Infineon XENSIV DPS310 Kit2Go User Manual

Pressure sensor 2go kit

Advertisement

Quick Links

XENSIV™ DPS310/368
Pressure Sensor 2Go Kit
User Guide
11/2/2022
Arrow.com.
Downloaded from

Advertisement

loading

Summary of Contents for Infineon XENSIV DPS310 Kit2Go

  • Page 1 XENSIV™ DPS310/368 Pressure Sensor 2Go Kit User Guide 11/2/2022 Arrow.com. Downloaded from...
  • Page 2 Pin out on top (head) is directly connected to the pins of the DPS Breakable head for individual sensor usage − After breaking, head and MCU/Debugger Peripherals can still be used independently Standard delivery interface mode is I²C 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 3 Pressure measurement results are readable through the serial I2C or SPI interface making it easily and quickly accessible by e.g. Arduino IDE or Platform.IO with Arduino Extension Link to Datasheet Product Page 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 4: Board Information

    Address 0x77 when the 0 Ohm resistors are soldered as shown on the MAKE SURE THAT NO VOLTAGE right picture APPLIED TO ANY OF THE PINS EXCEEDS THE ABSOLUTE Sales Name: KIT_DPS310_2GO and KIT_DPS368_2GO MAXIMUM RATING OF 4 V 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 5 Kit2Go PCB Details 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 6 Board Schematic (XMC2Go related) The Infineon DC-DC converter transforms the 5 V of the Micro-USB to 3.3 V for the MCU, Debugger and Peripherals circuits The green PWR LED indicates a proper power supply for the Kit2GO The 2 green User-LEDs (LED1 -> P1.0 and LED2 ->P1.1)
  • Page 7 J1 Jumper: If soldered, enables the pull-down resistor on the interrupt pin and changes the I²C address from 0x77 to 0x76 J2 Jumper: If soldered, connects the INT/GPIO3 pin 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 8 Extended information about the Arduino environment. Click here − How to import libraries? Click here − How to install additional boards? Click here − Problems related to Arduino? Click here for troubleshooting 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 9 SEGGER J-Link In order to use and program the Infineon XMC microcontroller in the Arduino IDE, SEGGER J-Link must be installed on your PC Please follow this link to SEGGER J-Link and install the J- Link Software and Documentation Pack for your operating...
  • Page 10 Open the Arduino IDE Navigate to Tools=>Board=>Boards Manager... Type in “xmc“ and install Infineon‘s XMC Microcontroller Boards After installation navigate to Tools=>Board=>XMC Family and select XMC1100 XMC2Go 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 11 Note Regularly check your installed libraries for updates In case of problems, please visit the corresponding GitHub Repository and open an issue to get further help 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 12 Select the related COM port from Tools=>Port and open the serial monitor with the set baud rate (see <baud rate> sketch/code with Serial.begin( Follow the same steps for the DPS310 Kit2Go 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 13: Important Warning

    SDA/SCL, will still be driven by 5 V Please use appropriate level shifting for these boards LEVEL SHIFTER 5 V -> 3.3 V 11/2/2022 Copyright © Infineon Technologies AG 2022. All rights reserved. Arrow.com. Downloaded from...
  • Page 14 DPS310.SchDoc Connection Ports Modular_S2G1_Pinout SPI_MOSI MOSI SPI_MISO MISO SPI_CS_N CS_N P0.9 P0.9 CS_N SPI_SCK P2.10 P2.10 P0.8 P0.8 P2.11 P2.11 P0.6 P0.6 MISO I2C_SDA P0.0 INT/GPIO3 P0.7 P0.7 MOSI I2C_SCL INT/GPIO3 INT/GPIO3 SPI/I²C Selection Circuit DPS310 +3V3 Power Supply Decoupling 10k/50V/1% +3V3 +3V3...
  • Page 15 DPS368.SchDoc Connection Ports Modular_S2G1_Pinout SPI_MOSI MOSI SPI_MISO MISO SPI_CS_N CS_N P0.9 P0.9 CS_N SPI_SCK P2.10 P2.10 P0.8 P0.8 P2.11 P2.11 P0.6 P0.6 MISO I2C_SDA P0.0 INT/GPIO3 P0.7 P0.7 MOSI I2C_SCL INT/GPIO3 INT/GPIO3 SPI/I²C Selection Circuit DPS368 Power Supply Decoupling +3V3 10k/50V/1% +3V3 I2C_SDA...
  • Page 16 Size: Document Name Rel. Rev. information regarding the application of the device, Infineon Technologies hereby disclaims any and all warranties V1.0 DPS368-PS2GO-Kit and liabilities of any kind, including without limitation, warranties of non-infringement of intellectual property rights of any third party.
  • Page 17 Arrow.com. Downloaded from...

This manual is also suitable for:

Xensiv dps368 kit2go
