Table of Contents

Advertisement

Quick Links

LINK:
CONTENT & A-Z
OWNER'S MANUAL.
BMW 8 SERIES CONVERTIBLE.
Online Edition for Part no. 01405A38D29 - VI/21
The Ultimate
Driving Machine®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8 Series 2022 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BMW 8 Series 2022

Summary of Contents for BMW 8 Series 2022

  • Page 1 LINK: CONTENT & A-Z The Ultimate Driving Machine® OWNER'S MANUAL. BMW 8 SERIES CONVERTIBLE. Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 2 Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 3 The more familiar you are with your vehicle, the better control you will have on the road. We therefore strongly suggest: Read this Owner's Manual before starting off in your new BMW. Also use the Integrated Owner's Manual in your vehicle. It contains important notes on ve‐...

  • Page 4: Table Of Contents

    On the road ........................CONTROLS Dashboard ........................Sensors of the vehicle ....................Operating state of the vehicle ..................iDrive ..........................BMW Remote Software Upgrade ................General settings ......................Personal settings ......................Connections ........................Opening and closing ..................... Seats, mirrors and steering wheel ................
  • Page 5 © 2021 Bayerische Motoren Werke Aktiengesellschaft Munich, Germany Reprinting, including excerpts, only with the written consent of BMW AG, Munich. US English ID7 VI/21, - Printed on environmentally friendly paper, bleached without chlorine, suitable for recycling. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 6: Notes Information

    Internet Validity of the Owner's Manual Vehicle information and general information on BMW, for instance, on technology, are available Production of the vehicle on the Internet: www.bmwusa.com. At the time of production at the plant, the printed Owner's Manual is the most current resource.
  • Page 7 ››...‹‹ Responses generated by the voice Owner's Manuals. activation system. Your BMW service center is happy to answer any Action steps questions that you may have about the features and options applicable to your vehicle. Action steps to be carried out are presented as a numbered list.
  • Page 8 The manufacturer of the vehicle recommends of the printed Owner's Manual for the vehicle. that you entrust corresponding procedures to a BMW center. If you choose to use another serv‐ After a software update in the ice facility, BMW recommends use of a facility that performs work, e.g., maintenance and repair,...
  • Page 9 Specifications for maintenance measures: which are known to the State of California to ▷ BMW Maintenance system. cause cancer and birth defects or other repro‐ ▷ Maintenance Booklet, available online and ac‐ ductive harm. To minimize exposure, avoid cessible via a QR code in the New Vehicle breathing exhaust, do not idle the engine ex‐...
  • Page 10 Information NOTES A failure to maintain your vehicle or improper The processed data is only processed in the ve‐ maintenance may affect your warranty coverage. hicle itself and generally volatile. The data is not Please consult the New Vehicle Limited War‐ stored beyond the operating period.
  • Page 11 Information NOTES Incorporation of mobile devices vehicle, which can be used to determine vehicle maintenance status, and facilitate quality im‐ Depending on the vehicle equipment, mobile de‐ provement. vices connected to the vehicle, for instance Fault and event memories in the vehicle can be smartphones, can be controlled via the vehicle reset when a dealer’s service center or another control elements.
  • Page 12 Information NOTES to data protection may also be found on the ▷ How far, if at all, the driver was depressing the manufacturer’s website. Personal data may be accelerator and/or brake pedal. used to perform online services. Data is ex‐ ▷...
  • Page 13 Left nameplate or death, you should immediately inform the Na‐ tional Highway Traffic Safety Administration NHTSA, in addition to notifying BMW of North America, LLC, P.O. Box 1227, Westwood, New Jersey 07675-1227, Telephone 1-800-831-1117.
  • Page 14 Information NOTES To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800-424-9153); go to http://www.safercar.gov; or write to: Administrator, NHTSA, 1200 New Jersey Avenue, SE., Washington, DC 20590. You can also obtain other information about mo‐ tor vehicle safety from http://www.safercar.gov.

  • Page 15: Owner's Manual Media

    Owner's Manual media NOTES Owner's Manual media Vehicle features and Manual for the vehicle will contain the latest in‐ formation. options Printed Owner's Manual This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are Concept not necessarily available in your vehicle, e.g., due The printed Owner's Manual describes all stand‐...
  • Page 16 Owner's Manual media NOTES Scrolling through the Owner's Manual Turn the Controller, until the next or previous contents are displayed. Context help General information The Integrated Owner's Manual can be ac‐ cessed from any menu. Depending on the se‐ lected function, either the associated description or the main menu of the Integrated Owner's Manual will be displayed.
  • Page 17 Owner's Manual media NOTES Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 18: Quick Reference Entering

    Entering QUICK REFERENCE Entering Opening and closing Buttons for the central locking system Buttons on the vehicle key Overview 1 Unlocking Buttons for the central locking system. 2 Locking 3 Opening the trunk lid Locking 4 Panic mode, pathway lighting Press the button with the front doors closed.
  • Page 19 Entering QUICK REFERENCE Comfort Access Opening and closing the trunk lid with no-touch activation Principle Principle The vehicle can be accessed without operating The trunk lid can be opened and closed with no- the vehicle key. touch activation using the vehicle key you are Carrying the vehicle key with you, e.g., in your carrying.
  • Page 20 Entering QUICK REFERENCE Displays, control elements Depending on the setting, the doors may also be unlocked. In the vicinity of the steering Closing wheel Press the button on the inside of the trunk lid. Convertible top Overview 1 Light switch element 2 Turn signal indicator, high beams 3 Instrument cluster 4 Wipers...
  • Page 21 Entering QUICK REFERENCE 5 Exterior mirrors Button Function 6 Opening/closing trunk lid Go to destination input menu for navi‐ gation. Switch console Go to the previous display. Go to the Options menu. Voice control Activating the voice control system Press the button on the steering wheel. 1 Selector lever Say the command.

  • Page 22: Set-Up And Use

    Set-up and use QUICK REFERENCE Set-up and use Seats, mirrors and steering Adjusting the distance: basis seat wheel Electrically adjustable seats ▷ Back: press the button and push the head re‐ straint toward the rear. ▷ Forward: pull the head restraint toward the front.
  • Page 23 Set-up and use QUICK REFERENCE Adjusting the steering wheel Entering the rear Electrical steering wheel adjustment Fold the seat backrest forward Pull the loop. Press the switch to adjust the forward/back posi‐ tion and height of the steering wheel to the seat Fold the seat backrest forward.
  • Page 24 Set-up and use QUICK REFERENCE "Show results" Button Function Select the desired entry. Press: turns sound output on/ If necessary, "Start guidance" off. Turn: adjusts the volume. Connecting a mobile phone General information Change the entertainment After the mobile phone is connected once to the source.
  • Page 25 Set-up and use QUICK REFERENCE Use the thumbwheel on the steering wheel to The vehicle's Bluetooth name is displayed on select: "Accept" the Control Display. ▷ Via touchscreen: tap on the corresponding On the mobile device, search for Bluetooth entry on the Control Display. devices in the vicinity and select the vehicle.

  • Page 26: On The Road

    On the road QUICK REFERENCE On the road Driving Releasing With drive-ready state switched on: Drive readiness Press the switch while stepping on the brake pedal or selector lever position P is set. Turning on drive readiness The LED and indicator light turn off. The parking brake is released.
  • Page 27 On the road QUICK REFERENCE Steptronic transmission, Sport A selector lever lock prevents the inadvertent shifting to selector lever position R or the inad‐ program and manual mode vertent shifting from selector lever position P. Engage selector lever position R only when the vehicle is stationary.
  • Page 28 On the road QUICK REFERENCE High beams, headlight flasher Icon Function Right roadside parking light. Left roadside parking light. Window wiper system Turn on window wiper system Press the lever forward or pull it backward. ▷ High beams on, arrow 1. The high beams light up when the low beams are switched on.
  • Page 29 On the road QUICK REFERENCE Cleaning the windshield ▷ Turn off: press the lever down until it reaches the 0 position. ▷ Flick wipe: press the lever down from the 0 position. Activate/deactivate rain sensor Pull the lever. Climate control Automatic climate control Activate: press the lever up once from its 0 posi‐...
  • Page 30 The friction during hard braking may produce brake dust and make the rims dirty. Brake dust Turn the fuel cap counterclockwise. can be removed by cleaning the rims. BMW rec‐ Place the fuel cap in the bracket attached to ommends using vehicle care and cleaning prod‐...
  • Page 31 The BMW Assist Concierge service offers infor‐ mation on events, filling stations or hotels, and provides phone numbers and addresses. Many hotels can be booked directly by the BMW Con‐ cierge service. The Concierge service is part of the optional BMW Assist Response Center.

  • Page 32: Dashboard

    Dashboard CONTROLS Dashboard Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 33 Dashboard CONTROLS Night Vision  198 Manual Speed Limiter  222 Light switch  173 Depending on the equipment: Cruise control on/off  224 Lights off Daytime driving lights  175 Parking lights  174 Depending on the equipment: Active Cruise Control on/off  226 Automatic headlight control  173 With steering and traffic jam assis‐ Adaptive light functions  175 tant  236:...
  • Page 34 Dashboard CONTROLS 13 Steering column stalk, right Steering wheel heating  124 Wipers  144 Adjusting the steering wheel  124 Rain sensor  145 Unlocking the hood  345 Cleaning the windshield  145 Horn, entire surface In the vicinity of the center console 1 Control Display  48 5 Automatic climate control  273 Hazard warning system  359 6 Radio/multimedia, see Owner's Manual for...
  • Page 35 Dashboard CONTROLS Opening and closing the ECO PRO driving mode convertible top  108 collar  126 ADAPTIVE driving mode Parking brake  140 Turning drive readiness state on/ off  135 Automatic Hold  141 Auto Start/Stop function  135 Driving Dynamics Control  138 Parking assistance systems  245 SPORT driving mode COMFORT driving mode Panorama View  265 DSC Dynamic Stability Con‐...
  • Page 36 Dashboard CONTROLS In the vicinity of the headliner Emergency Call, SOS  361 Reading lights  179 Indicator light, front passenger air‐ Interior lights  178 bag  184 Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 37: Sensors Of The Vehicle

    Sensors of the vehicle CONTROLS Sensors of the vehicle Vehicle features and Cameras options Front camera This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 38 Sensors of the vehicle CONTROLS Top view cameras System limits of the cameras The cameras may not be fully functional and may provide incorrect information in the following sit‐ uations: ▷ In heavy fog, wet conditions, or snowfall. ▷ On steep hills, in steep depressions or in tight curves.
  • Page 39 Sensors of the vehicle CONTROLS Radar sensors, side, front If applicable, a Check Control message will be displayed when the system limits are reached. Ultrasound sensors Ultrasound sensors in the front/ rear bumpers The ultrasound sensors of the Park Distance Control PDC are lo‐ The radar sensors are located in the bumper.
  • Page 40 Sensors of the vehicle CONTROLS ▷ For persons with certain clothing, for instance jacket. ▷ In case of external interference of the ultra‐ sound, for instance from passing vehicles, loud machines or other ultrasonic sources. ▷ Under certain weather conditions, e.g., high relative atmospheric humidity, wet conditions, snowfall, cold, extreme heat, or strong wind.

  • Page 41: Operating State Of The Vehicle

    Operating state of the vehicle CONTROLS Operating state of the vehicle Vehicle features and Safety information options Warning This chapter describes all standard, country-spe‐ An unsecured vehicle can begin to move and cific and optional features offered with the series. possibly roll away.
  • Page 42 Operating state of the vehicle CONTROLS Display in the instrument cluster ▷ After several minutes, if no operation takes place on the vehicle. OFF is displayed in the instru‐ ▷ If the charge state of the vehicle battery is ment cluster. The drivetrain is low.
  • Page 43 Operating state of the vehicle CONTROLS ▷ Set the parking brake. Additional information: ▷ On uphill grades or on a downhill slope, Power gauge, refer to page 163. turn the front wheels in the direction of the Display in the instrument cluster curb.

  • Page 44: Idrive

    Via the Controller. All functions of the entertainment system, ▷ Via the touchscreen. e.g., radio stations or connection with external ▷ Via the BMW Intelligent Personal Assistant. devices. ▷ Depending on the equipment: with the ges‐ ture control. Communication Phone and message functions, e-mail and Safety information calendar, and also the connection and manage‐...
  • Page 45 Management of apps, access to apps and ve‐ hicle functions. Additional apps and vehicle func‐ Several menu items are preceded by a check‐ tions can be purchased from the BMW Store. box. The checkbox indicates whether the func‐ tion is activated or deactivated. Selecting the Widgets menu item activates or deactivates the function.
  • Page 46 iDrive CONTROLS Icon Meaning Icon Meaning Roaming is active. Stop. Locating is active. Data protection. SMS text message received. Destination guidance active. Message received. Passengers on board. Reminder. Do not disturb. Sending not possible. Programmable memory buttons Entertainment symbols General information The iDrive functions can be stored on the pro‐...
  • Page 47 iDrive CONTROLS Executing a function Control Display Press the button. Safety information The function will work immediately. This means, for instance that the number is dialed when a NOTICE phone number is selected. Objects in the area in the front of the Control Display can shift and damage the Control Dis‐...
  • Page 48 iDrive CONTROLS Controller Buttons on the Controller Button Function General information The buttons can be used to open the menus di‐ Go to the main menu. rectly. The Controller can be used to select menu items and enter the settings. Go to Apps menu.
  • Page 49 iDrive CONTROLS Selecting a menu Adjusting contents Depending on the equipment, the contents of Selecting menu items menus "MEDIA", "COM" and "NAV" can be ad‐ justed, for instance to remove the entries of Turn the Controller until the desired menu functions that are not used from the menu.
  • Page 50 iDrive CONTROLS Deleting Entering special characters Icon Function Input Operation Press the Controller: delete letter or Delete a charac‐ Swipe to the left on the number. ter. touchpad. Hold the Controller down: delete all let‐ Enter a blank Swipe to the right in the ters or numbers.
  • Page 51 iDrive CONTROLS Opening the main menu ▷ To show the display bar, pull down the dis‐ play bar at the top edge of the screen. Tap on the icon. ▷ To hide the display bar, pull up the display bar at the top edge of the screen.
  • Page 52 BMW Intelligent Personal Assistant is availa‐ The microphone on the driver's side is active. ble depending on the national-market ver‐ ▷ Say the wake word ›Hello BMW‹ or a personal sion. wake word. ▷ The system includes special microphones on The microphones on the driver's or front pas‐...
  • Page 53 In addition to the preset or personal activation word, the ac‐ General information tivation word from connected third-party provid‐ Speaking the wake word ›Hello BMW‹ or the per‐ ers can be used. sonal wake word will start the system. "CAR"...
  • Page 54 iDrive CONTROLS Navigation Menu items ▷ ›Drive me to 300 Chestnut Ridge Road, The commands of the menu items are spoken Woodcliff Lake in New Jersey.‹ just as they are selected via the Controller. ▷ ›Take me home.‹ Activating the voice control system. ▷...
  • Page 55 iDrive CONTROLS rupted, for instance due to background noise or The voice activation of the smartphone is ac‐ conversations in the vehicle. tivated. "CAR" Release the button. "Settings" If activation is successful, a confirmation ap‐ "General settings" pears on the Control Display. If necessary, "Personal assistant"...
  • Page 56 iDrive CONTROLS Activate/deactivate System limits "CAR" ▷ The Personal Assistant provides information about vehicle functions that may not be in‐ "Experience Modes" stalled in the vehicle. Select the desired mode. This also applies to safety-related functions The mode can be deactivated: "End" and systems.

  • Page 57: Bmw Remote Software Upgrade

    Standby must be turned on to search for a soft‐ or quality improvements available. ware upgrade. General information Automatic search BMW recommends performing the Remote The vehicle regularly searches for updates in the Software Upgrade as soon as it becomes availa‐ background. ble.
  • Page 58 Display in the vehicle: Via BMW app "CAR" If an upgrade is available, information about the "Settings" new software version is displayed in the BMW "General settings" app. "Remote Software Upgrade" The data for the upgrade can then be down‐...
  • Page 59 Remove connected devices from the OBD In the event of a malfunction, follow the instruc‐ socket. tions on the control display or in the BMW app. If the malfunction cannot be remedied, contact a Starting installation dealer’s service center or another qualified serv‐...
  • Page 60 BMW Remote Software Upgrade CONTROLS After a software update in the vehicle After a vehicle software update, such as via Re‐ mote Software Upgrade, the Integrated Owner's Manual for the vehicle will contain the latest in‐ formation. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 61: General Settings

    General settings CONTROLS General settings Vehicle features and Setting the time format options "CAR" "Settings" This chapter describes all standard, country-spe‐ "General settings" cific and optional features offered with the series. "Date and time" It also describes features and functions that are "Time format:"...
  • Page 62 General settings CONTROLS Setting the date format data to analyze the attention of the driver. This system supports various vehicle assistance sys‐ "CAR" tems, e.g.: "Settings" ▷ Fatigue alert. "General settings" ▷ Steering and traffic jam assistant with Ex‐ "Date and time" tended Traffic Jam Assistant.
  • Page 63 General settings CONTROLS Speed warning Activating/deactivating pop-ups Principle For some functions, pop-ups are displayed auto‐ The speed warning can be used to set a speed matically on the Control Display. Some of these limit. A warning will be issued when this speed pop-ups can be activated or deactivated.
  • Page 64 Communication messages, for example e- mails, SMS text messages or reminders. General information ▷ Messages, for instance from the BMW app. The BMW Intelligent Personal Assistants allows ▷ Messages from the manufacturer of the vehi‐ the configuration of the range of messages that cle, for instance technical information or im‐...
  • Page 65 General settings CONTROLS "Notification display" Select the desired setting. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 66: Personal Settings

    Phone book. The vehicle offers different services, whose use ▷ Online data, for instance Favorites, cookies. requires a data transfer to BMW or a service pro‐ ▷ Office data, for instance voice memos. vider. The data transmission can be deactivated ▷...
  • Page 67 If the set-up assistant was opened in the in the driver's profile can be synchronized with guest profile: create driver profile. the personal BMW ConnectedDrive account. It is ▷ Pairing mobile devices with the vehicle. thereby possible to use these settings in other ▷...
  • Page 68 In the following cases the guest profile is auto‐ Scanning the displayed QR code will accept matically active: the access data for the ConnectedDrive ac‐ count from the BMW app. ▷ A driver profile has not been created yet. ▷...
  • Page 69 ConnectedDrive account. This means that it is possible to use the "CAR" personal settings in other BMW vehicles with "Driver profiles" ConnectedDrive access as well, if this function is Tilt the Controller to the right.
  • Page 70 "Avatar" Select the desired profile picture. ConnectedDrive countries: The profile image is transferred from the Con‐ nectedDrive customer portal or the BMW app. Deleting the driver profile "CAR" "Driver profiles" Tilt the Controller to the right.

  • Page 71: Connections

    Connections CONTROLS Connections Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 72 Connections CONTROLS Function Connection type Symbol in the device list Apple CarPlay: Bluetooth and WLAN. Using apps via iDrive and via voice op‐ eration. Android Auto: Bluetooth and WLAN. Using apps via iDrive and via voice op‐ eration. Displaying the vehicle identification The following connection types require one-time pairing with the vehicle: number and software part number...
  • Page 73 Bluetooth audio. phones via Bluetooth®. WLAN in the vehicle, Wi-Fi hotspot. ▷ "Apps" Apps. With the installed BMW app, apps from the smartphone can be displayed in the Screen Mirroring. vehicle. Apple CarPlay. ▷ "Wi-Fi®"...
  • Page 74 Compatible device with Bluetooth interface. pected. Compatible devices, refer to page 72. In this case, the following explanations can help: ▷ The vehicle key or BMW display key is in the Why could the mobile phone not be paired or vehicle. connected? ▷...
  • Page 75 Connections CONTROLS WLAN connection ▷ Transmission of the telephone book entries is not yet complete. ▷ It is possible that only the telephone book en‐ General information tries of the mobile phone or the SIM card are For certain applications, such as apps, the data transmitted.
  • Page 76 Connections CONTROLS Connecting a device to the Tilt the Controller to the right. Internet via the Wi-Fi hotspot "Settings" "Internet connection" Using the Internet for the first time via the Wi- Fi hotspot requires registration and possibly a Select the desired setting. data volume purchase from a service provider.
  • Page 77 Connections CONTROLS Apple CarPlay© Operation preparation For more information, refer to the Integrated Owner's Manual or the Owner's Manual for Navi‐ gation, Entertainment, Communication. Principle Frequently Asked Questions CarPlay allows certain functions of a compatible Apple iPhone to be used via Siri voice control All requirements are met and all required steps and iDrive.
  • Page 78 Connections CONTROLS Frequently Asked Questions Android smartphone with Android 11, regard‐ less of the manufacturer. All requirements are met and all required steps ▷ Compatible devices, refer to page 72. were completed in the specified order. Despite that, the mobile device does not function as ex‐ ▷...
  • Page 79 Connections CONTROLS ▷ Do not use force when plugging the connec‐ Additional information: tor into the USB port. USB port, refer to page 291. ▷ Use a flexible adapter cable. ▷ Protect the USB device against mechanical damage. ▷ Due to the large number of USB devices available on the market, it cannot be guaran‐...

  • Page 80: Opening And Closing

    There is a risk of injury. Take the cle key and the BMW display key. vehicle key with you so that the vehicle can be Each vehicle key contains a replaceable battery.
  • Page 81 Opening and closing CONTROLS ▷ Pressing the Start/Stop button. ▷ If only the driver's door and the fuel filler flap or all access to the vehicle will be unlocked ▷ Releasing the parking brake. when the button is pressed for the first time. ▷...
  • Page 82 Opening and closing CONTROLS Convenient opening Locking the vehicle Close the driver's door. Safety information Press the button on the vehicle key. The following functions are executed: Warning ▷ All doors, the trunk lid, and the fuel filler flap Body parts can be jammed when opening and are locked.
  • Page 83 Opening and closing CONTROLS Switching on the interior and NOTICE exterior lighting During opening, the trunk lid pivots back and Press the button on the vehicle key with up. There is a risk of damage to property, the vehicle locked. among other potential damage.
  • Page 84 Opening and closing CONTROLS cover with a lever movement of the If the lost vehicle key has an assigned driver pro‐ integrated key, arrow 2. file, the connection to this vehicle key must be deleted. A new vehicle key can then be assigned to the driver profile.
  • Page 85 General information Thescope of delivery of the BMW display key in‐ cludes an additional mechanical key. If the dis‐ play key is used, the mechanical key should be carried with you, for instance in the wallet. The mechanical key is used like the integrated key.
  • Page 86 Opening and closing CONTROLS Persons who spend a lengthy time in the vehi‐ 6 Back cle while being exposed to extreme tempera‐ 7 Turn the display on/off tures are at risk of injury or death. Do not lock 8 Micro-USB charging interface the vehicle from the outside when there are people in it.
  • Page 87 Opening and closing CONTROLS Operating concept If the information area contains more than one page, then page indicators are shown beneath The following information shows how to access the information. the information and functions using the main A solid indicator denotes the current menus.
  • Page 88 Opening and closing CONTROLS Charging erability of the standard buttons is retained until the battery is completely discharged. Via USB ▷ Charge the battery for at least three hours before using the display key for the first time Connect the display key via the micro-USB or if the key has not been used for an ex‐...
  • Page 89 If the display key is detected: A Check Control message is displayed. Turn on drive-ready state within 10 seconds. BMW display key detection by the vehicle may If the display key is not detected, slightly change malfunction under the following circumstances: the position of the display key and repeat the procedure.
  • Page 90 A vehicle key must be located in the vehicle to opened from the outside. deactivate the Key Card. When BMW Digital Key is activated for the vehi‐ cle, a digital key can be used instead of the vehi‐ cle key.
  • Page 91 CONTROLS BMW Digital Key Unlocking and locking the vehicle Principle BMW Digital Key allows the vehicle to be un‐ locked and locked, as well as started, with a compatible smartphone. General information The availability of the BMW Digital Key depends on the equipment and national-market version.
  • Page 92 The proof of authorization can be started via the themselves and traffic, for instance due to the BMW app or via the activation code in the corre‐ following actions: sponding smartphone function, for instance the ▷...
  • Page 93 Follow the corresponding instruc‐ tions on the smartphone or the Control Display. The digital remote control key must be enabled again to be able to use BMW Digital Key again. Deleting a shared key "CAR" "Settings"...
  • Page 94 Opening and closing CONTROLS The position of the near field communication an‐ ▷ The smartphone is shielded from the sensors tenna depends on the smartphone model. in the vehicle by a smartphone cover that is not suitable. When locking the vehicle with the smartphone, make sure that all doors including the trunk lid ▷...
  • Page 95 Opening and closing CONTROLS Removing Remove the cover. Unlock or lock the door lock using the integrated key. Press the button, arrow 1, and pull out the integrated key, arrow 2. The other doors must be unlocked or locked from the inside. Locking/unlocking via the door lock Alarm system...
  • Page 96 Touchless unlocking and locking of the vehi‐ closed. cle. ▷ The fuel filler flap remains unlocked. ▷ Unlocking and locking the vehicle using the BMW Digital Key. ▷ The vehicle is not secured against theft when locking. ▷ Opening trunk lid. ▷...
  • Page 97 Opening and closing CONTROLS ▷ If a driver profile was assigned to the vehicle ▷ All doors, the trunk lid, and the fuel filler flap key, this driver profile will be activated and the are locked. settings that are stored in it will be applied. ▷...
  • Page 98 Opening and closing CONTROLS Opening and closing the trunk lid NOTICE with no-touch activation During opening, the trunk lid pivots back and Principle up. There is a risk of damage to property, among other potential damage. Make sure that The trunk lid can be opened and closed with no- the area of movement of the trunk lid is clear touch activation using the vehicle key you are during opening and closing.
  • Page 99 Opening and closing CONTROLS The hazard warning system flashes and an If a passenger is detected in the front passenger acoustic signal sounds. seat during locking and the safety belt of the front passenger is engaged in the safety belt Moving your foot again will stop the closing mo‐...
  • Page 100 Opening and closing CONTROLS not possible until after the vehicle has been It may not be possible to open the trunk lid when driven. the vehicle is in valet parking mode. The trunk lid can normally not be opened if the Malfunction convertible top is not fully opened or closed.
  • Page 101 Opening and closing CONTROLS Opening and Closing ▷ By pressing the button on the vehicle key. Pressing again continues the opening mo‐ tion. Opening ▷ By pressing or pulling the button in the driv‐ From the outside er's door. Pressing again continues the open‐ ing motion.
  • Page 102 Opening and closing CONTROLS Valet parking mode ▷ By pressing the button on the inside of the trunk lid. Pressing again re-opens the trunk lid. Principle ▷ By releasing the button in the driver's door. In the valet parking mode, the Control Display is Pulling again and holding continues the clos‐...
  • Page 103 Opening and closing CONTROLS Via the vehicle settings The trunk lid will be locked and disconnected from the central locking system. "CAR" "Activate now" "Settings" This PIN can be used once to deactivate the "General settings" valet parking mode for the active guest pro‐ "Valet parking mode"...
  • Page 104 Opening and closing CONTROLS Guest profile "Doors/ vehicle access" Deactivate or activate the desired confirma‐ In the guest profile, the valet parking mode can tion signals: only be deactivated if the valet parking mode was activated in the guest profile. ▷...
  • Page 105 Opening and closing CONTROLS Trunk lid Establishing idle state after opening the front doors Trunk lid and doors "CAR" You can set up if only the trunk lid will be un‐ "Settings" locked or if the doors will also be unlocked when "Doors/ vehicle access"...
  • Page 106 Opening and closing CONTROLS Opening the doors with the alarm not correctly closed. Correctly closed access points are secured. system switched on When the still open access points are closed, The alarm system is triggered when a door is the interior motion sensor and tilt alarm sen‐ opened if the door was unlocked using the sor will be switched on.
  • Page 107 When a window is often opened in the same po‐ ▷ Standby state is switched on. sition, this task can be performed by the BMW ▷ Drive readiness is switched on. Intelligent Personal Assistant. For instance when The vehicle key must be in the car's interior.
  • Page 108 Opening and closing CONTROLS Opening together Safety information ▷ Press the switch to the resistance point. Warning All windows open while the switch is being Accessories on the windows such as antennas held. can impact jam protection. There is a risk of in‐ jury.
  • Page 109 Opening and closing CONTROLS the engine is started using the Start/Stop button or using the Auto Start/Stop function, Warning the convertible top movement is briefly inter‐ A convertible top that is not completely open or rupted. closed is not locked and can open by itself ▷...
  • Page 110 Opening and closing CONTROLS area of movement: 19.7 inches/0.5 me‐ ▷ The convertible top drive is not overheating. ters. ▷ The windows can be opened and closed au‐ ▷ Fully close the trunk lid. tomatically. ▷ Do not leave the convertible top open for ▷...
  • Page 111 Opening and closing CONTROLS Safety information ate switch again until the convertible operation is terminated. Warning Operation from the outside In case of an electrical malfunction, the When equipped with Comfort Access the convertible top cannot be locked in the fully convertible top can also be operated from out‐...
  • Page 112 Opening and closing CONTROLS Lifting out convertible top ing Bowden cables out to the stop in succes‐ sion. Grab both sides of the convertible top well storage cover on the side in the rear and swivel up and to the rear to the end position. When the convertible top well storage cover is unlocked, the trunk lid can no longer be opened.
  • Page 113 Opening and closing CONTROLS age cover. The end of the convertible top convertible frame is locked with the front must be folded up for this purpose. windshield frame. Fold the end of the convertible top down onto the convertible top well storage cover. NOTICE When driving in the rain or on a wet road sur‐...
  • Page 114 Opening and closing CONTROLS The wind deflector is most effective when the side windows are closed. Warning Operating the wind deflector while driving can General information distract from the surrounding traffic. There is a risk of accident. Operate the wind deflector A protective jacket for the removed wind deflec‐...
  • Page 115 Opening and closing CONTROLS Insert wind deflector from one side of the ve‐ Press the wind deflector downward in the hicle with the pins in the corresponding fixing middle, until the handle engages, arrows 1. points on the opposite side of the vehicle. Grasp the inner framework of the wind de‐...

  • Page 116: Seats, Mirrors And Steering Wheel

    Seats, mirrors and steering wheel CONTROLS Seats, mirrors and steering wheel Vehicle features and Seats options Safety information This chapter describes all standard, country-spe‐ cific and optional features offered with the series. Warning It also describes features and functions that are Seat setting while driving can lead to unex‐...
  • Page 117 Seats, mirrors and steering wheel CONTROLS Seat tilt The current seat position can be stored using the memory function. Overview Tilt switch up or down. Backrest tilt 1 Backrest width 2 Forward/backward, height, seat tilt 3 Backrest tilt, head restraint 4 Lumbar support Longitudinal direction Tilt switch forward or backward.
  • Page 118 Seats, mirrors and steering wheel CONTROLS Lumbar support Functional limitations It may not be possible to adjust the backrest Principle width at very high and very low temperatures. The curvature of the seat backrest can be ad‐ Entering the rear justed in a way that it supports the lumbar region of the spine.
  • Page 119 Seats, mirrors and steering wheel CONTROLS Safety information For equipment specification with M sport seat: Pull the lever. Warning Use of a safety belt to buckle more than one person will potentially defeat the ability of the safety belt to serve its protective function. There is a risk of injury or danger to life.
  • Page 120 Seats, mirrors and steering wheel CONTROLS Correct use of safety belts The safety belt reminder is also active when the front passenger seat belt is not buckled or ob‐ ▷ Wear the safety belt twist-free and tight to jects are on the front passenger seat. your body over your lap and shoulders.
  • Page 121 Seats, mirrors and steering wheel CONTROLS Front head restraints ▷ Only use accessories that have been de‐ termined to be safe for attachment to a head restraint. General information ▷ Do not use any accessories, for instance The current head restraint position can be stored pillows, while driving.
  • Page 122 Seats, mirrors and steering wheel CONTROLS Adjusting the distance: M Sport The mirror setting is stored for the driver profile currently in use. When a driver profile is selected, seat the stored position is called up automatically. The distance to the back of the head is adjusted The current exterior mirror position can be stored via the backrest tilt.
  • Page 123 Seats, mirrors and steering wheel CONTROLS Malfunction Activating In case of an electrical malfunction, adjust the slide the switch to the driver's side mirror by pressing the edges of the mirror glass. mirror position. Folding in and out Engage selector lever position R. Deactivating NOTICE Slide the switch to the front passenger's side...
  • Page 124 Seats, mirrors and steering wheel CONTROLS Steering wheel Steering wheel heating Overview Safety information Warning Steering wheel adjustments while driving can lead to unexpected steering wheel movements. Vehicle control could be lost. There is a risk of accident. Adjust the steering wheel while the vehicle is stationary only.
  • Page 125 Seats, mirrors and steering wheel CONTROLS Safety information The procedure stops when a switch for setting the seat is pressed or one of the memory but‐ tons is pressed again. Warning The adjustment of the seat position on the driv‐ Using the memory function while driving can er's side is interrupted after a short time while lead to unexpected seat or steering wheel...
  • Page 126 Seats, mirrors and steering wheel CONTROLS Air collar Highest level reached when three red LEDs light up on the button or three red bars are shown on the Control Display. Principle If the trip is continued within approx. 15 minutes The air collar ensures just the right temperature after a stop, the functions are switched on auto‐...
  • Page 127 Seats, mirrors and steering wheel CONTROLS Overview Air collar Turning on Press button once for each level. The maximum temperature and blower output is reached when three LEDs are lit. If ECO PRO is activated, the air collar may be temporarily deactivated.
  • Page 128 Seats, mirrors and steering wheel CONTROLS General information When both systems are active, a push of the but‐ ton reduces the intensity of both functions by The outside temperature at which the functions one level each. are to be automatically activated can be set via The last active function or function that is config‐...

  • Page 129: Transporting Children Safely

    Transporting children safely CONTROLS Transporting children safely Vehicle features and Warning options A heated vehicle may result in death to per‐ sons, especially children, or animals. There is a This chapter describes all standard, country-spe‐ risk of injury or danger to life. Do not leave per‐ cific and optional features offered with the series.
  • Page 130 Transporting children safely CONTROLS Installing child restraint Safety information systems Warning The safety belt cannot be fastened correctly on General information children shorter than 5 ft, 150 cm without suita‐ Pay attention to the specifications and the oper‐ ble additional child restraint systems. The pro‐ ating and safety information of the child restraint tective effect of safety gear, including safety system manufacturer when selecting, installing,...
  • Page 131 Transporting children safely CONTROLS On the front passenger seat Child seat security Deactivating airbags Warning Active front passenger airbags can injure a child in a child restraint system when the airbags are activated. There is a risk of injury. Make sure that the front passenger airbags are deacti‐...
  • Page 132 Transporting children safely CONTROLS Mounts for the lower LATCH Position anchors Icon Meaning General information The corresponding icon shows the mounts for the lower The lower anchors may be used to attach the LATCH anchors. CRS to the vehicle seat up to a combined child and CRS weight of 65 lbs/30 kg when the child is Seats equipped with lower restrained by the internal harnesses.
  • Page 133 Transporting children safely CONTROLS Child restraint systems Attachment points with tether strap Icon Meaning The respective icon shows the Safety information attachment point for the upper retaining strap. Seats with an upper top tether are marked Warning with this icon. It is located on the If the upper retaining strap is incorrectly used rear seat backrest, the rear shelf for the child restraint system, the protective ef‐...
  • Page 134 Transporting children safely CONTROLS Tighten the retaining strap. Push the seat backrest rearward and lock it Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 135: Driving

    Driving CONTROLS Driving Vehicle features and Auto Start/Stop function options Principle This chapter describes all standard, country-spe‐ The Auto Start/Stop function helps save fuel. cific and optional features offered with the series. The system switches off the engine during a It also describes features and functions that are stop, for instance in traffic jam or at traffic lights.
  • Page 136 Driving CONTROLS ▷ Depress the brake pedal forcefully again from ▷ The outside temperature is high and auto‐ the current pedal position. matic climate control is running. ▷ Engage selector lever position P. ▷ The car's interior has not yet been heated or cooled to the required level.
  • Page 137 Driving CONTROLS ▷ The driver's safety belt is unbuckled and the A message appears on the Control Display, driver's door is open. depending on the situation. ▷ Hood was unlocked. ▷ When a situation is detected in which the ve‐ hicle needs to drive off immediately, the en‐...
  • Page 138 Driving CONTROLS Switching off the vehicle during ▷ Engine characteristics. an automatic engine stop ▷ Steptronic transmission. ▷ Adaptive M chassis. General information ▷ Adaptive M Chassis Professional. During an automatic engine stop, the vehicle can ▷ Active roll stabilization. be switched off permanently, for instance when ▷...
  • Page 139 Driving CONTROLS Configuration Button Driving Configura‐ mode tion "CAR" "Settings" COMFORT COMFORT "Driving mode" ECO PRO ECO PRO INDIVIDUAL "SPORT INDIVIDUAL" ADAPTIVE ADAPTIVE Select the desired setting. Reset SPORT INDIVIDUAL to the standard set‐ When drive-ready state is switched on, the tings: COMFORT driving mode is selected automati‐...
  • Page 140 Driving CONTROLS Safety information Configuration "CAR" "Settings" Warning "Driving mode" An unsecured vehicle can begin to move and possibly roll away. There is a risk of accident. "ECO PRO INDIVIDUAL" Before exiting, secure the vehicle against roll‐ Select the desired setting. ing.
  • Page 141 Driving CONTROLS Overview Additional information: Emergency Stop Assistant, refer to page 212. Releasing Releasing manually Turn on drive readiness. Press the switch while stepping on the brake pedal or selector lever position P is set. The LED and indicator light turn off. Parking brake The parking brake is released.
  • Page 142 Driving CONTROLS Safety information damage. Deactivate Automatic Hold prior to entering the car wash. Warning Overview An unsecured vehicle can begin to move and possibly roll away. There is a risk of accident. Before exiting, secure the vehicle against roll‐ ing.
  • Page 143 Driving CONTROLS Activating the parking brake This process may take a few seconds. Some mechanical sounds associated with this process automatically are normal. The parking brake is automatically set if drive- ready state is switched off while the vehicle is The indicator light is no longer illumi‐...
  • Page 144 Driving CONTROLS High beams, NOTICE headlight flasher If the wipers are frozen to the windshield, the wiper blades can be torn off and the wiper mo‐ Press the lever forward or pull it backward. tor can overheat when switching on. There is a risk of damage to property, among other poten‐...
  • Page 145 Driving CONTROLS ▷ Turn off: press the lever down until it reaches In frosty conditions, wiping operation may not the 0 position. start. ▷ Flick wipe: press the lever down from the 0 position. Deactivate rain sensor The lever automatically returns to its 0 posi‐ Press the lever back into the 0 position.
  • Page 146 Driving CONTROLS Cleaning the windshield NOTICE If the wipers are frozen to the windshield, the wiper blades can be torn off and the wiper mo‐ tor can overheat when switching on. There is a risk of damage to property, among other poten‐ tial damage.
  • Page 147 Driving CONTROLS Steptronic transmission P is engaged automatically Selector lever position P is engaged automati‐ cally in situations such as the following: Principle ▷ After the drive-ready state is switched off and The Steptronic transmission combines the func‐ selector lever position R, D or M/S is en‐ tions of an automatic transmission with the pos‐...
  • Page 148 Driving CONTROLS Rolling or pushing the vehicle ▷ Unintentional shifting into selector lever posi‐ tion R. General information ▷ Unintentional shifting from selector lever po‐ sition P into another selector lever position. In some situations, the vehicle is to roll without Fasten driver's safety belt.
  • Page 149 Driving CONTROLS Sport program M/S Activating manual mode Press the selector lever to the left from selec‐ Principle tor lever position D, arrow 1. The shifting points and shifting times in the Sport program are designed for sportier han‐ dling. The transmission, for instance shifts up later and the shifting times are shorter.
  • Page 150 Driving CONTROLS D is displayed in the instrument cluster. left shift paddles. This is not possible in short- term manual mode. Shift paddles Shifting Principle The shift paddles on the steering wheel allow you to shift gears quickly while keeping both hands on the steering wheel.
  • Page 151 Driving CONTROLS Engage selector lever position N Do not steer the steering wheel when driving off with Launch Control. Unlocking is possible, if the starter can crank the Additional information: engine. Breaking-in period, refer to page 302. Press and hold down brake pedal. Press the Start/Stop button.
  • Page 152 Driving CONTROLS After using Launch Control To increase driving stability, activate DSC Dy‐ namic Stability Control again as soon as possible. System limits An experienced driver may be able to achieve better acceleration values in DSC OFF mode. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 153: Displays

    Displays CONTROLS Displays Vehicle features and Overview options This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions. This also applies to safety-related functions and sys‐...
  • Page 154 Displays CONTROLS Assisted Driving View ▷ Navigation displays such as the map view or, if destination guidance is active, a route pre‐ view with route guidance information. Principle ▷ Displays showing service notifications. Depending on the equipment, information about ▷ Assisted Driving View.
  • Page 155 Displays CONTROLS "Instrument panel" ▷ Trip data. "Display Assisted Driving View when Driver ▷ Efficiency display. Assistance is active" Selecting Display Continue to press the button on the turn signal Example: the indicator/warning lights for the Ac‐ lever until the desired widget is selected. tive Cruise Control with Stop &...
  • Page 156 Displays CONTROLS General information Driving Display mode A Check Control message is displayed as a com‐ bination of indicator or warning lights and text COMFORT Average consumption. messages in the instrument cluster and, if appli‐ SPORT Current consumption. cable, in the Head-up Display. Energy recovery.
  • Page 157 Displays CONTROLS Display General information The indicator/warning lights can light up in a vari‐ Check Control ety of combinations and colors. At least one Check Control message is Several of the lights are checked for proper func‐ displayed or stored. tioning and light up temporarily when drive-ready state is switched on.
  • Page 158 Displays CONTROLS Brake system Intervene immediately by braking or make an evasive maneuver. Brake system impaired. Continue to drive Additional information: moderately. Pedestrian Warning with City Collision Mitigation, Have the vehicle checked immediately refer to page 196. by a dealer's service center or another qualified service center or repair shop.
  • Page 159 Displays CONTROLS Drive power DSC Dynamic Stability Control is deactivated or DTC Dynamic Reduced drive power due to an over‐ Traction Control is activated heated drivetrain. DSC is deactivated or DTC is activated. Additional information: Additional information: Power gauge, refer to page 163. ▷...
  • Page 160 Displays CONTROLS Additional information: Additional information: Tire pressure monitor, refer to page 329. Turn signal, refer to page 143. Steering system Parking lights Steering system may not be working. Parking lights are switched on. Have the system checked by a dealer's Additional information: service center or another qualified serv‐...
  • Page 161 Displays CONTROLS Manual Speed Limiter Steering Assistant The indicator light lights up: the system Indicator light lights up: the system sup‐ is switched on. ports the driver in keeping the vehicle within the lane. The indicator light flashes: the set speed limit has been exceeded.
  • Page 162 Displays CONTROLS Fuel gauge Additional information: Power gauge, refer to page 163. Principle Gray lights The current fill level of the fuel tank is displayed. Active Cruise Control with Stop&Go General information function Vehicle inclination may cause the display to vary. Indicator light is illuminated: the system Additional information: is interrupted.
  • Page 163 Displays CONTROLS When the setting for the driving mode view is ac‐ pending on the available drive power, the range tivated, the activated tachometer is only shown in for POWER is adjusted automatically. the COMFORT or SPORT driving mode. If needed, icons in the power gauge indicate a reduction of the drive power.
  • Page 164 Displays CONTROLS Display Operating state of the vehicle, refer to page 41. Engine oil temperature Display ▷ Cold engine: the pointer is at the low temperature end. Drive at moderate RPM and vehicle speeds. Full Black Panel Display. ▷ Normal operating tempera‐ ture: the pointer is in the mid‐...
  • Page 165 With a low remaining range, a Check Control Some information on service notifications can message is briefly displayed. With a sporty driv‐ also be shown on the BMW display key. ing style, for instance fast cornering, the engine function is not always ensured.
  • Page 166 Displays CONTROLS Symbols Steptronic transmission: displaying Sym‐ Description Suggestions to shift up or down are displayed in bols the instrument cluster. No service is currently required. On vehicles without a gear shift indicator, the en‐ gaged gear is displayed. Example Description The time for recommended mainte‐...
  • Page 167 Displays CONTROLS Display played. Speed limits with extra text characters are always displayed. Speed Limit Info Safety information Current speed limit. Without a navigation system the Warning traffic signals are grayed out after The system cannot serve as a substitute for the curves or longer stretches of driver’s personal judgment in assessing visibility roadway.
  • Page 168 Displays CONTROLS System limits If necessary, the corresponding menu will open on the Control Display. System limits of the sensors Display Additional information: ▷ Cameras, refer to page 37. Functional limitations The system may not be fully functional and may provide incorrect information in the following sit‐...
  • Page 169 Displays CONTROLS Trip data The following information is displayed: ▷ Total kilometers. ▷ Configured interval for displaying trip data. Principle ▷ Distance traveled depending on the config‐ Values for the trip, such as the average con‐ ured interval. sumption or trip kilometers, are displayed. ▷...
  • Page 170 Displays CONTROLS With the button on the turn signal lever: ▷ Torque. ▷ Power. Continue to press the button on the turn sig‐ nal lever until the widget for the trip data is Displays selected. "CAR" "Driving information" "Sport displays" Display in the instrument cluster The Sport displays can be displayed in form of widgets in the instrument cluster.
  • Page 171 Displays CONTROLS Display Symbols Description "Check Control messages": dis‐ Overview playing stored Check Control The following information is displayed on the messages, refer to page 156. Head-up Display: "Required services": displaying ▷ Vehicle speed. service notifications, refer to ▷ Navigation instructions. page 165.
  • Page 172 Displays CONTROLS Adjusting the height Visibility of the display "CAR" The visibility of the displays in the Head-up Dis‐ play is influenced by the following factors: "Settings" ▷ Seat position. "Displays" ▷ Objects on the cover of the Head-up Display. "Head-up display"...

  • Page 173: Lights

    Lights CONTROLS Lights Vehicle features and Icon Function options Automatic headlight control. Adaptive light functions. This chapter describes all standard, country-spe‐ Low beams. cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due Instrument lighting.
  • Page 174 Lights CONTROLS The indicator light in the instrument clus‐ After the drive-ready state is switched on, the ter is illuminated when the low beams are automatic headlight control will be activated. switched on. Low beams System limits Switching on The automatic headlight control cannot replace Press the button on the light switch ele‐...
  • Page 175 Lights CONTROLS Welcome lights Setting the duration "CAR" Principle "Settings" "Exterior lighting" The exterior lighting is switched on automatically when approaching or unlocking the vehicle. "Pathway lighting" Select the desired setting. General information "OK" Depending on the equipment, the exterior light‐ ing of the vehicle can be set individually.
  • Page 176 Lights CONTROLS Activating well as the vehicle load conditions in order to avoid blinding oncoming traffic. Press the button on the light switch ele‐ ment. Automatic High Beam The LED in the button lights up. Assistant The adaptive light functions are active when the drive-ready state is switched on.
  • Page 177 Lights CONTROLS Safety information The indicator light in the instrument clus‐ ter is illuminated when the low beams are switched on. Warning The headlights are automatically switched be‐ If adjustments have been made or the sensitiv‐ tween low beams and high beams. ity has been modified, oncoming traffic may be momentarily blinded.
  • Page 178 Lights CONTROLS Instrument lighting wagons; when driving close to train or ship traffic; or at animal crossings. ▷ In tight curves, on hilltops or in depressions, Functional requirement in crossing traffic or half-obscured oncoming The parking lights or low beams must be traffic on highways.
  • Page 179 Lights CONTROLS To switch off permanently: press the button and "Interior lighting" hold for approx. 3 seconds. "Brightness" Select the desired setting. Turning reading lights on/off Dynamic light Press the button. Individual actions, for example incoming calls or opened doors, are indicated by light effects. Ambient light "CAR"...
  • Page 180 Lights CONTROLS Turning speaker lighting on/off The speaker lighting is switched on when the ve‐ hicle is unlocked, and switched off when the ve‐ hicle is locked. Setting the brightness "CAR" "Settings" "Interior lighting" "Bowers & Wilkins" "Brightness" Select the desired setting. Online Edition for Part no.

  • Page 181: Safety

    Safety CONTROLS Safety Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 182 Vehicle modifications for a person with disabili‐ against the backrest when crossing the ties may affect the air bag system; contact BMW hands and the upper body is as far back as Customer Relations for further information.
  • Page 183 Safety CONTROLS Operational readiness of the Strength of the driver's and front airbag system passenger airbag Safety information General information The power that triggers the driver's/front passen‐ ger airbags depends on the position of the driv‐ Warning er's/front passenger seat. Individual components can be hot after trigger‐...
  • Page 184 Safety CONTROLS Automatic deactivation of ▷ Do not attach covers, cushions, ball mats or other items to the front passenger seat un‐ the front passenger airbags less they are specifically determined to be safe for use on the front passenger seat. Principle ▷...
  • Page 185 Safety CONTROLS straint system has been detected and the front passenger airbags are not activated. Warning After triggering or damage, system functionality is limited or not available anymore. There is a Rollover protection system risk of injury or danger to life. Have the system checked and replaced by a Principle dealer’s service center or another qualified...
  • Page 186 Safety CONTROLS Overview ▷ Approach control warning with light braking function. Button in the vehicle ▷ Evasion Assistant. ▷ Intersection collision warning. ▷ Daytime Pedestrian Collision Mitigation. ▷ Night Vision with pedestrian and animal de‐ tection. ▷ Lane departure warning. ▷...
  • Page 187 Safety CONTROLS Safety information Press the button repeatedly. The follow‐ ing settings are switched between: "ALL ON": all Intelligent Safety systems are Warning switched on. Basic settings are activated for the The system cannot serve as a substitute for the sub-functions, for instance setting for warning driver’s personal judgment in assessing visibility time.
  • Page 188 Safety CONTROLS Manual switching off Intelligent Safety Press and hold this button. All Intelligent Safety systems are Sensors switched off. The system is controlled by the following sen‐ sors: Button Status ▷ Cameras behind the windshield. Button lights up green: all Intelligent ▷...
  • Page 189 Safety CONTROLS The system may also assist in braking if there is Icon Measure a risk of collision. Icon lights up red: prewarning. When the vehicle is traveling at a low speed, the Brake and increase distance. vehicle may come to a complete stop. City brake function: the brake intervention occurs Symbol flashes red and an acoustic to up to approx.
  • Page 190 Safety CONTROLS Detection range ▷ In tight curves. ▷ If the driving stability control systems are lim‐ ited or deactivated, for instance DSC OFF. ▷ Up to 10 seconds after the start of the engine via the Start/Stop button. Warning sensitivity The more sensitive the warning settings are, for example the warning time, the more warnings are displayed.
  • Page 191 Safety CONTROLS Warning with evasion support Warning Display in the instrument cluster Indicators and warnings cannot serve as a sub‐ stitute for the driver’s personal judgment. Due If a collision with a detected vehicle or a detected to its limits, the system may not issue warnings person is imminent, a warning symbol appears or reactions, or these may be issued late or in a on the instrument cluster and in the Head-up...
  • Page 192 Safety CONTROLS of damage to property. Actively intervene as ▷ In tight curves. warranted. Refer to the information in this Own‐ ▷ If the driving stability control systems are lim‐ er’s Manual regarding the scope of the sys‐ ited or deactivated, for instance DSC OFF. tem’s operation and limitations.
  • Page 193 Safety CONTROLS Safety information Intelligent Safety Warning Sensors The system cannot serve as a substitute for the The system is controlled by the following sen‐ driver’s personal judgment in assessing visibility sors: and traffic situation. There is a risk of accident. ▷...
  • Page 194 Safety CONTROLS Manual switching off Icon Meaning Press and hold this button. Danger of collision with vehicle cross‐ All Intelligent Safety systems are ing from the right. switched off. Danger of collision with vehicle cross‐ Button Status ing from the left. Button lights up green: all Intelligent Danger of collision with vehicle for Safety systems are switched on.
  • Page 195 Safety CONTROLS Brake intervention Detection range The warning prompts the driver to intervene. The system may also assist in braking if there is a risk of collision. The vehicle can be decelerated to a standstill. The brake intervention can be interrupted by stepping on the accelerator pedal or by actively moving the steering wheel.
  • Page 196 Safety CONTROLS cess of premature or unjustified warnings and re‐ style to traffic conditions. Watch traffic closely actions. and actively intervene where appropriate. Pedestrian Warning with Warning City Collision Mitigation Due to system limits, individual functions can malfunction during tow-starting/towing with the Intelligent Safety systems activated.
  • Page 197 Safety CONTROLS Detection range Press the button repeatedly. The following settings are switched be‐ tween: "ALL ON": all Intelligent Safety systems are switched on. Basic settings are activated for the subfunctions. "INDIVIDUAL": the Intelligent Safety systems are switched on according to the individual settings. Some Intelligent Safety systems cannot be indi‐...
  • Page 198 Safety CONTROLS to activate the Brake Assistant function, the ▷ Partially covered pedestrians. brakes must be applied sufficiently quickly and ▷ Pedestrians that are not detected as such be‐ forcefully. cause of the viewing angle or contour. If there is a risk of collision, the system may also ▷...
  • Page 199 Safety CONTROLS Thermal image In addition, the system also detects animals above a certain minimum size, for instance deer. Display on the Control Display with thermal im‐ age activated: ▷ People detected by the system: in light yel‐ low. ▷ Animals detected by the system: in dark yel‐...
  • Page 200 Safety CONTROLS Turning on style to traffic conditions. Watch traffic closely and actively intervene where appropriate. Turning on automatically When it is dark outside, the system is automati‐ Overview cally active after every driving off. Buttons in the vehicle Switching on the thermal image The thermal image from the Night Vision camera can be displayed on the Control Display in addi‐...
  • Page 201 Safety CONTROLS The displayed icon may vary and shows the side Prewarning for animals is displayed when an ani‐ of the road on which the person or animal was mal is detected in the front of the vehicle. detected. If a prewarning is issued, intervene by braking or making an evasive maneuver.
  • Page 202 Safety CONTROLS Lane departure warning manner that is not consistent with their normal use. There is a risk of accident. Adjust driving style to traffic conditions. Watch traffic closely Principle and actively intervene where appropriate. The lane departure warning alerts when the vehi‐ cle is about to run off the road or exit the lane.
  • Page 203 Safety CONTROLS Switching on manually Setting the warning time "CAR" Press the button. "Settings" The menu for the Intelligent Safety sys‐ tem is displayed. "Driver Assistance" If all Intelligent Safety systems were switched off, "Safety and Warnings" all systems are now switched on. "Lane Departure Warning"...
  • Page 204 Safety CONTROLS Depending on the national-market version, the The warning signal and Check Control message steering intervention is automatically active after are an encouragement to pay closer attention to every driving off. the lane. Display in the instrument cluster End of warning For instance, the warning will be canceled in the The icon illuminates green: at lane mark‐...
  • Page 205 Safety CONTROLS ▷ With lane boundaries that are covered by ob‐ Before you change lanes after setting the turn jects. signal, the system issues a warning in the situa‐ tions described above. ▷ When driving very close to the vehicle in front of you.
  • Page 206 Safety CONTROLS Overview Press the button repeatedly. The following settings are switched be‐ Button in the vehicle tween: "ALL ON": all Intelligent Safety systems are switched on. Basic settings are activated for the subfunctions. "INDIVIDUAL": the Intelligent Safety systems are switched on according to the individual settings.
  • Page 207 Safety CONTROLS "Vibration intensity" The warning stops when the other vehicle has left the critical area or the turn signal has been Select the desired setting. deactivated. The setting is applied to all Intelligent Safety sys‐ tems. Vehicles with side collision mitigation Vehicles with side collision When there is no response to the vibration of the...
  • Page 208 Safety CONTROLS Side collision mitigation System limits of the sensors Additional information: ▷ Radar sensors, refer to page 38. Principle ▷ On vehicles with side collision warning: cam‐ The side collision warning helps to avoid immi‐ eras, refer to page 37. nent side collisions.
  • Page 209 Safety CONTROLS Turning on/off Warning Turning on automatically Indicators and warnings cannot serve as a sub‐ stitute for the driver’s personal judgment. Due The side collision mitigation activates automati‐ to its limits, the system may not issue warnings cally after departure if the function was switched or reactions, or these may be issued late or in a on at the completion of the last trip.
  • Page 210 Safety CONTROLS If necessary, an active steering intervention takes Button Status place to prevent the collision and maintain the Button lights up green: all Intelligent vehicle within its own lane. Safety systems are switched on. The steering intervention can be noticed on the steering wheel and can be manually overridden Button lights up orange: some Intelli‐...
  • Page 211 Safety CONTROLS Safety information ▷ When driving very close to the vehicle in front of you. ▷ Up to 10 seconds after the start of the engine Warning via the Start/Stop button. The system cannot serve as a substitute for the A Check Control message is displayed when the driver’s personal judgment in assessing visibility system is not fully functional.
  • Page 212 Safety CONTROLS The system is deactivated in the following situa‐ tions, the vehicle is brought to a standstill on the tions: actual road. ▷ When driving in reverse. Overview System limits System limits of the sensors Additional information: ▷ Radar sensors, refer to page 38. Functional limitations The system may not be fully functional in the fol‐...
  • Page 213 Displays in the instrument cluster BMW Drive Recorder Icon Status Emergency Stop function active. Principle The BMW Drive Recorder stores brief video re‐ cordings of the vehicle surroundings, e.g., to document surrounding traffic. Without lane change function: Icon Status General information Green steering wheel symbol: There are various ways for storing video record‐...
  • Page 214 Activating/deactivating the BMW selector lever position P. Drive Recorder "Apps" The BMW Drive Recorder must be activated be‐ "Drive Recorder" fore the first use of the recording function. "Saved recordings" "Apps"...
  • Page 215 Safety CONTROLS PostCrash – iBrake Settings General information Principle Different settings can be made. In the event of an accident, PostCrash can bring the vehicle to a halt automatically without inter‐ Recording type vention by the driver in certain situations. "Apps"...
  • Page 216 Safety CONTROLS Safety information "General settings" "Fatigue and Focus Alert" Select the desired setting. Warning The system cannot serve as a substitute for the Display driver’s personal judgment in assessing one's If the driver becomes less alert or fatigued, a physical state.

  • Page 217: Driving Stability Control Systems

    Driving stability control systems CONTROLS Driving stability control systems Vehicle features and Adaptive brake assistant options In combination with Active Cruise Control ACC, this system ensures that the brakes respond This chapter describes all standard, country-spe‐ even more rapidly when braking in critical situa‐ cific and optional features offered with the series.
  • Page 218 Driving stability control systems CONTROLS Deactivating/activating DSC ▷ Skidding, which can lead to oversteering. ▷ Loss of adhesion of the front wheels, which General information can lead to understeering. When DSC is deactivated, driving stability is re‐ Safety information duced during acceleration and when driving in curves.
  • Page 219 Driving stability control systems CONTROLS DTC Dynamic Traction Activating/deactivating DTC Control Activating DTC Press the button. Principle TRACTION is displayed in the instru‐ Dynamic Traction Control (DTC) is a version of ment cluster and the indicator light for DSC OFF the Dynamic Stability Control (DSC) where drive lights up.
  • Page 220 Driving stability control systems CONTROLS namic Stability Control (DSC), further optimizes At higher speeds, the rear wheels are turned in traction and driving dynamics. the same direction as the front wheels. For in‐ stance, this results in a harmonious lane change. General information In critical driving situations, the Integral Active Steering can stabilize the vehicle through pur‐...
  • Page 221 Driving stability control systems CONTROLS Have the system checked by a dealer's service center or another qualified service center or re‐ pair shop. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 222: Driver Assistance Systems

    Driver assistance systems CONTROLS Driver assistance systems Vehicle features and Operation options Turning on Press the button on the steering wheel. This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are The current speed is accepted as the speed not necessarily available in your vehicle, e.g., due limit.
  • Page 223 Driver assistance systems CONTROLS Changing the speed limit Warning when the speed limit is exceeded Visual warning If the speed limit is exceeded: the indica‐ tor light in the instrument cluster flashes while the vehicle speed is greater than the set speed limit. Acoustic warning Press the rocker switch up or down repeatedly ▷...
  • Page 224 Driver assistance systems CONTROLS Cruise control Warning The set speed can be incorrectly adjusted or Principle called up by mistake. There is a risk of accident. With the Cruise Control, a set speed can be ad‐ Adjust the set speed to the traffic conditions. justed using the buttons on the steering wheel.
  • Page 225 Driver assistance systems CONTROLS DSC Dynamic Stability Control is switched on, if The stored speed is displayed on the speedom‐ necessary. eter. DSC Dynamic Stability Control is switched on, if Turning off necessary. Depending on the equipment version, The speed can also be stored by pressing a but‐ press the relevant button on the steer‐...
  • Page 226 Driver assistance systems CONTROLS Continuing cruise control The icon is displayed when the set speed is reached. An interrupted cruise control can be continued by calling up the stored speed. System limits Make sure that the difference between current speed and stored speed is not too large before The set speed is also maintained downhill.
  • Page 227 Driver assistance systems CONTROLS Safety information ▷ When fast approaching a slowly moving vehicle. ▷ Vehicle suddenly swerving into own lane. Warning ▷ When fast approaching standing vehicles. The system cannot serve as a substitute for the There is a risk of injury or danger to life. Watch driver’s personal judgment in assessing the traffic closely and actively intervene where ap‐...
  • Page 228 Driver assistance systems CONTROLS Set function Button Function When the system is active, press the Reduce distance. button repeatedly until the desired func‐ Switch distance control on/off. tion is selected in the toolbar. The toolbar for As‐ sisted Driving mode is displayed at the bottom of Rocker switch: the instrument cluster.
  • Page 229 Driver assistance systems CONTROLS Setting the speed With steering and traffic jam assistant. Maintaining and storing the speed Without steering and traffic jam assis‐ tant. The displays turn off. The stored set speed is deleted. Interrupting manually When active, press the button on the steering wheel: With steering and traffic jam assistant.
  • Page 230 Driver assistance systems CONTROLS ▷ Each time the rocker switch is tapped to the according to the traffic situation or the ambient resistance point, the set speed increases or conditions, for instance poor visibility. decreases by 1 mph/1 km/h. "CAR" ▷...
  • Page 231 Driver assistance systems CONTROLS Changing between cruise control Display in the speedometer with/without distance control Depending on the equipment, a mark in the speedometer displays the status of the system. Safety information ▷ Green marking: system is ac‐ tive, the marking indicates the desired speed.
  • Page 232 Driver assistance systems CONTROLS Detected vehicle Icon Description Symbol flashes gray: Icon Description The conditions are not adequate Green icon: for the system to work. A vehicle has been detected The system was deactivated but ahead of you. applies the brakes until you ac‐ tively resume control by press‐...
  • Page 233 Driver assistance systems CONTROLS Displays in the Head-up Display Two-wheeled vehicles for instance might not be detected. Set speed Deceleration Some system information can also be displayed in the Head-up Display. The system does not decelerate in the following situations: The icon is displayed when the set speed is reached.
  • Page 234 Driver assistance systems CONTROLS Cornering Weather The following restrictions can occur under unfav‐ orable weather or light conditions: ▷ Poorer vehicle detection. ▷ Short-term interruptions for vehicles that are already recognized. Drive attentively, and react to the current traffic situation. If necessary, intervene actively, for in‐ stance by braking, steering or evading.
  • Page 235 Driver assistance systems CONTROLS Safety information ▷ "Adjust manually": detected speed limits can be applied manually. ▷ "Show anticipation": current and upcom‐ Warning ing speed limits are displayed in the in‐ The system cannot serve as a substitute for the strument cluster without being applied.
  • Page 236 Driver assistance systems CONTROLS Steering Assistant Adapt to route Principle Principle The system can be configured so that the vehi‐ The Steering Assistant helps keep the vehicle in cle adapts the speed automatically to the route. the lane. For this purpose, the system executes For instance, the speed will be reduced in the supporting steering movements, for instance following situations, if necessary:...
  • Page 237 Driver assistance systems CONTROLS ▷ Cameras behind the windshield. Set function ▷ Front radar sensor. When the system is active, press the button repeatedly until the desired func‐ ▷ Radar sensors, side, front. tion is selected in the toolbar. The toolbar for As‐ ▷...
  • Page 238 Driver assistance systems CONTROLS The system does not perform supportive steer‐ Icon Description ing wheel movements. Yellow flashing steering wheel symbol: Interrupting automatically Lane marking driven over. The system interrupts the supporting steering The steering wheel vibrates movements automatically, for example in the fol‐ where applicable.
  • Page 239 Driver assistance systems CONTROLS Displays on the steering wheel Icon Description Depending on equipment, yel‐ low flashing steering wheel sym‐ bol: Lane marking driven over. The steering wheel vibrates where applicable. Yellow steering wheel symbol and a signal sounds, if applica‐ ble: The two LED lights above the buttons illuminate analogously to the displays in the instrument...
  • Page 240 Driver assistance systems CONTROLS Extended Traffic Jam warranted. Refer to the information in this Own‐ er’s Manual regarding the scope of the sys‐ Assistant tem’s operation and limitations. Principle System limits of the sensors Extended Traffic Jam Assistant supports the Additional information: driver with vehicle control in traffic jam situations.
  • Page 241 Driver assistance systems CONTROLS Displays in the instrument ▷ The function is only available on certain street types, e.g. freeways. cluster ▷ Driving on a road without pedestrians or cy‐ clists. Icon Description ▷ Sufficient lane width. Indicator light green: system is ▷...
  • Page 242 Driver assistance systems CONTROLS System limits Safety information General information Warning The limits of the Steering and Lane Control As‐ The system cannot serve as a substitute for the sistant system apply. driver’s personal judgment in assessing the Additional information: traffic situation.
  • Page 243 Driver assistance systems CONTROLS Changing lanes Displays in the instrument cluster Ensure that the traffic situation permits changing lanes. Icon Description Press the turn signal lever in the required di‐ rection to the pressure point for signaling Green steering wheel symbol. briefly.
  • Page 244 Driver assistance systems CONTROLS Depending on the Icon Description equipment version: lane Green steering wheel symbol. change with active Gray line for lane marking on the appropriate side. guidance Green arrow symbol for lane- changing. Principle The system carries out a lane The system assists the driver when lane change.
  • Page 245 Driver assistance systems CONTROLS Turn on adaptation to the course ▷ Adaptation to the course of the route is acti‐ vated. of the route ▷ The function must be available in the country "CAR" in which the vehicle is driven. "Settings"...
  • Page 246 Driver assistance systems CONTROLS ▷ Surround View with rearview camera, refer to page 260. Warning ▷ Panorama View, refer to page 265. Due to high speeds when PDC Park Distance Control is activated, the warning can be de‐ ▷ Remote 3D View, refer to page 267. layed due to physical circumstances.
  • Page 247 Driver assistance systems CONTROLS Warning ▷ If selector lever position R is engaged when the engine is running. Signal tones ▷ Depending on the equipment version: while approaching detected obstacles at a speed slower than approx. 2.5 mph/4 km/h. The ac‐ General information tivation distance depends on the situation in An intermittent tone indicates when the vehicle...
  • Page 248 Driver assistance systems CONTROLS Visual warning of damage to property. Actively intervene as warranted. Refer to the information in this Own‐ er’s Manual regarding the scope of the sys‐ tem’s operation and limitations. System limits of the sensors Additional information: ▷...
  • Page 249 Driver assistance systems CONTROLS Depending on equipment Additionally, the safety information for the PDC Park Distance Control and the Automatic Parking version: emergency brake Assistant apply. function, Active PDC Additional information: ▷ PDC Park Distance Control, refer to page 246. Principle ▷...
  • Page 250 Driver assistance systems CONTROLS General information ▷ Color markings: warning against detected ob‐ stacles. The system uses the ultrasonic sensors of the ▷ Gray markings, hatched area: no obstacles Park Distance Control PDC and the Parking As‐ were detected. sistant. ▷...
  • Page 251 Driver assistance systems CONTROLS Depending on the vehicle and vehicle surroundings closely and actively intervene where appropriate. equipment: switching on/off manually Overview Press the park assistance button. Depending on the vehicle ▷ On: the LED lights up. equipment: button in the vehicle ▷...
  • Page 252 Driver assistance systems CONTROLS More than one assistance function can be active Parking using lanes and turning circle lines at the same time. Position the vehicle so that the red turning circle line leads to within the limits of the Parking aid lines parking space.
  • Page 253 Driver assistance systems CONTROLS System limits ▷ When parking parallel to the road, parallel parking. System limits of the sensors ▷ When parking in reverse perpendicular to the road, perpendicular parking. The system ori‐ Additional information: ents itself with the middle of the parking ▷...
  • Page 254 Driver assistance systems CONTROLS Functional requirements closely and actively intervene where appropri‐ ate. For the measurement od parking spaces NOTICE ▷ Maximum speed while driving forward approx. The system can steer the vehicle over or onto 22 mph/35 km/h. curbs. There is a risk of damage to property, ▷...
  • Page 255 Driver assistance systems CONTROLS Switching on with reverse gear ▷ Parking assistant is activated and parking space search is active. Shift into reverse. ▷ Control Display shows suitable parking The current status of the parking space spaces at the edge of the road next to the ve‐ search is indicated on the Control Display.
  • Page 256 Driver assistance systems CONTROLS Parking using the Automatic ▷ When the driver grasps the steering wheel or takes over steering. Parking Assistant ▷ Possibly on snow-covered or slippery road. Parking ▷ When there are obstacles that are hard to overcome, such as curbs. Switching on and activating the parking assis‐...
  • Page 257 Driver assistance systems CONTROLS System limits Malfunction A Check Control message is displayed. Safety information The Automatic Parking Assistant has malfunc‐ tioned. Have the system checked by a dealer's service center or another qualified service center Warning or repair shop. The system is designed to operate in certain conditions and circumstances.
  • Page 258 Driver assistance systems CONTROLS closely and actively intervene where appropri‐ The system takes control of the maneuver. A ate. message will be displayed at the end of the maneuver. Additionally, the safety information for the PDC Make sure that the traffic situation permits Park Distance Control and the Automatic Parking driving out of the parking space and drive off Assistant apply.
  • Page 259 Driver assistance systems CONTROLS Safety information Take your hands off the steering wheel and carefully drive off with the accelerator pedal and the brake. Warning When driving in reverse, pay attention to the The system cannot serve as a substitute for the vehicle's surroundings, and if you encounter driver’s personal judgment in assessing the an obstacle, stop immediately and take over...
  • Page 260 Driver assistance systems CONTROLS ▷ After driving a stored distance with major Depending on the view, the vehicle's surround‐ steering-wheel angles, the function of the ings or a part of it is depicted. system will be limited for the return trip. Additionally, assistance functions are shown in ▷...
  • Page 261 Driver assistance systems CONTROLS Sensors Display on the Control Display The system is controlled by the following sen‐ Overview sors: ▷ Front camera. ▷ Top view cameras. ▷ Rearview camera. Additional information: Sensors of the vehicle, refer to page 37. Turning on/off Turning on automatically 1 Toolbar, left...
  • Page 262 Driver assistance systems CONTROLS Automatic camera perspective ▷ "Parking aid lines". ▷ "Obstacle mark.". The automatic camera perspective shows a steering-dependent view in the respective driv‐ ▷ "Settings": apply settings, for instance to ing direction. use the activation points for Panorama View. This perspective adapts to the respective driving Rearview camera situation.
  • Page 263 Driver assistance systems CONTROLS Car wash view Turning circle lines show the course of the small‐ est possible turning radius on a level road. Only one turning circle line is displayed after the steering wheel is turned past a certain angle. Parking using lanes and turning circle lines Position the vehicle so that the red turning circle line leads to within the limits of the...
  • Page 264 Driver assistance systems CONTROLS Setting brightness and contrast The system does not detect whether an obstacle moves later on. For this reason, at standstill, the Brightness and contrast can be adjusted with markings are not shown anymore in the display Surround View or Panorama View switched on.
  • Page 265 Driver assistance systems CONTROLS Additional information: Depending on the equipment version, the func‐ tion can only be used when driving forward. PDC Park Distance Control, refer to page 246. Additional information: Malfunction Surround View, refer to page 260. A camera malfunction is displayed on the Control Safety information Display.
  • Page 266 Driver assistance systems CONTROLS Display on the Control Display Using activation points The use of activation points can be switched on Press the button when the engine is run‐ and off. ning. Depending on the driving direction, the image of Press the button.
  • Page 267 Switching on/off individually Plus: Remote 3D View Pre-adjustment "CAR" Principle "Settings" The BMW app and the pictures of the Surround "General settings" View cameras in combination with the corre‐ "Data privacy" sponding equipment enable the display of the "Select services individually"...
  • Page 268 Driver assistance systems CONTROLS Cross traffic warning Overview Button in the vehicle Principle At blind driveway exits or when driving out of per‐ pendicular parking spaces, road users approach‐ ing from the side are detected sooner by the cross traffic warning than is possible from the driver's seat.
  • Page 269 Driver assistance systems CONTROLS Display in the PDC Park Distance "Cross Traffic Warning" Control view "Cross traffic warning" Turning on automatically If the system was activated on the Control Dis‐ play, it is automatically switched on as soon as PDC Park Distance Control or Panorama View is active and a gear is engaged.
  • Page 270 Driver assistance systems CONTROLS System limits System limits of the sensors Additional information: ▷ Radar sensors, refer to page 38. Functional limitations The system may be limited in the following situa‐ tions: ▷ In tight curves. ▷ When crossing objects move at a very slow or a very fast speed.

  • Page 271: Driving Comfort

    Driving comfort CONTROLS Driving comfort Vehicle features and depending on the equipment, the selected driv‐ ing mode. options Additional information: Driving Dynamics Control, refer to page 138. This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are Active roll stabilization not necessarily available in your vehicle, e.g., due...
  • Page 272 Driving comfort CONTROLS The Adaptive M Chassis Professional encom‐ passes the following systems: ▷ Low-lying sport chassis. ▷ Adaptive M chassis. ▷ Active roll stabilization. General information For active control, this system uses the available information, for instance from the navigation sys‐ tem or the Driving style analysis.

  • Page 273: Climate Control

    Climate control CONTROLS Climate control Vehicle features and Automatic climate control options Overview This chapter describes all standard, country-spe‐ Buttons in the vehicle cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 274 Climate control CONTROLS ▷ Air distribution, manual. Button Function ▷ Defrosting the windshield Seat and armrest heating, refer to page 125. Turning off Complete system: ▷ Button on the driver's side: Active seat ventilation, refer to page 127. Press and hold the button until the integrated automatic climate control Air conditioning.
  • Page 275 Climate control CONTROLS Temperature of the ventilation Via iDrive: "CAR" General information "Settings" The temperature of the ventilation in the upper "Climate control" body region can be adjusted. "Heating/ventilation" The air flow of the ventilation in the upper body "A/C" region heats or cools noticeably, depending on the adjusted temperature.
  • Page 276 Climate control CONTROLS The air flow, air distribution, and the temperature Via iDrive: are controlled automatically depending on the in‐ "CAR" terior and outside temperature and the desired "Settings" temperature setting including the selected inten‐ sity. "Climate control" "Heating/ventilation" Switching the AUTO program on/off "Driver"...
  • Page 277 Climate control CONTROLS Switching automatic recirculated-air If there is window condensation, switch off recir‐ culated-air mode or defog the windows. control on/off "CAR" Air flow, manual "Settings" "Climate control" Principle "Air quality" The air flow for climate control can be adjusted "Automatic"...
  • Page 278 Climate control CONTROLS SYNC program Rear window defroster Principle Principle The Sync program can be used to apply the set‐ Ice and condensation are removed from the rear tings on the driver's side to the passenger’s side. window quickly. Switching the SYNC program on/off Functional requirement "CAR"...
  • Page 279 Climate control CONTROLS Direct ventilation Functional requirements The air flow is directed towards the passengers. ▷ The vehicle is in idle state or standby state The air flow heats or cools noticeably, depending and not in drive-ready state. on the adjusted temperature. ▷...
  • Page 280 A minimum of 10 minutes should pass between Turning on setting/activating the departure time and the Switch on the display of the BMW display planned departure time to allow a sufficient pe‐ key. riod of time for the climate control.
  • Page 281 Activate the desired departure time. sufficient ventilation, e.g. in enclosed garages. Via BMW display key Switch on the display of the BMW display Warning key. When stationary climate control is in operation, "Preconditioning setting"...
  • Page 282 The automatic engine start must be enabled be‐ fore using the system. Otherwise, the engine Switching on via BMW display key cannot switch on automatically to climatize the Switch on the display of the BMW display car's interior. key. Via iDrive: "Preconditioning setting"...
  • Page 283 The system will be available again as soon as the drive-ready state is acti‐ BMW display key vated and deactivated again. Switch on the display of the BMW display Observe the information about the intended use key. of the vehicle.
  • Page 284 Climate control CONTROLS The parking lights are switched on as long as the system is switched on. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 285: Interior Equipment

    Interior equipment CONTROLS Interior equipment Vehicle features and Safety information options Warning This chapter describes all standard, country-spe‐ The operation of remote-controlled systems cific and optional features offered with the series. with the integrated universal remote control, It also describes features and functions that are such as the garage door, may result in injury, not necessarily available in your vehicle, e.g., due for example, body parts becoming jammed in a...
  • Page 286 Interior equipment CONTROLS Control elements on the interior Canada: if programming with the hand-held transmitter was interrupted, hold down the in‐ mirror terior mirror button and repeatedly press and release the hand-held transmitter button for 2 seconds. 6. ▷ The LED lights up green: programming completed.
  • Page 287 Interior equipment CONTROLS Synchronizing the universal remote control with Release the button. the system: ▷ The LED flashes fast: the hand-held transmitter was detected but program‐ Park the vehicle within range of the remote- ming is not complete. controlled system. Press the button on the interior mirror for Program the relevant button on the interior 2 seconds and release.
  • Page 288 Interior equipment CONTROLS Ashtray Deleting stored functions All stored functions will be deleted. The func‐ tions cannot be deleted individually. Front center console Press and hold the two outer buttons on the in‐ terior mirror simultaneously for approximately Opening 10 seconds until the LED on the interior mirror Press onto the cover.
  • Page 289 Interior equipment CONTROLS Emptying NOTICE Pull the ashtray with the closed cover out of the cup holder. If metal objects fall into the socket, they can cause a short circuit. There is a risk of damage to property, among other potential damage. In‐ sert the cigarette lighter or socket cover again after using the socket.
  • Page 290 Interior equipment CONTROLS Sockets Front center armrest Principle The lighter socket can be used as a socket for electrical equipment when standby and drive- ready state are switched on. General information The total load of all sockets must not exceed 140 watts at 12 volts.
  • Page 291 Qi standard. potential damage. Make sure that the area of movement of the cover is clear while opening ▷ Charging the BMW Display key. and closing it. General information When inserting the mobile phone, make sure there are no objects between it and the wireless charging tray.
  • Page 292 Interior equipment CONTROLS During charging, the surface of the tray and the charging mobile devices, make sure there are mobile phone may become warm. Higher tem‐ no objects between the device and the tray. peratures may lead to a reduction in the charge current through the mobile phone, and in iso‐...
  • Page 293 Interior equipment CONTROLS Operation The forgotten warning is displayed in the instru‐ ment cluster. Inserting the mobile phone Activating The mobile phone must not exceed the maxi‐ "CAR" mum size of approximately 6.0 x 3.1 x 0.7 in/154.5 x 80 x 18 mm. "Settings"...
  • Page 294 BMW dealer. You must not remove the booster from the car nor use it with any other than the preinstalled coupling device or antenna.

  • Page 295: Storage Compartments

    Storage compartments CONTROLS Storage compartments Vehicle features and Front passenger side glove options compartment This chapter describes all standard, country-spe‐ Safety information cific and optional features offered with the series. It also describes features and functions that are Warning not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 296 Storage compartments CONTROLS Closing the storage integrated key, for instance when the vehicle is parked by valet parking. compartment Additional information: Pull the cover on the handle bar back. Integrated key, refer to page 94. Center armrest, front Compartments in the doors General information General information A storage compartment is located in the center...
  • Page 297 Storage compartments CONTROLS not force objects into the cup holder. Use light‐ weight, shatterproof, and sealable containers. Do not transport hot beverages. Opening the cup holder Press onto the cover. Two cup holders are located in the center con‐ sole. Closing the cup holder Pull the cover on the handle bar back.

  • Page 298: Cargo Area

    Cargo area CONTROLS Cargo area Vehicle features and Warning options Improperly stowed objects can shift and be thrown into the car's interior, for instance in the This chapter describes all standard, country-spe‐ event of an accident or during braking and eva‐ cific and optional features offered with the series.
  • Page 299 Cargo area CONTROLS Lashing eyes in the cargo cargo and luggage load capacity calculated in Step 4. area If your vehicle will be towing a trailer, load from your trailer will be transferred to your ve‐ General information hicle. Consult this manual to determine how this reduces the available cargo and luggage Attach load securing aids, such as lashing straps, load capacity of your vehicle.
  • Page 300 Cargo area CONTROLS Opening the storage Warning compartment The stability of the child restraint system is lim‐ ited or compromised with incorrect seat setting or improper installation of the child seat. There is a risk of injury or danger to life. Make sure that the child restraint system fits securely against the backrest.
  • Page 301 Cargo area CONTROLS Folding back the backrest Return the rear seat backrest to the seat position and engage it. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 302: Driving Tips

    Things to remember when driving DRIVING TIPS Things to remember when driving Vehicle features and Engine, transmission, and axle drive options Up to 1,200 miles/2,000 km This chapter describes all standard, country-spe‐ Do not exceed the maximum engine and road cific and optional features offered with the series.
  • Page 303 Things to remember when driving DRIVING TIPS General driving notes Hot exhaust gas system Closing the trunk lid Warning High temperatures can occur underneath the Safety information body, for instance caused by the exhaust gas system, while driving. Contact with the exhaust gas system can cause burns.
  • Page 304 Things to remember when driving DRIVING TIPS contact between the tires and the road surface, tional noises have no effect on the performance ultimately undermining your ability to steer and and operational reliability of the brake. brake the vehicle. Objects in the area around the Driving through water pedals General information...
  • Page 305 Things to remember when driving DRIVING TIPS Condensation water under the brake system may overheat and reduce braking effect. parked vehicle You can increase the engine's braking effect by When using the automatic climate control, con‐ shifting down, going all the way to first gear, if densation water develops and collects under‐...

  • Page 306: Saving Fuel

    Saving fuel DRIVING TIPS Saving fuel Vehicle features and Tires options General information Tires can affect consumption in various ways, for This chapter describes all standard, country-spe‐ instance tire size may influence consumption. cific and optional features offered with the series. It also describes features and functions that are Check the tire pressure regularly not necessarily available in your vehicle, e.g., due...
  • Page 307 Have maintenance carried out Have the vehicle maintained regularly to achieve optimal vehicle efficiency and service life. BMW recommends that maintenance work be per‐ formed by a BMW service center. Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 308 Saving fuel DRIVING TIPS Overview Activating/deactivating ECO PRO functions The following ECO PRO functions can be acti‐ vated/deactivated: ▷ "Coasting" ▷ "ECO PRO seat heating" ▷ "ECO PRO climate control" ▷ "ECO PRO light and sight" Coasting Button Efficiency can be optimized by disengaging the engine and coasting with the engine idling.
  • Page 309 Saving fuel DRIVING TIPS ECO PRO bonus range ▷ Depending on the equipment: the total dis‐ tance driven while coasting. A modified driving style helps you ▷ The total time that the engine has been extend your driving distance. switched off during automatic engine stops. The range extension can be dis‐...
  • Page 310 Saving fuel DRIVING TIPS General information Display Coasting is a component of the ECO PRO driv‐ Display in the instrument cluster ing mode. The coasting distance traveled is indicated Coasting is automatically activated when ECO in coasting mode. PRO driving mode is called via the Driving Dy‐ namics Control.
  • Page 311 Saving fuel DRIVING TIPS Driving style analysis Principle The function helps develop an especially effi‐ cient driving style and to conserve fuel. For this purpose, the driving style is analyzed. The assessment is done in various categories and is displayed on the Control Display. This display will help you adjust your driving style and save some fuel.

  • Page 312: Mobility

    Refueling MOBILITY Refueling Vehicle features and Safety information options NOTICE This chapter describes all standard, country-spe‐ With a driving distance of less than cific and optional features offered with the series. 30 miles/50 km the engine may no longer have It also describes features and functions that are sufficient fuel.
  • Page 313 Refueling MOBILITY Turn the fuel cap counterclockwise. Have fuel filler flap unlocked by a dealer’s service center or another qualified service center or re‐ pair shop. Place the fuel cap in the bracket attached to the fuel filler flap. Closing Warning The retaining strap of the fuel cap can be jam‐...

  • Page 314: Wheels And Tires

    Wheels and tires MOBILITY Wheels and tires Vehicle features and Tire pressure specifications options In the tire inflation pressure table The tire inflation pressure table, refer to This chapter describes all standard, country-spe‐ page 314, contains all tire inflation pressure cific and optional features offered with the series.
  • Page 315 Wheels and tires MOBILITY Checking using tire inflation The corrected tire inflation pressures are applied automatically. Make sure that the correct tire set‐ pressure specifications in the tire tings have been made. inflation pressure table With tires that cannot be found in the tire pres‐ Determine the intended tire inflation pressure sure values on the Control Display, reset the Tire levels for the mounted tires.
  • Page 316 Wheels and tires MOBILITY 840i xDrive Tire size Pressure specifica‐ tions in bar/PSI Tire size Pressure specifica‐ 245/40 R 19 98 H XL 2.2 / 32 2.7 / 39 tions in bar/PSI Specifications in 245/40 R 19 98 V XL bar/PSI with cold tires Front: 245/45 R 18 2.2 / 32...
  • Page 317 Wheels and tires MOBILITY Tire inflation pressures at max. Tire size Pressure specifica‐ speeds above 100 mph/160 km/h tions in bar/PSI Rear: 275/40 R 18 2.3 / 33 103 V XL M+S Warning In order to drive at maximum speeds in excess Front: 245/40 R 19 2.2 / 32 of 100 mph/160 km/h, please observe, and, if...
  • Page 318 Wheels and tires MOBILITY Tire size Pressure specifica‐ Tire size Pressure specifica‐ tions in bar/PSI tions in bar/PSI Rear: 275/35 R 19 2.8 / 41 Front: 245/40 R 19 2.7 / 39 100 H XL A/S 98 H XL A/S Rear: 275/35 R 19 2.9 / 42 Front: 245/45 R 18...
  • Page 319 Wheels and tires MOBILITY Uniform Tire Quality Grading Rating – GAWR. Note, front vs. rear GAWR and tire loads, respectively. Quality grades can be found where applicable on the tire sidewall between tread shoulder and Speed letter maximum section width. E.g.: Treadwear 200;...
  • Page 320 Wheels and tires MOBILITY Temperature Winter tires The temperature grades are A, the highest, B, Do not drive with a tire tread of less than and C, representing the tire's resistance to the 0.16 in/4 mm, as such tires are less suitable for generation of heat and its ability to dissipate heat winter operation.
  • Page 321 Wheels and tires MOBILITY Changing wheels and tires ▷ Unusual vibrations. ▷ Unusual tire or running noises. ▷ Unusual handling such as a strong tendency Mounting and wheel balancing to pull to the left or right. Have mounting and wheel balancing carried out Damage can be caused by the following situa‐...
  • Page 322 Wheels and tires MOBILITY Drive conservatively for the first 200 miles/300 km. Warning Mounted steel wheels can cause technical Retreaded tires problems, for instance unexpected loosening of the lug bolts and damage to the brake discs. There is a risk of accident. Do not mount steel Warning wheels.
  • Page 323 Wheels and tires MOBILITY Rotating wheels between axles Follow the instructions for continued driving with a flat tire. Warning Safety information Rotating tires between the axles on vehicles with different tire sizes or rim sizes on the front Warning and rear axles can cause damage to the tires and the vehicle.
  • Page 324 Wheels and tires MOBILITY Overview hazardous area in a safe place, such as be‐ hind a guardrail. Storage ▷ If necessary, set up a warning triangle at an appropriate distance. Tire repair set Principle With the tire repair set, minor tire damage can be sealed temporarily to enable continued driving.
  • Page 325 Wheels and tires MOBILITY 3 Tire pressure display NOTICE 4 Reduce tire inflation pressure button The compressor can overheat during extended 5 On/off switch operation. There is a risk of damage to prop‐ 6 Compressor erty, among other potential damage. Do not run 7 Connector/cable for socket the compressor for more than 10 minutes.
  • Page 326 Wheels and tires MOBILITY Checking and adjusting the tire Screw the filler hose of the sealant bottle onto the tire valve of the nonworking wheel. inflation pressure Checking Switch off the compressor. Read the tire pressure on the tire pressure display.
  • Page 327 Wheels and tires MOBILITY Adjustment Insert the connector into the power socket in the vehicle interior. Stop at a suitable location. Screw the connection hose of the compres‐ sor directly onto the tire valve stem. With standby or drive readiness turned on, turn on the compressor and let it run for a maximum of 10 minutes.
  • Page 328 Wheels and tires MOBILITY Reset the Tire Pressure Monitor again. Replace the faulty tire and the sealant bottle of Use only in pairs on the rear wheels, equipped the tire repair set promptly. with the tires of the following size: Additional information: ▷...
  • Page 329 Wheels and tires MOBILITY Switching off rear axle steering Safety information The rear axle steering is switched off by specify‐ ing that tire chains are installed. Warning "CAR" The display of the target pressures is not a substitute for the tire inflation pressure details "Settings"...
  • Page 330 Wheels and tires MOBILITY Tire settings Status display General information Current status The tire sizes of the mounted tires can be gath‐ The system status can be displayed on the Con‐ ered from the tire inflation pressure details on the trol Display, e.g., whether or not the system is ac‐...
  • Page 331 Wheels and tires MOBILITY Tire conditions Reset tire pressure: "Perform reset". Drive away. General information The wheels are displayed in gray and the follow‐ Tire and system status are indicated by the color ing is displayed "Resetting tire pressure…". of the wheels and a text message on the Control After a travel time of several minutes, the set tire Display.
  • Page 332 Wheels and tires MOBILITY Icon Possible cause Icon Possible cause Inflation was not carried out according There is a flat tire or a major tire pres‐ to specifications, for instance when the sure loss. tire has not been sufficiently inflated or in the case of a natural steady tire pres‐...
  • Page 333 Wheels and tires MOBILITY If a tire inflation pressure check is Measure required Reduce the vehicle speed. Do not exceed a speed of 80 mph/130 km/h. Message At the next opportunity, for instance at a filling An icon with a Check Control message appears station, check the tire inflation pressure in all on the Control Display.
  • Page 334 Wheels and tires MOBILITY Actions in the event of a flat tire Continued driving with a flat tire Follow the following when continuing to drive Normal tires with a damaged tire: Identify the damaged tire. Avoid sudden braking and steering maneu‐ Check the tire pressure in all four tires, for in‐...
  • Page 335 Wheels and tires MOBILITY System limits ▷ For tires with special approval: the system was unable to complete the reset. Perform a system reset again. Temperature ▷ Tire Pressure Monitor malfunction: have the The tire inflation pressure depends on the tire's system checked by a manufacturer service temperature.
  • Page 336 Wheels and tires MOBILITY Status display function exists. When the malfunction indicator is illuminated, the system may not be able to de‐ The current status of the Flat Tire Monitor FTM tect or signal low tire pressure as intended. can be displayed, for instance whether the FTM TPMS malfunctions may occur for a variety of is active.
  • Page 337 Wheels and tires MOBILITY Safety information When the tire inflation pressure in all four tires is correct, the Flat Tire Monitor FTM may not have been initialized. In this case, initialize the Warning system. A damaged regular tire with low or missing tire If identification of flat tire damage is not pos‐...
  • Page 338 Wheels and tires MOBILITY Possible driving distance with a ▷ The system has not been initialized. depressurized tire ▷ When driving on a snowy or slippery road. The distance for which it may be possible to ▷ Sporty driving style: slip on traction wheels, drive safely varies depending on how the vehicle high lateral acceleration (drifting).
  • Page 339 Wheels and tires MOBILITY Warning Warning The jack, issued by the vehicle manufacturer, is A vehicle that is raised on a vehicle jack may fall provided in order to perform a wheel change in off of the jack if lateral forces are exerted on it. the event of a breakdown.
  • Page 340 Wheels and tires MOBILITY On a slight downhill gradient Unscrewing Attach the adapter to the lug lock bolt. Unscrew the lug lock bolt. Remove the adapter after unscrewing the lug bolt. Screwing on Attach the adapter to the lug lock bolt. If nec‐ essary, turn the adapter until it fits on the lug lock bolt.
  • Page 341 Wheels and tires MOBILITY Jacking points for the vehicle Hold the vehicle jack with one hand, arrow 1, jack and grasp the vehicle jack crank or lever with your other hand, arrow 2. The jacking points for the vehicle jack are lo‐ Insert the vehicle jack into the rectangular re‐...
  • Page 342 Wheels and tires MOBILITY Make sure that the vehicle jack foot stands Hand-tighten the remaining lug bolts and vertically and at a right angle beneath the tighten all lug bolts well in a crosswise pat‐ jacking point. tern. Turn the vehicle jack crank counterclockwise to retract the vehicle jack and lower the vehi‐...

  • Page 343: Engine Compartment

    Engine compartment MOBILITY Engine compartment Vehicle features and not necessarily available in your vehicle, e.g., due to the selected options or country versions. This options also applies to safety-related functions and sys‐ tems. When using these functions and systems, This chapter describes all standard, country-spe‐ the applicable laws and regulations must be ob‐...
  • Page 344 Engine compartment MOBILITY 8-cylinder engine 1 Filler neck for washer fluid 5 Oil filler neck 2 Jump-starting, positive battery terminal 6 Jump-starting, negative battery terminal 3 Coolant reservoir, engine 7 Vehicle identification number 4 Coolant reservoir, auxiliary cooling Hood Warning The engine compartment accommodates mov‐...
  • Page 345 Engine compartment MOBILITY Hood is unlocked. Warning An incorrectly locked hood can open while driv‐ ing and restrict visibility. There is a risk of acci‐ dent. Stop immediately and correctly close the hood. Warning Body parts can be jammed when opening and After the lever is released, pull the lever again, closing the hood.

  • Page 346: Operating Materials

    Operating materials MOBILITY Operating materials Vehicle features and Safety information options CAUTION This chapter describes all standard, country-spe‐ The use of poor-quality fuels may result in cific and optional features offered with the series. harmful engine deposits or damage. Addition‐ It also describes features and functions that are ally, problems relating to drivability, starting and stalling, especially under certain environmental...
  • Page 347 Different Check Control messages appear on the Control Display depending on the engine oil level. Recommended gas quality Safety information BMW recommends AKI 91. M Performance model: BMW recommends AKI 93. NOTICE Refuel with this gasoline to achieve the rated An engine oil level that is too low causes en‐...
  • Page 348 Operating materials MOBILITY Electronic oil measurement Detailed measurement Principle General information The engine oil level is checked when the vehicle The electronic oil measurement has two measur‐ is stationary and displayed via a scale. ing principles: If the engine oil level is outside its permissible ▷...
  • Page 349 Operating materials MOBILITY Take care not to add too much engine oil. Opening, refer to page 345. Open the lid counterclockwise. Safety information Warning Operating materials, for instance oils, greases, coolants, fuels, can contain harmful ingredients. There is a risk of injury or danger to life. Follow the instructions on the containers.
  • Page 350 There is a risk of damage to property. It is recommended that you do not The BMW Longlife-14 FE+ and BMW Long‐ exceed the service intervals indicated in the ve‐ life-17 FE+ oil specifications are not suitable for hicle.
  • Page 351 Operating materials MOBILITY Safety information The coolant level is correct if it lies between the minimum and maximum marks in the filler neck. Warning With the engine hot and the cooling system open, coolant can escape and lead to scalding. There is a risk of injury.
  • Page 352 Follow the usage instructions on the washer fluid container. Use of BMW’s Windshield Washer Concentrate The washer fluid reservoir is located in the en‐ or the equivalent is recommended.

  • Page 353: Maintenance

    Therefore, hand the service advisor the vehicle key with which the vehicle was driven most re‐ BMW maintenance system cently. Storage periods The maintenance system provides service notifi‐ cations and thereby provides support in main‐...
  • Page 354 Maintenance MOBILITY Socket for OBD Onboard Emissions Diagnosis ▷ The warning light lights up: Emissions are deteriorating. Have the vehicle checked as soon as possible. General information ▷ The warning light flashes under certain cir‐ Devices connected to the OBD socket trigger cumstances: the alarm system when the vehicle is locked.

  • Page 355: Replacing Components

    Replacing components MOBILITY Replacing components Vehicle features and switch on the wiper without a wiper blade in‐ stalled. options This chapter describes all standard, country-spe‐ NOTICE cific and optional features offered with the series. Folded-away wipers can be jammed when the It also describes features and functions that are hood is opened.
  • Page 356 Replacing components MOBILITY Headlight glass Insert the new wiper blade and press it on un‐ til it you hear it snap into the holder. The inside of the headlight glass can fog up in Fold down the wipers. cool or humid weather. When driving with the lights switched on, the condensation evaporates after a short time.
  • Page 357 Replacing components MOBILITY Register the battery to the Charging the battery vehicle Charge the battery only when the engine is off and via the starting aid terminals in the engine The manufacturer of the vehicle recommends compartment. that you have a service center or another quali‐ fied service center or repair shop register the ve‐...
  • Page 358 Information on the fuse layout, as well as the po‐ sitions of any other fuse boxes, is available on the Internet: www.bmw.com/fusecard. Additional fuse boxes Additional fuse boxes are located in the vehicle. In the case of a malfunction, contact a dealer's service center or another qualified service center or repair shop.

  • Page 359: Breakdown Assistance

    Breakdown Assistance MOBILITY Breakdown Assistance Vehicle features and Warning triangle options This chapter describes all standard, country-spe‐ cific and optional features offered with the series. It also describes features and functions that are not necessarily available in your vehicle, e.g., due to the selected options or country versions.
  • Page 360 Control Display. If the vehicle is equipped with Teleservices, sup‐ port is offered through Teleservice Diagnosis. When BMW Accident Assistance is activated, data on the vehicle's condition is sent to BMW. "APPS" "Installed apps" Functional requirements "BMW Assist"...
  • Page 361 Assistance Overview If an accident is detected automatically A text message relating to BMW Accident Assis‐ tance appears on the Control Display. The connection can be established directly: "Contact accident assistance" The Check Control message for BMW Accident...
  • Page 362 Do not touch any components that are contact with the occupants of the vehicle and under voltage. initiates further steps to help. Even if you are unable to respond, the BMW Response Center can take further steps to Warning help you under certain circumstances.
  • Page 363 Breakdown Assistance MOBILITY Tow-starting and towing Connecting the cables Before you begin, switch off all unnecessary electronic systems/components, such as the Safety information radio, on the assisting and receiving vehicles. Open the cover of the starting aid terminal. Warning Attach one terminal clamp of the positive Due to system limits, individual functions can jumper cable to the positive battery terminal, malfunction during tow-starting/towing with the...
  • Page 364 Breakdown Assistance MOBILITY Additional information: NOTICE Rolling or pushing the vehicle, refer to page 148. If the tow bar or tow rope is attached incor‐ Tow truck rectly, damage to other vehicle parts can occur. There is a risk of damage to property, among other potential damage.
  • Page 365 Breakdown Assistance MOBILITY Tow fitting Safety information General information NOTICE If the tow fitting is not used as intended, there may be damage to the vehicle or to the tow fit‐ ting. There is a risk of damage to property, among other potential damage.

  • Page 366: Vehicle Care

    Vehicle Care MOBILITY Vehicle Care Vehicle features and Distances and temperature ▷ Maximum temperature: 140 ℉/60 ℃. options ▷ Minimum distance from sensors, cameras, seals: 12 inches/30 cm. This chapter describes all standard, country-spe‐ cific and optional features offered with the series. Automatic washing systems or It also describes features and functions that are car washes...
  • Page 367 Vehicle care products General information General information BMW recommends using vehicle care and In a car wash, the vehicle must be able to roll cleaning products from BMW. Suitable vehicle freely. care products are available from a dealer’s serv‐...
  • Page 368 Vehicle Care MOBILITY Vehicle paintwork ▷ Remove bird droppings immediately as their corrosive effect will otherwise attack the convertible top and damage the rubber seals. General information ▷ Hard to remove tree sap or bird droppings Regular vehicle care contributes to driving safety can be removed from the convertible top with and value retention.
  • Page 369 Vehicle Care MOBILITY Leather care Caring for special components Remove dust from the leather regularly, using a Light-alloy wheels cloth or vacuum cleaner. When cleaning the vehicle, use only neutral rim Otherwise, particles of dust and road grime chafe cleaners having a pH value from 5 to 9. Do not in pores and folds, and lead to heavy wear and use abrasive cleaning agents or steam cleaners premature degradation of the leather surface.
  • Page 370 Vehicle Care MOBILITY Plastic components Make sure that there is sufficient clearance for the pedals. Ensure that the floor mats are se‐ curely fastened again after they were removed, NOTICE for instance for cleaning. Cleaning agents that contain alcohol or sol‐ vents, such as lacquer thinners, heavy-duty The floor mats can be removed from the car's in‐...
  • Page 371 Vehicle Care MOBILITY Further information is available from a dealer's service center or another qualified service center or repair shop. Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 372: Reference

    The dimensions can vary depending on the The height of the vehicle can also differ, e.g. due model version, equipment version or country- to tires and vehicle load. specific measurement procedure. BMW 8 Series Convertible Width with mirrors in/mm 84.1/2,137 Width without mirrors in/mm 74.9/1,902...
  • Page 373 5,291/2,400 Payload lbs/kg 860/390 Approved front axle weight lbs/kg 2,546/1,155 Approved rear axle weight lbs/kg 2,877/1,305 M850i xDrive powered by BMW M Approved gross vehicle weight lbs/kg 5,545/2,515 Payload lbs/kg 787/357 Approved front axle weight lbs/kg 2,723/1,235 Approved rear axle weight...

  • Page 374: Appendix

    The following chapters were updated in the printed version of the Owner's Manual after the editorial deadline for the Integrated Owner's Manual in the vehicle had closed: ▷ Opening and closing: BMW Digital Key: gen‐ eral. Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 375 Appendix REFERENCE Online Edition for Part no. 01405A38D29 - VI/21...

  • Page 376: Everything From A To Z

    Everything from A to Z REFERENCE Everything from A to Z Index Air distribution, manual Air drying, see air conditioning Air flow, automatic climate control 3D View, see Surround View Air outlets, see Ventilation Air pressure, tires Air quality Alarm system ABS Antilock Braking System Alarm, unintentional Acceleration Assistant, see Launch Control...
  • Page 377 Everything from A to Z REFERENCE Assisted Driving View BMW Accident Assistance Audio, see Owner's Manual for Navigation, En‐ BMW Assist, see Owner's Manual for Navigation, tertainment and Communication Entertainment and Communication AUTO H button, see Parking brake BMW Digital Key...
  • Page 378 Car wash, automatic Climate control rules Catalytic converter, see Hot exhaust gas sys‐ Closing with the Key Card Closing with the smartphone, see BMW Digital CBS Condition Based Service Cell phone, see Owner's Manual for Navigation, Coasting Entertainment and Communication Coasting with engine decoupled, see Coast‐...
  • Page 379 Device list ture Diagnosis connection Cooling, maximum Differential lock Cooling system Digital Key Cornering light Digital Key, see BMW Digital Key Corrosion on brake discs Dimensions Cosmetic mirror Dimmable exterior mirrors Cross traffic warning Dimmable interior mirror Cruise control Direct dial buttons, see Programmable memory buttons Online Edition for Part no.
  • Page 380 Driving out of parking space Display key Driving stability control systems Display key, malfunction Driving, Start/Stop button Display key, see BMW display key Driving style analysis, ECO PRO Display lighting, see Instrument lighting Driving through water Display, notifications, BMW Intelligent Personal...
  • Page 381 Exhaust gas system Front airbags Exhaustion warner Front collision mitigation Exhaust, see Exhaust gas system Front collision mitigation, see Forward Collision Experience Modes, BMW Intelligent Personal Warning Assistant Front collision mitigation, see Intersection Colli‐ Exterior lighting during unlocking sion Warning Exterior lighting with the vehicle locked Front collision mitigation, see Pedestrian Warn‐...
  • Page 382 Everything from A to Z REFERENCE Front-seat passenger airbags, indicator light Head-up Display, care Front seats Head-up Display, store position, see Memory Fuel function Fuel cap Heated steering wheel Fuel filler flap Heating, neck Fuel filler flap, unlocking manually Heavy cargo, stowing Fuel gauge Height, vehicle Fuel quality...
  • Page 383 Key Card List of all notifications Keyless Go, see Comfort Access Load Key, mechanical Loading Key, see BMW display key Loading the cargo area, see Stowing cargo Key, see Vehicle key Local time, see Time Kickdown, Steptronic transmission Locking, automatic...
  • Page 384 Mobile devices, managing Lug bolt lock Mobile phone, connecting Lumbar support Mobile phone, see Owner's Manual for Naviga‐ tion, Entertainment and Communication Mobile Service, see BMW Accident Assis‐ tance Mobile Service, see BMW Roadside Assis‐ Maintenance tance Maintenance recommendations Mobility System, see Tire repair set...
  • Page 385 Pathway lines, rearview camera Opening and closing Payload, technical data Opening with the Key Card PDC Park Distance Control Opening with the smartphone, see BMW Digital Pedestrian detection, see Night Vision Pedestrian Warning with braking function Operating concept, iDrive Performance Control...
  • Page 386 Remote 3D View Remote control for audio, see Owner's Hand‐ book for Navigation, Entertainment, Communi‐ Safe braking cation Safe Share function, see BMW Digital Key Remote control, see Vehicle key Remote control, universal Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 387 Smartphone, connecting Sensors of the vehicle Smartphone Integration, Android Auto prepara‐ Service and warranty tion Service Center, see BMW Accident Assis‐ Smartphone Integration, Apple CarPlay prepara‐ tance tion Service Center, see BMW Roadside Assis‐ Smartphone, see Owner's Manual for Navigation,...
  • Page 388 Everything from A to Z REFERENCE Speed Limit Assist Stopping the engine, see Drive-ready state Speed Limit Assistant Storage compartment, cargo area Speed Limit Device, Speed Limiter Storage compartment, center console Speed limit display, see Speed Limit Info Storage compartments Speed Limit Info Storage compartments, locations Speed warning...
  • Page 389 Everything from A to Z REFERENCE Temperature display electric motor, see Sport TPM Flat Tire Monitor displays Traction control Temperature display, see outside tempera‐ TRACTION, driving dynamics ture Traffic bulletins, see Owner's Handbook for Navi‐ Temperature, engine oil gation, Entertainment, Communication Theft alarm system, see Alarm system Traffic Jam Assistant, see Assisted Driving Thermal camera, see Night Vision...
  • Page 390 Upgrade, see Remote Software Upgrade Voice command response Upholstery material care Voice control Upper retaining strap, top tether Voice control, see BMW Intelligent Personal As‐ USB connection sistant USB port, position in vehicle Voice control system Used battery, disposing of...
  • Page 391 Everything from A to Z REFERENCE Wi-Fi hotspot Wind deflector Window, defrosting Windows, powered Windshield, defrosting Windshield washer fluid, see Washer fluid Windshield washer nozzles Windshield wiper, see Wiper system Winter storage, see Long-term vehicle stor‐ Winter tires Winter tires, tread Wiper blades, replacing Wiper fluid, see Washer fluid Wiper, fold-away position...
  • Page 392 *BL5A38D2900K* 01405A38D29 ue Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 395 California Proposition 65 Warning For vehicles sold in California: Online Edition for Part no. 01405A38D29 - VI/21...
  • Page 396 The Ultimate Driving Machine® BMW DRIVER'S GUIDE APP. Your customized information about the vehicle in an app. Optimized for smartphones & tablets. Can be used offline. *BL5A38D2900K* 01405A38D29 ue Online Edition for Part no. 01405A38D29 - VI/21...

This manual is also suitable for:

Convertible 8 series 2022840i 2022840i xdrive 2022M850i xdrive 2022

Table of Contents

Save PDF
