Distech Controls GS-AQOPM Series Installation Manual

GS-AQOPM Series

Product Description

The Outside Particular Matter Sensor uses an optical sensor based on laser scattering principles and features innovative
contaminationresistance technology to perform highly accurate and reliable PM measurements. With a continuous-oper-
ation lifetime of more than 8 years, the sensor will provide long-term reliability and high-resolution particle size binning for
the detection of environmental dust and other particles.
The sensor is housed within a weatherproof enclosure to monitor outside PM levels. The sensor achieves excellent per-
formance characteristics, including high accuracy and low power consumption to ensure stable long-term operation. The
outside particulate sensor features both 4-20 mA and voltage outputs (0-5 / 0-10 Vdc) for simple integration into any build-
ing automation system to assure good air quality. The device is also available with an RS-485 MS/TP network connection
including either Modbus or BACnet

General Installation Recommendations

Use electrostatic discharge precautions during installation and do not exceed the device ratings.
Read these installation instructions carefully before commissioning the PM Sensor.

Failure to follow these instructions may result in product damage.

Do not use in an explosive or hazardous environment, with combustible or flammable gases, as safety or emergency

stop devices or in any other application where failure of the product could result in personal injury.
protocol.
®
I n s t a l l a t i o n G u i d e
