Summary of Contents for Hisense HV6135C

  • Page 1 OPERATING INSTRUCTIONS DISHWASHER HV6135C www.gorenje.com...

  • Page 2: Table Of Contents

    Contents Your dishwasher ..................Safety instructions ..................Before washing for the first time ............... Loading the dishwasher ................Using the dishwasher ................Settings ..................... Care and cleaning ..................Troubleshooting ..................Installation ....................Service ...................... Information for test institute ............... Technical information ................Your dishwasher 1.

  • Page 3: Safety Instructions

    Safety instructions General Installation • Read the operating instructions and See the chapter Installation. keep them in a safe place! Child safety • Never use the dishwasher for any Children must be watched. Do not allow purpose other than that specified in children to use or play with the these operating instructions.

  • Page 4: Before Washing For The First Time

    Before washing for the first time • Supports made from untreated wood. Checking water hardness • Protective plastic made from In order to achieve good dishwashing results, the dishwasher needs soft water polyethylene (PE). (water with low mineral content). Hard Disposal water leaves a white coating on dishes The dishwasher is manufactured and...
  • Page 5 achieve a better dishwashing result with Set the Water hardness clear and spotless dishes. Chapter Settings describes how to adjust the water softener. Press to open Top up with salt 1. Open the rinse aid compartment lid. 2. Carefully top up with rinse aid to the Salt compartment lid level marked max.

  • Page 6: Loading The Dishwasher

    Loading the dishwasher Greener dishwashing • Angle dishes with hollows, such as cups, so that the rinse water will run off. • Do not rinse under running water. This is also important for plastic items. Simply scrape off large food particles •...
  • Page 7 the wine glass shelf and knives are placed Foldable tines in the knife stand on the right (if fitted). The foldable tines can be folded up or down to make it easier to load pots, bowls and glasses. Release the foldable tines by pressing the catch inwards before adjusting their position.

  • Page 8: Using The Dishwasher

    Using the dishwasher Add detergent detergent will not be released properly if the lid is tight and will not open correctly. Press to open NOTE! Dishwasher tablets are not recommended for short programmes (less than 75 minutes). Use powder or liquid dishwasher detergent instead.
  • Page 9 effective programme in terms of combined PROGRAM - Select a energy and water consumption. programme Select a programme to suit the type of Quick wash dishes and how dirty they are. This programme is used for glasses and Press the Programme selector one or porcelain that is slightly dirty, such as more times until the desired programme coffee cups.
  • Page 10 If you want to load more dishes Half load Open the door. The dishwasher stops This option adapts the dishwashing automatically. Add the dishes and close programme to a half-filled dishwasher, the door. After a while, the dishwasher using less energy and water. continues the programme.

  • Page 12: Settings

    Settings Open the settings menu: First, open the door. Turn off the machine. Press and hold the main power switch until the display lights up. Within 10 seconds: - press the Programme selector and the option button for Speed wash. The display shows the settings menu (current setting and its currently set value).
  • Page 13 Settings Options Water hardness 2:00 - 2:09 Adjusting the water softener. Select a setting depending on the hardness of the water supply. It is important that this setting is correct! German French wa- Recom- water ter hard- mended hardness ness scale setting scale 0-5°dH...
  • Page 14 Settings Options 3:00 (Off) You can activate this setting when (3-in-1/all-in-one 3:01 (On) using 3-in-1/ All-in-one detergent. The detergent) dishwashing programmes automatically adapt to provide the best possible dishwashing and drying results every time. If this setting is activated there is no need to add rinse aid since this option disables rinse aid dispensing.

  • Page 15: Care And Cleaning

    Care and cleaning WARNING! Top up with rinse aid In order to avoid rust stains a When the rinse aid needs topping up, the dishwashing programme must be started above symbol lights on the display. immediately after adding salt. Press to open Never pour dishwasher detergent into the salt compartment.
  • Page 16 2. Lift the filter straight up using the Lower spray arm handle. Free the coarse filter to clean • Pull the lower spray arm straight up to the fine filter. release it. 3. Refit in reverse order. Check that the edges seal properly when refitting the fine filter.
  • Page 17 • Call the service department. The dishwasher tub The dishwasher tub is made of stainless steel and is kept clean through normal use. Limescale deposits If you have hard water, limescale deposits Drainage pump stop may build up in the dishwasher. If this happens, run the Intensive wash programme with two tablespoons of citric NOTE!

  • Page 18: Troubleshooting

    Troubleshooting Type of fault on the dis- Action play Overfilling Clear the drainage pump. See the chapter Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem”...
  • Page 19 Problem Possible causes Action Cannot close door. The baskets are not Check that the baskets are correctly positioned. correctly positioned horizontally. Check that the dishes are not blocking the baskets from sliding properly into place. The door lock does not click Check the door lock.
  • Page 20 Problem Possible causes Action The dishwasher does not The door is not properly Check. start. closed. You have opened the Close the door and wait. dishwasher to add more After a while, the dishes while a programme dishwasher continues the is in progress.
  • Page 21 Problem Possible causes Action The dishes are not clean. The spray arms do not Remove the arms and clean rotate. them. Check that the dishes are not blocking the spray arms. Spray arm holes or bearings Clean the spray arms. See blocked.
  • Page 22 Problem Possible causes Action Spots on stainless steel or Some foodstuffs, such as Rinse off these types of silver. mustard, mayonnaise, foodstuffs if not starting the lemon, vinegar, salt and dishwasher immediately. dressings, can mark Use the Rinse programme. stainless steel if left for too long.
  • Page 23 Problem Possible causes Action Spots left after washing. Lipstick and tea can be Use a detergent with a difficult to wash off. bleaching agent. Detergent residue in the The detergent compartment The detergent compartment detergent compartment after was damp when adding must be dry when adding dishwashing.
  • Page 24 Problem Possible causes Action Bad odour in dishwasher. Dirt around the seals and in Clean with washing-up corners. brush and low foaming cleaner. Low temperature Run a programme with a programmes have been higher temperature about selected for a prolonged once a month.

  • Page 25: Installation

    Installation [mm] 1194 Door length Nominal dimensions. Actual measurements may vary. It is important that you read through and Check also that none of the follow the instructions and directions connections leak. below. Conduct installation and WARNING! connection in accordance with the Turn off the water supply when installing separate installation instructions.
  • Page 26 • Affix the protective film (packed in the Attach the drainage hose with a hose document bag) to the underside of the clamp. Ensure that the drainage hose has worktop. The protective film is to protect no kinks. the worktop from moisture. Connection to water supply •...

  • Page 27: Service

    Service Read the chapter Troubleshooting before Electrical connection contacting the service department. Information about the electrical connection Provide the details on the serial number can be found on the serial number plate. plate in all contact. Include the article This specification must match the number (1) and the serial number (2).

  • Page 28: Information For Test Institute

    Information for test institute Request test institute information via e-mail ART. NO. dishwashers@appliance-development.com. SERIAL NO. The request should include the details on the serial number plate. Include the article number (1) and the serial number (2).
  • Page 29 Your notes...
  • Page 30 Your notes...
  • Page 31 Your notes...

  • Page 32: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 Hisense Model designation: HV6135C Number of standard place settings: Energy efficiency class: A+++ Annual energy consumption(AE 245 kWh per year Energy consumption of the standard cleaning cycle(E 0.86 kWh...
