VonHaus 3500230 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

3500230
Please read all instructions carefully before use and
retain for future reference.
CAUTION Sharp edges.
Maintain a safe distance from bystanders.
Protect your eyes.
Protect your ears.
Protect your hands.
A5P | 01
Protective clothing must be worn
Protective Footwear must be worn
Please read all instructions carefully before use and retain
for future reference.
INTENDED USE Only operate the power tool/machine
for its intended purpose and within the parameters
specified in this manual.
This power tool/machine is for domestic use only. Do not
use outdoors or on wet surfaces.
This power tool/machine is not intended for use by
persons with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
supervised or given appropriate instruction concerning
the product's use by a person responsible for their safety.
GENERAL PRECAUTION Do not allow to be used as a
toy. Children should be supervised to ensure they do not
play with the power tool/machine.
If the power tool/machine is not functioning properly,
has been dropped, damaged, left outdoors, or immersed
in liquid, do not use, contact DOMU Brands Customer
Services.
Do not use the power tool/machine if any parts appear to
be faulty, missing or damaged.
Ensure all parts are securely attached before use.
RISK OF PERSONAL INJURY Avoid body contact with
earthed or grounded surfaces such as pipes,radiators,
ranges and refrigerators. There is an increased risk of
electric shock if your body is earthed or grounded.
Prevent unintentional starting. Ensure the switch is in the
off position before connecting to the power source and/
or battery pack, picking up or carrying the tool. Carrying
power tools with your finger on the switch, or energising
power tools that are switched on, invites accidents.
Do not operate power tools in explosive atmospheres
such as in the presence of flammable liquids, gases or
dust. Power tools create sparks which may ignite the
dust or fumes.
Always wear eye protection. Any power tool can throw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3500230 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for VonHaus 3500230

Summary of Contents for VonHaus 3500230

  • Page 1 3500230 Please read all instructions carefully before use and Protective clothing must be worn retain for future reference. Protective Footwear must be worn CAUTION Sharp edges. Please read all instructions carefully before use and retain for future reference. Maintain a safe distance from bystanders.
  • Page 2 foreign objects into your eyes and cause permanent poorly maintained power tool/machines. eye damage. Always wear safety goggles (not glasses) Keep cutting tools sharp and clean. that comply with ANSI safety standard Z87.1. Every day Properly maintained cutting tools with sharp cutting glasses have only impact resistant lenses.
  • Page 3 and the chainsaw out of control. charge and discharge the cells or batteries several times Use extreme caution when cutting brush and saplings. to obtain maximum performance. Fine branches can catch in the chain, whipping them Do not short-circuit a cell or battery. towards you and/or pulling you off balance.

  • Page 4: Technical Specification

    result in fire or electric shock. Never attempt to connect two chargers together. Use the battery charger indoors only. Make sure that the charger cable is positioned where it will not be stepped on, tripped over or otherwise subjected to damage or stress. Keep the cord away from operating appliance/power tool/machine.
  • Page 5 COMPONENTS A5P | 01...
  • Page 6 BATTERY 60mins Status Green Flickering Ready to charge Solid Red Charging Solid Green Fully Charged Solid Green and Red Battery/Charger is faulty. Green LED Red LED A5P | 01...
  • Page 7 FITTING A NEW CHAIN Sprocket 1. Remove the cover using the Chain Bar Locking Nut 2. Wearing suitable heavy chainsaw gloves carefully (6) by unscrewing counter-clockwise until it detaches. position the Chain (7) onto the Chain Guide Bar (8) seating in the groove, ensuring it is facing the correct way around.
  • Page 8 ASSEMBLY TELESCOPIC ADJUSTMENT A5P | 01...

  • Page 9: Operation

    ANGLE ADJUSMENT 20º OPERATION A5P | 01...
  • Page 10 BALANCE AND WORKING POSITION Pole trimmers are often referred to as being difficult to balance or being heavy as the motor in the cutting head is far away from the position of the gripping surfaces during use. To ensure that good balance is felt in the product, it is important to: Always wear safety goggles, non-slip footwear and gloves.
  • Page 11 SPROCKET MAINTNENCE WARNING: Wear heavy duty work gloves when handling the bar and chain. CAUTION: The sprocket tips on your new saw have been pre-lubricated at the factory. Failure to lubricate the guide bar sprocket tip will result in poor performance and seizure, voiding the manufacturer’s warranty.

  • Page 12: Sawing Techniques

    SAWING TECHNIQUES WARNING! BE THOROUGHLY AWARE OF THE DANGER OF REBOUNDING BRANCHES. SAWING SMALL BRANCHES Set your saw cut of small branches (0-3inches) from top to bottom as illustrated. Be aware of early breaking of the branch if you have underestimated the size and weight.

  • Page 13: Chain Maintenance

    CHAIN MAINTENANCE WARNING! Always ensure the battery is removed before performing any cleaning and maintenance tasks. CHAIN TENSIONING AND ADJUSTMENT CHECK Correct tension of the saw chain is extremely important and must be checked before starting, as well as during any cutting operation.

  • Page 14: Chain Sharpening

    CHAIN SHARPENING Parts of a Cutter Top Plate Cutting Corner Side Plate Depth Gauge Rivet Hole Heel Gullet WARNING: Improper Chain sharpening increases the potential of kickback. Failure to replace or correctly repair a damaged Chain can cause serous injury. For the inexperienced chainsaw user, we recommend that your chain be professionally sharpened by your nearest gardening equipment repair centre.

  • Page 15: Troubleshooting

    TROUBLESHOOTING PROBLEM SOLUTION Ensure the Battery is fully charged and inserted correctly. Tool does not power on Activate the ON/OFF Trigger Switch. Driver gear may be broken. Contact DOMU Brands Customer Blade does not move Services. Chain may be damaged and will need changing as outlined in the ‘Chain Maintenance’...

  • Page 16: Declaration Of Conformity

    M3 7BF DOMU Brands Ltd Unit 30, Finlan Road Stakehill Industrial Estate Middleton, Manchester M24 2RW Declare under our sole responsibility the product: 3500230 Description: 40V Cordless Pole Chainsaw Complies with the essential requirements of the following directives: 2006/42/EC 2000/14/EC 2014/30/EU...
  • Page 17 A5P | 01...
  • Page 18 Thank you for purchasing your product/appliance. Should you require further assistance with your pur- chase, you can contact us at support@domu.co.uk VonHaus is a registered trademark of DOMU Brands Ltd. Made in China for DOMU Brands. M24 2RW. A5P | 01...
