SWIT BM-U miniLED User Manual

High 4k definition monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BM-U miniLED
High 4K Definition Monitor
Model: BM-U325MD
User Manual
Please read this user manual throughout before using
Ver： A
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BM-U miniLED and is the answer not in the manual?

Questions and answers

Related Manuals for SWIT BM-U miniLED

Summary of Contents for SWIT BM-U miniLED

  • Page 1 BM-U miniLED High 4K Definition Monitor Model: BM-U325MD User Manual Please read this user manual throughout before using Ver： A...

  • Page 2: Preface

    All internal technologies of this product are protected, including device, software and trademark. Reproduction in whole or in part without written permission is prohibited. All brands and trademarks of SWIT Electronics Co., Ltd. are protected and other relative trademarks in this user manual are the property of their respective owners.

  • Page 3: Maintenance

    Maintenance Warning 1. In order to reduce the risk of fire and electrical shock, do not lay this product in rain or damp places. 2. Please keep away from the strong magnetic field; it may cause the noise of the video and audio signals.

  • Page 4: Table Of Contents

    Contents Preface. Maintenance Contents Packing List Introduction Operation Introduction Front panel Rear panel Menu Configuration Size Specification Trouble-Shooting Packing list Standard package Details Monitor Warrantee card Tabletop stand Power cord Introduction This series of monitors adopt Mini LED panel, with an ultra-high contrast ratio of 1000000:1， the resolution is up to 3840×2160, H178°...

  • Page 5: Operation Introduction

    Operation Instructions ·Front panel (11) (1) (2) (4)(5) (7) (8) (9) (10) (1) Speaker: For SDI/ HDMI® embedded audio. (Will not work if earphone is plugged in) (2) Desktop Stand Feet (3) User1~User4: User shortcut key, which can be used to quickly enter the set user mode. Long press to save user settings.
  • Page 6 Source Brightness Contrast Saturation SDI 1 SDI 2 SDI 3 SDI 4 4xSDI SQD Source 4xSDI 2SI Backlight Volume Source HDMI Multiview Brightness: Adjust the brightness. -100~100 adjustable, default value is 0. Contrast: Adjust contrast. -100~100 adjustable, default value is 0. Saturation: Adjust saturation.

  • Page 7: Rear Panel

    ·Rear panel (10) (11) （12） （1） Backlight cooling Fan （2） SFP IN: Optical fiber interface 12G/6G/3G/HD/SD-SDI video signal fiber input interface Fiber optic module is optional ● （3） SDI IN1~4:12G-SDI （4） SDI OUT1~4: 12G-SDI （5） ETHERNET: Network interface 1000M high-speed RJ45 Ethernet port, for web server IP external control. （6）...

  • Page 8: Osd

    ·OSD TC:00:15:13:07 CAMERA 1 Before Calibration After Calibration 400mV 200mV Mg75 -200mV Cy75 in phase -400mV YI75 Delta = 1.0 Delta = 0.9 DCI-P3 1 2 3 4 5 6 7 8 910111213141516 R -13DB 02CH L -32DB 01CH （11） （10）...
  • Page 9 (10) Histogram Parallel display R/G/B/Y histogram for SDI and HDMI® video. User can set function keys F1～F5 or GPI pins as “Histogram” to turn on or off this function. (11) Audio VU/PPM meters Display meters of SDI/HDMI® embedded audio or analog audio. The audio meter display channels, on screen positions, markers and background colors are adjustable.
  • Page 10 Key configuration. Steps 1. Press “Menu/ Enter” button, the main menu will pop up from the left top of the screen. The selected main menu highlights in yellow . 2. Revolve “Menu/ Enter” to select submenu, the selected submenu highlights in yellow, press “Menu/ Enter”...

  • Page 11: Menu Configuration

    Menu Configuration Menu configuration introduces the main menu and each sub-menu. Menu items marked * will give more detailed menu description or operation explanation after the list 1. Input ‒ Set the color of input video Menu Item Menu Description Value Full 0-1023 SDI Full 4-1019 Input Range *1...
  • Page 12 3. Color management—Settings about video colors Menu Description Menu Item Value Set gamut values Color Gamut *1 LCD Panel,DCI-P3,Rec.709,Rec.2020 1.0,1.8,2.2,2.4,2.6, BT1886， 2.4 （ HDR)， Set gamma values Gamma*2 PQ1000,HLG1000,S-Log3 HLG System Set HLG System Gamma 1.0,1.1,1.2(default),1.3,1.4,1.5 Gamut and Gamma *3 gamma values are OFF,J-Log1,Log-C,S-Log2,C-Log,V-Log,...
  • Page 13 4. Scanning—Setting for picture scan, zoom, etc. Menu Item Menu Description Value Set up a scanning mode that matches the audio to Pixel To Pixel, Panel Fit, Original scan Scanning Mode *1 the screen Off, Top Left, Top, Top Right, Left, Center, Zoom -in*2 Set a zoom mode Right, Bottom Left, Bottom ,Bottom Right...
  • Page 14 5.Control—Setting for TALLY, UMD, IP control to the monitor Value Menu Description Menu Item OFF,ON GPI Control *1 Open or close GPI Control GPI 1Pin SFP, SDI1, SDI2, SDI3, SDI4, 4×SDI(2-SI)、 GPI 2Pin 4×SDI(SQD), HDMI®, Red Tally, Green Tally, Yellow Tally ,Time Code, Freeze Frame, WFM GPI 3Pin Set the function of each pin Type, WFM Single Line, UMD, Marker , Wave-...
  • Page 15 *1 GPI control Connect the GPI remote control terminal through the GPI interface on the real panel of the monitor, turn on “GPI control” and set the function of GPI 1-6 buttons. The GPI control allows you to control both the Tally light and the on screen TALLY light on at the same time: On Screen Tally Tally Lamp...
  • Page 16 Cascade: 6. Assist— Setting for Vector scope and Histogram patterns. Menu Item Menu Description Value False Color Turn false color display on or off OFF, ON Turn blue only on or off Blue Only OFF, ON Turn on or off focus assist and adjust the color of the OFF, Blue, Red Focus Assist focus assist...
  • Page 17 Turn the colour gamut chart on or off On,Off Top left, Top right, Adjusting the position of the colour gamut map on CIE Position Bottom left, Bottom right the screen Turning alarms on or off Gamut Warning On，off Set the transparency of the background colour of Off, Low, High CIE Blending the colour gamut map...
  • Page 18 *2.Horizontal / Vertical When marker select is USER 1, Users can adjust the Horizontal and Vertical of the marking line according to their own needs， Coordinate value is adjustable from 50% to 99%； when marker select is USER2， the value of Horizontal is adjustable between 0~3840， the value of Vertical is adjustable between 0~2160.
  • Page 19 3D LUT cube and calibrate itself automatically. *2.Probe Select This monitor supports the following probes models: BRAND MODE X-rite I1 Pro OEM （SWIT OEM） *3.Start Calibration JETI Specbos 1211 Steps: 1、 Put the monitor into a dark room. Switch on the monitor.
  • Page 20 Auto Calibration Please make sure the monitor is in dark room,and the sensor probe is put in the center marker and close Auto Calibration Please make sure the monitor is in to the screen. dark room,and the sensor probe is put in the center marker and close to the screen.
  • Page 21 9. System— User profile saving, firmware update. Menu Item Menu Description Value Key Lock *1 Set lock key OFF, Lock All Recall Profile*2 Select make user mode current Factory,USER1,USER2,USER3,USER4 Save Profile Save the current state as a user setting USER1,USER2,USER3,USER4 HDR maximum Setting the brightness of HDR mode 400~1600...
  • Page 22 *2 Recall Profile/ Save Profile User Settings provide 4 menu Settings, that is, users can save the current monitor menu Settings as one user Settings (USER1~USER4) according to usage habits. Then, when switching menu Settings, just select the corresponding "USER1~USER4" through the “Recall Profile” item to display the corre- sponding menu Settings.
  • Page 23 *6.IP Connect the monitor to the LAN through an ETHERNET interface, and the Monitor can be controlled by web page. Pin No Pin Name MD0P MD0N MD1P MD1N MD2P MD2N MD3P MD3N Enter Menu- System ‒ IP/Net Mask/Gateway/Port to set the monitor address. Set the computer Ether- net IP addresses at the same LAN environment as the Monitor.
  • Page 24 *� Status Switch Status Switch on, with multi-screen display of current colour gamut and gamma。 *�.Update System software can update by USB interface, and steps are as follows: �. Download the latest software package into the U-disk root direction. �. Open the monitor and plug U-disk into USB into port. �.

  • Page 25: Size

    10． Multiview setting *1 Menu items Menu description Item values Quad View,PBP,PIP Multiview type*� Setting the multi-screen type For � screens and picture-in-picture, PIC� SDI�~�, HDMI® select the channel displayed for PIC� screens � and � Bottom Left、 Bottom Right ﹑Top Select PIC�...

  • Page 26: Specification

    Specification LCD Performance Model BM-U325MD Size 31.5 Display area 697.30×392.23mm Resolution 3840*2160 Display Color 1.07B Display ratio 16:9 Brightness 1500 cd/m Contract 1 000 000： 1 Viewing Angle Horizontal/ Vertical： 178°/ 178° Input /Output BNC×4 12G/6G/3G/HD/SD-SDI×4 HDMI®×1 HDMI® input RS-485×2 GPI×1.UMD×1 Input USB×1...
  • Page 27 Supported Format： Signals below can display on the monitor Input terminal Signal format shown in the Status Display as Format SDI1~4 Multiview HDMI® SDI1~4&SFP HDMI® &SFP √ — √ 1280*720P50 1280*720P50 1280×720/50P √ — √ 1280*720P59.94 1280*720P60 1280×720/59.94P √ — √...
  • Page 28 Input terminal Signal format shown in the Status Display as Format SDI1~4 Multiview HDMI® SDI1~4&SFP HDMI® &SFP ����×����/��P √ √ 3840*2160P50 3840*2160P50 √ 3840×2160/59.94P √ √ 3840*2160P59.94 3840*2160P60 √ 3840×2160/60P √ √ 3840*2160P60 3840*2160P60 √ 4096×2160/23.98P √ √ 4096*2160P23.98 4096*2160P24 √...

  • Page 29: Trouble-Shooting

    Trouble-shooting Solution symptom Possible causes Please check if the power is connected, and then The power is not turned on press “POWER” button to turn on the monitor Unstable power voltage Reconnect to power supply No display BNC or HDMI® cable loose Check and correctly connect the BNC or HDMI®cable contact or not correctly connected...
  • Page 30 Technological Development Zone, Nanjing 210038, P.R.China Tel: +86-25-85805753 Email: contact@swit.cc SWIT Electronics Europe GmbH Add: Hochstr. 17, 47228 Duisburg, Germany Tel: +49(0)20659799339 Email: info@swit-europe.com SWIT Electronics America, Inc Add: 3350 Scott Boulevard 61-02, Santa Clara, CA 95054, USA Tel: (408)260-8258, 1-866-986-SWIT(7948) Email: info@swit.us...

This manual is also suitable for:

Bm-u325md
