- Page 1 ASSEMBLY INSTRUCTIONS MODEL: AD-A4 PROGRAMMABLE SINGLE MOTOR STANDING DESK WITH TABLETOP Please take the time to carefully read this manual before using the product. If you need customer support, please call us at 1-800-267-1783 www.AnthroDesk.ca [Canada] www.AnthroDesk.com [USA]...
- Page 2 Handset Interface Height Settings: The system supports the height limit of the desk. The operation method is to press and hold the <↑> and <↓> buttons simultaneously for 5 seconds at the desired height until you hear the buzzer, indicating that the limit position is successfully stored. When the desk is in the upper half of the stroke, the limit is the highest position.
- Page 3 2. The running time exceeds 2 mins within 18 mins. 2. Let the system rest for at least 18 mins. Internal Parameters and Installation Distance Setting: The Motor 1 is not connected. Check the power cable of the motor. To access the internal parameters and installation distance settings, long-press <S> for 15 Error in the Motor 1 current sampling seconds.
- Page 4 Parts and Tool List Begin by mounting the motor onto the hex rod. Next, insert the assembled hex rod into one of the legs and secure the motor in place using two M4*35 screws. Then, attach the other end of the hex NAME NAME rod to the remaining leg.
- Page 5 Attach sidebar to legs using 4 of M6*10 screws fit the 8 rubber cushions to the sidebar. Connect the motor and the adaptor to the handset, connect the power cord to the adaptor. 4mm Allen Key Rubber Cushion*8 M6*10 Screw*4 Secure the frame to the table top using 8 ST4.816 screws.
