POWERBLOCK POWERMAX STAND ASSEMBLY
ITEM NO.
1
2
3
4
5
6
TOOLS NEEDED: ONE 17 mm WRENCH AND ONE 6 mm HEX ALLEN WRENCH.
1. ATTACH LEFT LEG (ITEM 2) TO SPACER SUPPORT (ITEM 1) WITH SUPPLIED HARDWARE.
ALIGN PEG ON SPACER SUPPORT WITH PEG HOLE ON LEG. DO NOT TIGHTEN HARDWARE.
2. ATTACH RIGHT LEG (ITEM 3) TO SPACER SUPPORT (ITEM 1) WITH SUPPLIED HARDWARE.
TIGHTEN ALL HARDWARE.
4
ALIGNMENT
PEG HOLE
5
6
STEP ONE
DESCRIPTION
POWERMAX STAND SPACER SUPPORT
POWERMAX STAND LEFT LEG
POWERMAX STAND RIGHT LEG
M10 - 1.5 mm X 50 mm BUTTON HEAD SCREW
M10 WASHER
M10 - 1.5 mm LOCK NUT
2
1
3
QTY.
1
1
1
4
8
4
Advertisement
Table of Contents
Related Manuals for PowerBlock POWERMAX STAND
Summary of Contents for PowerBlock POWERMAX STAND
- Page 1 POWERBLOCK POWERMAX STAND ASSEMBLY STEP ONE ITEM NO. DESCRIPTION QTY. POWERMAX STAND SPACER SUPPORT POWERMAX STAND LEFT LEG POWERMAX STAND RIGHT LEG M10 - 1.5 mm X 50 mm BUTTON HEAD SCREW M10 WASHER M10 - 1.5 mm LOCK NUT TOOLS NEEDED: ONE 17 mm WRENCH AND ONE 6 mm HEX ALLEN WRENCH.
- Page 2 1. ATTACH BOTH TOPS (ITEM 2) TO LEG ASSEMLBY (ITEM 1) WITH SUPPLIED HARDWARE. TIGHTEN HARDWARE. 2. APPLY TRAY MATS (ITEM 4) TO TOPS (ITEM 2). 3. APPLY POWERBLOCK DECAL (ITEM 5) TO SPACER SUPPORT OF LEG ASSEMBLY. TIGHTEN ALL HARDWARE. FOR USE ON FIRM AND FLAT SURFACE ONLY.
