Phiaton BonoBeats Lite Owner's Manual

Bluetooth noise cancelling headphone
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNER'S GUIDE
Bluetooth® Noise Cancelling Headphone

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BonoBeats Lite and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Phiaton BonoBeats Lite

Summary of Contents for Phiaton BonoBeats Lite

  • Page 1 OWNER'S GUIDE Bluetooth® Noise Cancelling Headphone...

  • Page 2: Table Of Contents

    - Please follow the directions and read the guidelines carefully before use. - Please keep the owner’s guide for future reference. - Some functions of the BonoBeats Lite may not be available when it is paired with certain devices. - The specifications are subject to change without prior notice for quality improvement.

  • Page 3: Safety And General Information

    10) When cleaning the device, use a clean dry cloth to wipe the device clean. (Do not use solvents.) 11) Keep the device in the protective case when the product is not being used. 12) Replacement ear pads can be purchased from Phiaton Customer Service. Email us at SUPPORT@PHIATON.COM 13) Using the device while walking or driving may prevent user from hearing important sounds such as signals or alarms and may impose hazardous conditions on yourself or others.

  • Page 4: Components & Features

    2. COMPONENTS & FEATURES 1) Contents - BonoBeats Lite - USB-C TO USB-C Charging Cable - Quick Guide - Warranty Card 2) Features NC mode button + button MFB button - button LED Indicator USB TYPE C Port...

  • Page 5: Charging

    ※ In connection Waiting Mode, the headphone should be entered to ‘Pairing Mode’ for connection to ‘Bluetooth device’ again after power off. If not, BonoBeats Lite will turn off within 5 minutes after starting ‘Connection Waiting Mode’.

  • Page 6: Pairing With A Bluetooth Device

    - Place the BonoBeats Lite within 3 feet of the ‘Bluetooth Device’ you want to connect. - Press and hold the MFB button for over 6 seconds with the BonoBeats Lite power on to enter Pairing Mode. Pairing mode will automatically start the first time the BonoBeats Lite are turned on after purchase.

  • Page 7: Multipoint Connection

    ※ If the second ‘Bluetooth Device’ is not connected during the process of connecting ‘Multipoint Connection’, the BonoBeats Lite will be turned off after 5 minutes. ※ When the BonoBeats Lite is turned off and back on, the first and second paired devices will automatically be connected.

  • Page 8: Noise Cancelling Function

    7. NOISE CANCELLING FUNCTION 1) What is ‘Noise Cancelling’? - Noise Cancelling refers to a technology that reduces noise from mid/low pitched sounds under 1kHz. 2) Turn On Noise Cancelling - The Noise Cancelation function is automatically activated when the device is powered on or when the audio cable is plugged in.

  • Page 9: Listening To Music (Play & Control)

    9. LISTENING TO MUSIC (PLAY & CONTROL) 1) Playing Music - Short press the MFB Button once to play music from the ‘Bluetooth Device’. - While music is playing, short press the MFB Button to pause the playing music. The music will resume from the paused point when playing again.

  • Page 10: Using The Call Function

    - Press and hold the MFB button for about 1 second to end the current call and connect the second call. 5) Switching between Mobile Phone to BonoBeats Lite - To switch the call from mobile phone to the headphone, press the MFB button for 1 second.

  • Page 11: Miscellaneous Features

    12. MISCELLANEOUS FEATURES 1) Checking Remaining Battery - With the power on, short press the MFB button twice to announce the remaining battery level by voice guidance. - For Apple iOS version 5 or above, the remaining battery is displayed at the top right side of the screen.

  • Page 12: Specifications

    13. SPECIFICATIONS ® Communication Network Bluetooth Bluetooth Profiles HFP v1.8 / A2DP v1.3.2 / AVRCP v1.6.2 ® Audio Codec SBC, Qualcomm aptX™,aptX™HD, AAC Operating Frequencies 2.4 GHz (2.402 GHz ~ 2.480 GHz) Operating Range Within 10 m / 33 ft. Music Play NC ON 30 hrs Standby Time...

  • Page 13: Product Issues And Troubleshooting

    14. PRODUCT ISSUES AND TROUBLESHOOTING 1) The power does not turn on: - Charge the device. If the power does not turn on even after charging, contact Phiaton Customer Service. 2) The device does not charge: - Check whether the USB charging cable has been properly connected with the device.

  • Page 14: Certification

    15. CERTIFICATION FCC Compliance Information FCC ID: V2R-BN0300 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment NOTE :...
  • Page 15 TN0620 a été testé et jugé conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF) CNR-102 de l’ISDE. CE Compliance Information Hereby, PHIATON declares that this product is in compliance with the essential requirements and other relevant provi- sions of RE Directive 2014/53/EU 2011/65/EU.
  • Page 16 Responsible Party-U.S. Contact Information PHIATON Corporation 9550 Warner Ave #360 Fountain Valley CA 92708 To learn more, visit our website, www.phiaton.com Phiaton is a trademark of Phiaton Corporation...

This manual is also suitable for:

Ppu-bn0300wh01Ppu-bn0300bk01
