- Page 1 Refrigerator User Manual RDNE650E40DXBR 58 5592 0000/AF -EN...
- Page 2 Dear Customer, Please read this manual before using the product. Thank you for choosing this product. We would like you to achieve the optimal efficiency from this high quality product which has been manufactured with state of the art tech- nology.
-
Page 3: Table Of Contents
1 Safety Instructions 6.7 Ice maker......19 6.8 The dairy (cold storage) compartment ..19 6.9 Crisper . -
Page 4: Safety Instructions
Safety Instructions • This section includes the safety 1.2 Safety of children, instructions necessary to prevent vulnerable persons and pets the risk of personal injury or material • This product may be used by children damage. aged 8 years and older and persons • Our company shall not be held with underdeveloped physical, responsible for damages that may... -
Page 5: Electrical Safety
Important safety and environment instructions 1.3 Electrical safety 1.5 Installation Safety • The product shall not be plugged • Contact the Authorized Service into the outlet during installation, for the product’s installation. To maintenance, cleaning, repair, and prepare the product for installation, transportation operations. -
Page 6: Operational Safety
Important safety and environment instructions refrigerant available in your product is • Do not connect your refrigerator to power specified in the Type Label. saving devices. These systems are harmful for the product. • The installation place of the product shall not be exposed to direct sunlight 1.6 Operational safety and it shall not be in the vicinity of a... - Page 7 Important safety and environment instructions flammable objects, dry ice or other closing the door and cause injuries chemical agents in the vicinity of and/or material damages. the refrigerator. Risk of fire and • Do not hit or exert excessive pressure explosion! on glass surfaces.
-
Page 8: Maintenance And Cleaning Safety
Important safety and environment instructions 1.7 Maintenance and cleaning safety • Do not pull by the door handle if you shall move the product for cleaning purposes. Handle may cause injuries if it is pulled too hard. • Do not clean the product by spraying or pouring water on the product and inside the product. -
Page 9: Environmental Instructions
Environmental instructions 2.1 Compliance with the WEEE Directive and Disposing of the Waste Product: This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equip- ment (WEEE). This symbol indicates that this product shall not be disposed with other house- hold wastes at the end of its service life. -
Page 10: Your Refrigerator
Your Refrigerator 10- Filter 1- Freezer compartment door shelves 2- Cooler compartment door shelves 11- Glass shelves 3- Egg Holder 12- Fan 4- Water fountain 13- Icematics 5- Cooler compartment small door shelves 14- Freezer compartment glass shelf 6- Bottle shelf 15- Freezer compartment 7- Adjustable stands 16- Cooler compartment... -
Page 11: Installation
Installation 4.1 The right place for installation WARNING: The product's power cable Your product requires adequate air circulation to must be unplugged during installation. Failure to do so may result in death or function efficiently. If the product will be placed in an serious injuries! alcove, remember to leave at least 5 cm clearance WARNING:... -
Page 12: Adjustment Of The Feet
Installation 4.5 Electrical connection 2. Attach 2 plastic wedges on the ventilation cover as shown in the figure. WARNING: Do not use extension or multi sockets in power connection. WARNING: Damaged power cable must be replaced by Authorized Service. • Our firm will not assume responsibility for any 4.4 Adjustment of the feet damages due to usage without earthing and If the product is not in balanced position, adjust the... -
Page 13: Preparation
Preparation 5.2 First operation Read the “Safety Instructions” section first! Before using your refrigerator, make sure the necessary preparations are made in line with the instructions in "Safety and environment 5.1 What to do for energy saving instructions" and "Installation" sections. mehmet • Keep the product running without placing any Connecting the product to electronic... -
Page 14: Operating The Product
Operating the Product • Do not use any mechanical tools or any other tools than the recommendations of the manufacturer to speed up the thawing operation. • Do not use parts of your refrigerator such as the door or drawers as a support or a step. This may cause the product to trip over or its components to be damaged. -
Page 15: Operation Of The Product
Operation of the Product 6.2 Indicator panel Indicator panels may vary depending on the model of your product. Audial and visual functions of the indicator panel will assist in using the refrigerator. 1- Support Service Key 2- Quick Freezing Key/ Handle Light Function Setting Key 3- Fault Condition Indicator 4- Energy Saving (Display Off) Indicator 5- Freezing Compartment Temperature Setting Key... - Page 16 Using the product 6. Compartment Conversion Key freezing button ( ) for 3 seconds. In the closed When the compartment conversion key is pressed for mode, the handle light is only activated when the 3 seconds, freezer compartment switches between appliance door is opened and it goes out after a cooler, off, and freezer modes respectively.
- Page 17 Using the product If the connection cannot be established for a long period, check your connection settings and refer to the “Troubleshooting” section provided in the user manual. HomeWhiz application shall be used for wireless connection. Installation steps are described on the application during installation.
-
Page 18: Humidity Controlled Crisper (Everfresh+)
Using the product 6.3 Humidity controlled 6.4 Blue Light/HarvestFresh crisper (EverFresh+) (Optional) (Optional) Thanks to the humidity controlled crisper, For Blue light, vegetables and fruits may be stored for a longer Vegetables and fruit stored in crispers illuminated period at an environment with ideal humidity with blue light continue to perform photosynthesis conditions. -
Page 19: Anti-Odour Module
Using the product 6.5 Anti-Odour Module (FreshGuard) (This feature is optional) Anti-odour module removes odour that occur inside your refrigerator before it permeates on the surfaces. Thanks to this module positioned on the roof the fresh food compartment, bad odour is removed while the air is actively passed through the odour filter, and the air cleaned in the filter is directed back to the fresh food compartment. -
Page 20: Ice Bucket
Using the product 6.7 Ice maker 6.6 Ice bucket (This feature is optional) (This feature is optional) Ice maker allows you take ice easily from the Ice bucket allows you take ice easily from the refrigerator. refrigerator. Using the ice bucket Using the ice bucket 1. -
Page 21: Crisper
Using the product 6.9 Crisper You may store your food for a longer period of time The refrigerator's crisper is designed to keep by placing the foods sensitive to ethylene gas in vegetables fresh by preserving humidity. For one of the compartments separated by the crisper this purpose, the overall cold air circulation separator, and the foods that generate ethylene is intensified in the crisper. -
Page 22: Cleaning Of The Crisper Separator
Using the product Put the filter back, and close the upper cover. To provide maximum effectiveness of your filter and to preserve its performance, avoid contact with oil and similar fluids, and materials such as water and detergents. Communicate with the service to replace your filter with a new one after such contact. -
Page 23: Freezing Fresh Food
Using the product 6.13 Freezing fresh food • Make sure the food items are packed before putting in the freezer. Use freezer holders, • Activate the fast freezing function by pressing tinfoil and damp-proof paper, plastic bag the «Fast Freeze» button 24 hours before load- or similar packaging materials instead of ing the food to be frozen. -
Page 24: Deep Freezer Details
Using the product 6.15 Deep freezer details 6.18 Illumination lamp As per the IEC 62552 standards, at 25°C room Interior light uses a LED type lamp. Contact the temperature, the freezer must have the capacity authorized service for any problems with this lamp. to freeze 4,5 kg of food items at -18°C or lower Lamp(s) used in this appliance cannot be used for temperatures in 24 hours for each 100 litres of... -
Page 25: Maintenance And Cleaning
Maintenance and cleaning compartment. Do not clean, and never apply oils WARNING: Read the “Safety or similar materials. Instructions” section first! • Use a mildly dampened micro-fiber cloth to clean the external surface of the product. WARNING: Unplug the refrigerator Sponges and other types of cleaning clothes may cleaning it. -
Page 26: Preventing Odours
Maintenance and cleaning For routine cleaning processes, *non-alkaline and non-corrosive water based cleaning products shall be used. In order to have a longer service life of this coating, alkaline and corrosive substances shall not be used during cleaning. A tempering process is applied to increase the resistance of these glasses against impacts and breakage. -
Page 27: Troubleshooting
Troubleshooting Check this list before contacting the service. Doing • In case of sudden power failure or pulling so will save you time and money. This list includes the power plug off and putting back on, the frequent complaints that are not related to faulty gas pressure in the product's cooling system workmanship or materials. - Page 28 Troubleshooting The food items kept in cooler compartment • The new product may be larger than the drawers are frozen. previous one. Larger products will run for longer periods. • The cooler compartment temperature is • The room temperature may be high. >>> set to a very low degree.
- Page 29 Troubleshooting There is sound of wind blowing coming from • The food items may be in contact with the the product. upper section of the drawer. >>> Reorganize the • The product uses a fan for the cooling food items in the drawer. process.
