  • Page 1 OWNER’S MANUAL DEHUMIDIFIER MODELS 3PFD22, 3PFD35, 3PFD50, 3PFDP50...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ..................... 4 IDENTIFICATION OF PARTS ......................13 POSITIONING THE UNIT ........................14 OPERATING INSTRUCTIONS ......................15 OTHER FEATURES ..........................17 REMOVING THE COLLECTED WATER ..................18 CARE AND MAINTENANCE ......................21 PREPARING FOR STORAGE ......................21 TROUBLESHOOTING........................22 IMPORTANT NOTE: Read the manual carefully. Make sure to save this manual for future reference. Illustrations in this manual are for explanatory purposes only, your actual product may look slightly different.
  • Page 4: Important Safety Instruction

    IMPORTANT SAFETY INSTRUCTION READ THESE SAFETY PRECAUTIONS BEFORE INSTALLATION AND OPERATION. For your safety, it is important that you read and follow the instructions in this manual to minimize the risk of personal injury, fire or electrical shock. This symbol shows that this appliance uses a flammable refrigerant.
  • Page 5 IMPORTANT SAFETY INSTRUCTION (Continued) • Close all doors, windows and other outside NOTE ABOUT FLUORINATED GASSES openings to the room. • Continuous drainage uses gravity to • When first using the dehumidifier, operate pull the Fluorinated greenhouse gases the unit continuously 24 hours. Make sure are contained in hermetically sealed the plastic cover on the continuous drain equipment.
  • Page 6 IMPORTANT SAFETY INSTRUCTION (Continued) IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference. Explanation of symbols displayed on the unit CAUTION This symbol shows that the operation manual should be read carefully. This symbol shows that a service personnel should be handling this equipment with CAUTION reference to the installation manual.
  • Page 7 IMPORTANT SAFETY INSTRUCTION (Continued) General work area WARNING • All maintenance staff and others (For using R290/R32 refrigerant only) working in the local area shall be instructed on the nature of work being Transport of equipment containing carried out. Work in confined spaces flammable refrigerants shall be avoided.
  • Page 8 IMPORTANT SAFETY INSTRUCTION (Continued) Checks to electrical devices WARNING • Repair and maintenance to electrical (For using R290/R32 refrigerant only) components should include initial safety checks and component inspection Ventilated area procedures. If a fault exists that could • Ensure that the area is in the open or compromise safety, then no electrical that it is adequately ventilated before supply shall be connected to the circuit...
  • Page 9 IMPORTANT SAFETY INSTRUCTION (Continued) Detection of flammable refrigerants WARNING • Under no circumstances, should (For using R290/R32 refrigerant only) potential sources of ignition be used in the searching for or detection of • Ensure that seals or sealing materials refrigerant leaks. A halide torch (or any have not degraded such that they no other detector using a naked flame) longer serve the purpose of preventing...
  • Page 10 IMPORTANT SAFETY INSTRUCTION (Continued) Charging procedures WARNING • In addition to conventional charging (For using R290/R32 refrigerant only) procedures, the following requirements should be followed. Ensure that Removal and evacuation contamination of different refrigerants • When breaking into the refrigerant does not occur when using charging circuit to make repairs or for any other equipment.
  • Page 11 IMPORTANT SAFETY INSTRUCTION (Continued) • Pump down refrigerant system, if WARNING possible. (For using R290/R32 refrigerant only) • If a vacuum is not possible, make a manifold so that refrigerant can be Decommissioning removed from various parts of the • Before carrying out this procedure, system.
  • Page 12 IMPORTANT SAFETY INSTRUCTION (Continued) • The recovery equipment shall be WARNING in good working order with a set of instructions concerning the equipment (For using R290/R32 refrigerant only) that is at hand and shall be suitable for Labelling the recovery of flammable refrigerants. •...
  • Page 13: Identification Of Parts

    IDENTIFICATION OF PARTS BEFORE YOU BEGIN ACCESSORIES CAUTION 1x Power Cord Holder NOTE: The illustrations in the manual are (Shipped inside of bucket) for explanation purpose only. The design specifications are subject to change without prior notice. Your dehumidifier may be slightly different. The most up-to-date version of the manual can be found at www.perfectaire.us Consult with customer support for details.
  • Page 14: Positioning The Unit

    POSITIONING THE UNIT • This dehumidifier should not be used for commercial or industrial applications. • Place the dehumidifier on a smooth, level floor strong enough to support the unit with a full bucket of water. • For good air circulation and best performance, allow at least 8 inches of air space on all sides of the unit and a minimum of 16 inches of air space at the side air outlet.
  • Page 15: Operating Instructions

    Your machine may not contain some indicators or buttons. The actual shape shall prevail. NOTE: Current Room Humidity will show on display during regular use. 3PFD22, 3PFD35, 3PFD50 NOTE: Current Room Humidity will show on display during regular use. 3PFDP50 COMFORT BUTTON •...
  • Page 16 OPERATING INSTRUCTIONS (Continued) FILTER BUTTON SETTING THE TIMER • The FILTER light (clean filter indicator light) • The TIMER button can be used to set a desired will illuminate after 250 hours of fan motor ON or OFF time for the dehumidifier. The operation.
  • Page 17: Other Features

    OPERATING INSTRUCTIONS (Continued) HUMIDITY SET CONTROL LEFT/RIGHT (BUTTONS) PUMP BUTTON (3PFDP50 ONLY) • The humidity set control buttons are used to • Press to activate the pump operation. set the desired humidity level. NOTE: Make sure the pump drain hose is •...
  • Page 18: Removing The Collected Water

    REMOVING THE COLLECTED WATER 3PFDP50 MODELS ONLY: There are three ways to remove collected water: Pump arm needs to be pushed back up into place before reinserting the bucket. USING THE BUCKET • If the unit is OFF, and the bucket is full, the FULL indicator light will illuminate.
  • Page 19 REMOVING THE COLLECTED WATER (Continued) CONTINUOUS DRAINING PUMP DRAINAGE (3PFDP50 ONLY) Continuous drainage uses gravity to pull the water Water pumps provide much more flexibility for out of the unit through a hose. A white screw cap drainage options. It can pump water vertically covers the continuous drain outlet;...
  • Page 20 REMOVING THE COLLECTED WATER (Continued) CAUTION The pump operation light will blink will at 1Hz if there is an operational failure of the pump. Please turn off the unit and unplug the power. Push in on the edge of the CHECK THE FOLLOWING THINGS: pump inlet •...
  • Page 21: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE AIR FILTER Turn the dehumidifier off and unplug it from the wall outlet before cleaning. • THE FILTER IS INTEGRATED WITH THE • Use water and a mild detergent. Do not use BACK PANEL OF THE UNIT AND NOT A bleach or abrasives.
  • Page 22: Troubleshooting

    TROUBLESHOOTING Before calling for service, review the chart below. Problem What to check Make sure the dehumidifier s plug is pushed completely into the outlet. Check the house fuse/circuit breaker box. Unit does not start Dehumidifier has reached its preset level or bucket is full. Water bucket is not in the proper position.
