WIRELESS DMX

This ALGAM LIGHTING fixture is equipped with a DMX wireless transmission system. "WIRELESS DMX".

PAIRING YOUR DMX FIXTURE

1 • Connect the transmitter (Algam Lighting DMX-WT) to your DMX controller OUTPUT or turn ON the
EVENTPAR MINI set up as transmitter.
2 • Power up transmitter and the EVENTPAR MIN receiver.
3 • Press the pairing button on the EVENTPAR MINI' s WIRELESSDMX receiver
4 seconds, and the LED
turns white, indicating that your receiver is waiting to be paired.
3
4 • Press now on transmitter button to start pairing. Both receiver and transmit-
ter will blink rapidly (transmitter in blue color and receiver in green color). The
pairing is processing. Once pairing is done, the transmitter status LED is now
fixed blue color and receiver status LED is fixed green color.
If Transmitter or receiver looses DMX signal, the status LED will blink slowly.

ADD A FIXTURE IN AN ACTIVE GROUP

1 • Press and hold 3 seconds on receiver button on your new fixture to reset the
pairing until the status LED becomes white.(this means that receiver is now
ready to be paired).
2 • Press now on transmitter button to start pairing. Both receiver and transmit-
ter will blink rapidly (transmitter in blue color and receiver in green color). The
pairing is processing. Once paring is done, the transmitter status LED is now
fixed blue color and receiver status LED is fixed green color. The other fixtures
already paired in this group with this transmitter remain paired of course.

SET UP A NEW GROUP

To set up a new group is very easy. You need one more transmitter of course. Keep the existing groups active , and start
the procedure above called « Pairing you DMX fixture».
NOTES
This DMX wireless system from Algam Lighting is not limited in number of groups and in number of fixtures connected in
a group.

DMX PROTOCOL

4 CHANNEL
CHANNEL VALUE
CH1 R dimming
CH2 G dimming
B dimming
CH3
CH4 W dimming
will flash blue. When you release the button, the LED
3
FUNCTION
Red dimming - From dark to bright
Green dimming - From dark to bright
Blue dimming - From dark to bright
White dimming - From dark to bright
for
2
The EVENTPAR MINI fixture
is automatically set as «Re-
ceiver» if the fixture is set in
DMX mode and if no DMX signal
is received by the connector
«DMX IN».
The EVENTPAR MINI fixture is
automatically set as «Trans-
mitter» if it receives a DMX
signal on its input «DMX IN» or
if it is set up in : AUTO, COLO,
STAT or SOUN mode.
P.23
!
