Summary of Contents for Asus PRIME H370M-PLUS
- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Asus Prime H370M Plus o cerca il tuo prodotto tra le migliori offerte di Schede Madri PRIME H370M-PLUS...
- Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.
-
Page 3: Table Of Contents
Contents Safety information ...................... iv About this guide ......................iv Package contents ....................... vi ASUS PRIME H370M-PLUS specifications summary ..........vi Chapter 1: Product Introduction Before you proceed ................... 1-1 Motherboard overview ................1-1 Central Processing Unit (CPU) ..............1-9 System memory .................. -
Page 4: Safety Information
Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device. - Page 5 Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.
-
Page 6: Package Contents
Extreme Memory Profile (XMP) ® * The maximum memory frequency supported varies by processor. ** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). 1 x PCIe 3.0/2.0 x16 slot Expansion 1 x PCIe 3.0/2.0 x16 slot (max. at x4 mode) slots 2 x PCIe 3.0/2.0 x1 slots... - Page 7 - 6 x USB 2.0 ports (4 ports @mid-board; 2 ports @back panel) ASUS 5X PROTECTION III - ASUS SafeSlot Core: Fortified PCIe with solid soldering - ASUS LANGuard: Protects against LAN surges, lightning strikes and static- electricity discharges! - ASUS Overvoltage Protection: World-class circuit-protecting power design...
- Page 8 ASUS PRIME H370M-PLUS specifications summary Gaming Scenario Audio Features - Audio that roars on the battlefield ASUS Exclusive Features - ASUS Ai Charger - ASUS AI Suite 3 - ASUS file transfer ASUS Special EZ DIY Features UEFI BIOS EZ Mode...
- Page 9 * Chassis intrusion header is built in the system panel connector. 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi- language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, BIOS F6 Qfan Control, F3 My Favorites, F9 Search, Last Modified log, F12 PrintScreen,...
-
Page 11: Chapter 1: Product Introduction
Failure to do so may cause severe damage to the motherboard, peripherals, or components. Motherboard overview Place this side towards the rear of the chassis Unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components. ASUS PRIME H370M-PLUS... - Page 12 1.2.1 Layout contents Connectors/Jumpers/Slots Page ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) Intel LGA1151 CPU socket ® CPU, chassis, and AIO pump fan connectors (4-pin CPU_FAN, 4-pin CHA_FAN1~2, 4-pin AIO_PUMP FAN) DDR4 DIMM slots Intel H370 Serial ATA 6.0 Gb/s connector (7-pin SATA6G_1~6) ® USB 3.1 Gen 1 connector (20-1 pin U31G1_56) M.2 sockets (M.2_1; M.2_2) System panel connector (20-3 pin PANEL) Clear RTC RAM (2-pin CLRTC) 10. USB 2.0 connectors (10-1 pin USB78, USB1114) 11. TPM connector (14-1 pin TPM) 12. Serial port connector (10-1 pin COM) 13. Mono out header (2-pin MONO_OUT) 14. Front panel audio connector (10-1 pin AAFP) 15. Digital audio connector (4-1 pin SPDIF_OUT) 16. PCI Express 3.0/2.0 x16 slots 17. PCI Express 3.0/2.0 x1 slots ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) EATX12V Correctly orient the ATX power supply plugs into these connectors and push down firmly until the connectors...
- Page 13 RSATA_TXP RSATA_TXN disk drives via Serial ATA 6.0 Gb/s signal cables. RSATA_RXN RSATA_RXP USB 3.1 Gen 1 connector (20-1 pin U31G1_56) U31G1_56 Connect a USB 3.0 module to any of these connectors PIN 1 USB3+5V for additional USB 3.0 front or rear panel ports. These USB3+5V IntA_P1_SSRX- IntA_P2_SSRX- IntA_P1_SSRX+ connectors comply with USB 3.0 specifications and IntA_P2_SSRX+ IntA_P1_SSTX- provides faster data transfer speeds of up to 5 Gbps, IntA_P2_SSTX- IntA_P1_SSTX+ IntA_P2_SSTX+ IntA_P1_D- faster charging time for USB-chargeable devices, IntA_P2_D- IntA_P1_D+ IntA_P2_D+ optimized power efficiency, and backward compatibility with USB 2.0 ASUS PRIME H370M-PLUS...
- Page 14 M.2 sockets (M.2_1; M.2_2) M.2(SOCKET3) These sockets allow you to install M.2 (NGFF) SSD modules. • The M.2_1 socket supports M Key and 2242/2260/2280 storage devices (both SATA & PCIE x2 mode). • The M.2_2 socket supports M Key and 2242/2260/2280 storage devices (PCIE x4 mode). • The M.2_1 socket supports data transfer speed up to 16Gb/s. • The M.2_2 socket supports data transfer speed up to 32Gb/s. • When a device in SATA mode is installed on the M.2_1 socket, SATA_2 port cannot be used. System panel connector (20-3 pin PANEL) This connector supports several chassis-mounted functions. • System power LED (4-pin PWR_LED) This 4-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.
- Page 15 PIN 1 PIN 1 TPM connector (14-1 pin TPM) This connector supports a Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures PIN 1 platform integrity. Serial port connector (10-1 pin COM) This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis. PIN 1 ASUS PRIME H370M-PLUS...
- Page 16 Mono out header (2-pin MONO_OUT) MONO_OUT This internal mono out header allows connection to an PIN 1 internal, low power speaker for basic system sound capability. The subsystem is capable of driving a speaker load of 4 Ohms at 2 Watts (rms). Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports HD Audio standard. Connect one end of the front panel audio I/O module AAFP cable to this connector. HD-audio-compliant pin definition Digital audio connector (4-1 pin SPDIF_OUT)
- Page 17 Microphone port (pink). This port connects to a microphone. Refer to the audio configuration table for the function of the audio ports in 2.1, 4.1, 5.1, or 7.1-channel configuration. Audio 2, 4, 5.1, or 7.1-channel configuration Headset Port 4-channel 5.1-channel 7.1-channel 2-channel Light Blue (Rear panel) Line In Rear Speaker Out Rear Speaker Out Rear Speaker Out Lime (Rear panel) Line Out Front Speaker Out Front Speaker Out Front Speaker Out Pink (Rear panel) Mic In Mic In Bass/Center Bass/Center Lime (Front panel) Side Speaker Out ASUS PRIME H370M-PLUS...
- Page 18 To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output. USB 3.1 Gen 1 Type-A port. These 9-pin Universal Serial Bus (USB) ports are for USB 3.1 Gen 1 devices. • USB 3.1 Gen 1 devices can only be used for data storage. • We strongly recommend that you connect USB 3.1 Gen 1 devices to USB 3.1 Gen 1 ports for faster and better performance from your USB 3.1 Gen 1 devices. USB 3.1 Gen 2 Type-A ports. These 9-pin Universal Serial Bus 3.1 (USB 3.1) ports are for USB 3.1 Gen 2 devices. • Due to the limitation of USB 3.1 Gen 2 and USB 3.1 Gen 1 controller, USB 3.1 Gen 2 and USB 3.1 Gen 1 devices can only be used under Windows OS environment and after the USB 3.1 Gen 2 and USB 3.1 Gen 1 driver installation. • We strongly recommend that you connect USB 3.1 Gen 2 and USB 3.1 Gen 1 devices to USB 3.1 Gen 2 and USB 3.1 Gen 1 ports for faster and better performance from your USB 3.1 Gen 2 and USB 3.1 Gen 1 devices. USB 3.1 Gen 1 Type-C™ port. This 24-pin Universal Serial Bus (USB) port is for USB (Type C) devices.
-
Page 19: Central Processing Unit (Cpu)
NOT install a CPU designed for LGA1150, LGA1155 and LGA1156 sockets on the LGA1151 socket. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1151 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. Installing the CPU Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. ASUS PRIME H370M-PLUS... -
Page 20: System Memory
• Always install DIMMs with the same CAS latency. For optimal compatibility, we recommend that you install memory modules of the same version or date code (D/C) from the same vendor. Check with the retailer to get the correct memory modules. • According to Intel CPU spec, DIMM voltage below 1.35V is recommended to protect ® the CPU. • Due to Intel chipset limitation, DDR4 2666MHz and higher memory modules will run ® at max. 2666MHz on Intel 8th Gen. 6-core or higher processors. ® • Due to Intel chipset limitation, DDR4 2400MHz and higher memory modules will run ® at max. 2400MHz on Intel 8th Gen. 4-core processors. ® • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. • For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs). • Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List) 1-10 Chapter 1: Product Introduction... - Page 21 Installing a DIMM To remove a DIMM ASUS PRIME H370M-PLUS 1-11...
- Page 22 1-12 Chapter 1: Product Introduction...
-
Page 23: Chapter 2: Bios Information
Managing and updating your BIOS Save a copy of the original motherboard BIOS file to a USB flash disk in case you need to restore the BIOS in the future. Copy the original motherboard BIOS using the ASUS Update utility. - Page 24 2.1.2 ASUS EZ Flash 3 The ASUS EZ Flash 3 allows you to download and update to the latest BIOS through the Internet without having to use a bootable floppy disk or an OS‑based utility. • Ensure to load the BIOS default settings to ensure system compatibility and stability.
- Page 25 2.1.3 ASUS CrashFree BIOS 3 utility The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support DVD or a USB flash drive that contains the updated BIOS file.
- Page 26 ENTER to select boot device ESC to boot using defaults P2: ST3808110AS (76319MB) aigo miniking (250MB) UEFI: (FAT) ASUS DRW-2014L1T(4458MB) P1: ASUS DRW-2014L1T(4458MB) UEFI: (FAT) aigo miniking (250MB) Enter Setup When the booting message appears, press <Enter> within five (5) seconds to enter FreeDOS prompt.
- Page 27 DO NOT shut down or reset the system while updating the BIOS to prevent system boot failure. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit BIOS menu. See section 2.3 Exit Menu for details. ASUS PRIME H370M-PLUS 2‑5...
-
Page 28: Bios Setup Program
The BIOS setup screens shown in this section are for reference purposes only, and may not exactly match what you see on your screen. • Visit the ASUS website at www.asus.com to download the latest BIOS file for this motherboard. •... - Page 29 Click to go to Advanced mode Loads optimized Search on the FAQ default settings Click to display boot devices Selects the boot device priority The boot device options vary depending on the devices you installed to the system. ASUS PRIME H370M-PLUS 2‑7...
- Page 30 2.2.2 Advanced Mode The Advanced Mode provides advanced options for experienced end‑users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To access the EZ Mode, click EzMode(F7) or press <F7>. Search(F9) Configuration fields Scroll bar...
- Page 31 It also allows you to change the motherboard’s SATA mode from AHCI to RAID mode. Search (F9) This button allows you to search for BIOS items by entering its name, enter the item name to find the related item listing. ASUS PRIME H370M-PLUS...
- Page 32 Move your mouse over this button to show a QR code, scan this QR code on your mobile device to connect to the BIOS FAQ web page of the ASUS support website. You can also scan the following QR code:...
-
Page 33: Exit Menu
<Esc>, a confirmation window appears. Select OK to discard changes and exit. Launch EFI Shell from USB drives This option allows you to attempt to launch the EFI Shell application (shellx64.efi) from one of the available USB devices. ASUS PRIME H370M-PLUS 2-11... - Page 34 2-12 Chapter 2: BIOS Information...
-
Page 35: Appendix
Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. ASUS PRIME H370M-PLUS... - Page 36 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 37 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
- Page 38 доступний на: www.asus.com/support Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Türkçe AsusTek Computer Inc., bu aygıtın temel gereksinimlerle ve ilişkili Čeština Společnost ASUSTeK Computer Inc. tímto prohlašuje, že toto Yönergelerin diğer ilgili koşullarıyla uyumlu olduğunu beyan eder.
- Page 39 +1-510-608-4555 Web site https://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support https://www.asus.com/support/Product/ContactUs/ Services/questionform/?lang=en-us ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site https://www.asus.com/de/ Technical Support Telephone +49-2102-5789555 Support Fax +49-2102-959911 Online support https://www.asus.com/support/Product/ContactUs/...
- Page 40 800 Corporate Way, Fremont Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : PRIME H370M-PLUS Conforms to the following specifications: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
