- Page 1 INSTALL MANUAL TOY6 www.gromaudio.com www.gromaudio.com/support.html...
-
Page 2: Table Of Contents
CONTENTS Package contents......................3 CHAPTER 1 — INSTALLATION.................3 1.1 Before Installation 1.2 Tools 1.3 Vehicle Installation 1.4 Safety Guidelines & Appropriate Use Connect VLine Interface Cable to factory headunit ...........4 Display connections ....................5 Connecting to VLine....................6 Routing the GPS Antenna. -
Page 3: Package Contents
GROM-VLINE SYSTEM PACKAGE CONTENTS MCFTOY Power Cable VLine module GVMF Video + Red P-Tap Cable GPS Antenna Microphone USB Extension cable CHAPTER 1 — INSTALLATION 1.1 Before the installation Before starting work with any wiring, please wait 90 seconds after turning the ignition to the OFF position and disconnecting the battery’s negative (-) terminal. -
Page 4: Safety Guidelines & Appropriate Use
wiring installation requires special technical skills and experience. If you do not feel comfortable doing the installation please consult with your local car audio shop or installation professional for instructions or assistance if necessary. Carefully remove the factory Stereo and Display out of the dash cavity with proper tools. -
Page 5: Display Connections
Connect supplied GVMF video cable to the factory display Locate the BLUE display port on the rear of the car stereo. If the port is empty, plug the supplied video cable GVMF into the port and leave the female portion of the cable with nothing attached. If a cable is plugged in (typically with the blue connector), disconnect it from the back of the stereo. -
Page 6: Connecting To Vline
Connect the VLine power interface cable MCFTOY to the factory stereo, connect the REVERSE wire with the P-Tap Locate the 12-pin connector at the back of the stereo, as shown in one illustration on page 6. Unplug what was previously connected, if anything. Plug in the supplied power interface cable, MCFTOY, into a 12-pin slot. -
Page 7: Routing The Gps Antenna
Routing the GPS antenna The GPS Antenna module is magnetic and supplied with double-sided tape. It can be mounted to the top of the dashboard or outside of the vehicle, whichever you prefer. Route the antenna to the desired loca- tion. -
Page 8: Routing The Microphone
Routing the microphone Route the microphone to a location where it can pick up the voice. We recom- mend mounting the microphone near the rearview mirror but not directly on the windshield glass. Avoid sticking it to a hard surface, as it will pick up more noise. -
Page 9: Mounting The Vline Module
Testing the VLine operation WARNING: Ensure to reconnect all unplugged connectors to the vehicle before cycling the ignition. Cycle the ignition and press the MODE button to enter the USB mode of the stereo which is VLine mode. You can also select the USB source from the source tab. -
Page 10: Understanding Vline Ports
Understanding the VLine p orts H DMI WiFi / Bluetooth Output Antenna USB1 iPhone GPS / AV / Camera Input USB 1 HDMI IN HDMI OUT USB 2 CAMERA AV1 HDMI Input MicroSD Card Microphone (Pin side up*) USB2 OTG/USB storage USB1 iPhone connection Any other USB device (Keyboard / Mouse) -
Page 11: Chapter 2 - Getting Started
CHAPTER 2 — GETTING STARTED 2.1 Initializing After connecting the VLine module to the stereo, cycle the ignition for the stereo to discover the VLine and allow the VLine to self-configure. To INITIALIZE: 1. Put the ignition switch to “the ACC” or “ON” position 2. -
Page 12: Support
Adjusting Audio Bass, Treble, Balance/Fade for VLINE Mode - using Factory UI Use the Factory UI icon to get to the factory UI and adjust sound settings. While in the VLine VL2 main screen, press on empty PLUS sign and go to Short- cuts -->... - Page 13 Troubleshooting Ensure you have the latest updates on the CarPlay/Android Auto does not VLine by connecting the VLine to the WiFi connect wireless, or VLine mis- and going to: Settings -> System -> VLine behaves. System Updates -> Check For Updates Ensure the cable you are using to connect CarPlay/Android Auto does not the VLine and Phone is a high quality cable,...
-
Page 14: Warranty
Unless otherwise prescribed by law, GROM Audio shall not be liable for any personal injury, property damage and or any incidental or consequential damages of any kind (including water damage) resulting from malfunc- tions, defects, misuse, improper installation or alteration of this product. -
Page 15: Grant Of License
IN CONNECTION WITH ANY BUSINESS, LOSS OF ANY GOODWILL, OR DAM- AGES. THE TERM ‘INCIDENTAL DAMAGES’ REFERS TO THE EXPENSES OF TRANSPORTING THE PRODUCTS TO THE GROM AUDIO SERVICE CENTER, LOSS OF THE END-USERS [ORIGINAL PURCHASER’S] TIME, LOSS OF THE USE... - Page 16 TO THE CARE AND CUSTODY OF THE PRODUCT. THE TERM ‘CONSEQUENTIAL DAMAGES’ REFERS TO THE COST OF REPAIRING OR REPLACING OTHER PROPERTY, WHICH IS DAMAGED WHEN THIS PRODUCT DOES NOT WORK PROPERLY, RESULTING FROM THE USE OR INABILITY TO USE THE PRODUCTS, INCLUDING ANY DAMAGES INCURRED DUE TO THE NEGLIGENT OPERATION OF A MOTOR VEHICLE, IN CONJUNCTION WITH THE USE OF SAID PRODUCTS.
- Page 17 - in a manner that would distract the driver or that may otherwise cause injury or death to vehicle occupants or bystanders. GROM Audio is not in any way responsible for any such use by you. In all cases, GROM Audio may limit or revoke your use for any reason and at...
- Page 18 By using the Third Party Materials, you agree to comply with the use terms of the provider of such Third-Party Materials. GROM AUDIO does not warrant or endorse and does not assume and will not have any liability or responsibility to you or any other person for any Third Party Materials or for any other materials, products, or services of third parties.
- Page 19 A. INDEMNIFICATION OF GROM AUDIO, ITS AGENTS AND EMPLOYEES. By Purchasing, Installing and Using the Products, You, the End- User, agree to indemnify, defend and hold harmless, GROM AUDIO, and it s Affiliates, Directors, Officers, Agents and Employees from any Liabilities, Damage, Loss, Claim and Expense (including reasonable Attorney’s Fees) arising out of the...
- Page 20 GROM AUDIO. Quantit- ies are subject to availability. E. ENTIRE AGREEMENT. These terms and conditions constitute the entire...
