- Page 1 MAESTRO 40 USER MANUAL MAESTRO 60 OVENS FOR DOMESTIC USE MAESTRO MODELS 40 / 60 REV 1.1 FFMAES40 FFMAES60...
- Page 2 Try our tasty Simple Pizza Dough Recipe: GENERAL WARNINGS SAFETY WARNINGS WARRANTY INSTALLATION LINKS Other Recipes - Cooking with Fontana Forni STORAGE, SERVICE, MAINTENANCE INDICATIONS FOR USE AND SPECIFICATIONS FIRST IGNITION TROUBLESHOOTING TECHNICAL AND SAFETY NOTES We’re constantly adding new recipes so be sure to follow us on socials for more ideas! We’d love for you to tag us in your delicious creations! #FontanaForniUSA...
- Page 3 the fire extinguishes. All interventions must be carried out in safe conditions and with - Wear heat-resistant kitchen gloves when using the oven. the gas line closed and/or disconnected - The parts sealed by the manufacturer must not be modified by the user. - Do not leave the appliance unattended during cooking, which may release grease or oils.
- Page 4 WARRANTY INSTALLATION In compliance with Italian and European regulations, ovens are covered by the legal WARNING. Oven exterior walls may reach temperatures above 50°C (120°F) any guarantee, payable by the retailer, 24 months from the date of purchase. After the 24- flammable materials must not be within 1 meter of the oven.
- Page 5 CONNECTION ONLY FOR LPG MODELS Pressure REGULATOR (not supplied): CONNECT THE LPG CYLINDER TO THE OVEN This appliance must be equipped with a pressure regulator in compliance with local/natio- The cylinder, always equipped with a pressure regulator (not supplied), must be nal standards and/or regulations with a nominal pressure output of: connected to the oven via a flexible rubber tube (not supplied) suitable for use and CATEGORY I3+(28-30/37) Propane 37 mbar.
- Page 6 STORAGE AND PRESERVATION When storing the appliance for long periods of unused time, remove the cylinder and cover it so that good ventilation can be guaranteed to reduce condensation. Store the Cylinder outdoors in a well-ventilated area. SERVICE This gas appliance must not be altered or tampered with. This unit comes standard as Propane (LP), if converting to Natural Gas, any modifications must be carried out by a certified plumber.
- Page 7 These indications are valid for the entire MAESTRO series, below the technical characteristics of the MAESTRO 40 and 60 models that have the components in common but differ in nominal power.
- Page 8 FIRST IGNITION CAUTION: CHECK FLAME AFTER IGNITION. All burner holes should show a flame of about 2.5cm on max knob position. If you smell gas, if backfire occurs, if the burner makes small bursts or the flames are uneven along the length of the burner there may be a problem with the venturi tube. SWITCH THE OVEN OFF IMMEDIATELY.
- Page 9 BURNER: may backfire and partially ignite. WARNING! DANGER OF BURNS. VERY HOT PARTS DURING OPERATION OF THE APPLIANCE. If there are flame returns, immediately close the gas supply (cylinder or domestic line) and turn off the fire. Probably the venturi tube has obstructions that must be removed, even simple cobwebs can compromise its operation.
- Page 10 MAESTRO 40 MAESTRO 60 MAX POWER 7Kw (509 g/h LPG --- 667dm³/h NG) POTENZA MAX 9Kw (655 g/h LPG --- 858dm³/h NG) Ø INJECTOR Ø INJECTOR CATEGORY I3+(28-30/37) 1.30 mm CATEGORY I3+(28-30/37) 1.50 mm CATEGORY I3B/P(30) 1.30 mm CATEGORY I3B/P(30) 1.50 mm...
- Page 11 EXAMPLE OF DATA PLATE (the shape may vary while maintaining the same pattern NOTES of information) DISPOSAL INFORMATION: THE PRODUCT AT THE END OF ITS LIFE MUST BE DELIVERED TO THE APPROPRIATE COL- LECTION CENTRES FOR BULKY FERROUS, ELECTRICAL OR ELECTRONIC WASTE...
- Page 12 FONTANA FORNI USA 1305 East Palmetto Street Florence, South Carolina 29506 support@fontanaforniusa.com www.fontanaforniusa.com F O N T A N A F O R N I U S A...
