Hobbytech BXR.S2 KIT VERSION Instruction Manual page 18

⓲
BAG
S /
teeRIng SeRvo mount
m
ontage du SeRvo de dIRectIon
REV-030
REV-157
15 mm
Tighten / Serrer Tighten / Serrer
REV-095
REV-027
⓳
BAG
F -
Ront and ReaR antI Roll BaR mount
m
ontage deS BaRReS antI RoulIS avant et aRRIèRe
x1
REV-063
R/H 3x8
x4
R/H 3x10
REV-033
x4
SET 3x8
x4
SET 3x3
/
REV-059
Servo (not included)
Servo (non inclus)
x8
F/H 3x8
REV-038
18
REV-039
