Translation of the original instructions
EN
POWER PACK 520

SAFETY INSTRUCTIONS

This manual includes guidelines on the operation of your device
and the precautions to follow for your own safety. Ensure it
is read carefully before first use and keep it handy for future
reference. This device should only be used for charging and
/ or power supply within the limits indicated on the device
and in the manual. The safety instructions must be followed.
In case of improper or unsafe use, the manufacturer cannot
be held responsible
Device suitable for indoor use only. Do not expose to rain or
excessive moisture.
This device may be used by children from age 8 and by
persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, provided that they are
under supervision or have been told how to use the device
safely and are aware of the potential risks. Children must
not use the device as a plaything. Cleaning and servicing
tasks may not be carried out by children unless they are
supervised.
Do not use for charging non-rechargeable batteries.
Do not operate the device with a damaged power supply
cord or a damaged mains plug.
Do not use the device if the charging cable appears to be
damaged or assembled incorrectly in order to avoid any
risk of short circuiting the battery.
Never charge a frozen or damaged battery.
Do not cover the device.
Do not place the device near a fire or subject it to heat or to
longterm temperatures exceeding 50°C
Do not obstruct the cooling vents. Refer to the installation
section before operating the machine.
The automatic mode of operation and usage restrictions are
explained below in these operating instructions.
Connection:
Class II device (for the charger).
Maintenance:
• Service should be performed by a qualified person
• Warning! Always remove the power plug from the USB
input socket before carrying out any work on the device.
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POWER PACK 520 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GYS POWER PACK 520

  • Page 1 Translation of the original instructions POWER PACK 520 SAFETY INSTRUCTIONS This manual includes guidelines on the operation of your device and the precautions to follow for your own safety. Ensure it is read carefully before first use and keep it handy for future reference.
  • Page 2 PRODUCT DESCRIPTION The POWER PACK 520 is a portable power station suitable for home emergency power, outdoor travel, emergency interventions or field work. It is equipped with an internal battery (Lithium-Ion Polymer) with a capacity of 518 Wh (20 Ah) allowing to supply all types of devices operating at 5 / 9 / 12 / 15 / 20 Vdc as well as 230 Vac thanks to its internal inverter.
  • Page 3 520. Press button (1), the LCD display will light up. In case all outputs are inactive: after 10 seconds of inactivity, the backlight will turn off. After 30 seconds of inactivity, the display will turn off. The POWER PACK 520 will automatically switch to standby.
  • Page 4 1. Plug the charger port (3.5 mm) into the DC 24 V input (3) of the POWER PACK 520. 2. Connect the other end of the charger to a 230 V mains socket. 3. Allow the POWER PACK 520 to recharge and then disconnect it from the power supply by performing the reverse procedure.
  • Page 5 The DC 24 V / 2.5 A input (3) can accommodate the energy from a solar panel (80 W max - < 30 V no-load) . 1. Place the solar panel in direct sunlight without exposing the POWER PACK 520 to direct sunlight or moisture.
