INSTALLATION INSTRUCTION
13 RS
The following parts are required:
• Electric drill with
5 mm and 8 mm SDS
• Various HSS-drills
3,5 mm, 4,2 mm, 6,5 mm
• Cordless screwdriver with bits TX
15, 20, 25, 30 mm PH2 cross
• Various allen keys
• Water level at least 1 m or laser
• Small wooden wedges
Various Philips-HP screwdrivers
Several wooden blocks height 15 cm
• Several glass blocks 5 mm
• Hammer, rubber hammer
Pop rivet gun
Standard tools
• At least 2 scissor jacks
• Chop and fermentation saw with
blade for aluminum
• Hand-held circular saw if required
with blade for plastic and
non-ferrous metals
Short cuts for parts:
SPL
- Left side section
SSL
- left part for side wall
SPM
- Middle section
SPR
- Right side section
SSR
- right part for side wall
TW
- Partition
SWF
- End wall with leg
SCHW
- Privacy screen
TUL
- Left door
TUR
- Right door

Advertisement

loading
Need help?

Need help?

Do you have a question about the 13 RS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for META 13 RS

  • Page 1 - left part for side wall - Middle section - Right side section - right part for side wall - Partition - End wall with leg SCHW - Privacy screen - Left door - Right door INSTALLATION INSTRUCTION 13 RS...
  • Page 2 Marking of the wall connections (U profiles) Example Dimension 1, 2, 3 = axial dimension The cabin axis dimensions (dimension 1) can be taken from your drawing if neccessary. If no dimensions are specified, the width of the system is divided into equal parts. Dimension 1 Dimension 1 Dimension 3...
  • Page 3 Marking doors, middle, end part left end part right side and corner parts (corner section) (wall connection) middle parts side wall First of all, the dimensions of the front parts have to be marked on the floor. Please note the following: End part For end parts, the clearance in the drawing must be added to the width of the end wall connection.
  • Page 4 Setting up the doors, middle-, end- and corner parts Place the side part on the marking and insert it into the U-profile. (please do not screw yet) Place the U-profile U-13G (according to the dimensions in the drawing) flush with the bottom and in the center of the middle section, mark the drill holes, and fasten the U-profile with 4,8 x 11 mm screws (pre-drill 4,2 mm).
  • Page 5 upper door clearance lower door clearance using 5 mm glass blocks Mounting the cover profiles To determine the exact length of the cover profiles (AD13RFK), place the corner connector on the corners of the front and side walls. Mark the cover profiles and cut to length accordingly. (Only if SW) Corner connector To attach the cover profile (AD13RFK), the holes in the profile...
  • Page 6 Now drill the holes in the center of the front and side cover profiles in the area of the markings using a 6,5 mm diameter drill bit. In the area of the wall connections, push the cover cap onto the cover profile and position the profiles on the system using the corner connector.
  • Page 7 Alignment of the system Check that the door is properly aligned with the profile and the distance to the upper profile. By raising or lowering the partition and side walls, the door stop can be changed. If necessary, a correction can also be made using the adjustable support feet.
  • Page 8 Inclined wall connection Angling Schräger Wandanschluß ! ABW13RF-A + ABW13RF-B Filler Füllstück ABW13RF-A ABW13RF-B AD13RFK AD13RFK DETAIL A Inclined wall connection with recess. Schräger Wandanschluß mit Aussparung! An orifice plate is inserted here! Hier wird eine Blende eingesetzt! MAßSTAB 1 : 2 ABW13RF-A + ABW13RF-B AD13RFK UP13G...
  • Page 9 Mounting hook nylon Mounting buffer nylon The hooks are marked and then fastened with 5 mm dowels Mark the buffers at the height of the door handles. Fasten and screws 4 x 40. Use screws 3,9 x 13 when fastening to door the bottom parts using an 8 mm dowel and screws 5 x 50 or TW.
  • Page 10 Installation Lock RS1 the following tools are required: Phillips-HP screwdriver Torx driver 15 small hammer Always place the lock case on the side after which the door is opened. First the 2 coiled spring pins (3 x 10 mm, without illustration) must be inserted into the housing (1) with pliers. (squeeze if necessary) The base plates of the red/white locking device (2, 3) and the 2 screws 3,5 x 35 (12) must be ready to hand before attaching the lock case.
  • Page 11 Installation lock RS2, RS3 the following tools are required: Phillips-HP screwdriver Torx key 15 small hammer Allen key 2,5 mm Screw it together with 2 Torx-screws 3,9 x 32 (5). First, the 2 dowel pins (3 x 10 mm, without Observe the position of the red/white-indicator! illustration) must be inserted into the housing (1).
  • Page 12 Installation lock RS4 the following tools are required: Torx key 15 und 20 Allen key 2,5 mm Indicator part Ground part (POM) (3031) (3033) Turned part Square with red/white (2925) (3066) und (3142) Lock case Fixing screws (2148) M5 x 45 ES SK DIN 965 (2920) Slide (2127) Lock case fixing screw...
  • Page 13 Type 13 RS without clearance UP13G For the floor connection, the UP13G profiles must be cut to the width of the front elements on site. They are then screwed to the floor. How to tense spring hinges Keep the door closed.
  • Page 14: Installation Procedure

    Example: Floor- and ceiling support with clearance! Measurements Installed system Recess Fixing AD13 to angle with 4,8 x 16 mm screws Axis measure for angle External dimension 1000 mm Fixing AD13 to sheet with 4,8 x 32 mm screws Fixing AD13 to sheet with 4,8 x 32 mm screws Fixing AD13 to sheet with 4,8 x 32 mm screws...
  • Page 15 Example: Floor- and ceiling support without clearance! Measurements Installed system Recess Fixing AD13 to angle with 4,8 x 16 mm screws Axis measure for angle External dimension 1000 mm Fixing AD13 to sheet with 4,8 x 32 mm screws Fixing AD13 to sheet with 4,8 x 32 mm screws Fixing AD13 to sheet with 4,8 x 32 mm screws...
  • Page 16 Trennwandanlagen • Metastraße 2 • D-56579 Rengsdorf • Tel. +49 26 34 / 66-0 • Fax +49 26 34 / 66 450 • E-mail: info@meta.de • Internet: www.meta.de 10/23...
