Claypaky C61602 Quick Start Manual

REFLECTOR CONVERSION KIT
C61601 - KIT Scenius Profile Reflector (Flat for Scenius Spot)
C61602 - KIT Scenius Spot Reflector (Hot Spot for Scenius Profile)
Foreword
This document provides useful information and procedures to install the Flat Reflector kit for Scenius
series. All the needed parts are included in the kit, and no change to the firmware or to the standard
DMX personalties of the fixtures are needed before using the product after conversion.
If you store and label the parts you will remove during the installation process it will be possible in the
future to go back to a "peaky beam" Scenius. Replacement of common parts subject to wearing
(such as those installed in zones subject to extreme heat) might be needed if many working hours
pass between subsequent conversions.
No additional safety precaution is given by this modification during the normal use of the fixture, but
you are required to follow all the cautions and warnings stated in the user manual included with the
fixture. These safety information also apply to all steps of the conversion procedure, considering
access to the lamp zone and removal of such components is one of the required operations.
1.

KIT CONTENT / NEEDED MATERIAL

2. Covers Removal
3. Reflector Installation
IST00W/001
SCENIUS SERIES
KIT077/801 - KIT Flat Beam for Scenius Unico
INDEX
2
2
3
