RHAPSODYA
INSTRUCTION MANUAL
INDEX
Congratulations on choosing a Claypaky product!
We thank you for your custom.
Please note that this product, as all the others in the
rich Claypaky range, has been designed and made with
total quality to ensure excellent performance and best
meet your expectations and requirements.
CL3024
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Claypaky RHAPSODYA
Summary of Contents for Claypaky RHAPSODYA
-
Page 1: Table Of Contents
Safety information Please note that this product, as all the others in the Unpacking and preparation rich Claypaky range, has been designed and made with total quality to ensure excellent performance and best Installation and start-up meet your expectations and requirements. -
Page 2: Safety Information
1. SAFETY INFORMATION SAFETY INFORMATION IMPORTANT: Claypaky recommends you carefully read and keep the safety information on this product, also available in digital format at the following link: www.claypaky.com Ref: FIS02R - Safety Information Rhapsodya INFORMAZIONI DI SICUREZZA IMPORTANTE: Claypaky raccomanda di leggere accuratamente e conservare le informazioni di sicurezza relative a questo prodotto, sempre reperibili in versione digitale al seguente link: www.claypaky.com... -
Page 3: Unpacking And Preparation
2. UNPACKING AND PREPARATION 2 x 183102/805 Packing contents - Fig. 1 LOCKED UNLOCKED PAN Mechanism Lock and Release (every 90°) - Fig. 2 TILT Mechanism Lock and Release (every 45°) - Fig. 3 RHAPSODYA... -
Page 4: Installation And Start-Up
This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base. Fuse Mains Power DMX IN Ethernet Ethernet Display User buttons (5 pin) THRU Switch Control panel - Fig. 5 RHAPSODYA... -
Page 5: Connecting To Manis Supply
A terminating plug must be inserted into the last projector with a resistance of 120Ohm (minimum 1/4 W) between terminals 2 and 3. IMPORTANT: The wires must not make contact with each other or with the metal casing of the connectors. The casing itself must be connected to the shield braid and to pin 1 of the connectors. ‘ Continue RHAPSODYA... -
Page 6: Switching On The Fixture And Basic Setup Maintenance
Dmx Address Warning Message Switching on the projector - Fig. 9 Press the switch. The projector starts resetting the effects. At the same time, the following information scrolls on the display: RHAPSODYA Firmware xxx (Fixture ID) System errors Version X.X.X Dmx Address xxx E: ...... - Page 7 The projector’s DMX address, as well as other possible operating options, can also be set when the appliance is disconnected from the electricity supply. All that is needed is to press to momentarily activate the display and thus access the settings. Once the required operations have been carried out, the display will switch off again after a wait time of 30 seconds. RHAPSODYA...
-
Page 8: Opening The Covers
1/4 Turn 1/4 Turn 1/4 Turn CLICK!! Locking and releasing Pan and Tilt movements - Refer to the instructions in the UNPACKING AND PREPARATION section. Opening the head covers - Fig. 11. Closing the head covers - Fig. 12. RHAPSODYA... -
Page 9: Periodical Cleaning
• General cleaning of internal parts. • Restoring lubrication of all parts subject to friction, using lubricants specifically supplied by Claypaky. • General visual check of the internal components, cabling, mechanical parts, etc. -
Page 10: Effects Module Removal
Lower side Extraction of the effect modules: Preliminary operations - Fig. 14. NOTE: - Do not disconnect wiring harnesses when the fixtures is switched-on, to avoid to damage electronic boards. - Do not switch-on the fixtures with wiring harness disconnected. RHAPSODYA... - Page 11 Extraction of the effect modules - Fig. 15. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 15, 16 and 17 in reverse order. ‘ Continue RHAPSODYA...
- Page 12 Extraction of the effect modules - Fig. 16. IMPORTANT: Grasp the modules using the support structure and not the details which could get damaged. Insertion of the effect modules: Repeat the operations indicated in Fig. 15, 16 and 17 in reverse order. RHAPSODYA...
-
Page 13: Cleaning Of The Filters
4.4 Cleaning of the filters 1/4 Turn Cleaning of the grids - Fig. 17 ‘ Continue RHAPSODYA... - Page 14 31.8 ±0.1 Replacing rotating gobos (max 27 mm image – thickness 1.1 mm) - Fig. 19 - The rotating gobo wheel only use dichroic glass gobos (it is not possible to use metal gobos); - For more information contact Claypaky; RHAPSODYA...
- Page 15 To determine which side of a godo is coated, hold an odject up to it. On the uncoated side, there is a space between the object and its reflection. Gobo orientation - Fig. 20 The pictures shown the correct gobos orientation. ‘ Continue RHAPSODYA...
-
Page 16: Battery Removal
4.6 Battery removal This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the regulation in force. RHAPSODYA... -
Page 17: Dimensions
Call an authorised technician. Signal transmission cable faulty or disconnected. Replace the cables. Incorrect addressing. Check addresses (see instructions). Fault in the electronic circuits. Call an authorised technician. Lenses broken Call an authorised technician. Dust or grease deposited. Clean (see instructions). RHAPSODYA... - Page 18 RHAPSODYA...
- Page 19 RHAPSODYA...
- Page 20 – Service support & Helpdesk: https://e-assist.tech...
