Egimotors RZR XP CREW 1000 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Egimotors
2024
OWNER'S MANUAL
TRACTOR
RZR XP CREW 1000
Owner's manual part Number - OM24TRZRCREW1000
Read this manual carefully. It contains important safety
information. This is an adult Quadricycle only.
Operation is prohibited for those under 18 years of age.
WARNING

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RZR XP CREW 1000 and is the answer not in the manual?

Questions and answers

Related Manuals for Egimotors RZR XP CREW 1000

Summary of Contents for Egimotors RZR XP CREW 1000

  • Page 1 Egimotors 2024 OWNER’S MANUAL TRACTOR RZR XP CREW 1000 Owner’s manual part Number - OM24TRZRCREW1000 Read this manual carefully. It contains important safety information. This is an adult Quadricycle only. Operation is prohibited for those under 18 years of age.
  • Page 4 The original instruction is in English. Other languages are provided as translation of the original Instruction see the Egimotors website for more details and procedure.
  • Page 6 SAFETY SYMBOLS AND SIGNAL WORDS The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is involved when these words and symbols are used. Become familiar with their meanings before reading the manual. DANGER DANGER indicates a hazardous situation which, if not avoided, WILL result in death or serious injury.

  • Page 7: Table Of Contents

    Introduction ................7 Safety ..................15 Features and Controls ............41 Operation ................. 83 Emission Control Systems ............. 89 Maintenance ................91 Specifications ................ 147 Polaris Products ..............151 Troubleshooting ..............153 Warranty ................. 159 Maintenance Log ..............167...
  • Page 8 If after reading this manual, you still have some questions please do not hesitate to contact your dealer that will be available to help you. Be sure to visit us online at www.Egimotors.it for the latest news and for product and Safety information.

  • Page 9: Introduction

    INTRODUCTION INTRODUCTION IMPORTANT INFORMATION WARNING Failure to follow the warnings contained in this manual can result in severe injury or death. This vehicle is not a toy and can be hazardous to operate. This vehicle handles differently than other vehicles. A collision or rollover can occur quickly, even during routine maneuvers, if you fail to take proper precautions.
  • Page 10 The original instruction is in English. Other languages are provided as translation of the original Instruction see the Egimotors website for more details and procedure.
  • Page 11 INTRODUCTION ORV CERTIFICATE OF PRE-DELIVERY INSPECTION IMPORTANT It is recommended that the owner of this vehicle receive a completed Certificate of Pre-Delivery Inspection form. If you did not receive this form (or a similar version to the sample below), consult your authorized dealer to obtain one.
  • Page 12 INTRODUCTION...
  • Page 13 INTRODUCTION TOOLS FOR SAFE RIDING To safely operate this vehicle, it is important to become familiar with its features, controls, and characteristics. Review the Safety Briefings for this vehicle that apply to you: • Operators • Riders • Owners • Trailering the Vehicle •...
  • Page 14 INTRODUCTION NEAR-FIELD COMMUNICATION (NFC) (IF EQUIPPED) Some Polaris vehicles come equipped with a near-field communication (NFC) chip. The NFC chip is embedded in the Polaris emblem located at the front of the vehicle and seamlessly connects you to a digital platform of vehicle information and tools.
  • Page 15 INTRODUCTION RADIO COMPLIANCE STATEMENTS NOTE Some vehicle models contain radio equipment as detailed in this section. EUROPEAN UNION (EU) RADIO COMPLIANCE This vehicle may contain the following radio equipment or components that contain radio equipment: Component 9200 Series Display Component ID RC-7 Manufacturer Polaris Industries Inc.
  • Page 16 INTRODUCTION VEHICLE IDENTIFICATION NUMBERS Record your vehicle’s identification number and engine serial number in the spaces provided. Remove the spare key and store it in a safe place. An ignition key can be duplicated only by ordering a POLARIS key blank (using your key number) and mating it with one of your existing keys.

  • Page 17: Safety

    SAFETY SAFETY OWNER REQUIREMENTS Improper use, maintenance, or modification of this vehicle can lead to serious injury or death. Require proper use of your vehicle. Do not allow anyone to operate your vehicle or ride as a passenger unless they are properly instructed and you are sure they are willing to ride responsibly.
  • Page 18 SAFETY DRIVER AND PASSENGER QUALIFICATIONS Make sure operators are 18 or older with a valid driver’s license. Just because a teenager has a license does not mean that they will make good judgments about driving and avoid risk taking. POLARIS recommends that you supervise younger drivers. Set rules and put limits on how, when, and where they are allowed to use this vehicle.
  • Page 19 SAFETY PREPARE VEHICLE FOR THE RIDE Before starting off, always perform the Pre-Ride Inspection. Failure to inspect and verify that the vehicle is in safe operating condition increases the risk of an accident, which can lead to serious injury or death. ITEM REMARK REFERENCE...
  • Page 20 SAFETY ITEM REMARK REFERENCE Seat Belts Check length of belt for page 54 damage, check latches for proper operation Exhaust Inspect spark arrester page 127 and clean if needed. – Vehicle Debris Remove grass, leaves, and other flammable material or debris, especially near the exhaust system.
  • Page 21 SAFETY Improper tire maintenance can lead to loss of control and an accident, which could result in serious injury or death. To reduce your risk of injury: • Maintain POLARIS recommended tire pressure. Check pressure before operating. Even if your vehicle has only been driven a short distance, the tire pressure readings can become higher.
  • Page 22 SAFETY PREPARE YOURSELF, PASSENGERS, AND CARGO FOR THE RIDE Wear an approved helmet. Riding in this vehicle without wearing an approved helmet increases the risk of serious injury. For example, a helmet reduces your risk of injury from head strikes with the vehicle or other objects even if there is no crash.
  • Page 23 SAFETY Always stay completely inside the vehicle and hold the steering wheel or hand holds. Body parts outside of the vehicle can be struck by passing objects or crushed during a rollover. Do not put any part of your body outside of the vehicle for any reason.
  • Page 24 SAFETY DRIVING GUIDELINES Drive responsibly. This vehicle is not a toy and can be hazardous to operate. This vehicle has higher ground clearance and other features to handle rugged terrain. It can be overturned in situations where some other vehicles may not. Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control, rollovers, severe injury or death.
  • Page 25 SAFETY Watching someone else go over a jump or go airborne does not mean you can safely do so. Polaris cannot determine whether any jump you may encounter is appropriate for this vehicle. Any jump, even a small one, could be poorly maintained, designed, or not suitable for this vehicle and may cause serious injury or death.
  • Page 26 SAFETY MD MODELS ONLY Avoid Operating on Public Roads (Paved or Otherwise). This vehicle does not have highway safety features that on-road vehicles may have (air bags, anti-lock brakes, stability control, etc.). If another vehicle collides with you, the likelihood of a serious injury or death may be greater. Also, you may not be able to avoid a crash or rollover if you make sudden or abrupt maneuvers such as swerving or emergency braking.
  • Page 27 SAFETY Riding in snow Always keep the brake and accelerator pedals free of snow and ice. Apply the brakes frequently to prevent ice or snow accumulation on the brake pads which can reduce brake performance. Riding on ice Never operate the vehicle on a frozen body of water unless you have verified that the ice can support the weight of the vehicle.
  • Page 28 SAFETY On trails, be prepared to make space for other vehicles to pass. If you need to stop on a trail, move your vehicle to the edge of the path to allow others to pass safely. Correct a skid by turning the steering wheel in the direction of the skid. Never apply the brakes during a skid.
  • Page 29 SAFETY Vehicle rollaway can cause serious injury or death. This vehicle can roll whenever the gear selector is not in the PARK (P) position. Always shift to PARK (P) when stopping the engine or leaving the vehicle. When leaving the vehicle on an incline is unavoidable, use extra care.
  • Page 30 SAFETY TOWING A RZR XP CREW 1000 Towing this vehicle is not recommended. Always transport the vehicle on a trailer or flatbed with all four wheels off the ground. See the Transporting the Vehicle section for details. If towing a disabled vehicle is unavoidable, place the disabled vehicle’s transmission in neutral.
  • Page 31 SAFETY TOTAL TOWED TOTAL TOWED TOTAL HITCH MAXIMUM LOAD WEIGHT LOAD WEIGHT VERTICAL TOWING (LEVEL (15° GRADE) WEIGHT SPEED GROUND) 1,500 lb 850 lb 150 lb 10 mph (681 kg) (386 kg) (68 kg) (16 km/h) TOWING WARNING Towing improperly can alter vehicle handling and may cause loss of control or brake instability.
  • Page 32 SAFETY TRAILERING SAFETY The weight distribution of the cargo loaded onto the trailer is important and will have an impact on how the vehicle handles on the road. Ensure the weight of the cargo is distributed properly and the trailer is not rear, front, or side heavy. Improperly trailering or attempting to tow this vehicle can result in serious injury or death.
  • Page 33 SAFETY TRANSPORTING THE VEHICLE Follow these procedures when transporting the vehicle. 1. Place the transmission in PARK. Stop the engine. 2. Slowly release the brake pedal and make sure the transmission is in PARK before exiting the vehicle 3. Remove the key to prevent loss during transporting. 4.
  • Page 34 SAFETY Rear tie-down points (both sides of vehicle)
  • Page 35 SAFETY HAULING CARGO WARNING NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow this instruction could lead to serious burn injuries or death. Overloading the vehicle or carrying cargo improperly can alter vehicle handling and may cause loss of control or brake instability. Always follow these precautions when hauling cargo: Never exceed the stated load capacity for this vehicle.
  • Page 36 SAFETY Your POLARIS vehicle has been designed to carry a specific capacity. Reduce speed and allow a greater distance for braking when carrying cargo. Loads should be centered and carried as low as possible in the box. For stability on rough or hilly terrain, reduce both speed and cargo. Exercise caution if the cargo load extends over the side of the box.
  • Page 37 Always seek safe shelter when lightning is imminent and keep a safe distance from powerlines. For more information about safety, contact an authorized dealer or visit the web site at WWW.EGIMOTORS.COM FORESTRY APPLICATION AND CROP SPRAYING This vehicle does not have a Falling Objects Protective Structure (FOPS).
  • Page 38 SAFETY SAFETY LABELS AND LOCATIONS Warning labels have been placed on the vehicle for your protection. Read and follow the instructions of the labels on the vehicle carefully. If any of the labels depicted in this manual differ from the labels on your vehicle, always read and follow the instructions of the labels on the vehicle.
  • Page 39 SAFETY GENERAL ALERT WARNING Always read the owner’s manual. Never allow anyone under 16 years of age to operate this vehicle. Never use alcohol or drugs before or while driving or riding. This vehicle is not approved for on-road operation. Part number: 7183306 GENERAL ALERT (7183307) •...
  • Page 40 SAFETY INTAKE ALERT (7185975) Use a Polaris approved air filter. The use of a non-Polaris approved air filter may cause engine damage. Before installing filter ensure there is no dirt or debris in the clean side of the intake tube. The air filter must be properly seated and the hinges fully inserted when the lid is reinstalled.
  • Page 41 Never carry passengers in cargo box. Passengers can be thrown off. This can cause serious injury or death. Read owner’s manual. Never carry or transport fuel on this vehicle. Label Location: In the cargo box. Specification RZR XP CREW 1000 Maximum Cargo Box Load 136 kg Front: 131 / 1,31 Tire Pressure...

  • Page 43: Features And Controls

    FEATURES AND CONTROLS FEATURES AND CONTROLS COMPONENT LOCATIONS Cargo Box Cab Door ROPS Frame NFC Chip Radiator Fuel Tank Cap Cargo Tie-Downs (4 corners) Brake Pedal Throttle Pedal GearSelector Hand Hold / Lug Wrench...
  • Page 44 FEATURES AND CONTROLS CONSOLE Ignition Switch Headlight Switch Battery Charge Port AWD Switch Instrument Cluster 12V Accessory Outlet Green Light : indicator of position light Red Light : Parking Brake P Position on the shift lever...
  • Page 45 FEATURES AND CONTROLS IGNITION SWITCH / LIGHT SWITCH Use the ignition switch to start the engine and to turn the lights on or off. The key can be removed from the switch when it is in the OFF position. Turn the key to the OFF position to stop the engine.
  • Page 46 FEATURES AND CONTROLS ALL WHEEL DRIVE (AWD) SWITCH Use the All Wheel Drive (AWD) rocker switch to change the vehicle’s driveline mode. There are two available settings: • All Wheel Drive (AWD) • Two Wheel Drive (2WD) Press the top of the rocker switch to engage All Wheel Drive.
  • Page 47 FEATURES AND CONTROLS AUXILIARY OUTLETS WARNING To avoid electric shock, do not touch power outlets with wet hands or insert any object that the power outlet is not designed to receive. Close the lid when not in use. NOTICE The front console accessory outlet is always active. The accessory outlet in the armrest storage bin is only active when the ignition switch is set to ON.
  • Page 48 FEATURES AND CONTROLS ELECTRONIC POWER STEERING (EPS) Electronic power steering engages when the ignition key is turned to the ON position. EPS remains engaged whether the vehicle is moving or idle. The EPS warning indicator briefly illuminates when the key is turned to the ON position.
  • Page 49 FEATURES AND CONTROLS SEAT ADJUSTMENTS SEAT ADJUSTMENT On seats equipped with an adjustment lever under the front edge of the seat, pull the lever to the left. Slide the seat forward or rearward to the desired position. Release the lever. The seat will lock into the new position.
  • Page 50 FEATURES AND CONTROLS TIE-DOWN LOCATIONS Front tie-down points (both sides of vehicle) Rear tie-down points (both sides of vehicle)
  • Page 51 FEATURES AND CONTROLS FUEL WARNING Gasoline and gasoline vapor is highly flammable and explosive. Refuel outdoors or in a well ventilated area free of any source of flame or sparks, including pilot lights from water heaters, furnaces, or clothes dryers. To avoid fires and explosions, follow these precautions when refueling.
  • Page 52 FEATURES AND CONTROLS WARNING Gasoline can expand while inside the tank. To avoid fires and explosions, do not overfill the tank. Allow room for gasoline to expand inside the tank by leaving the tank neck empty. NOTICE Use minimum 87 Octane (or higher) unleaded fuel (minimum pump octane number of 87 R+M2).
  • Page 53 FEATURES AND CONTROLS CAB DOORS This vehicle is equipped with cab doors. Riding in this vehicle without closed and latched cab doors increases the risk of serious injury or death in the event of an accident or rollover. Always make sure all cab doors are closed and latched when riding in this vehicle.
  • Page 54 FEATURES AND CONTROLS LUG WRENCH The passenger hand hold can be used as an adjustable lug nut wrench with 18 mm and 19 mm sockets. To remove the lug nut wrench, do the following: 1. Release the lever lock by rotating downward 2.
  • Page 55 FEATURES AND CONTROLS HOOD To remove the hood, do the following: 1. Unscrew the hood fasteners with a T40 Torx drive bit. 2. Grasp the upper hood edge and pull upward to disengage the fasteners. 3. Pivot the hood forward and lift upward to disengage the lower hood hooks. 4.
  • Page 56 FEATURES AND CONTROLS SEAT BELTS This POLARIS vehicle is equipped with seat belts for all riders. Always make sure the seat belts are secured for the operator and all passengers before riding. The driver’s seat belt is equipped with a seat belt interlock. Vehicle speed will be limited to 15 mph (24 km/h) if the seat belt is not secured.
  • Page 57 FEATURES AND CONTROLS Shoulder Belt Buckle Release Button Harness Pads Harness Buckle Tilt-locks Thigh Belt Chest Clip Lap Belt INSPECTING THE HARNESS WARNING Failure to perform regular inspection can reduce the effectiveness of the seat belt during a crash and could result in serious injury or death. Before each ride, perform the following inspection:...
  • Page 58 FEATURES AND CONTROLS 1. Inspect belt fabric on entire system for cuts, fraying, extreme or unusual wear. Most common areas of belt wear include the buckle/ tongue area, the shoulder guide area, and any place where the belt makes contact with vehicle or seat.
  • Page 59 FEATURES AND CONTROLS 5. Inspect shoulder web guide. Seat belt must move freely through shoulder web guide. Shoulder web guides must be free of obstructions and must not snag or wear webbing fabric. Corrective Action: Adjust shoulder web guide hardware and/or remove obstruction.
  • Page 60 FEATURES AND CONTROLS Down, locked position 2 Up unlocked position To adjust the harness: 1. Put your arms through the shoulder belts. The belts should lay flat and not be twisted. The shoulder belt should not rub against your neck or fall off your shoulder.
  • Page 61 FEATURES AND CONTROLS 4. Tighten thigh belts. If your harness is equipped with thigh belts, adjust them for comfort and be sure to keep the harness buckle centered and below your belly button. The lap belt must remain pressed against your pelvic bones. 5.
  • Page 62 FEATURES AND CONTROLS SEAT BELT INSPECTION Inspect all seat belts for proper operation before each use of the vehicle. 1. Push the latch plate into the buckle until it clicks. The latch plate must slide smoothly into the buckle. A click indicates that it's securely latched. 2.
  • Page 63 FEATURES AND CONTROLS GEAR SELECTOR NOTICE Do not attempt to shift the transmission while the vehicle is moving or damage to the transmission could result. Always shift when the vehicle is stationary and the engine is at idle. To change gears, stop the vehicle, and with the engine idling, move the lever to the desired gear.
  • Page 64 FEATURES AND CONTROLS SERVICE ACCESS PANELS REAR ACCESS PANEL The rear access panel is located behind the seats on the frame of the vehicle. Remove the seats and turn the 1/4 studs to remove the access panel to reach the air filter, oil filter, and other serviceable engine components.
  • Page 65 FEATURES AND CONTROLS BRAKE AND THROTTLE PEDALS BRAKE PEDAL Press the brake pedal to slow or stop the vehicle. Apply the brakes while starting the engine. THROTTLE PEDAL Push the throttle pedal down to increase engine speed. Spring pressure returns the pedal to the rest position when released. Always check that the throttle pedal returns normally before starting the engine.
  • Page 66 FEATURES AND CONTROLS ALL WHEEL DRIVE (AWD) SYSTEM The All Wheel Drive system is controlled by the AWD switch. Once the vehicle is in gear, the switch is set to one of two modes. When the switch is on 2X4 , the vehicle is in two-wheel drive at all times.
  • Page 67 FEATURES AND CONTROLS DISENGAGING AWD Move the AWD switch to the center or bottom position to disengage AWD. If the switch is turned off while the front hubs are driving, they will not release until the rear wheels regain traction. In some situations, the front gearcase may remain locked after turning the AWD switch off.
  • Page 68 FEATURES AND CONTROLS WINCH OPERATION Read the Winch Safety Precautions in the preceding pages before using your winch. Consider practicing the operation and use of your winch before you actually need to use it in the field. WARNING Improper winch use can result in SEVERE INJURY or DEATH. Always follow all winch instructions and warnings in this manual.
  • Page 69 FEATURES AND CONTROLS WARNING Never put your fingers into the hook. This could lead to SEVERE INJURY. • Attach the hook itself onto the load or use a tow strap or chain to secure the load to the winch cable. A “tow strap”...
  • Page 70 FEATURES AND CONTROLS • If possible, keep the winch cable aligned with the centerline of the winching vehicle. This will help the spooling of the winch cable and reduce the load on the fairlead. • If freeing a stuck vehicle by attaching to a tree, use an item such as a tow strap to avoid damaging the tree during winch operation.
  • Page 71 FEATURES AND CONTROLS c. On a long pull, it may be necessary to stop winching so that the damper can be repositioned to the new mid-point of the winch cable. Always release the tension on the winch cable before repositioning the damper. d.
  • Page 72 FEATURES AND CONTROLS 13. Extensive winching will run down the battery on the winching vehicle. Let the winching vehicle’s engine run while operating the winch to prevent the battery from running low if winching for long periods. 14. The winch motor may become hot during winch use. If you winch for more than 45 seconds, or if the winch stalls during operation, stop winching and permit the winch to cool down for 10 minutes before using it again.
  • Page 73 FEATURES AND CONTROLS INSTRUMENT CLUSTER NOTICE High water pressure may damage components. Wash the vehicle by hand or with a garden hose using mild soap. Certain products, including insect repellents and chemicals, will damage the speedometer lens and other plastic surfaces.
  • Page 74 FEATURES AND CONTROLS...
  • Page 75 FEATURES AND CONTROLS With the ignition key off, pressing the MODE button or either toggle button will power up the Rider Information Center for 10 seconds to allow viewing of the odometer and the clock. INDICATOR LAMPS LAMP INDICATES CONDITION When standard mode is selected, speed displays in miles per hour.
  • Page 76 FEATURES AND CONTROLS LAMP INDICATES CONDITION If this lamp illuminates while the engine is running, promptly contact an authorized dealer or another qualified person who can assist with diagnosis. If abnormal engine operation is Check Engine detected the light will remain on as long as the fault condition exists.
  • Page 77 FEATURES AND CONTROLS LAMP INDICATES CONDITION Cruise Control Before using the cruise control, read the safety Engaged (if and operation procedures. equipped) Performance Limited (if Not applicable. equipped) RIDER INFORMATION CENTER The rider information center is in the instrument cluster. All segments will light up for one second at start-up.
  • Page 79 FEATURES AND CONTROLS Fuel Gauge The segments of the fuel gauge show the level of fuel in the fuel tank. When the last segment clears, a low fuel warning is activated. The outline of the fuel display will flash. Refuel immediately.
  • Page 80 FEATURES AND CONTROLS ACCESSING MENUS AND OPTIONS GAUGE SETTINGS MENU Press and release the MODE button to cycle through the Area 1 modes until the desired default mode displays. See the Mode Information Displays section for details. Press and hold the MODE button to enter the settings menu. The OPTIONS screen will display for a few seconds.
  • Page 81 FEATURES AND CONTROLS BACKLIGHT BRIGHTNESS The information center backlight can be set to either blue or red. 1. Press and hold the MODE button to enter the settings menu. 2. Press either toggle button to cycle to the “BL LEVEL” option. Press MODE to select.
  • Page 82 FEATURES AND CONTROLS DISPLAY UNITS (STANDARD/METRIC) 1. Press and hold the MODE button to enter the settings menu. 2. Press either toggle button to cycle to the desired “UNITS” option (distance, temperature or volume). Press MODE to select. 3. Press either toggle button to cycle to the desired setting. 4.
  • Page 83 FEATURES AND CONTROLS PROGRAMMABLE SERVICE INTERVAL The service interval counter is programmed to 25 hours at the factory. As hours of engine operation increase, the counter decreases. The wrench icon will flash for about 10 seconds when the counter reaches zero (0), and each time the key is turned on thereafter, until the counter is reset.
  • Page 84 FEATURES AND CONTROLS PIN ACTIVATED SECURITY SYSTEM (IF EQUIPPED) The Pin Activated Security System (P.A.S.S.) allows you to safely lock and unlock your vehicle from the gauge screen. 1. Press and hold the MODE button to enter the Options Menu. NOTICE “OPTIONS”...
  • Page 85 FEATURES AND CONTROLS To require a PIN for your vehicle to start, select “REQUIRE PIN TO START” from the Advanced Menu using the following steps: Reference the image shown above: Press the MODE button. Toggle the Up/Down buttons to view “ON” or “OFF”. Press the MODE button to select and return to the Advanced Menu.
  • Page 86 FEATURES AND CONTROLS 1. Press and hold the MODE button to enter the settings menu. 2. Press either toggle button to cycle to the “DIAGCODE” option. Press MODE to select. 3. More than one diagnostic code may be present. Press the toggle UP button to see if more codes are present.

  • Page 87: Operation

    OPERATION OPERATION VEHICLE BREAK-IN ENGINE AND DRIVETRAIN BREAK-IN 1. Fill the fuel tank with the recommended fuel. See the Refueling section for details. Always exercise extreme caution whenever handling fuel. 2. Check the oil level. See the Oil Check section for details. Add the recommended oil as needed to maintain the oil level in the safe operating range.
  • Page 88 OPERATION BRAKE BURNISHING It is recommended that a burnishing procedure be performed on new vehicles or after installation of new brake pads or rotors. This helps to conform the pads to the rotor surface and achieve optimum braking performance. Test drive the machine and gradually accelerate to more than 20 mph. Apply light to moderate pressure to the brake pedal to slow the vehicle to roughly 5 mph.
  • Page 89 OPERATION PVT BREAK-IN (CLUTCHES / BELT) A proper break-in of the clutches and drive belt will ensure a longer life and better performance. If a belt fails, always clean any debris from the duct and from the engine compartment. STANDARD BREAK-IN Drive at slower speeds for the first 50 miles (80 km) of operation.
  • Page 90 OPERATION OPERATING GUIDELINES STARTING THE ENGINE NOTICE Operating the vehicle immediately after starting could cause engine damage. Allow the engine to warm up for several minutes before operating the vehicle. 1. Position the vehicle on a level surface outdoors or in a well- ventilated area. 2.
  • Page 91 OPERATION DRIVING IN REVERSE WARNING Before shifting into reverse, use extra care to make sure the area is clear of people or obstacles. When it’s safe to proceed, back slowly. Follow these precautions when operating in reverse: 1. Always check for obstacles or people behind the vehicle. 2.

  • Page 93: Emission Control Systems

    EMISSION CONTROL SYSTEMS EMISSION CONTROL SYSTEMS NOISE EMISSION CONTROL SYSTEM Do not modify the engine, intake or exhaust components, as doing so may affect compliance with governmental noise level requirements. CRANKCASE EMISSION CONTROL SYSTEM This engine is equipped with a closed crankcase system. Blow-by gases are forced back to the combustion chamber by the intake system.

  • Page 95: Maintenance

    MAINTENANCE MAINTENANCE ELEVATING THE VEHICLE FOR SERVICE Some service procedures require that the vehicle be elevated. Before proceeding, remember to: • Always position the vehicle on a firm, level surface before elevating. • Only use an appropriate sized lift or jack. •...
  • Page 96 MAINTENANCE Careful periodic maintenance will help keep your vehicle in the safest, most reliable condition. Inspection, adjustment and lubrication of important components are explained in the periodic maintenance chart. Inspect, clean, lubricate, adjust and replace parts as necessary. When inspection reveals the need for replacement parts, genuine parts are available from your dealer.
  • Page 97 MAINTENANCE INITIAL BREAK-IN SERVICE FIRST 25 HOURS / 1 MONTH Engine Oil and Filter Change the engine oil and filter. Inspect air filter; replace as necessary. Ensure proper installation of filter and airbox cover. Engine Air Filter Inspect ducts and screens; clean and replace as necessary.
  • Page 98 MAINTENANCE Vehicles subjected to severe use must be serviced at 50% of the stated interval. Examples of Severe Use: Frequent immersion in mud, water, or sand, constant high RPM use, prolonged low-speed heavy load operation, extended idle, short trip cold weather operation, and prolonged high speed operation. EVERY 25 HOURS / 500 MILES (800 KM) OR 6 MONTHS FOLLOWING INITIAL BREAK-IN SERVICE Inspect air filter;...
  • Page 99 MAINTENANCE Vehicles subjected to severe use must be serviced at 50% of the stated interval. Examples of Severe Use: Frequent immersion in mud, water, or sand, constant high RPM use, prolonged low-speed heavy load operation, extended idle, short trip cold weather operation, and prolonged high speed operation. EVERY 50 HOURS / 1000 MILES (1600 KM) OR 12 MONTHS FOLLOWING INITIAL BREAK-IN SERVICE Engine Oil and Filter...
  • Page 100 MAINTENANCE EVERY 50 HOURS / 1000 MILES (1600 KM) OR 12 MONTHS FOLLOWING INITIAL BREAK-IN SERVICE Fluid level inspection; inspect for fluid leaks; add coolant if needed. Inspect coolant strength Cooling System seasonally; pressure test system yearly. Wheel Bearings Inspect; replace as needed. Cycle key to pressurize fuel pump;...
  • Page 101 MAINTENANCE Vehicles subjected to severe use must be serviced at 50% of the stated interval. Examples of Severe Use: Frequent immersion in mud, water, or sand, constant high RPM use, prolonged low-speed heavy load operation, extended idle, short trip cold weather operation, and prolonged high speed operation. ADDITIONAL MAINTENANCE INTERVALS Every 2000 miles Replace fluid;...
  • Page 102 MAINTENANCE...
  • Page 103 MAINTENANCE LUBRICATION RECOMMENDATIONS Check and lubricate all components at the intervals outlined in the Periodic Maintenance Chart beginning on page , or more often under severe use, such as wet or dusty conditions. Items not listed in the chart should be lubricated at the general lubrication interval.
  • Page 104 MAINTENANCE ENGINE OIL OIL RECOMMENDATIONS WARNING Vehicle operation with insufficient, deteriorated, or contaminated engine oil will cause accelerated wear and may result in engine seizure, accident, and injury. Always perform the maintenance procedures as outlined in the Periodic Maintenance Chart. Ambient Temperature Range Recommended Oil -35 °F to +100 °F...
  • Page 105 MAINTENANCE OIL CHECK Always check the oil when the engine is cold. If the engine is hot when the oil is checked, the level will appear to be overfull. Access the oil check dipstick through the right rear wheel well. Access the oil fill cap by removing the cargo box.
  • Page 106 MAINTENANCE OIL AND FILTER CHANGE WARNING Spilled oil left on engine components or in the engine area may pose a fire hazard. Use shop rags to clean any spilled oil. If needed, use a non-flammable solvent on the rag to aid the cleaning process. Do not use any device such as pressurized water or air as this may disperse the oil onto engine components and could pose a fire hazard.
  • Page 107 MAINTENANCE 5. Access the oil filter behind where the driver seat would be. 6. Place shop rags under the filter to catch any spilled oil during removal. Using the your hand, or an Oil Filter Wrench, turn the oil filter counter-clockwise until oil starts to drain through the slot in the skid plate.
  • Page 108 MAINTENANCE 11. Remove the cargo box. See the Cargo Box Removal section for details. Add engine oil through the oil fill located on top of the engine valve cover. 12. Fill the engine to the recommended specification. See the Specifications chapter.
  • Page 109 MAINTENANCE 18. Add the recommended oil as necessary to bring the oil level within the SAFE range (between the holes) on the dipstick. Do NOT overfill. 19. When finished, reinstall dipstick. 20. Reinstall the cargo box. 21. Dispose of used oil, filter, and rags properly. IMPORTANT A rising oil level between checks during cold weather operation can indicate contaminants such as gas or moisture collecting in the crankcase.
  • Page 110 MAINTENANCE TRANSMISSION (MAIN GEARCASE) Always check and change the fluid at the intervals outlined in the Periodic Maintenance Chart section. Refer to the Gearcase Specifications Chart section for recommended lubricants, capacities and torque specifications. FLUID CHECK The fill plug is located on the rear of the gearcase. Maintain the fluid level at the bottom of the fill plug hole.
  • Page 111 MAINTENANCE FLUID CHANGE The drain plug is located on the bottom of the gearcase. Access the drain plug through the drain hole in the skid plate. 1. Remove the fill plug. 2. Place a drain pan under the drain plug. 3.
  • Page 112 MAINTENANCE DEMAND DRIVE UNIT (FRONT GEARCASE) Always check and change the fluid at the intervals outlined in the Periodic Maintenance Chart. Refer to the Gearcase Specifications Chart for recommended lubricants, capacities and torque specifications. DEMAND DRIVE FLUID CHANGE The demand drive drain plug is located on the bottom of the gearcase.
  • Page 113 MAINTENANCE GEARCASE SPECIFICATION CHART Use of other fluids may result in improper operation of components. See the POLARIS Products section for part numbers. DRAIN FILL PLUG PLUG GEARCASE LUBRICANT CAPACITY TORQUE TORQUE Transmission 1650 ml 14-19 Nm 14-19 Nm (Main Gearcase Gearcase) Lubricant &...
  • Page 114 MAINTENANCE SPARK PLUG REMOVAL AND REPLACEMENT WARNING To avoid burns, do not touch hot components or attempt maintenance before allowing to cool. 1. Remove the cargo box to access the engine. See the Cargo Box Removal section for details. 2. Remove the two fasteners holding the plug shield in place.
  • Page 115 MAINTENANCE 4. Clean out plug wells with compressed air to remove any loose dirt or debris. 5. Rinse plug wells with water and dry with compressed air. NOTICE Spark plug wells have drain holes built into the cylinder head to allow water to drain out.
  • Page 116 MAINTENANCE 11. Install spark plugs and torque to specification. TORQUE Spark Plug Torque: 9 ft-lbs (12 Nm) 12. Re-install the two plug covers. 13. Re-install the plug shield with the two retained fasteners. 14. Re-install the plug covers. TORQUE Plug Cover Fastener Torque: 7 ft-lbs (10 Nm) 15.
  • Page 117 MAINTENANCE FUSE / RELAY CENTER If the engine stops or will not start, if the power steering stops working (if equipped), or if you experience other electrical failures, a fuse may need replacement. Locate and correct any short circuits that may have caused the blown fuse, then replace the fuse.
  • Page 118 MAINTENANCE LABEL VALUE FUNCTION Accessory Relay Coil, ECM Wake-Up, Pump Relay Coil, Chassis Relay Coil, Start Relay Coil, EFI Relay Coil, Mag/PTO 10A Fuse Inject, Lights Relay Coil, Fan Relay Coil, Ignition Relay Coil, Starter Solenoid Coil, Brake Relay Coil Parent block to TERM and INSTR ACCY ACCY 15A Fuse...
  • Page 119 MAINTENANCE COOLING SYSTEM CAUTION Escaping steam can cause burns. Never remove the pressure cap while the engine is warm or hot. Always allow the engine to cool before removing the pressure cap. The engine coolant level is maintained by a remote pressurized tank system. The remote pressurized tank is connected to both radiators and provides a single pressure cap and fill point for the vehicle.
  • Page 120 MAINTENANCE RADIATORS AND COOLING FAN Always check and clean the screens and radiator fins at the intervals outlined in the Periodic Maintenance Chart section. Do not obstruct or deflect air flow through the radiators by installing unauthorized accessories in front of the radiators or behind the cooling fan.
  • Page 121 MAINTENANCE 1. If only needing to check coolant level, there is a view from driver’s side rear fender. A flashlight may be needed. The coolant level can also be viewed by removing the cargo box. Ensure engine has cooled off prior to checking. 2.
  • Page 122 MAINTENANCE 3. Slowly remove the radiator pressure cap 4. Remove the pressure cap and use a funnel to add coolant as needed. Maintain the coolant level at the cold fill mark on the side of the pressure tank (only when the fluid has cooled, if after operation). 5.
  • Page 123 MAINTENANCE VARIABLE TRANSMISSION (PVT) SYSTEM WARNING Failure to comply with the instructions in this warning can result in severe injury or death. Do not modify any component of the PVT system. Doing so may reduce its strength so that a failure may occur at a high speed. The PVT system has been precision balanced.
  • Page 124 MAINTENANCE BELT REPLACEMENT / DEBRIS REMOVAL If a belt fails, always clean any debris from the outlet duct and from the clutch and engine compartments when replacing the belt. Wiggling and rocking the cover will help it move around the bolts on the clutch towers.
  • Page 125 MAINTENANCE 7. Slide the cover outward until it hits the shock spring. 8. Rotate the cover downward. 9. Slide the cover down underneath the skid plate. • For easiest removal, ensure the vehicle is sitting on the ground at normal ride height or lower, which will provide more clearance between the cover and the shock...
  • Page 126 MAINTENANCE 10. Insert the clutch spreader tool into the driven clutch . The clutch spreader tool is provided in the tool kit. 11. Turn the tool clockwise to open the sheaves on the driven clutch. 12. Remove ALL debris wrapped in and around the PVT system. 13.
  • Page 127 MAINTENANCE PVT DRYING There may be some instances when water is accidently ingested into the PVT system. Use the following instructions to dry it out before operating. NOTICE When washing the vehicle, always avoid spraying water directly toward the PVT intake duct. See the Washing the Vehicle section for details. 1.
  • Page 128 MAINTENANCE FILTER SYSTEMS INTAKE PRE-FILTERS The engine intake pre-filter located on the right side of the vehicle. The clutch air intake is located on the left side of the vehicle. IMPORTANT Ensure there are no obstructions on either side of the pre-filters, including obstructions caused by items stored in the cargo box.
  • Page 129 MAINTENANCE 1. Remove the driver’s seat and front passenger seat. See the Seat Removal section for details. 2. Remove the access panel. See the Access Panel Removal section for details. 3. Clean all dirt and debris from the air box area. 4.
  • Page 130 MAINTENANCE 7. With the filter removed, clean the intake tube and air box thoroughly. Wipe well with a clean, dry cloth. NOTICE Dirt or debris in the intake tube could result in severe engine damage. Always clean all dirt and debris from the intake tube before installing the filter. 8.
  • Page 131 MAINTENANCE SPARK ARRESTOR WARNING Never operate the vehicle without the spark arrestor. Remove any combustible materials from the area. Failure to heed the following warnings while servicing the spark arrestor could result in serious injury or death. Never run the engine in an enclosed area. Exhaust contains poisonous carbon monoxide gas that can cause loss of consciousness or death in a very short time.
  • Page 132 MAINTENANCE BRAKES WARNING Operating the vehicle with a spongy brake pedal can result in loss of braking, which could cause an accident resulting in severe injury or death. Never operate the vehicle with a spongy-feeling brake pedal. The front and rear brakes are hydraulic disc type brakes activated by the brake pedal.
  • Page 133 MAINTENANCE BRAKE INSPECTION WARNING Do not apply WD-40® or any petroleum product to brake discs. These types of products are flammable and may also reduce the friction between the brake pad and caliper. 1. Check the brake system for fluid leaks. 2.
  • Page 134 MAINTENANCE BRAKE FLUID WARNING After opening a bottle of brake fluid, always discard any unused portion. Never store or use a partial bottle. Brake fluid is hygroscopic, meaning it rapidly absorbs moisture from the air. The moisture causes the boiling temperature of the brake fluid to drop, which can lead to early brake fade and the possibility of accident or severe injury.
  • Page 135 MAINTENANCE SUSPENSION SETTINGS FRONT / REAR SHOCK COMPRESSION ADJUSTMENT The compression damping clicker knob is located at the top of the shock reservoir. 1. Turn the clicker clockwise to increase compression damping. 2. Turn the clicker counter-clockwise to decrease compression damping. Shock Compression Settings Model Location...
  • Page 136 MAINTENANCE WALKER EVANS RACING® SHOCKS Front Shock Preload Measurement Rear Shock Preload Measurement FACTORY DEFAULT PRELOAD SETTINGS FACTORY DEFAULT PRELOAD SETTINGS WALKER 1.25 inches (32 mm) Front RZR CREW 1000 5.25 inches (133 mm) Rear Follow these guidelines if you make adjustments to this suspension. •...
  • Page 137 MAINTENANCE TIRES WARNING Operating your vehicle with worn tires will increase the possibility of skidding, loss of control and an accident, which could result in serious injury or death. Always replace tires when the tread depth measures 1/8 in (3 mm) or less. Improper tire inflation or the use of non-standard size or type of tires may adversely affect vehicle handling, which could result in vehicle damage or personal injury.
  • Page 138 MAINTENANCE If the nut slot does not align with the hole, do not loosen. Apply additional torque until slot aligns with the hole. WHEEL REMOVAL 1. Position the vehicle on a level surface. 2. Place the transmission in PARK. 3. Stop the engine. 4.
  • Page 139 MAINTENANCE LIGHTS Headlight and taillight lenses become dirty during normal operation. Clean all lights frequently to ensure a clear field of vision as well as visibility to other vehicles. LED LAMPS If an LED headlamp appears to have moisture or fogging inside the lens, disconnect the wiring harness from the headlamp(s) for a few days to allow the moisture to clear out.
  • Page 140 MAINTENANCE HEADLIGHT BEAM ADJUSTMENT The headlight beam can be adjusted slightly upward or downward and to the left or right. 1. Ensure the tire pressure of all tires is at the recommended levels. 2. Position the vehicle on a level surface. The headlight should be approximately 25 ft.
  • Page 141 MAINTENANCE HEADLIGHT LAMP REPLACEMENT Do not service the headlamps until they've cooled sufficiently. 1. Unplug the headlamp from the wiring harness. Be sure to pull on the connector, not on the wiring. 2. Turn the lamp counter-clockwise to remove it. 3.
  • Page 142 MAINTENANCE STEERING WHEEL INSPECTION Check the steering wheel for specified freeplay and smooth operation at the intervals outlined in the Periodic Maintenance Chart. 1. Position the vehicle on level ground. 2. Lightly turn the steering wheel left and right. 3. There should be 20-25 mm (0.8-1.0”) of freeplay. 4.
  • Page 143 MAINTENANCE BATTERY WARNING Improperly connecting or disconnecting battery cables can result in an explosion and cause serious injury or death. When removing the battery, always disconnect the negative (black) cable first. When reinstalling the battery, always connect the negative (black) cable last. Your vehicle has a low-maintenance battery.
  • Page 144 MAINTENANCE The single most important thing about maintaining a sealed battery is to keep it fully charged. Check the battery voltage with a voltmeter or multimeter. A fully charged battery will register 12.8 V or higher. If the voltage falls below 12.5V, charge it immediately, or the battery runs the risk of sulfation and reduced battery life.
  • Page 145 MAINTENANCE BATTERY INSTALLATION Using a new battery that has not been fully charged can damage the battery and result in a shorter life. It can also hinder vehicle performance. Follow the instructions in the Battery Charging section before installing the battery. 1.
  • Page 146 MAINTENANCE CLEANING AND STORAGE WASHING THE VEHICLE Keeping your POLARIS vehicle clean will not only improve its appearance but it can also extend the life of various components. Water in the PVT system could cause the drive belt to become wet and slip in the clutches.
  • Page 147 MAINTENANCE If a high pressure water system is used for cleaning, exercise extreme caution. The maximum pressure should not exceed 3000 PSI, 2.5 GPM with a 40° pressure washer nozzle. Make sure to keep the pressure washer nozzle 70 Cm ft from the vehicle away from the surface being cleaned. The water may damage components and could remove paint and labels.
  • Page 148 MAINTENANCE POLISHING THE VEHICLE POLARIS recommends the use of common household aerosol furniture polish for polishing the finish on your vehicle. Follow the instructions on the container. POLISHING TIPS • Avoid the use of automotive products, some of which can scratch the finish of your vehicle.
  • Page 149 MAINTENANCE • Demand drive fluid (front gearcase) • Rear gearcase fluid (if equipped) • Transmission fluid • Brake fluid (change every two years and any time the fluid looks dark or contaminated) • Coolant (test strength/fill) INSPECT AND LUBRICATE Inspect all cables and lubricate all areas of the vehicle as recommended in the Periodic Maintenance Chart section.
  • Page 150 MAINTENANCE STORAGE AREA / COVERS Be sure the storage area is well ventilated. Cover the vehicle with a genuine cover. Do not use plastic or coated materials, they do not allow enough ventilation in order to prevent condensation, and may promote corrosion and oxidation.

  • Page 151: Specifications

    SPECIFICATIONS SPECIFICATIONS RZR XP CREW 1000 Gross Vehicle Weight 1320 kg Dry Weight 810 kg Test GVW - Rollover Protection 1247 kg per OECD Code 4 System (ROPS) Rear Cargo Box Capacity 136 kg Maximum Weight Capacity 408 kg (Payload)
  • Page 152 SPECIFICATIONS Front Suspension Independent double a-arm with 40.6 cm travel Rear Suspension Independent trailing arms with 45.7 cm travel Lubrication System Wet Sump Driving System Type Automatic Variable Transmission Shift Type Dual Range P/R/N/L/H Tire Size - Front 29x9-14 Tire Size - Rear 29x11-14 Tire Speed / Load Index Front: 84J...
  • Page 153 The measured noise and vibration values are for stationary vehicles, noise and vibration values during operation/traveling in foreseeable normal use of the vehicles are not significantly different. OUTPUT GEAR RATIOS OUTPUT GEAR RATIOS FOR RZR XP Crew 1000 Rear High Gear 13.01 Low Gear 28.84...

  • Page 155: Polaris Products

    POLARIS PRODUCTS LUBRICANTS / SERVICE PRODUCTS PART NUMBER DESCRIPTION Engine Lubricant 502484 PS-4 Full Synthetic 5W-50 4-Cycle Oil — (1 L) 502485 PS-4 Full Synthetic 5W-50 4-Cycle Oil — (4 L) 503220 PS-4 Extreme Full Synthetic 0W-50 4-Cycle Oil — (1 L) 503221 PS-4 Extreme Full Synthetic 0W-50 Engine Oil —...

  • Page 157: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING DRIVE BELT WEAR/BURN POSSIBLE CAUSE SOLUTION Driving onto a pickup or tall Use low range during loading. trailer in high range Starting out going up a steep Use low range. incline Driving at low RPM or ground Drive at a higher speed or use low range more frequently. speed –...
  • Page 158 TROUBLESHOOTING ENGINE DOESN’T TURN OVER POSSIBLE CAUSE SOLUTION Low battery voltage Recharge the battery to 12.8 VDC Loose battery connections Check all connections and tighten Loose solenoid connections Check all connections and tighten Loose electronic control box Inspect, clean, reinstall connectors connections Your dealer or other qualified Mechanical failure...
  • Page 159 TROUBLESHOOTING ENGINE BACKFIRES POSSIBLE CAUSE SOLUTION Out of fuel Refuel Inspect, clean and/or replace spark Weak spark from spark plug plugs Incorrect spark plug gap or heat Set gap to specs or replace plugs range Replace with fresh recommended Old or non-recommended fuel fuel Incorrectly installed spark plug wires Your dealer or other qualified...
  • Page 160 TROUBLESHOOTING ENGINE RUNS IRREGULARLY, STALLS, OR MISFIRES POSSIBLE CAUSE SOLUTION Fouled or defective spark plugs Inspect, clean and/or replace spark plugs Your dealer or qualified person can Worn or defective spark plug wires assist Incorrect spark plug gap or heat Set gap to specs or replace plugs range Loose or missing intake system...
  • Page 161 TROUBLESHOOTING POSSIBLE LEAN FUEL CAUSE SOLUTION Your dealer or qualified person can Clogged fuel filter assist Your dealer or qualified person can Low fuel pressure assist ENGINE STOPS OR LOSES POWER POSSIBLE CAUSE SOLUTION Out of fuel Refuel Kinked or plugged fuel tank vent line Inspect and replace or filter Water is present in fuel...
  • Page 162 TROUBLESHOOTING POSSIBLE CAUSE SOLUTION Your dealer or other qualified Other mechanical failure person can assist Clean radiator screen and core, clean Overheated engine engine exterior, check coolant level. Your dealer or other qualified person can assist.

  • Page 163: Warranty

    WARRANTY WARRANTY LIMITED WARRANTY This warranty covers parts and labor charges for repair or replacement of defective parts and begins on the date of purchase by the original retail purchaser. The duration of this warranty may vary by international region based upon local laws and regulations.
  • Page 164 WARRANTY WARRANTY COVERAGE AND EXCLUSIONS LIMITATIONS OF WARRANTIES AND REMEDIES This limited warranty excludes any failures that are not caused by a defect in material or workmanship. THIS WARRANTY DOES NOT COVER CLAIMS OF DEFECTIVE DESIGN. This warranty also does not cover acts of God, accidental damage, normal wear and tear, abuse or improper handling.
  • Page 165 WARRANTY LUBRICANTS AND FLUIDS 1. Mixing oil brands or using non-recommended oil may cause engine damage. We recommend the use of POLARIS engine oil. 2. Damage or failure resulting from the use of non-recommended lubricants or fluids is not covered by this warranty. This warranty provides no coverage for personal loss or expense, including mileage, transportation costs, hotels, meals, shipping or handling fees, product pick-up or delivery, replacement rentals, loss of product use, loss of profits, or...
  • Page 166 WARRANTY This warranty excludes damages or failures resulting from improper lubrication; improper engine timing; improper fuel; surface imperfections caused by external stress, heat, cold or contamination; operator error or abuse; improper component alignment, tension, adjustment or altitude compensation; snow, water, dirt or other foreign substance ingestion/contamination; improper maintenance;...
  • Page 167 WARRANTY LUBRICANTS AND FLUIDS 1. Mixing oil brands or using non-recommended oil may cause engine damage. We recommend the use only POLARIS engine oil. 2. Damage or failure resulting from the use of non-recommended lubricants or fluids is not covered by this warranty. This warranty provides no coverage for personal loss or expense, including mileage, transportation costs, hotels, meals, shipping or handling fees, product pick-up or delivery, replacement rentals, loss of product use, loss of profits, or...
  • Page 168 WARRANTY If you are traveling temporarily outside the country where your product was purchased, you should take your product to an authorized dealer. You must show the dealer photo identification from the country of the selling dealer's authorized location as proof of residence. Upon residence verification, the servicing dealer will be authorized to perform the warranty repair.
  • Page 169 WARRANTY EXPORTED PRODUCTS EXCEPT WHERE SPECIFICALLY REQUIRED BY LAW, THERE IS NO WARRANTY OR SERVICE BULLETIN COVERAGE ON THIS PRODUCT IF IT IS SOLD OUTSIDE THE COUNTRY OF THE SELLING DEALER'S AUTHORIZED LOCATION. This policy does not apply to products that have received authorization for export.

  • Page 171: Maintenance Log

    MAINTENANCE LOG MAINTENANCE LOG Use the following chart to record periodic maintenance. DATE MILES (KM) SERVICE PERFORMED / TECHNICIAN OR HOURS COMMENTS...
  • Page 172 Tractor Certificate of Pre-Delivery Year ______ Model______________________________ VIN___________________________________________ Engine Serial Number ____________________________ Key Number ____________ Km / Hours______________ Registration Plate Number_________________________ ASSEMBLY / SERVICE / INSPECTION - SEALED BATTERY – Apply dielectric grease to terminal bolts and install cable. Check Voltage and charge if below 12,8 Volts.
  • Page 173 Tractor Certificate of Pre-Delivery Year ______ Model______________________________ VIN___________________________________________ Engine Serial Number ____________________________ Key Number ____________ Km / Hours______________ Registration Plate Number_________________________ TEST RIDE ENGINE – Starting acceleration and smoothness. - IDLE SPEED – Verify when cold and hot the engine idle properly. - TROTTLE –...
  • Page 174 - SAFETY TRAINING COURSE SVIA – I have instructed the owner on the authorized SVIA Safety training online course. - PRE-DELIVERY CERTIFICATION – I certify that pre-delivery inspection and service have been perform on this vehicle in accordance with the instructions issued by Egimotors. DEALERSHIP NAME____________________________#_________ DELIVERED BY_________________________________________...
  • Page 175 Key Number ____________ Km / Hours______________ Registration Plate Number_________________________ CUSTOMER ACCEPTANCE - I have reviewed the Egimotors warranty Policy / Policies - I have inspected the Quadricycle and it meets my satisfaction. - I understand the importance of following the Owner’s Manual and instructions.
  • Page 176 Egimotors Via Filippo da Desio 49/51 20832 Desio (MB) ITALY info@polarisitalia.com For more informations visit www.Egimotors.it...

Table of Contents
