QUICK START GUIDE
E200BT
Languages x 1: EN
E200BT
QUICK START
GUIDE
www.onkyo.com
2015 © Gibson Innovations Limited.
All rights reserved.
This product has been
manufactured by, and is sold under
the responsibility of Gibson
Innovations Ltd., and Gibson
Innovations Ltd. is the warrantor in
relation to this product.
Gibson Innovations Netherlands
B.V. Building
Box size: W95 x H150 x D25 mm
QSG size: W89 x H144 mm( Folded)
Binding: 1. Folded / 2. Glue / 3.Saddle stitch
Sleeve size: W210 x H50 mm
QSG (A1/B1) - Print color: 2 colors ( Black + PMS186c)
Revised illustration_EN (2015.07.23)
EN
Quick start guide
On/O button,
Volume/
Music/Call
Track
control
control
[ 1.0 Charge the battery ]
1. Plug one end of USB cable into the charger (or into the USB port of a computer).
2. Plug the other end of the cable into the micro USB charging slot on the headset.
3. When the headset is charging, a white indicator light will be displayed.
4. When the headset is fully charged, the white light goes o .
[ 2.0 Turn on and o the headset ]
1. Turn the headset on. Press and hold for 2 sec.
2. Turn the headset o . Press and hold for 4 sec. A white
indicator light turns on for 1.5 sec. and then the
headset will turn o .
[ 3.0 Manual Pairing ]
1. Make sure your headset is turned o .
2. Press and hold until an alternating blue and white
light flashes.
10:30 10:31 10:32
3. Turn on the Bluetooth function on your phone.
Settings Connectivity Settings Settings Connectivity
Bluetooth Devices Found
4. Your phone will start searching for Onkyo E200BT.
Enter Password
Add Onkyo E200BT
Bluetooth 5. Follow the on-screen instructions to pair your phone.
****
device
0000 (Check your phone's user manual for details)
Select Select
Select Back Back Back
'0000' not required for
some mobile phones
[ 4.0 Use music and call controls ]
MUSIC CONTROLS CALL CONTROLS
Play/Pause Press once Pick up call/Hang up
Volume up Press once Reject incoming call
Skip forward Long Press
Switch caller while
Volume down Press once
in a call
Skip backward
Long Press
Mute/unmute the mic
while in a call
[ 5.0 LED Indicator light ]
A white light triple flashes every 10 seconds. The battery is low.
An alternating white and blue light flashes.
The headset is in pairing mode.
A blue light flashes at every 8 seconds.
The headset is both paired & connected.
A blue light flashes rapidly. The headset is switched on but not connected.
If no connection can be made, the headset will
turn o itself after 5 minutes.
Please refer to www.onkyo.com/welcome for the full user manual
Micro USB
charging slot
Microphone
LED
indicator
light
Press once
Press & hold
for 2 sec.
Press twice
Press once
