66 The fuel tank contains no more have the fault rectified than the reserve quantity of by a specialist workshop, fuel. preferably an authorised Reserve fuel BMW Motorrad retailer. Hazard warning lights system approx. 4 l is switched on Refuel. ( 147) flashes green.
  • Page 67 Have your motorcycle ser- viced regularly by a specialist Service due workshop, preferably by an is displayed in white. authorised BMW Motorrad re- tailer. Service due! Have The vehicle remains oper- service performed by a ationally reliable and road- specialist workshop.
  • Page 68 INSTRUMENT CLUSTER...
  • Page 69 WARNINGS CONTROLS MY VEHICLE SETTINGS BLUETOOTH PAIRING OPERATING FOCUS NAVIGATION MEDIA TELEPHONE SOFTWARE VERSION LICENCE INFORMATION...

  • Page 70: Warnings

    INSTRUMENT CLUSTER WARNINGS CONTROLS Multi-Controller WARNING Operation of a smartphone while riding the vehicle Risk of accident Always comply with the road traffic regulations in force where you are riding. Do not use a smartphone while riding. This applies Multi-Controller with the exception of ap- Move the cursor up in lists plications without opera-...
  • Page 71 MENU rocker button top section of the rocker but- ton. Instructions given by the navigation system are displayed as a dialogue if the menu has not Navigation been called up. Operation of the MENU rocker button is temporarily restricted. Display Pure Ride view Short-press the top section of Long-press the top section of MENU rocker button 1:...
  • Page 72 INSTRUMENT CLUSTER the menu item you want is Operating pointer 2: You can highlighted. scroll to the right. Short-press the bottom sec- Operating pointer 3: You can tion of button 2. scroll down. Operating pointer 4: You can menu can Settings scroll to the left.

  • Page 73: My Vehicle

    Operating pointer 2: One System status displays more submenu level can be The system status is displayed accessed. in the lower area of the menu if Operating pointer 3: There a function is switched on or off. are more entries than can be displayed.

  • Page 74: Settings

    INSTRUMENT CLUSTER The following values can be SETTINGS reset: Select the content of the top Break status line Navigate to Settings Journey Display Status line content Switch on the desired dis- Current plays. You can switch between the Speed selected displays in the top status line.
  • Page 75 Select the content of the top Break 1 status line. ( Break 2 (Average) Speed 1 (Average) Speed 2 with tyre pressure control (RDC) Tyre pressure Long-press button 1 to obtain the Pure Ride view. Repeatedly short-press but- Fuel tank level ton 1 to select the value in the top status line 2.

  • Page 76: Bluetooth Pairing

    When ambient brightness iOS operating system, the drops below a defined BMW Motorrad Connected app threshold, the display is has to be opened prior to use. dimmed to the brightness set During the pairing process, the here.
  • Page 77 Select Rider's helmet Bluetooth connection may be and con- Passenger helm. restricted. BMW Motorrad firm. recommends keeping the Make the helmet's communic- mobile device above the fuel ation system visible. tank (e.g. carried in a jacket...

  • Page 78: Operating Focus

    INSTRUMENT CLUSTER Select Pair new rider's OPERATING FOCUS helmet Pair new pas- with radio preparation and confirm. seng. helmet Helmets are searched for. with preparation for naviga- tion system The Bluetooth symbol flashes in the bottom Change of operating focus status line during pairing.

  • Page 79: Navigation

    Enter the destination address Enter special destinations Connect a mobile device. Special destinations, such as points of interest, can be dis- Call up the BMW Motorrad played on the map. Connected app and start the Navigate to route guidance. Navigation...
  • Page 80 INSTRUMENT CLUSTER Select where the special des- Edit route guidance tinations should be looked for. Navigate to Navigation For example, the following spe- New destination cial destination can be selected: You can choose from the fol- lowing destinations: Filling station Select and confirm the special Recent destinations destination.

  • Page 81: Media

    Media Vehicle is connected to a BMW Motorrad recom- compatible mobile device. The mends setting the volume BMW Motorrad Connected app for media and phone calls on is installed on the mobile the mobile device to maximum device. before riding off.

  • Page 82: Telephone

    INSTRUMENT CLUSTER Select the Muting Now playing During active phone calls, the artists All albums category for microphone in the helmet can All tracks search and playback. be muted. Select Playlists Phone calls with multiple You can make the following participants adjustments in the While a phone call is in pro-...
  • Page 84 OPERATION...
  • Page 85 IGNITION SWITCH/STEERING LOCK IGNITION WITH KEYLESS RIDE ELECTRONIC IMMOBILISER (EWS) EMERGENCY-OFF SWITCH (KILL SWITCH) RUN-ON SPECIAL FUNCTIONS INTELLIGENT EMERGENCY CALL LIGHTING LIGHT SIGNALS SOUND SIGNALS AUTHORITY-VEHICLE SPEEDOMETER TRACTION CONTROL (DTC) ELECTRONIC SUSPENSION ADJUSTMENT (D-ESA) RIDING MODE CRUISE CONTROL ANTI-THEFT ALARM (DWA) TYRE PRESSURE MONITORING (RDC) HEATED GRIPS SEATS...

  • Page 86: Ignition Switch/Steering Lock

    Engine can be started. well. Consult a specialist work- Pre-Ride-Check is performed. shop, preferably an authorised 137) BMW Motorrad retailer. ABS self-diagnosis is in pro- Engaging steering lock gress. ( 138) Turn the handlebars all the DTC self-diagnosis is in pro- way to the left.

  • Page 87: Ignition With Keyless Ride

    Handlebars not locked. The vehicle cannot be Key can be removed. started if the radio con- Electrically powered accessor- trol key is not within range (e.g. ies remain operational for a key inside one of the cases or limited period of time. the topcase).
  • Page 88 OPERATION Version 1: Short-press button 1. Side lights and all function circuits are switched on. Pre-Ride-Check is performed. 137) ABS self-diagnosis is in pro- gress. ( 138) DTC self-diagnosis is in pro- gress. ( 139) Press and hold down but- ton 1.
  • Page 89 The engine continues running and charges the battery. The vehicle is secured. To switch the function off, bring the radio-operated key into range and retract the side stand. There may be a delay be- fore the key is detected. There are two ways of deac- The key symbol is displayed in tivating the ignition.
  • Page 90 OPERATION Replacing battery of radio- operated key Requirement The radio-operated key does not react because the battery is weak. Remote key battery weak. Function lim- Remove the front seat. ited. Change battery. 118) Insert the spare key or folded- DANGER in radio-operated key with Swallowing a battery the empty battery 1 into ring...

  • Page 91: Electronic Immobiliser (Ews)

    Battery type CR 2032 Install battery cover 2. Red LED in the instrument cluster flashes. The radio-operated key is again ready for use. Press button 1. ELECTRONIC IMMOBILISER Key bit flips out. (EWS) Push battery cover 2 up. Remove battery 3. The on-board electronics Dispose of the old battery in access the data saved in the...

  • Page 92: Emergency-Off Switch (Kill Switch)

    Emergency-off switch (kill You can obtain extra keys switch) only through an authorised BMW Motorrad retailer. The ignition keys are part of an WARNING integrated security system, Operation of the kill switch so the retailer is under an...

  • Page 93: Run-On Special Functions

    Plug connection for auxiliary battery Engine switched off Normal operating position A precondition for operation (run) with auxiliary battery and the associated special functions RUN-ON SPECIAL is that jumper 1 was installed FUNCTIONS in isolating plug 2 for the pre- with auxiliary battery delivery check.
  • Page 94 The BMW Call Center answers in this language. The language for the emergency call can be changed only by the authorised BMW Motorrad retailer. The time until transmission The language assigned to of the emergency call is dis- the vehicle varies from the played.
  • Page 95 Remove helmet. Emergency call in the event of After expiry of the timer, a a light fall voice contact to the BMW Call A minor fall or a crash is de- Center is established. tected. An acoustic signal is sounded. The connection was estab- lished.

  • Page 96: Lighting

    OPERATION LIGHTING Low-beam headlight and sidelights The side lights switch on auto- matically when the ignition is switched on. The side lights place a strain on the battery. Switch on the ignition for a The connection was estab- limited time only. lished.
  • Page 97 after the vehicle has been parked, for example. Parking lights Switch off the ignition. Push switch 1 forward to switch on the high-beam headlight. Pull switch 1 back to operate the headlight flasher. Headlight courtesy delay Immediately after switching feature off the ignition, push but- Switch off the ignition.
  • Page 98 OPERATION If necessary, increase the size of the light cone by extending the pole of the 360° marker strobe. The surround lighting switches off automatically when you ride off. LED auxiliary headlights with additional headlight Make sure the ground is level Requirement and firm and place the motor- The auxiliary headlights are act-...
  • Page 99 Press button 1 (F2) to switch on the Cruising Light. The LED 360° marker strobe and the LED flashing beacons are dimmed. Switching off Cruising Light with cruising light Requirement Press bottom section of but- Ignition is switched on. ton 1 to switch on the LED auxiliary headlights.
  • Page 100 OPERATION The low-beam headlight and the front side lights are WARNING switched off. Switching on the daytime In the dark or in tunnels: riding light in the dark. Press button 1 again to Risk of accident switch off the daytime riding Do not use the daytime rid- light and switch on the low- ing light in the dark.
  • Page 101 response of the automatic The changeover between daytime riding light to the daytime riding light and change in ambient brightness low-beam headlight includ- is delayed). ing front side lights can be ef- If you press the button again fected automatically. the daytime riding light is Navigate to Settings...

  • Page 102: Light Signals

    OPERATION ard warning flashers for longer than absolutely necessary. Push button 1 to the left or right, as appropriate, to switch on the turn indicators. Press button 1 to switch on The comfort turn indicators the hazard warning lights sys- are cancelled automatically tem.
  • Page 103 BMW Motorrad LED marker strobes for a lim- retailer. ited time period only. See "Technical data" for details Press the top section of but- of the special functions. ton 1 to switch on the front See the notes on using the LED flashing beacons.
  • Page 104 OPERATION an authorised BMW Motorrad retailer. See "Technical data" for details of the special functions. The high-beam headlight and the auxiliary headlights light up alternately together with the LED flashing beacon. If ambient brightness drops Long-press the bottom sec- below a certain threshold...
  • Page 105 To have the coding changed consult a WARNING specialist workshop, preferably Riding with the 360° marker an authorised BMW Motorrad strobe extended. retailer. Risk of accident See "Technical data" for details Do not ride the motorcycle of the special functions.
  • Page 106 Germany only and can be used only when the Your authorised marker strobe is switched off. BMW Motorrad retailer can encode the displayed text. Press button 1 again to switch off the stop signal. Meaning of the indicator light:...
  • Page 107 BMW Motorrad re- tailer. The following stop signals are encoded in the factory settings: Signal 1, front: STOP POLICE Signal 2, front: ATTENTION Signal 1, rear: PLEASE FOL- Press button 1 at top to Signal 2, rear: switch on rear signal 1.

  • Page 108: Sound Signals

    OPERATION SOUND SIGNALS WARNING Hailing system with hailing system, elec- Insufficient visibility for tronic other road users Risk of accident Exercise caution when using the "lights off" function. Comply with the statutory regulations. Operate switch 1 at top to switch the warning and com- mand system to stand-by mode.
  • Page 109 Operate switch 1 at bottom can be encoded by your au- to switch the emergency thorised BMW Motorrad re- power siren "wail" to tailer. continuous operation. See "Technical data" for details With the siren active, oper-...

  • Page 110: Authority-Vehicle Speedometer

    OPERATION siren "hold & peak" with the Voice announcements can horn button 2. now be made. Operate switch 3 at bottom Adjust volume using the po- to operate the emergency tentiometer 4. Turn the po- power siren "airhorn" with tentiometer while making the horn button 2.

  • Page 111: Traction Control (Dtc)

    TRACTION CONTROL (DTC) Minimum speed for the activation of the author- Switching off DTC ities speed indicator Switch on the ignition. You have the option of min 5 km/h deactivating Dynamic Hold down the right side of Traction Control (DTC) while the 1 button to save the ac- the motorcycle is on the move.

  • Page 112: Electronic Suspension Adjustment (D-Esa)

    OPERATION The DTC function is switched A DTC fault has oc- off. curred if the DTC in- Switch on DTC dicator light shows when the motorcycle accelerates to a speed in excess of the min- imum stated below after the ignition was switched off and then on again.
  • Page 113 Viewing suspension settings Short-press button 1 to view Switch on the ignition. the current setting. To adjust damping: Short-press button 1 to view Repeatedly short-press but- the current setting. ton 1 until the setting you want to use is displayed. You can adjust the damp- ing characteristic while the motorcycle is on the move.
  • Page 114 OPERATION : Damping for One-up with luggage Dynamic dynamic on-road riding : Damping for off- Enduro Two-up (with luggage) road riding. Available only in riding mode and ENDURO The following message is not adjustable in this riding displayed if it is not possible mode.

  • Page 115: Riding Mode

    Riding-mode preselection RIDING MODE with riding modes Pro Using riding modes Riding mode preselection is BMW Motorrad has developed a function for shortlisting the operational scenarios for your rider's subset of preferred rid- motorcycle from which you can ing modes.
  • Page 116 OPERATION even after the ignition is switched off. Select the riding mode Switch on the ignition. ATTENTION Activation of the off-road mode (ENDURO) when rid- ing on-road Risk of crash due to lack of Press button 1. stability when the vehicle brakes in the control range of ABS or accelerates in that of DTC.
  • Page 117 Adaptive cruise control deac- The intervention of riding tivated. dynamics control systems The selected riding mode can be restricted, depending on is retained with the engine- which riding mode is selected characteristic, ABS, DTC and and how the selected mode is Dynamic ESA adaptation set- configured.

  • Page 118: Cruise Control

    OPERATION Dynamic ESA adaptation set- Display when adjusting tings even after the ignition settings (Speed Limit Info has been switched off. active) CRUISE CONTROL with cruise control Display when adjusting settings (Speed Limit Info not active) Symbol 1 for cruise control is displayed in the Pure Ride view and in the top status line.
  • Page 119 Setting road speed Push button 1 forward and hold it in this position. The vehicle accelerates smoothly. The current speed is main- tained and saved if button 1 is not pushed again. Decelerating Short-push button 1 forward. Adjustment range for cruise control (gear-de- pendent) 15...190 km/h...

  • Page 120: Anti-Theft Alarm (Dwa)

    OPERATION Indicator light for adaptive Switching off cruise control cruise control goes out. Resuming former cruising speed Slide switch 2 to the left. The system is deactivated. Button 1 is disabled. Short-push button 1 back to ANTI-THEFT ALARM (DWA) return to the speed saved be- with anti-theft alarm (DWA) forehand.
  • Page 121 ated key again during the ac- with Keyless Ride tivation phase. Turn indicators flash three times. Confirmation tone sounds three times (if programmed). Tilt sensor is deactivated. Alarm signal A DWA alarm can be triggered Switch off the ignition. Motion sensor Press button 1 on the radio- Switch-on attempt with an operated key twice.
  • Page 122 The on with unauthorised vehicle type of acoustic alarm tone can be set by an authorised Flashes 4x: Disconnection of BMW Motorrad retailer. the anti-theft alarm from the with Keyless Ride vehicle's battery Flashes 5x: Motion sensor 3 Deactivation Switch on the ignition.

  • Page 123: Tyre Pressure Monitoring (Rdc)

    30 seconds if When the vehicle is go- Arm automat- is switched on. ing to be transported, de- ically activate the tilt sensor to pre- Turn indicators flash once. Confirmation tone sounds vent the anti-theft alarm (DWA) once (if programmed). from being triggered.

  • Page 124: Heated Grips

    OPERATION Navigate to pears in front of heated grip Settings symbol 3. Vehicle settings Switch The handlebar grips can be Target pressure on or off. heated to three levels. High warn. heating power is for heating HEATED GRIPS the grips quickly: it is advisable Operating heated handlebar to switch back to a lower heat- grips...
  • Page 125 Installing rider's seat Turn ignition key 1 clockwise. Front seat is unlocked. Push rider’s seat 1 in direction of arrow 3 into holders 2. Press rider’s seat firmly in dir- ection of arrow 4. The rider’s seat engages with an audible click. Removing passenger seat Requirement Place the motorcycle on its...
  • Page 126 OPERATION Remove passenger seat 1 in direction of arrow 5. Place the seat, upholstered side down, on a clean surface. Installing passenger seat Install passenger seat 1 in holders 2. Push passenger seat 1 in dir- ection of arrow 3 into hold- ers 2.
  • Page 128 ADJUSTMENT...
  • Page 129 MIRRORS HEADLIGHT WINDSCREEN CLUTCH BRAKES SPRING PRELOAD DAMPING...

  • Page 130: Mirrors

    Have the headlights adjusted to the prevailing conditions by a specialist workshop, preferably an authorised BMW Motorrad Retailer. Headlight beam throw and Push protective cap 1 over spring preload the threaded fastener of the...

  • Page 131: Windscreen

    If there are doubts about the correct headlight beam throw, have the setting checked by a specialist work- shop, preferably an authorised BMW Motorrad retailer. Adjusting headlight beam throw WARNING Adjusting the windscreen while riding Risk of falling...

  • Page 132: Brakes

    ADJUSTMENT WARNING Adjusting the handbrake lever while riding Risk of accident Do not attempt to adjust the handbrake lever unless the vehicle is at a standstill. Turn adjusting screw 1 clock- wise to increase the span between the clutch lever and the handlebar grip.

  • Page 133: Spring Preload

    SPRING PRELOAD without Dynamic ESA Adjustment It is essential to set spring pre- load of the rear suspension to suit the load carried by the motorcycle. Increase spring preload when the motorcycle is heavily loaded and reduce WARNING spring preload accordingly when the motorcycle is lightly Spring preload setting and loaded.

  • Page 134: Damping

    ADJUSTMENT Adjusting damping for rear Basic setting of spring wheel preload, rear Make sure the ground is level Turn the adjuster knob and firm and place the motor- counter-clockwise as far as cycle on its stand. it will go, then back it off 20 turns in the clockwise direction.
  • Page 135 Basic setting of rear- suspension damping characteristic Turn the adjusting screw as far as it will go clockwise, then back it off 1.5 turns. (One-up without luggage) Turn the adjusting screw as far as it will go clockwise, then back it off 0.5 turns. (One-up with luggage) Turn the adjusting screw as far as it will go clockwise,...
  • Page 136 RIDING...
  • Page 137 SAFETY INFORMATION REGULAR CHECK STARTING RUNNING IN SHIFTING GEAR OFF-ROAD USE BRAKES PARKING YOUR MOTORCYCLE REFUELLING SECURING MOTORCYCLE FOR TRANSPORTATION...

  • Page 138: Safety Information

    This applies even to short tion entitled "Technical data"). journeys, and to every season of the year. Your authorised WARNING BMW Motorrad retailer will be happy to advise you on When a motorcycle with the correct clothing for every lowered suspension is cor- purpose.
  • Page 139 also the section entitled Lowering the motorcycle's "Accessories" ( 221). suspension shortens spring travel. Ride comfort might be Payload per case restricted as a result. Be sure to adjust spring preload ac- max 8 kg cordingly, particularly for riding two-up. Maximum permissible speed for riding with Loading correctly...
  • Page 140 RIDING Maximum speed with knobbly Maximum speed for rid- tyres or winter tyres ing with a loaded tank DANGER max 130 km/h Top speed of the motorcycle with rear softbag higher than the permissible Note the maximum payload of tyre maximum speed the rear softbag.
  • Page 141 WARNING WARNING Exhaust gases adversely af- Opening radiator cap fecting health Risk of burning Do not open the radiator Risk of asphyxiation Do not inhale exhaust cap when the system is hot. Check and, if necessary, top fumes. Do not run the engine in an up the coolant in the expan- enclosed space.

  • Page 142: Regular Check

    RIDING When load status changes: Risk of overheating without Dynamic ESA Adjust the spring preload for ATTENTION the rear wheel. ( 127) Engine running for pro- Adjust the damping for the longed period with vehicle rear wheel. ( 128) at standstill with Dynamic ESA Overheating due to insuf- Adjust the suspension.

  • Page 143: Starting

    Lubricate the chain. ( 197) Check the chain tension. 198) STARTING Starting engine ATTENTION Sufficient gearbox lubrica- Press starter button 1. tion only with the engine is The start attempt is auto- running. matically interrupted if Gearbox damage battery voltage is too low. Re- Do not allow the motorcycle charge the battery before you to roll for a lengthy period...
  • Page 144 Have the fault rectified as and how the selected mode is quickly as possible by a spe- configured. cialist workshop, preferably an Possible restrictions are indic- authorised BMW Motorrad re- ated by a pop-up message, tailer. for example Warning! ABS ABS self-diagnosis &...
  • Page 145 (The motorcycle has to reach cialist workshop, preferably an a defined minimum speed authorised BMW Motorrad re- with the engine running for tailer. the wheel-speed sensors to DTC self-diagnosis be checked: min 5 km/h)

  • Page 146: Running In

    RIDING Brake pads RUNNING IN New brake pads have to be run Engine in before they can achieve their Until the running-in check, optimum frictional force. You vary the throttle opening can compensate for this initial and engine-speed range reduction in braking efficiency frequently;...

  • Page 147: Shifting Gear

    For safety reasons, cruise load-change reaction. control is automatically BMW Motorrad recommends deactivated when Gear Shift disengaging the clutch for Assistant Pro downshifts. shifts in these circumstances. Cruise control remains active It is advisable to avoid using during upshifts.

  • Page 148: Off-Road Use

    RIDING OFF-ROAD USE ATTENTION After off-roading BMW Motorrad recommends Riding on unsurfaced or checking the following after dirty roads off-roading: Increased brake pad wear Check the thickness of the Tyre pressure brake pads more frequently and replace the brake pads WARNING in good time.

  • Page 149: Brakes

    Un- nature. der these circumstances the front wheel can lock up. BRAKES BMW Motorrad ABS prevents How can stopping distance be the front wheel from locking minimised? Each time the brakes are ap- plied, a load distribution shift...
  • Page 150 RIDING ate and vehicle speed reaches Wetness and dirt on the brake 20 km/h. discs and the brake pads di- minish braking efficiency. Descending mountain passes Delayed braking action or poor braking efficiency must be WARNING reckoned with in the follow- Braking mostly with the rear ing situations: Riding in the rain or through...

  • Page 151: Parking Your Motorcycle

    Possibility of a fall not PARKING YOUR precluded MOTORCYCLE Although ABS Pro provides the Side stand rider with valuable assistance Switch off the engine. and constitutes a huge advance in safety for braking with the ATTENTION motorcycle banked for corner- ing, it cannot under any circum- Poor ground underneath the stances be considered as re-...

  • Page 152: Refuelling

    More Do not lean or sit on the information is available from vehicle with the centre stand your authorised BMW Motorrad extended. retailer. Extend the centre stand and Recommended fuel lift the motorcycle on to the grade stand.
  • Page 153 Alternative fuel grade ATTENTION Wetting of plastic surfaces Regular unleaded by fuel (power- and consump- Damage to the surfaces (sur- tion-related restrictions.) faces become unsightly or (max 15 % ethanol, dull) E10/E15) Clean plastic surfaces im- 91 ROZ/RON mediately after contact with 87 AKI fuel.
  • Page 154 RIDING Remove the ignition key and close the protective cap. Refuelling with Keyless Ride Requirement The steering lock is disen- gaged. Do not fill the tank past the WARNING bottom edge of the filler neck. Fuel is highly flammable When refuelling after run- Risk of fire and explosion ning on reserve, make Do not smoke.
  • Page 155 Make sure the ground is level and firm and place the motor- cycle on its side stand. with centre stand Make sure the ground is level and firm and place the motor- cycle on its centre stand. with Keyless Ride Switch off the ignition.
  • Page 156 BMW Motorrad re- The "usable fuel capacity" tailer. specified in the technical data is the quantity that the...

  • Page 157: Securing Motorcycle For Transportation

    Close the fuel filler cap emer- gency release. ( 151) Closing fuel filler cap emergency release with Keyless Ride Requirement Fuel filler cap is in closed posi- tion. ATTENTION Vehicle topples to side when being lifted on to stand Risk of damage to parts if vehicle topples Secure the vehicle to pre- vent it toppling, preferably...
  • Page 158 RIDING compressed as tightly as possible front and rear. ATTENTION Trapping of components Component damage Do not trap components such as brake lines or cable legs. At the front, secure the straps to the bottom fork bridge on both sides and tighten the straps.
  • Page 160 ENGINEERING DETAILS...
  • Page 161 GENERAL NOTES ANTILOCK BRAKE SYSTEM (ABS) TRACTION CONTROL (DTC) DYNAMIC ENGINE BRAKE CONTROL DYNAMIC ESA RIDING MODE DYNAMIC BRAKE CONTROL TYRE PRESSURE CONTROL (RDC) GEAR SHIFT ASSISTANT ENGINE RUN-ON CIRCUIT...

  • Page 162: General Notes

    At this ficients of friction than a clean, instant the BMW Motorrad ABS dry asphalt surface. The lower must assume an extremely the coefficient of friction, the low coefficient of friction longer the stopping distance.
  • Page 163 BMW Motorrad ABS can sible that the BMW Motorrad ensure directional stability on any surface. Limitations ABS will be unable to prevent inherent to the design principle...
  • Page 164 Take care when cornering! When you apply the brakes on a corner, the vehicle's weight and momentum take over and even BMW Motorrad ABS is unable to counteract their ef- fects.

  • Page 165: Traction Control (Dtc)

    Evolution of ABS to ABS Pro more uniform across the range Until now, BMW Motorrad ABS of ABS intervention. has helped ensure a very high degree of safety for braking Advantages for the rider with the motorcycle upright The advantages of ABS Pro for and travelling in a straight line.
  • Page 166 The BMW Motorrad DTC dummy value is used for the can be deactivated in these bank angle or the DTC function cases.

  • Page 167: Dynamic Engine Brake Control

    Sharp braking during sporty slightly when lifting the front riding. wheel in order to reach a stable driving condition again as soon In the same way as as possible. BMW Motorrad DTC dynamic traction control, dynamic engine brake control compares the wheel circumferential...

  • Page 168: Dynamic Esa

    ENGINEERING DETAILS velocities of the front and rear Dynamic ESA function wheels calculated from the Dynamic ESA uses a ride height wheel speeds and the tyre sensor to detect movements in radius. Dynamic engine brake the suspension and responds control uses this differential to by adjusting the damper valve.
  • Page 169 with riding modes Pro off detection is reduced to with Pro riding modes achieve an enhanced braking DYNAMIC effect. ENDURO In RAIN, ROAD and DYNAMIC riding modes, the ABS is set For each of these riding modes, up for on-road riding. there is a matching setting In ENDURO riding mode, the for the ABS, DTC systems, for...

  • Page 170: Dynamic Brake Control

    ENGINEERING DETAILS In ENDURO riding mode, DTC How Dynamic Brake Control is set up for off-road riding works with road tyres. The Dynamic Brake Control function assists the rider in Driving stability emergency braking situations. In RAIN riding mode, DTC in- Detection of emergency tervenes early to maximise braking...

  • Page 171: Tyre Pressure Control (Rdc)

    If emergency braking ceases for some time after the vehicle and the rider still has not comes to a stop. changed the position of the Time for transmission of throttle grip, Dynamic Brake measured values after Control steadily ramps engine vehicle comes to a stop: torque back to the rider's min 15 min...

  • Page 172: Gear Shift Assistant

    ENGINEERING DETAILS The tyre pressures are Example shown in the display as temperature compensated The following value is shown and always refer to the fol- in the display: lowing tyre air temperature: 2.3 bar 20 °C So pressure is low by: The air lines available to the 0.2 bar public in petrol stations and...
  • Page 173 because the shift pauses are A change in the position of shorter. the throttle twistgrip during It is not necessary to close the a gearshift can cause the throttle valve when shifting function to abort and/or lead under acceleration. to a missed shift. Gear Shift When braking and downshift- Assistant Pro provides no ing (throttle valve closed),...

  • Page 174: Engine Run-On Circuit

    ENGINEERING DETAILS ENGINE RUN-ON CIRCUIT with Keyless Ride Engine run-on circuit function The vehicle is secured against misuse when the engine is run- ning with the help of the en- gine run-on circuit. This allows the rider to step away from the vehicle when the battery is be- ing charged and consumers (e.g.
  • Page 176 MAINTENANCE...
  • Page 177 GENERAL NOTES TOOLKIT FRONT-WHEEL STAND REAR-WHEEL STAND ENGINE OIL BRAKE SYSTEM CLUTCH COOLANT TYRES RIMS AND TYRES WHEELS CHAIN AIR FILTER LIGHTING TRIM PANEL COMPONENTS JUMP-STARTING BATTERY FUSES DIAGNOSTIC CONNECTOR...

  • Page 178: General Notes

    If in doubt consult a Non-reusable cable ties specialist workshop, preferably Non-reusable cable ties are an authorised BMW Motorrad used at some points to secure retailer. cables and lines. To prevent damage to cables and lines...

  • Page 179: Toolkit

    TOOLKIT FRONT-WHEEL STAND Installing front-wheel stand ATTENTION Use of the BMW Motorrad front-wheel stand without also using the auxiliary stand Risk of damage to parts if vehicle topples Screwdriver handle Place the motorcycle on an Reversible screwdriver auxiliary stand before lift-...

  • Page 180: Rear-Wheel Stand

    (the procedure for installation. higher the temperature, the BMW Motorrad offers an aux- higher the oil level) iliary stand suitable for every Engine damage due to incor- vehicle. Your BMW Motorrad...
  • Page 181 Seat the oil dipstick on the oil operating temperature and filler neck, but do not engage hold the motorcycle upright. the threads. Turn the dip- BMW Motorrad recommends stick one full turn backward using a suitable auxiliary to make the oil level easier to stand.

  • Page 182: Brake System

    Have the oil level corrected by a specialist workshop, Use of insufficient engine oil preferably an authorised or too much engine oil BMW Motorrad retailer. Engine damage due to incor- rect oil filling Install the oil dipstick. Always make sure that the To avoid unnecessary engine oil level is correct.
  • Page 183 1.0 mm (Friction pad by a specialist workshop, only, without backing plate. preferably an authorised The wear indicators, i.e. the BMW Motorrad retailer. grooves, must be clearly vis- ible.) Checking brake pad thickness, front brakes If the wear indicating marks are...
  • Page 184 MAINTENANCE Have the brake pads replaced by a specialist workshop, preferably an authorised BMW Motorrad retailer. Checking brake pad thickness, rear brakes Make sure the ground is level and firm and place the motor- cycle on its stand. Brake-pad wear limit, rear min 1.0 mm (Friction pad...
  • Page 185 Checking brake-fluid level, Move the handlebars to the front brakes straight-ahead position. WARNING Not enough brake fluid in brake fluid reservoir, or con- taminants in brake fluid Considerably reduced braking power due to presence of air, contaminants or water in the brake system Check the brake fluid level in Cease operation of the...
  • Page 186 Have the fault rectified as cycle on its centre stand. quickly as possible by a spe- cialist workshop, preferably an authorised BMW Motorrad re- tailer. Checking brake-fluid level, rear brakes WARNING Not enough brake fluid in...

  • Page 187: Clutch

    If the brake fluid level drops below the permitted level: Have the fault rectified as quickly as possible by a spe- cialist workshop, preferably an authorised BMW Motorrad re- tailer. CLUTCH Checking operation of the Repeatedly pull clutch lever 1 clutch tight against the grip.

  • Page 188: Coolant

    (measured at the inside) must be no more than 8 ±1.5 Consult a specialist workshop, preferably an authorised BMW Motorrad retailer, if the distance has to be exceeded in order to obtain the correct Check the coolant level in ex- clutch play.
  • Page 189 If the coolant drops below the permitted level: Top up the coolant. Topping up coolant WARNING Opening radiator cap Risk of burning Pull radiator cowl 1 out of Do not open the radiator holders 2. cap when the system is hot. Check and, if necessary, top up the coolant in the expan- sion tank only.

  • Page 190: Tyres

    MAINTENANCE TYRES Check the tyre pressures WARNING Incorrect tyre pressure Impaired handling charac- teristics of the motorcycle, shorter useful tyre life Press radiator cowl 1 into Always check that the tyre holders 2. pressures are correct. The radiator cowl engages with an audible click.

  • Page 191: Rims And Tyres

    Tyre recommendation Make sure the ground is level For each size of tyre, and firm and place the motor- BMW Motorrad tests and cycle on its stand. classifies as roadworthy certain Measure the tyre tread depth makes. BMW Motorrad cannot...
  • Page 192 Remove screw 3 and remove beforehand, preferably an the wheel speed sensor from authorised BMW Motorrad its bore. retailer. In some cases, the data programmed into the control units can be changed to...
  • Page 193 ATTENTION Use of hard or sharp-edged objects in proximity to com- ponent Component damage Take care not to scratch components; cover or mask as necessary. Disengage the cable for the wheel speed sensor from Mask off the parts of the holding clip 4 and holder 5.
  • Page 194 Raise front of motorcycle un- til the front wheel can turn freely. BMW Motorrad recom- mends the BMW Motorrad front-wheel stand for lifting Remove axle 13, while sup- the motorcycle.
  • Page 195 Damage, or threaded fasten- front suspension. ers work loose Always have the security of the fasteners checked by a specialist workshop, preferably an authorised BMW Motorrad dealer. Lubricate the quick-release axle 11. Lubricant Unirex N3 Lubricate the running surface of spacer bush 12.
  • Page 196 MAINTENANCE forks several times. Do not operate the handbrake lever WARNING in this process. Improper installation of the Install the front-wheel stand. quick-release axle 173) Loosening of the front wheel Tighten left axle clamping After securing the brake cal- screws 9 to the specified ipers and relieving the front torque.
  • Page 197 Tighten right axle clamping Install securing screws 6 with screws 10 to the specified holder 5 of the left brake cal- tightening torque. iper and tighten to the spe- cified torque. Brake caliper to tele- scopic fork M10 x 45 38 Nm Tighten securing screws 6 of the right brake caliper to the...
  • Page 198 MAINTENANCE Wheel-speed sensor, WARNING front, to fork leg Brake pads not lying against 8 Nm the brake disc Risk of accident due to delayed braking effect. Before driving, check that the brakes respond without delay. Operate the brake several times until the brake pads are bedded.
  • Page 199 Removing rear wheel ATTENTION Unwanted inward movement of the brake pads Component damage on at- tempt to install the brake cal- iper or because brake pads have to be forced apart Press the brake caliper 1 Do not operate the brakes against the brake disc 2.
  • Page 200 MAINTENANCE Back off adjusting screws 7 on both sides. Remove chain tensioner 6 and push the axle in as far as it will go. Roll the rear wheel to the rear and clear of the swinging arm and at the same time pull brake-caliper carrier 10 back far enough to allow the rear wheel to clear it.
  • Page 201 Roll the rear wheel farther by a specialist workshop, into the swinging arm, while preferably an authorised pushing brake-caliper car- BMW Motorrad dealer. rier 1 forward at the same time. The chain sprocket and the spacer bushes on left and right are loose fits in the wheel.
  • Page 202 MAINTENANCE Insert right chain tensioner 6 Clean thread for screw 1. Insert the wheel speed sensor into the swinging arm. Lubricate quick-release axle 5 into the bore and tighten and install it in brake caliper new screw 1 to the specified mounting bracket 4 and rear torque.

  • Page 203: Chain

    BMW Motorrad chain a suitable cleaning product, lubricant, or: dry it and apply chain lub- Lubricant ricant. To prolong chain life, BMW Motorrad recommends Chain spray, O-ring compat- the use of BMW Motorrad ible chain lubricant or: Wipe off excess lubricant.
  • Page 204 MAINTENANCE Lubricant Chain deflection Chain spray, O-ring compat- 35...45 mm (Motorcycle with ible no weight applied, supported Wipe off excess lubricant. on its side stand) If measured value is outside Check the chain tension permitted tolerance: Make sure the ground is level Adjust the chain tension.
  • Page 205 144 mm (measured from the centre of 10 rivets, chain pulled taut) If the chain has stretched to the maximum permissible length: Consult a specialist work- shop, preferably an authorised BMW Motorrad retailer. Check whether third marker line 1 is fully visible.

  • Page 206: Air Filter

    Chain riveting is OK. If one or more rivet heads have twisted out of line: Consult a specialist work- shop, preferably an authorised BMW Motorrad retailer. AIR FILTER Remove the air filter Remove frame 4. Remove the tank cover. Remove air filter insert 5.
  • Page 207 Install air filter 5 in frame 4. Clip hose 1 into retaining lugs 2. with Keyless Ride Make sure that air filter 5 is correctly seated on lugs 6 of Make sure that cable 7 is not frame 4. trapped. Install frame 4.

  • Page 208: Lighting

    Remove screws 2. portunity. Consult a special- Remove tank cover 3, noting ist workshop, preferably an the mounting clips and retain- authorised BMW Motorrad ing lugs. Retailer. Install the tank cover All light sources of the vehicle are LED light sources. The...

  • Page 209: Jump-Starting

    ATTENTION Excessive current flowing when the motorcycle is jump-started Wiring smoulders/ignites or damage to the on-board elec- tronics If the motorcycle has to be Install screws 2. jump-started connect the Install screws 1. Install the rider's seat. leads to the battery termin- 119) als;...

  • Page 210: Battery

    MAINTENANCE ative to the battery's negative Remove the front seat. terminal. 118) When jump-starting the en- Run the engine of the donor gine, do not disconnect the vehicle during jump-starting. battery from the on-board Start the engine of the vehicle electrical system.
  • Page 211 For Keep the surface of the bat- more information, consult an tery clean and dry. Do not open the battery. authorised BMW Motorrad re- Do not top up with water. tailer. Be sure to read and comply with auxiliary battery...
  • Page 212 The suitable charger is avail- If you are unable to able from your authorised charge the battery BMW Motorrad dealer. through the on-board socket, you may be using a charger ATTENTION that is not compatible with your motorcycle's electronics.
  • Page 213 recharge the battery before Then disconnect positive bat- restoring it to use. tery cable 2. Remove screws 4 and work Removing battery battery holder 5 forward until Make sure the ground is level it is clear of the battery. and firm and place the motor- Lift the battery up and out;...
  • Page 214 MAINTENANCE Press in the lock and flip open Wiring harness to bat- positive terminal cover 1. tery M6 x 13.5 ATTENTION 5 Nm Battery not connected in ac- with anti-theft alarm (DWA) cordance with correct pro- If applicable, switch on the cedure anti-theft alarm.
  • Page 215 with single seat with radio transceiver box Remove bolt 1 and loosen negative battery cable 2. Remove bolt 3 and loosen Raise two-way radio box 1 positive battery cable 4. and secure it in the raised po- Remove auxiliary battery 5. sition by inserting a suitable Pull off hook-and-loop tape 6.

  • Page 216: Fuses

    MAINTENANCE with single seat with radio with single seat with radio transceiver box transceiver box Mount battery cover 3. Install screws 1. Install screws 2. Close the two-way radio box. Place on radio transceiver 223) box 1. with anti-theft alarm (DWA) without single seat with radio If applicable, switch on the transceiver box...
  • Page 217 Jumpering of blown fuses workshop, preferably an au- Risk of short-circuit and fire thorised BMW Motorrad re- Never attempt to jumper a tailer. blown fuse. Always replace a defective Main fuse fuse with a new fuse of the same amperage.

  • Page 218: Diagnostic Connector

    10 A (Slot 1: instrument it to be disconnected cluster, alarm system (DWA), except in the course of a ignition lock, diagnostic BMW Motorrad service by socket, coil main relay) a specialist workshop or by other authorised persons. 7.5 A (Slot 2: multifunction...
  • Page 219 Disengage diagnostic socket 2 from holder 3. The interface to the diagnosis and information system can be connected to the diagnostic connector 2. Securing diagnostic socket Disconnect the interface for the diagnosis and information system. Insert diagnostic socket 2 into holder 3.
  • Page 220 ACCESSORIES...
  • Page 221 GENERAL NOTES POWER SOCKETS USB CHARGING SOCKET CASES CASE FOR SPECIAL VEHICLE FIRE EXTINGUISHER TWO-WAY RADIO BOX TOPCASE NAVIGATION SYSTEM...

  • Page 222: General Notes

    Use of other-make products tion and use regulations applic- Safety risk able in your country. BMW Motorrad cannot ex- Your authorised amine or test each product BMW Motorrad retailer of outside origin to ensure can offer expert advice on the...

  • Page 223: Usb Charging Socket

    Operating electrical Automatic shutdown accessories The USB charging sockets are You can start using electrical shut down automatically under accessories connected to the the following circumstances: If battery charge state is too sockets only when the ignition low, to maintain the motor- is switched on.

  • Page 224: Cases

    ACCESSORIES Cable routing Note the following with regard to the routing of cables from USB charging sockets to items of electronic equipment: Make sure that cables do not impede the rider. Make sure that cables do not restrict the steering angle or Push yellow button 1 down, obstruct handling.
  • Page 225 Capacity, left case 25...35 l Capacity, right case 15...23 l Closing cases with case ATTENTION Turn the lock with the key un- til it is at right angles to the Closure of carrying handle forward direction of travel. with case lock latched Close the case lid.
  • Page 226 ACCESSORIES Press and hold down yel- low latch 2 and pull out carry handle 3. Insert case into brackets 1 and 2 from above. Pull red release lever 1 up. Latching flap 2 pops up. Fully open the latching flap. Take a firm grip of the carry handle and lift the case out of the holder.

  • Page 227: Case For Special Vehicle

    Payload per case max 8 kg CASE FOR SPECIAL VEHICLE with painted case with holder for special vehicle Opening cases ATTENTION Closure of carrying handle with case lock latched Damage to locking tab Make sure that the case lock is at right angles to the forward direction of travel when you close the carry Open case lock 1 with igni-...

  • Page 228: Fire Extinguisher

    ACCESSORIES Installing fire extinguisher FIRE EXTINGUISHER with fire extinguisher with holder Removing fire extinguisher Requirement The fire extinguisher is inside the left case. The operating instructions for the fire extinguisher Hold the fire extinguisher by are printed on the fire extin- carry handle 1 and engage guisher.
  • Page 229 40 seconds for opening the two-way radio box after the ignition has been switched off. Your authorised BMW Motorrad retailer can change this run-on time to Move screwdriver 2 in open- any of various settings (0, 20, ing 1, to shift lever 3 (arrow).

  • Page 230: Topcase

    ACCESSORIES TOPCASE Opening topcase with topcase Engage lever 1 in the front limit position for the larger volume. Engage lever 1 in the rear Turn key 1 clockwise. limit position for the smaller Press and hold down yel- volume. low latch 2 and pull out carry Close the topcase.
  • Page 231 Press and hold down yel- low latch 2 and pull out carry handle 3. ATTENTION Closure of carrying handle Pull red lever 1 to the rear. with case lock latched Latching flap 2 pops up. Damage to locking tab Fully open the latching flap. Make sure that the topcase Take a firm grip of the handle lock is vertical when you...
  • Page 232 ACCESSORIES Engage the topcase in front holders 1 of the topcase car- ATTENTION rier plate. Closure of carrying handle Press the rear of the top- with case lock latched case on to the topcase carrier Damage to locking tab plate. Make sure that the topcase lock is vertical when you close the carry handle.

  • Page 233: Navigation System

    Insert navigation device 1 at Navigation prepara- bottom and pivot it toward tion is suitable from the rear. BMW Motorrad Navigator IV The navigation device en- onward. gages with an audible click. The latching system of Push lock retainer 2 all the the Mount Cradle is not way to the right.
  • Page 234 BMW Motorrad ConnectedRide Navigator. Only the latest version of Turn ignition key 1 counter- the BMW Motorrad com- clockwise. munication system is suppor- Pull lock retainer 2 all the way ted. A software update of the to the left.
  • Page 235 Security settings Always follow the safety instructions in the oper- ating instructions of the BMW Motorrad ConnectedRide Navigator. The navigation system is oper- ated using Multi-Controller 1 and MENU rocker button 2. Turning Multi-Controller 1 up/ down Select menu Change volume...
  • Page 236 CARE...
  • Page 237 CARE PRODUCTS WASHING THE VEHICLE CLEANING EASILY DAMAGED COMPONENTS CARE OF PAINTWORK PAINT PRESERVATION LAYING UP MOTORCYCLE RESTORING MOTORCYCLE TO USE...

  • Page 238: Care Products

    BMW Motorrad retailer. The BMW Motorrad recommends substances in BMW Care that you use BMW insect re- Products have been tested in mover to soften and wash off laboratories and in practice;...

  • Page 239: Cleaning Easily Damaged Components

    BMW Motorrad re- the vehicle. tailer. To prevent stains, do not wash CLEANING EASILY DAMAGED the vehicle immediately after COMPONENTS it has been exposed to strong Plastics sunlight and do not wash it in the sun.

  • Page 240: Care Of Paintwork

    BMW Care Products range. Treat rubber components with This is particularly important to water or BMW rubber-care counter the effects of salt. products. Use BMW Motorrad high-gloss polish for additional treatment. CARE OF PAINTWORK Radiator Clean the radiator regularly to ATTENTION...

  • Page 241: Paint Preservation

    For this, we recommend BMW Motorrad Fuel additives clean the solvent cleaner followed by fuel injection system and BMW Motorrad gloss polish for the combustion zone. It is ad- preservation. visable to use fuel additives Marks on the paintwork are...

  • Page 242: Restoring Motorcycle To Use

    CARE RESTORING MOTORCYCLE TO USE Remove the protective wax coating. Clean the motorcycle. Install the battery. Install the auxiliary battery. Checklist. ( 136)
  • Page 244 TECHNICAL DATA...
  • Page 245 TROUBLESHOOTING CHART THREADED FASTENERS FUEL ENGINE OIL ENGINE CLUTCH TRANSMISSION FINAL DRIVE FRAME CHASSIS AND SUSPENSION BRAKES WHEELS AND TYRES ELECTRICAL SYSTEM DIMENSIONS WEIGHTS PERFORMANCE FIGURES COUNTRY-SPECIFIC CODING FOR HAILING-SYSTEM SOUND SIGNALS FUNCTION-BUTTON ASSIGNMENT SPECIAL FUNCTIONS...

  • Page 246: Troubleshooting Chart

    TECHNICAL DATA TROUBLESHOOTING CHART Special functions or optional equipment for authorities not work- ing or available only while the vehicle is on the move. Possible cause Rectification Plug connection for auxiliary Insert bridge in isolating plug battery is disconnected. The engine does not start: Possible cause Rectification Side stand extended and gear...
  • Page 247 The Bluetooth connection is not established. Possible cause Rectification The steps required for pairing Check the necessary steps were not carried out. for pairing in the operating instructions for the communic- ation system. The communication system Switch off the helmet's com- was not connected automatic- munication system and recon- ally despite successful pairing.
  • Page 248 Active route guidance is not displayed in the TFT display. Possible cause Rectification Navigation from the The BMW Motorrad Connec- BMW Motorrad Connec- ted app is opened on the con- ted app was not transmitted. nected mobile device prior to departure.

  • Page 249: Threaded Fasteners

    THREADED FASTENERS Front wheel Value Valid Brake caliper to tele- scopic fork M10 x 45 38 Nm Clamp of quick-re- lease axle M8 x 35 Tightening sequence: Tighten screws six times in alternate se- quence 19 Nm Axle screw in front quick-release axle M20 x 1.5 50 Nm...

  • Page 250: Fuel

    Engine oil, capacity approx. 3.0 l, with filter change Specification SAE 5W-40, API SL / JASO MA2, Additives (e.g. molybdenum-based) are not permissible because they can attack coated components of the engine, BMW Motorrad recommends BMW Motorrad ADVANTEC Ultimate oil. BMW recommends...

  • Page 251: Engine

    Please do not hesit- ate to contact your authorised BMW Motorrad retailer if you have any questions relating the choice of a suitable engine oil for your motorcycle.

  • Page 252: Clutch

    TECHNICAL DATA Torque 91 Nm, at rpm: 6750 min with power reduction to 70 Nm, at rpm: 4500 min 35 kW Maximum engine speed max 9250 min Idle speed 1250 ±50 , Engine at reg- ular operating temperature CLUTCH Clutch type Multiplate oil-bath clutch (anti- hopping) TRANSMISSION...

  • Page 253: Frame

    FRAME Frame type Bridge-type steel frame in shell construction Type plate location Frame, front left at steering head Position of the vehicle identi- Frame, front right by steering fication number head CHASSIS AND SUSPENSION Front wheel Type of front suspension Telescopic forks Spring travel, front 170 mm, at front wheel...

  • Page 254: Brakes

    WHEELS AND TYRES Recommended tyre combina- Your authorised tions BMW Motorrad retailer will be happy to supply an up- to-date list of the approved wheel/tyre combinations. Speed category, front/rear V, required at least: 240 km/h...

  • Page 255: Electrical System

    Front wheel Front-wheel type Aluminium cast wheel Front-wheel rim size 2.50" x 19" Tyre designation, front 110/80 R 19 Load index, front tyre min. 59 Permissible front-wheel imbal- max 5 g ance Rear wheel Rear-wheel type Aluminium cast wheel Rear wheel rim size 4.25"...
  • Page 256 TECHNICAL DATA Fuse box 10 A, Slot 1: instrument cluster, alarm system (DWA), ignition lock, diagnostic socket, coil main relay 7.5 A, Slot 2: multifunction switch left, tyre pressure con- trol (RDC) with single seat with radio 10 A, Slot 1: instrument transceiver box cluster, alarm system (DWA), ignition lock, diagnostic socket,...

  • Page 257: Dimensions

    Lighting All light sources DIMENSIONS Length of motorcycle 2296 mm, over topcase Height of motorcycle 1230 mm, without mirrors, at DIN unladen weight with windscreen, high 1428 mm, without mirrors, at DIN unladen weight Width of motorcycle 910 mm, without mounted parts Height of rider's seat mm, Without rider;...

  • Page 258: Performance Figures

    TECHNICAL DATA PERFORMANCE FIGURES Top speed 190 km/h with case 160 km/h with tank bag 130 km/h COUNTRY-SPECIFIC CODING FOR HAILING-SYSTEM SOUND SIGNALS Code 0 Germany DIN Code 1 France, police Code 2 France, gendarmerie Code 3 Netherlands, 2-tone Code 4 Italy, police Code 5 Austrian police...

  • Page 259: Function-Button Assignment

    F1 to F4, depending on equip- ment fitted and customer re- quest. Consult a specialist workshop, preferably an au- thorised BMW Motorrad re- tailer, to have changes made to the coding. Marker light + sound signal with radio preparation...

  • Page 260: Special Functions

    Depending on the equipment and customer request, the fol- lowing special functions can be encoded. To change the coding consult a specialist workshop, preferably an au- thorised BMW Motorrad re- tailer. Alternating frontal light Flash pattern Flash sequence Marker lights, circuits...
  • Page 262 SERVICE...
  • Page 263 REPORTING SAFETY-RELEVANT DEFECTS RECYCLING BMW MOTORRAD SERVICE BMW MOTORRAD SERVICE HISTORY BMW MOTORRAD MOBILITY SERVICES MAINTENANCE WORK MAINTENANCE SCHEDULE BMW MOTORRAD RUNNING-IN CHECK MAINTENANCE CONFIRMATIONS SERVICE CONFIRMATIONS...

  • Page 264: Reporting Safety-Relevant Defects

    SERVICE REPORTING SAFETY-RELEVANT DEFECTS with Canada export If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately in- form the NHTSA (National Highway Traffic Safety Administration) in addition to notifying the BMW of North America, LLC. If the NHTSA receives other, similar complaints, it may open an investigation.

  • Page 265: Recycling

    Information about recycling and sustainability BMW MOTORRAD SERVICE can be viewed on the country- BMW Motorrad has an specific websites of the extensive network of retailers manufacturer. Additional in place to look after you and...

  • Page 266: Bmw Motorrad Service History

    An authorised firmed in the "Service" chapter BMW Motorrad retailer or a in this manual. Evidence of specialist workshop can also regular preventive maintenance view data that is stored in the is essential for generous electronic service booklet.

  • Page 267: Bmw Motorrad Mobility Services

    500 km and 1200 km. the vehicle owner. In this in- BMW Motorrad Service stance, no entry is made in the The BMW Motorrad Service electronic service booklet of is carried out once a year; the the vehicle. extent of servicing can vary,...
  • Page 268 SERVICE The service-due indicator in the display reminds you about one month or 1000 km in advance when the time for a service is approaching. To find out more about service go to: bmw-motorrad.com/service The maintenance tasks neces- sary for your vehicle are set out in the maintenance sched- ule below.

  • Page 269: Maintenance Schedule

    MAINTENANCE SCHEDULE BMW Motorrad running- for the first time after one in check (including oil year, then every two years change and oil filter change) BMW Motorrad Service, standard scope Engine-oil change, with filter Check valve clearances Replace all spark plugs...

  • Page 270: Bmw Motorrad Running-In Check

    SERVICE BMW MOTORRAD RUNNING-IN CHECK BMW Motorrad running-in check The tasks included in the BMW Motorrad running-in check are listed below. The actual scope of work applicable for your vehicle may vary. Performing vehicle test with BMW Motorrad diagnostic system...

  • Page 271: Maintenance Confirmations

    MAINTENANCE CONFIRMATIONS BMW Motorrad Service standard scope The tasks included in the BMW Motorrad Service standard scope are listed below. The actual scope of maintenance work applic- able for your vehicle may vary. Performing vehicle test with BMW Motorrad diagnostic system...
  • Page 272 SERVICE BMW Motorrad pre- BMW Motorrad running-in delivery check check carried out carried out odometer reading Next service at the latest or, when reached earlier odometer reading Stamp, signature Stamp, signature...
  • Page 273 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 274 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 275 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 276 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 277 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 278 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 279 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 280 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 281 BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...
  • Page 282 SERVICE BMW Motorrad service carried out odometer reading Next service at the latest or, when reached earlier odometer reading Work performed BMW Motorrad service Engine oil change with filter Checking valve clearance Renewing all spark plugs Replacing the air filter element...

  • Page 283: Service Confirmations

    SERVICE CONFIRMATIONS The table is intended as a record of maintenance and repair work, the installation of optional accessories and, if appropriate, technical campaign work. Work performed odometer Date reading...
  • Page 284 SERVICE Work performed odometer Date reading...
  • Page 286 DECLARATION OF CONFORMITY RADIO EQUIPMENT TFT INSTRUMENT CLUSTER RADIO EQUIPMENT TYRE PRESSURE CONTROL (RDC) KEYLESS RIDE ECU KEYLESS RIDE KEY RADIO EQUIPMENT ELECTRONIC IMMOBILISER RADIO EQUIPMENT INTELLIGENT EMERGENCY CALL...

  • Page 287: Declaration Of Conformity

    DECLARATION OF CONFORMITY Manufacturer Bayerische Motoren Werke Aktiengesellschaft Petuelring 130, 80809 Munich, Germany Simplified EU Declaration of Conformity according to EU RED (2014/53/EU). Simplified UK Declaration of Conformity according to Radio Equipment Regulations 2017 of the United Kingdom. Hereby, BMW AG declares that the radio equipment components listed below are in compliance with Directive 2014/53/ EU and with Radio Equipment Regulations 2017 of the United Kingdom.
  • Page 288 APPENDIX Radio Compo- Frequency band Output/ equip- nent Transmis- ment sion Power Keyless allowed ZB001 134.5 kHz Ride 66 dBµA/ m @ 10m max. Keyless ZB002 433.92 MHz 10 dBm Ride e.r.p TXBM- 433.05 MHz - 434.79 MHz 18.8 dBm RDC3 433.92 MHz <...
  • Page 289 Radio Compo- Frequency band Output/ equip- nent Transmis- ment sion Power Peak max. 76 - 77 GHz Re14FCR 32 dBm Nom max. 27 dBm Front Peak max. ARS513 77 GHz radar 30 dBm Rear ra- Peak max. SRR521 77 GHz 30 dBm Intelli- TL1P22...
  • Page 290 APPENDIX Radio Compo- Frequency band Output/ equip- nent Transmis- ment sion Power Keyless ZB006 134.5 kHz < 10 mW 433.92 MHz Ride Ac- e.r.p. tive Key TFT In- 2400 MHz - 2483.5 MHz < 3 dBm LIN2BTLE strument Gateway Cluster...

  • Page 291: Radio Equipment Tft Instrument Cluster

    RADIO EQUIPMENT TFT IN- (1) this device may not cause STRUMENT CLUSTER interference, and (2) this device must accept any For all Countries without EU interference, including interfe- Model name: ICC6.5in rence that may cause undesired Manufacturer operation of the device. Robert Bosch GmbH Changes or modifications not Robert Bosch Str.

  • Page 292: Radio Equipment Tyre Pressure Control (Rdc)

    APPENDIX Technical information causar su operación no dese- ada. Frequency band: 433,92 MHz Maximum effective radiated Taiwan power: 16,75 dBm 根據 NCC 低功率電波輻射性電 機 管理辦法 規定: 第十二條 經 Country 型式認證合格之低功率射頻電 Argentina 機，非經許可，公司、商號或使 用 者均不得擅自變更頻率、加大 功率 或變更原設計之特性及功 能。 第十四條 低功率射頻電機之使用不得影響 飛 航安全及干擾合法通信；經發 現有...

  • Page 293: Keyless Ride Ecu

    Morocco KEYLESS RIDE ECU AGREE PAR L'ANRT MAROC For all Countries without EU Numéro d'agrément : Model name: HUF8485 MR 20577 ANRT 2019 Manufacturer Date d'agrément : Huf Hülsbeck & Fürst GmbH & 26/07/2019 Co. KG Singapore Steeger Str. 17, 42551 Vel- Complies with bert, Germany IMDA Standards...
  • Page 294 APPENDIX Pakistan (1) L’appareil ne doit pas pro- duire de brouillage; (2) L’utilisateur de l'appareil doit acceptor tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionne- ment. TAC NO: 9.122/2022 Indonesia Paraguay 81597/SDPPI/2022 13349 Malaysia 2022‑01‑I‑0052 Philippines HIDF17000037...

  • Page 295: Keyless Ride Key

    South Africa Technical information Frequenzy band: 433,92 MHz Output/Transmission Power: 10 mW Country Canada This device complies with TA‑2022/0251 part 15 of the FCC Rules APPROVES and Industry Canada licence- Sultanate of Oman exempt RSS standard(s). OMAN - TRA Operation is subject to the R/13020/22 following two conditions: D100428...
  • Page 296 APPENDIX Paraguay Indonesia 81598/SDPPI/2022 13349 Malaysia 2022‑01‑I‑0051 Philippines HIDF17000037 Morocco AGREE PAR L'ANRT MAROC Numéro d'agrément : Type Approved MR00031289ANRT2022 No. ESD‑RCE‑2228693 Date d'agrément : Serbia 06/01/2022 Nigeria Connection and use of this communications equipment is permitted by the Nigerian Communications Commission И005 22 Pakistan...

  • Page 297: Radio Equipment Electronic Immobiliser

    South Africa THACO AUTO C900248 RADIO EQUIPMENT ELEC- TRONIC IMMOBILISER For all countries without EU Model name: EWS 4 Manufacturer TA‑2022/0252 BECOM Electronics GmbH APPROVED Technikerstraße 1, A-7442 Sultanate of Oman Hochstraß, Austria OMAN ‑ TRA Technical information R/13021/22 D100428 Frequency Band: 134 kHz Transponder: TMS37145/Type Taiwan...
  • Page 298 APPENDIX Brunei India ETA‑SD‑20200905860 Israel ‫ד ר‬ ‫ש‬ ‫מ‬ ‫ל‬ ‫ש‬ ‫י ט‬ ‫ו ח‬ ‫ל א‬ ‫ר‬ ‫ו ש‬ ‫י א‬ ‫ר‬ ‫פ ס‬ ‫מ‬ ‫א‬ ‫ו ה‬ ‫ת ר‬ ‫ו ש‬ ‫ק ת‬ ‫ה‬ TA No: DTA‑007061 74908 ­...

  • Page 299: Radio Equipment Intelligent Emergency Call

    Philippines Taiwan Type Approved 低功 電波 射性電機管 辦法 第十 No.: ESD‑RCE‑2023298 二條 經型式認證合格之低 功率射 頻電 機，非經許可，公 司、商號 Serbia 或使用者均不得擅 自變 更頻率、 加大功率或變更原設計 之特性及 功能。第十四條 低功 率射頻電 機之使用不 得影響飛航 安全及干 擾合法通信；經發現有 干 擾現象 時，應立即停用，並改 善至無干 P1620118300 擾時方 得繼續使用。 前 項合法 Singapore 通信，指依電信法規定作...
  • Page 300 APPENDIX Model name: TL1P22 onnements d’Industrie Canada Manufacturer pour un environment non con- trôlé. Il doit être installé de LG ELECTRONICS INC. façon à garder une distance 10, Magokjungang 10-ro, minimale de 3.5 centimétres Gangseo-gu Seoul, Republic of entre la source de rayonne- Korea ments et votre corps.
  • Page 302 INDEX 360° marker strobe, 98 Care Care products, 232 Chrome, 234 Abbreviations and symbols, 4 Paintwork preservation, 235 Washing the vehicle, 232 Engineering details, 156 Cases, 218 Self-diagnosis, 138 Chain Warning indicators, 56, 57 Checking wear, 199 Ambient temperature, 42 Lubricating, 197 Auxiliary battery Sag, 198...
  • Page 303 Engine oil Engineering details, 159 Checking fill level, 174 operating, 105, 106 Filler neck, 18 Self-diagnosis, 139 Oil dipstick, 18 Warning indicators, 57, 58 Technical data, 244 topping up, 176 Indicator light, 27 Engine run-on circuit Warning indicator lights, 47 Engineering details, 168 Warning indicators, 46 switching on and off, 83...
  • Page 304 INDEX Warning indicators, 42, 43 Hazard warning flashers, 95 Keys, 80, 81 Control, 21 operating, 90 Light signals Headlight STOP signal, front, 99 Headlight beam throw, 124, STOP signal, rear, 100 Lighting Right- or left-hand traffic, 124 replacing, 202 Headlight courtesy delay Technical data, 251 feature, 91 Warning indicators, 45...
  • Page 305 Motorcycle Power socket care, 230 Notes on use, 216 cleaning, 230 Position on the vehicle, 18 lashing, 151 Pre-Ride-Check, 137 laying up, 235 Pure Ride, 31 parking, 145 restoring to use, 236 Radio-operated key Multifunction display Replacing battery, 84 Control, 21 Warning indicators, 42, 43 Multifunction switch Overview, left side, 21...
  • Page 306 INDEX Service Two-way radio box BMW Motorrad Service, 259 emergency unlocking, 223 Reporting safety-relevant operating, 222 Type plate, 19 defects, 258 Service history, 260 Tyres Checking tread depth, 184, Warning indicators, 60, 61 Shift assistant Checking tyre pressure, 184 Engineering details, 166...
  • Page 307 Outside temperature warning, 42 RDC, 50 Service, 60, 61 Side stand, 55 TPM, 51, 52, 53, 54 Warning light, drive malfunction, 48 Warning lights Instrument cluster, 27 Overview, 30 Warnings, overview, 37 Weights Payload table, 18 Technical data, 251 Wheels Change of size, 186 Checking rims, 185 installing, 189, 194...
  • Page 308 Errors and omissions excepted. © 2023 Bayerische Motoren Werke Aktiengesellschaft 80788 Munich, Germany Not to be reproduced by any means whatsoever, wholly or in part, without the written per- mission of BMW Motorrad, After Sales. Original rider’s manual, printed in Germany.
  • Page 309 Important data for refuelling: Fuel Premium unleaded (max Recommended fuel grade 15 % ethanol, E10/E15) 95 ROZ/RON 90 AKI Usable fuel capacity approx. 15 l Reserve fuel approx. 4 l Tyre pressure Tyre pressure, front 2.2 bar, One-up, tyre cold 2.5 bar, Riding with passenger and/or luggage, with cold tyres Tyre pressure, rear...

Table of Contents
