- Page 1 CB6 Series Speakerphone Enclosures Model: ENBS01, ENBS14 Admin Guide Installation | Configuration | Support | Maintenance | Use 800.205.7186 • www.codeblue.com...
- Page 2 OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF. Code Blue Corporation reserves the right to make any modifications to this guide or the information contained herein at any time without notice. The software described herein may also be governed by the terms of a separate user license agreement.
-
Page 3: Table Of Contents
CB6 Series Administrator Guide Table of Contents Section Section Title Page # 2 Introduction 3 Safety Information 4 Installation Instructions Tools Needed Getting Started Phone Enclosure Installation S-1000 & S-1050 Strobe/Beacon 5 Programming 6 Power Requirements 7 Alternative Mounting 8... -
Page 4: Introduction
CB6 Series phone enclosures for your Code Blue application. The rugged housings along with Code Blue's speakerphones, meet the need for a vandal resistant unit while providing a cost effective & reliable solution. CB6 Series phone enclosures are a good choice for hallways, transit centers, parking decks and other sheltered structures. -
Page 5: Safety Information
In some countries, a certified electrician may be required. NOTICE When transporting a Code Blue product, use the original packaging or equivalent to prevent damage to the product. Code Blue products shall be used in compliance with local laws and regulations. -
Page 6: Installation Instructions
CB6 Series Administrator Guide 4 Installation Instructions Tools Needed All CB6 Units Require: • Ladder to reach above the unit - For Remote Beacon Strobe Only. • Drill & Security Bit for removing & inserting security screws on phone. • 3/8" Socket in mount unit onto the wall, •... -
Page 7: Getting Started
Important Notes: EIA/TIA, ANSI, CSA and BICSI cabling or similar standards shall be adhered to for proper operation of Code Blue communication devices connected to copper or fiber infrastructures. Communications cable and electrical cable in the same conduit is not an acceptable installation and shall not be supported. -
Page 8: Phone Enclosure Installation
CB6 Series Administrator Guide Phone Enclosure Installation Instructions PRE-INSTALLATION 1.1 Electrical preparation – The unit may have supply wires run from either (a) behind the unit through the wall, or (b) below the unit using an external conduit through the bottom of the unit’s back plate. -
Page 9: S-1000 & S-1050 Strobe/Beacon
CB6 Series Administrator Guide S-1000 & S-1050 Strobe Operation NOTE: Instructions pertain to: Model S-1000 LED Beacon/Strobe and Model S-1050 LED Beacon/Strobe only. POSITIVE (12-24V DC or AC) BLACK COMMON (GROUND) YELLOW (FLASH MODE) CONTACT CLOSED = "ON" YELLOW (FLASH MODE) CAUTION REMOVE ALL POWER FROM UNIT BEFORE SERVICING. -
Page 10: Programming
CB6 Series Administrator Guide 5 Programming PROGRAMMING PRIMARY & SECONDARY MODES 1. Remove power from unit. 2. Short the Yellow wires together. 3. Restore power to the unit and wait until the unit begins to flash. Once the unit begins to flash, remove the short. The unit will alternately demonstrate the Secondary-Flash Mode and Primary-Steadyburn Mode that will be displayed during operation. -
Page 11: Power Requirements
CB6 Series Administrator Guide 6 Power Requirements The following tables on pages 11-14 include and ALL OTHER Code Blue devices & enclosures for reference. • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 11 of 22... - Page 12 CB6 Series Administrator Guide • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 12 of 22 Code Blue GU-156-M...
- Page 13 CB6 Series Administrator Guide • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 13 of 22 Code Blue GU-156-M...
- Page 14 CB6 Series Administrator Guide • 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com page 14 of 22 Code Blue GU-156-M...
-
Page 15: Alternative Mounting
CB6 Series Administrator Guide 7 Alternative Mounting Phone Enclosure Pole Mount Installation Instructions 1.0 THREAD MOUNTING STRAPS THROUGH SLOTS Use outside slots for larger poles and inside slots for smaller poles. 2.0 HOLD BRACKET TO POLE Set the height of the bracket (C) so that the speakerphone push button(s) on the unit will be at desired height (please check with local codes for ADA compliance). -
Page 16: Wiring Diagrams
CB6 Series Administrator Guide 8 Wiring Diagrams 100-240 AC / DC or 24V AC @ 60 Watt or 24V DC Product wiring diagram shown reasonably represents current offering and is intended to assist in component identification and service. Earlier product production may have different components and wiring connections. -
Page 17: Locating Unit Serial Number
CB6 Series Administrator Guide 9 Locating Unit Serial Numbers Remove the IP or Analog Phone with the special security bit. The serial number will be listed on the manufacturer’s label located on the backside of the unit behind the phone opening. -
Page 18: Warranty
10 Warranty Code Blue Corporation provides a limited warranty on this product. Refer to your sales agreement to establish the terms. In addition, Code Blue’s standard warranty language, as well as information regarding support for this product while under warranty, is available at www.codeblue.com/support... -
Page 19: Maintenance Schedule
CB6 Series Administrator Guide 11 Maintenance Schedule LEGEND Guard Tasks Technician Tasks DAILY OR WEEKLY Perform functional communications check. Action: Press Red Button Strobe activates Red LED "Call Placed" light turns on Message plays Call connects, green LED "Call Received" light turns on... - Page 20 The Surface Care Frequency table below provides general guidelines to assist in configuring a schedule. Please note that the frequency of care required to guard the Code Blue unit’s surface from damage will also be dictated by local environmental characteristics.
-
Page 21: Download Information
CB6 Series Administrator Guide 12 Download Information Code Blue now has a centralized location where you can find installation, setup, information, configuration and operation instructions. Admin Guides: www.codeblue.com/resources/guides Frimware: www.codeblue.com/resources/firmware Maintenance Tips: www.codeblue.com/support Product Sheets: www.codeblue.com/resources/sheets Specifications: www.codeblue.com/resources/specifications For Legacy Product Information: www.codeblue.com/legacy-products... -
Page 22: Legal & Regulatory Information
This digital apparatus complies with CAN ICES-3 (Class A). The product shall and fitness for a particular purpose. Code Blue shall not be liable or be connected using a shielded network cable (STP) that is properly responsible for incidental or consequential damages in connection with grounded.
