- Page 1 User Manual HKS0201A3U & HKS0401A3U HKS0201A3U & HKS0401A3U English...
- Page 3 English...
- Page 4 Preface It’s our great honor that you have chosen the HDMI KVM Switch produced by our company, Tesla Elec Technology Co.,Ltd. In this user manual, you will learn how to operate and use this product. Please read this user manual comprehensively before use.
-
Page 5: Table Of Contents
Contents 1. Safety Tips and Warnings ··································01 9.1 Built-in Charging Module 2. Battery Description···········································02 9.2 Auto Scan Mode 3. Warranty Information········································03 9.3 Mouse Wheel Switching 4. Preface··························································04 10. Operation Method···········································23 5. Features·························································05 10.1 Front Panel Button Switching Method 6. Packing List·····················································06 10.2 IR Remote Control 7. -
Page 6: Safety Tips And Warnings
1. Safety Tips and Warnings Tips: Please read the safety tips and warnings for HDMI KVM Switch comprehensively before use. Use this produce in accordance with its instructions, safety tips and warnings to prevent unnecessary damage to the product and potential dangers to users. Keep the product away from water. -
Page 7: Battery Description
2. Battery Description Tips: By default, the remote control is not equipped with batteries, due to the safety requirements of some express companies. Install AAA dry cells before use. Caution: Improper disposal of the lithium battery may cause an explosion. Do not throw the battery into fire. -
Page 8: Warranty Information
3. Warranty Information We warrant this product as free of defects in material and workmanship for a period of one (1) year from the date of shipment. If during the period of warranty this product proves defective under normal use, we will repair or replace this product, provided that this product has not been subjected to mechanical, electrical, or other abuse or modifications. -
Page 9: Preface
4. Preface Dear Users, HDMI KVM Switch can easily integrate cross-platform computer devices and greatly simplify the devices management. 2x1/4x1 HDMI KVM Switch can control 2~4 PCs with only 1 HDMI display. This KVM support USB 3.0 ports with superspeed data transfer rate. With 1 USB-A charge port on the front panel, support BC 1.2 protocol to charge devices like mobile phones and tablets. -
Page 10: Features
5. Features Control 2~4 PCs with only 1 set of keyboard, mouse and monitor Ÿ Support resolution up to 3840x2160@60Hz 4:4:4 Ÿ HDMI 2.0 compliant Ÿ HDCP 2.2 compliant Ÿ Support HDR 10 and Dolby Vision Ÿ Support Unix/Windows/ Debian/ Ubuntu/Fedora/ MacOS X/ Raspbian/ Ubuntu for Raspberry Pi and Ÿ... -
Page 11: Packing List
6. Packing List HKS0201A3U HKS0401A3U 1 * 2x1 HDMI KVM Switch 1 * 4x1 HDMI KVM Switch Ÿ Ÿ 2 * KVM Cables 4 * KVM Cables Ÿ Ÿ 1 * IR Remote Control 1 * IR Remote Control Ÿ... -
Page 12: Panel Description
7. Panel Description 7.1 2x1 KVM Switch Panel Description Name Function Name Function Data transfer Can be used to transfer data LEDs will be lit (blue) if the USB connection and charging and charge your mobile KVM's USB ports are connected status indicators port devices. - Page 13 Name Function DC 12V 12V DC power supply. HDMI output Connect to HDMI display for video output. USB 3.0 port Connect to USB 3.0 device. Keyboard and mouse input For USB keyboard and mouse input. Each group contains a HDMI port (left) and 1 USB port (right). KVM input port group Connect the ports to corresponding input devices for signal input.
-
Page 14: 4X1 Kvm Switch Panel Description
7.2 4x1 KVM Switch Panel Description Name Function Name Function Data transfer Can be used to transfer data and charging and charge your mobile IR receiver Receive IR remote signal. port devices. The corresponding LEDs will be Input selection Input selection lit (blue) to indicate the current Select input sources separately. - Page 15 DC 12V Name Function DC 12V 12V DC power supply. HDMI outputs Connect to 2 HDMI displays for video output. USB 3.0 port Connect to USB 3.0 device. Keyboard and mouse input For USB keyboard and mouse input. Each group contains a video ports (HDMI on the left) and an USB port (USB-A on the right).
-
Page 16: Connection Description
8. Connection Description 8.1 Connection Diagram-2x1 KVM Switch Hard disk Printer Headset drive Driver Monitor Keyboard Mouse PC 2 PC 1... -
Page 17: Connection Diagram-4X1 Kvm Switch
8.2 Connection Diagram-4x1 KVM Switch Hard disk Headset Printer drive Driver UHD Monitor DC 12V Keyboard Mouse PC 4 PC 3 PC 2 PC 1 Tips: For your better use of this product, we suggest you connect each group port on the KVM to the same PC. -
Page 18: Connection Preparation
8.3 Connection Preparation Take into consideration all devices required to be connected and prepare a workbench large Ÿ enough before the connection. Lay out the cables properly to facilitate the layout of power supply as a lot of power sockets Ÿ... -
Page 19: Connection Steps
8.4 Connection Steps Here we take 4x1 KVM Switch as an example to demonstrate the connect steps. The 2x1 KVM Switch is as the same steps to connect. 1. Connect PC1 with 1 KVM cable, use HDMI end to connect PC1 to the HDMI port on the KVM, use USB Type-A end to connect PC1 and Type-B end to connect the KVM. - Page 20 3. Connect external mouse and keyboard to KVM's keyboard and mouse input port. Tips: For the normal service of hotkeys, we recommend you use the full-key external keyboard with a separate [Scroll Lock] key (as shown above 4. Connect USB 3.0 device to KVM's standard USB 3.0 port.
- Page 21 5. Connect KVM's HDMI output port to a HDMI display with a HDMI cable. 6. Connect external audio device to KVM's L/R out port.
- Page 22 7. Connect the power cable to KVM's DC port and plug it to a power socket. 8. By now, the connection has been completed. Turn on the power supply and the KVM Switch will begin to work. Tips: Please refer to Page 20 for how to use the front panel charging port.
-
Page 23: Kvm Workbench
8.5 KVM Workbench A workbench with 2x1 HDMI KVM Switch successfully connected is shown as below:... - Page 24 A workbench with 4x1 HDMI KVM Switch successfully connected is shown as below:...
-
Page 25: Function Description
9. Function Description 9.1 Built-in Charging Module The HDMI KVM Switch has built-in charging module which can charge your phone, tablet and other devices. Use the USB-A port on the front panel of the KVM can support data transmission while charging. The USB-A port support BC 1.2 protocol, and is able to match voltage and current automatically based on the specifications of charging devices. -
Page 26: Auto Scan Mode
9.2 Auto Scan Mode Auto Scan can automatically switch the display at regular intervals between the input devices that are powered on and connected to the KVM. As a result, any input devices connected to each port can be monitored without user intervention. Auto scan mode is off by default. -
Page 27: Mouse Wheel Switching
9.3 Mouse Wheel Switching Mouse wheel switching method can quickly switch input sources by mouse operation, double-click the mouse wheel to switch to the next input port. Mouse wheel switching mode is off by default. You can use keyboard hotkey command [Right-Ctrl] + [Right-Ctrl] + [F6] to turn on mouse wheel switching mode. -
Page 28: Operation Method
10. Operation Method 10.1 Front Panel Button Switching Method The 2x1/4x1 HDMI KVM Switch can switch to any input devices at any time with front panel keypad, IR remote control, keyboard hot keys and mouse wheel switch mode. You can choose your favorite switching method according to your personal needs and habits. - Page 29 4x1 KVM Switch front panel Ÿ Switch the input devices by pressing those [Select] buttons on the front panel of the KVM à Switch. Press the button [Select] corresponding to the identification of each PC to switch to the desired PC. The indicators will be lit to indicate which PC is currently displayed.
-
Page 30: Ir Remote Control
10.2 IR Remote Control Switch to input port 1 Switch to input port 2 Switch to input port 3 Switch to input port 4 Tips: 1. Button [3] and button [4] are only for 4x1 HDMI KVM Switch. 2. Unspecified buttons at above are non-functional. -
Page 31: Keyboard Hot Keys
10.3 Keyboard Hot Keys Use external keyboard hot keys to switch the input source or set up some other functions.. à Tips: The keyboard hot keys can only work with external keyboard correctly connected to the keyboard and mouse input port of the KVM. After press [Right-Ctrl] key twice within 2 seconds then please enter the commands within 3 seconds and the KVM will execute the corresponding commands. - Page 32 Select port by port number(For 4x1 KVM Switch): Right Right Ctrl Ctrl [Right-Ctrl]→[Right-Ctrl]→[1]~[4] The following hot-key commands do work for both 2x1 KVM Switch and 4x1 KVM Switch: Turn on/off mouse wheel switching mode: Right Right Ctrl Ctrl [Right-Ctrl] →[Right-Ctrl] →[F6] Disable or enable buzzer sound: Right Right...
- Page 33 Increase or decrease auto scan time interval: Right Right Ctrl Ctrl [Right-Ctrl] →[Right-Ctrl] →[+]/[-] Tips: This hot key command can only work while the auto scan mode is activated. Press [Right-Ctrl] twice and keep pressing [+]/[-] key to adjust the time interval continuously. Increase or decrease 1 second at one time.
-
Page 34: Change Hot Key Combination
11. Change Hot Key Combinations There are three kinds of trigger hot keys in this product, the default is [Right-Ctrl] key, and the alternative are the [Scroll Lock] and [Left-Ctrl] key. You can switch the hot key to others Method 1: 10 seconds after powering on the KVM, press and keep holding the [Select] button on the à... -
Page 35: Pass Through Mode Description
12. Pass Through Mode Description 12.1 Introduction of Pass through mode Pass through mode is a built-in function of KVM, which is able to improve keyboard and mouse compatibility and enhance user experience. In the pass through mode, the keyboard and mouse are equivalent to directly connecting to the computer. At this time, you can use more keyboard and mouse functions and special functions that are not supported by traditional KVM. -
Page 36: Keyboard And Mouse Compatible Model List
12.2 Keyboard and Mouse Compatible Model List Tips: The following list is from the most representative models of keyboard and mouse that have been tested in the laboratory, mainly from manufacturers with a high market share. Model Brand Model Brand Model Brand Brand... - Page 37 31.00.0450-V001...
- Page 38 To Enjoy Smart HKS0201A3U & HKS0401A3U Tesla Elec Technology Co.,Ltd WEEE-Reg.-Nr. DE 66784279...
