- Page 1 AURORA® UNIVERSAL OUTDOOR TV FIXED TILT MOUNT F2AA004ABBK [2022260478] USER MANUAL *Product picture is for reference only.
-
Page 2: Table Of Contents
Contents Welcome ....................................2 Important Safety Instruction ............................2 What's in the box ................................3 Before Installation ................................4 Installation ....................................5 Operation and Adjustment ............................9 CCD-0007284 Rev: 02-20-23 - 1 -... -
Page 3: Welcome
Welcome Thank you for purchasing the Furrion Universal Outdoor Fixed Tilt Mount for 49"/50"/55"/ 65"/75" Furrion Aurora™ TV. Before operating your new product, please read these instructions carefully. This instruction manual contains information for safe use, installation, introduction of the product. -
Page 4: What's In The Box
FOLLETO DE LA GARANTÍA ......ESPAÑOL (ES) *Product picture is for reference only. https://furrion.com/pages/downloads-audio-visual * To view the multi-language user manual, please access the link or scan the QR code. * Pour obtenir le manuel d’utilisateur multilingue, accédez au lien ou scannez le QR code. -
Page 5: Before Installation
Specification and Features ● Max loading : 185 lbs (84 kg) ● Fit all Furrion Aurora™ TVs : Max VESA 23 5/8" x 23 5/8" (600 mm x 600 mm) ● Tilt range: 6° up/7° down ● Distance from wall: 2 7/16" (62.5 mm) 23 5/8"... -
Page 6: Installation
Before Installation Furrion Aurora™ TV VESA Mounting Pattern (W x H mm) Model FDU***CBS FDU***CSA Size FDU***CBR FDU***Y1A 43" 200 x 200mm 200 x 200mm 49" 200 x 400mm 50" 200 x 400mm 55" 400 x 400mm 400 x 200mm 65"... - Page 7 Installation Part 1B - Mounting to the Wall mm (3/8”) hole at each marked location. (Concrete) Remove any excess dust from the holes. 4. Insert a concrete anchor (C) into each WARNING: For safety reasons, the hole so that it is flush with the concrete concrete wall must be capable of supporting surface (see Fig.
- Page 8 Installation Part 2 - Attaching Mount Arms the surface, you will use the shorter to the Display screws (D, E or H) from the hardware kit. ● If the back of your display is curved, CAUTION: Use extra care during this part has a protrusion, or if the mounting of the installation.
- Page 9 Installation Part 3 - Final Assembly CAUTION: Verify that both arms are locked to the wall plate. For safety reasons, this mount cannot be used unless both arms 1. With the help of anoher person, carefully are securely locked (see Fig.8) To avoid lift your display and place it on the wall accidental unlocking, stow the pull strings plate.
-
Page 10: Operation And Adjustment
Operation and Adjustment Change Tilt Angle, Level Correction Adjustments 2. To make level correction adjustments, have one person hold the display firmly 1. To change the tilt angle of your display, in place while another person slightly have one person hold the display firmly in raises or lowers the level correction place while another person loosens the tilt screws using the long Allen key (L) (see... - Page 11 CCD-0007284 Rev: 02-20-23 - 10 -...
- Page 12 ● Toll free/Numéro gratuit/Línea telefónica gratuita:1-800-789-3341 ● Email/Courriel/Correo electrónico: support@furrion.com ©2007-2022 Furrion Ltd. Furrion® and the Furrion logo are trademarks licensed for use by Furrion Ltd. and registered in the U.S. and other countries. ©2007-2022 Furrion Ltd. Furrion® et le logo Furrion sont des marques commerciales utilisées sous licence par Furrion Ltd.
