Safety Xpress FDBOL800PAD Product Information & Installation Manual

2 2
MONTHS MONTHS

Product Features:

SafetyXpress Parking Spot Protector will stop any
carpark pincher attempting to park in your spot.
This unit stands at 800mm high and folds flat to a
low lying 80mm to ensure your car won't scrape it
when it's not standing guard.
The Parking Protector Fold Down Bollard is easily
locked in the upright position using the 2 keys
supplied with the unit.
Powder coated in Safety Yellow means it's visibility
you can't miss, and we even put a reflective strip
around it so you can spot it even better at night.

Tools Required:

• Hammer drill with 14mm drill bit for M10
coach screw 100mm, or 10mm drill bit for
M10 concrete screw anchors
• Fixing kit (M10 coach screws 100mm,
or 60mm M10 concrete screw anchors, or
100mm M10 concrete screw anchors)
• The correct sized socket
• A hammer
• A hand broom or industrial vacuum
1300 049 246
PRODUCT INFORMATION &
Fold Down Parking Protector
Bollard 800mm - with Padlock
Re ective
SKU
Material
Colour
FREE
Dimensions:
Fixings
Item Weight
Pad Lock
Stickers
Fixings

Installation:

1. Read instruction steps from beginning to end.
2. Determine exactly where the bollard will be placed. If
you are installing more than one bollard, it is a good idea
to mark the ground to ensure that you have a straight line
to assist you with the correct placement of your bollards.
3. Using your hammer drill, drill a guide hole in the surface,
through each hole in the bollard using the drill bit. (This is
to mark the surface so that you know where to continue to
drill).
4.Remove the bollard and brush or vacuum away the dust.
5. Continue to drill each guide hole to almost the entire
length of your fixings.
6. If you are using a plastic plug component, put it in the
drilled hole and hammer in.
7. Place the bollard over the holes, line up and place your
fixing in the holes and screw or hammer in.
8. Use your socket to tighten the screw if applicable. Be
careful not to overtighten.
INSTALLATION GUIDE

Specifications

FDBOL800PAD
Galvanised Steel
Powder Coated Yellow with
Class 1 Red Reflective Tape
Height: 800mm (upright)
80mm (folded down)
Column: 150mm x 50mm
11kg
1 x Padlock with 2 Keys Included
Options, at cost
Sticker Text Option:
NO PARKING, RESERVED, VISITOR
FREE fixings 4pcs x M10 Coach
Screws 100mm, washers and plugs.
Concret screws (at cost)
M10 60mm OR M10 100mm
www.safetyxpress.com.au
