  • Page 1 • • • • • • • • • • • • • • • • • • • • • • • • • • Cheetah 18LP • • • • • • • • • • • • • • • • • • • • • • • • • •...

  • Page 2: Table Of Contents

    Seagate Technology, Inc. Cheetah, SeaFAX, SeaFONE, SeaBOARD, and SeaTDD are either trademarks or registered trademarks of Seagate Technology, Inc. or one of its subsidiaries. All other trademarks or registered trademarks are the property of their respective owners.

  • Page 3: Preface

    10 to learn more about this drive’s multimode capabilities, data bus details, specifica- tions, and cooling requirements. Additional information is available in the Cheetah 18LP Product Manual (part number 83329400). Contact your Seagate sales representative if you need to order this publication.

  • Page 4: Electrostatic Discharge Protection

    Protect the drive from static discharge by making sure you are well grounded before touching the drive. We recommend wearing a grounded wrist strap (Seagate part number 12263496) throughout the installation process. Do not touch the connectors or any part of the printed circuit board.

  • Page 5: Important Safety Information And Precautions

    • Ground yourself to the drive whenever the drive electronics are or will be exposed. Connect yourself to ground with a wrist strap (Seagate part number 12263496). Connection may be made to any grounded metal assembly. As a general rule, remember that you and the drive electronics must all be grounded to avoid potentially damaging static discharges.
  • Page 6 Cheetah 18LP Installation Guide, Rev. C lowed to minimize or eliminate the risk of personal injury. The warnings point out conditions or practices that may endanger you or others. The cautions point out conditions or practices that may damage the unit, possibly making it unsafe for use.

  • Page 7: Wichtige Sicherheitshinweise

    As a component, this drive is designed to be installed and oper- ated in accordance with UL1950, EN60950, CAN/CSA C22.2 950-M95, and VDE0805. Seagate takes all reasonable steps to ensure that its products are certifiable to currently accepted standards. Typical applica- tions of these disc drives include customer packaging and sub- system design.
  • Page 8 Cheetah 18LP Installation Guide, Rev. C sam, die Sie oder andere gefährden könnten. Die Vorsichtshinweise machen auf Situationen oder Praktiken aufmerksam, die Einheit beschädigen können, so daß deren Gebrauch mit Risiko behaftet ist. Die Warn- und Vorsichtshinweise sind nicht allumfassend! Es ist uns einfach nicht möglich, alle Wartungsmethoden oder die eventuellen...
  • Page 9 Als Teilkomponente ist dieses Laufwerk für die Installation und den Betrieb in Übereinstimmung mit UL 1950, EN60950, CAN\CSA C22.2 950-M95 und VDE0805 vorgesehen. Seagate ist ständig bemüht, die Zulassungsfähigkeit von Seagate- Produkten im Rahmen der gegenwärtig geltenden Standards zu gewährleisten. Zu den typischen Anwendungen dieser Festplatten- werke zählen Systemeinbau durch den Kunden und die Konstruktion...

  • Page 10: Regulatory Agency Compliance

    • Printer • External modem • Mouse Although the test system with this Seagate model complies to the directives/standard(s), we cannot guarantee that all systems will comply. The computer manufacturer or system integrator shall confirm EMC compliance and provide CE Marking and C-...
  • Page 11 Cheetah 18LP Installation Guide, Rev. C Electromagnetic compliance for the European Union If this model has the CE Marking it complies with the European Union requirements of the Electromagnetic Compatibility Direc- tive 89/336/EEC of 03 May 1989 as amended by Directive 92/31/ EEC of 28 April 1992 and Directive 93/68/EEC of 22 July 1993.

  • Page 12: General Description

    Cheetah 18LP Installation Guide, Rev. C General description Cheetah 18LP SCSI disc drives are high-speed, random-access digital-data storage devices capable of operating in single-ended (SE) or low voltage differential (LVD) modes. This multimode capability allows you to use this drive in systems that use the traditional SE technology or in LVD-capable sys- tems.
  • Page 13 Cheetah 18LP Installation Guide, Rev. C Single-ended and low voltage differential modes This drive incorporates two different transceivers to allow you to use it in systems which use single-ended (SE) drivers and receivers, or in low voltage differential (LVD) capable systems which use LVD drivers and receivers.
  • Page 14 Cheetah 18LP Installation Guide, Rev. C Data bus widths These drives have a wide (16-bit) SCSI data bus. You can use these drives on a non-wide (8-bit) data bus if you provide proper termination to the upper eight data lines. This is often referred to as providing “high-9 termination”...

  • Page 15: Kühlung Des Systems

    Cheetah 18LP Installation Guide, Rev. C by the fans either pushing or drawing air. The overall flow pattern can be directed from front to back, back to front, or side to side. Kühlung des Systems Die Gehäusekonstruktion muß eine ausreichende Kühlung des Lauf- werkes gewährleisten.
  • Page 16 Cheetah 18LP Installation Guide, Rev. C Above unit Under unit Note. Air flows in the direction shown (back to front) or in reverse direction (front to back) Above unit Under unit Note. Air flows in the direction shown or in reverse direction (side to side) Figure 2.
  • Page 17 Cheetah 18LP Installation Guide, Rev. C ST318203 ST318233 Characteristics ST39103 ST39133 Interface Ultra2 SCSI Ultra160 SCSI Capacity Unformatted (Gbytes) 21.6 (ST318203) 21.6 (ST318233) 10.8 (ST39103) 10.8 (ST39133) Formatted (Gbytes) 18.2 (ST318203) 18.2 (ST318233) 9.10 (ST39103) 9.10 (ST39133) Recording Cylinders (user)
  • Page 18 Average idle current 0.65 0.88 0.65 ST39133LWV/LCV Maximum start current 0.81 1.71 0.89 1.71 Maximum operating current 0.83 0.98 0.93 0.98 Average idle current 0.45 0.88 0.45 For more detailed power information, refer to the Cheetah 18LP Product Manual, publication number 83329400.

  • Page 19: How To Install The Drive

    Cheetah 18LP Installation Guide, Rev. C How to install the drive This installation guide provides step-by-step instructions to make your drive installation as easy as possible. Follow the installation steps listed for your drive model as listed below: LW/LWV models (use the installation steps beginning below).
  • Page 20 Cheetah 18LP Installation Guide, Rev. C Drive Front Jumper Plug (enlarged to show detail) Pin 1 SCSI ID = 0 SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5...
  • Page 21 Cheetah 18LP Installation Guide, Rev. C Configure termination. If you are installing the drive in a system that has other SCSI devices installed, terminate only the end devices on the SCSI bus. Figure 4 shows the three most common termination configu- rations.
  • Page 22 Cheetah 18LP Installation Guide, Rev. C Internal SCSI cable Internal Controller SCSI drive Terminate Internal SCSI cable Internal Internal Controller SCSI device SCSI device Terminate Internal SCSI cable External SCSI cable Internal Internal External External Controller SCSI device SCSI device...
  • Page 23 Cheetah 18LP Installation Guide, Rev. C Configure termination power. Terminators have to get power from some source. The default configuration results in the drive not suppling termi- nation power to the bus. You should normally leave this drive set at this default unless your host system requires that the drive supply termination power to the bus.
  • Page 24 Cheetah 18LP Installation Guide, Rev. C Connect the drive activity remote LED (optional) This drive provides connections for a remote drive activity LED. This step is optional because the drive will work fine without an LED connected, but many people find this to be helpful to determine when the drive is actively reading or writing data.
  • Page 25 Cheetah 18LP Installation Guide, Rev. C Check the other available jumper settings (optional) This drive provides several features for unique configura- tions. You will not normally need to change from the default settings for normal operation. See Figure 7 on page 24.
  • Page 26 Cheetah 18LP Installation Guide, Rev. C Pin 1 Pin 2 Reserved Single-Ended Mode option Use single-ended or low voltage differential mode. Force the drive to operate only in single-ended mode. Delay Motor Start option (valid only if the Enable Motor Start jumper is not connected) Disable the Delay Motor Start option (default).
  • Page 27 Cheetah 18LP Installation Guide, Rev. C Mount the drive in the host system and connect cabling. Mount the drive to the host system’s chassis using four 6-32 UNC screws. Two mounting holes are in each side of the drive and there are four mounting holes in the bottom of the drive.
  • Page 28 Cheetah 18LP Installation Guide, Rev. C Power Cable Figure 8. Connecting cables to the drive...
  • Page 29 Cheetah 18LP Installation Guide, Rev. C “LW” Model Drive Inline Note: Terminator Do not mix “LW” and “WD” model drives on the daisy chain. 2 through X SCSI devices [1] Pin 1 SCSI ID 1 (check your adapter for Pin 1 location)
  • Page 30 Cheetah 18LP Installation Guide, Rev. C Notes: Mounting holes are 6-32 UNC 2B, three on each side and four on the bottom. Max screw penetration into side of drive is 0.15 in. (3.81 mm). Max screw tightening torque is 6.0 in-lb (3.32 nm) with minimum full thread engagement of 0.12 in.
  • Page 31 Cheetah 18LP Installation Guide, Rev. C Additional connector on LW and LWV model drives LW and LWV model drives have a connector located between the SCSI I/O connector and the DC power connector to allow you to set the SCSI ID and connect LEDs from the back of the drive.
  • Page 32 Cheetah 18LP Installation Guide, Rev. C LC and LCV model installation Set the SCSI ID on the drive. Determine which SCSI IDs are already being used in the system and then assign the disc drive a SCSI ID that isn’t already being used.
  • Page 33 Cheetah 18LP Installation Guide, Rev. C Drive Front Jumper Plug (enlarged to show detail) Pin 1 SCSI ID = 0 SCSI ID = 1 SCSI ID = 2 SCSI ID = 3 SCSI ID = 4 SCSI ID = 5...
  • Page 34 Cheetah 18LP Installation Guide, Rev. C Configure termination. LC and LCV model drives are designed for installation in host systems that have a backplane with single connector attachment (SCA) connections. Termination is normally pro- vided on this backplane. Check your host system documen- tation for details.
  • Page 35 Cheetah 18LP Installation Guide, Rev. C Check the other available jumper settings (optional) This drive provides several features for unique configura- tions. You will not normally need to change from the default settings for normal operation. See Figure 13 on page 34.
  • Page 36 Cheetah 18LP Installation Guide, Rev. C Pin 1 Pin 2 Reserved Single-Ended Mode option Use single-ended or low voltage differential mode. Force the drive to operate only in single-ended mode. Delay Motor Start option (valid only if the Enable Motor Start jumper is not connected) Disable the Delay Motor Start option (default).
  • Page 37 Cheetah 18LP Installation Guide, Rev. C Mount the drive in the host system. To mount the drive, plug it into the system’s single connector attachment (SCA) position on the system’s backplane. The SCA connector on the drive contains interface and power functions, so it does not require a separate power connec- tor.
  • Page 38 Cheetah 18LP Installation Guide, Rev. C Notes: Mounting holes are 6-32 UNC 2B, three -Z- -X- on each side and four on the bottom. Max screw penetration into side of drive is 0.15 in. (3.81 mm). Max screw tightening torque is 6.0 in-lb (3.32 nm) with minimum full thread engagement of 0.12 in.
  • Page 39 • Protect against power failure or other power interrup- tions during the format. Cheetah 18LP disc drives are designed to operate with a variety of operating systems. Some brief instructions are provided below for DOS, Windows 3.1, Windows 95, Win- dows 98, and Macintosh systems.
  • Page 40 Cheetah 18LP Installation Guide, Rev. C Note. Hardware platform, operating system, and host adapter variations can limit access to the full capac- ity of this and other high capacity drives. Refer to your system, host adapter, or drive utility documen- tation for detailed instructions.
  • Page 41 Cheetah 18LP Installation Guide, Rev. C the drive you want to partition. Make sure that your new drive is selected. If you accidently repartition your old hard drive, you will erase all data on the drive. Press to select “Create DOS partition or logical DOS drive”...
  • Page 42 Cheetah 18LP Installation Guide, Rev. C Macintosh Use a third-party drive utility to initialize the drive and follow the instructions provided with the utility. Note: versions of Apple Drive Setup prior to version 1.3.1 do not recognize non-Apple drives.

  • Page 43: Seagate Technology Support Services

    ® SeaBOARD is a computer bulletin board system that contains information about Seagate disc and tape drive products and is available 24 hours daily. Set your communications software to eight data bits, no parity and one stop bit (8-N-1). Automated Services SeaFONE®...
  • Page 44 If you need additional help, you can talk to a Seagate technical support specialist. Before calling, note your system configuration and drive model number (ST####).
  • Page 45 P.M. (central time) Monday through Friday. Customer Service (CSO) Warranty Service Seagate offers worldwide customer support for Seagate drives. Seagate direct OEM, Distribution and System Integrator custom- ers should contact their Seagate service center representative for warranty information. Other customers should contact their place of purchase.
  • Page 46 Cheetah 18LP Installation Guide, Rev. C Warranty Service 1-800-468-3472 FAX: +1-405-949-6740 Mexico and Latin America +1-405-949-7758 FAX: +1-405-949-6738 Canada Memofix +1-905-660-4936 FAX: +1-905-660-4951 or 1-800-636-6349 http://www.memofix.com Adtech +1-905-812-8099 FAX: +1-905-812-7807 or 1-800-624-9857 http://www.adtech1.com Brazil MA Informatica +55-21-516-6649 FAX: +55-21-516-5280 e-mail: sgt_cso@gbl.com.br...
  • Page 47 Cheetah 18LP Installation Guide, Rev. C Germany 0 800-182 6831 Ireland 1 800-55 21 22 Italy 800-790695 Netherlands 0 800-732 4283 Norway 800-113 91 Poland 00 800-311 12 38 Spain 900-98 31 24 Sweden 0 207 90 073 Switzerland 0 800-83 84 11...
  • Page 48 Cheetah 18LP Installation Guide, Rev. C Japan — FAX: +81-3-5462-2979 Singapore +65-488-7584 FAX: +65-488-7528 Taiwan +886-2-2514-2237 FAX: +886-2-2715-2923 SeaFAX Australia +61-2-9756-5170 Warranty Service Japan +81-3-5462-2904 FAX: +81-3-5462-2979 Asia/Pacific and +65-485-3595 FAX: +65-488-7503 Australia...
  • Page 52 Seagate Technology, Inc. 920 Disc Drive, Scotts Valley, CA 95066-4544, USA Publication Number: 83329410, Rev. C, Printed in USA...
