Retrax EQ Installation Sheet

PARTS INCLUDED IN YOUR KIT
1 EQ keypad
A
1 Access code card
B
TOOLS REQUIRED
•
Isopropyl alcohol
CABIN MODULE
•
Mentioned but only included
with cover.
1
To program the keypad:
1. Set the cabin module to pairing mode. (Before proceeding you must:
1. Unlock the vehicle using the factory remote. 2. Enter the vehicle. 3. Close
all doors. Then follow these steps within one minute: Turn IGN ON. Open
and close the door. Press and hold the brake. Open the door. Release the
brake.)
2. On the keypad, enter configuration mode by simultaneously pressing buttons
1/2, 3/4, and 9/0 (A) for at least 2 seconds. Backlight LED (B) will flash three
times.
3. Enter the master code. The backlight and green LED (B) will flash slowly two
5
times and then turn off.
3
7
4. Within 20 seconds, press and hold the 5/6 button (C) until the backlight LED
5
flashes rapidly and the cabin module unlocks the vehicle, confirming pairing
9
has been successful.
7
Important! If pairing fails,
wait for the LEDs to
turn off. Then, repeat
steps 2 and 3, and at
step 4 press and hold
7/8 until the LED
flashes rapidly.
Finally, you can
A
repeat steps 1-4.
5
9
7
Retrax • 917 S. 46th St., Grand Forks, ND 58201 • 800-206-4070 © Retrax is Retrax Holdings, LLC, 2023
4 1
1
2
2
1
6 1 3
2
2
3
4
4
4
5
3
8 6 5
7
4
8
6
6 9
0
5
7
0
6
8
4
8
7
1
5
2
6 1
3
3
7
4
5
6
8
7
8
9
6
0
0
8
5-Button Keypad Guide
INSTALLATION SHEET
Any damaged or missing parts?
Parts will be shipped to you directly.
Call 800-206-4070 Mon - Fri, 8:30 a.m. - 5:00 p.m. CST
or email retrax@retrax.com
1
A
2
3
4
5
6
7
8
9
0
1
B
2
1
3
2
2
C
4
4
3
5
4
6
5
7
6
8
7
The 5-button keypad is designed to be
placed on the outside of the driver's
side pillar, rear of cabin.
2
To mount the keypad:
1. Clean and prep the installation area
with an isopropyl alcohol-based solution.
2. Allow the surface to dry completely before
placing the keypad on the pillar.
3. Remove the red plastic backing from the
adhesive pad on the rear of the keypad.
Firmly press for 60 seconds to ensure
proper adhesion to the vehicle.
4000-151 Rev. 6-26-23
