INSTALLATION GUIDE
Customizable Button Module (NUDM3–HE)
9
Specifications
Wire/terminations
Compatible electrical boxes (metal
or plastic)
TD 93506EN / 02 March 2022 / Ver. A
Cat 5/5e/6/7, U/UTP
Cat 6/7 cable will work electrically but may be too stiff for
some back boxes.
• EU box (or equivalent) Single backbox with mounting holes
60mm (2.36in.)
• MK Honeywell models (or equivalent) 1-gang: 861ZIC, 866ZIC,
877ZIC Note: UK backboxes require single (NUMP86-HK) or
dual (NUMPD86-HK) mounting plates.
