- Page 1 OM-CP-PRTRANSIS-A2 Xxxxx Xxxxxx Rugged Pressure Data Logger Xxxxx Xxxxxx Xxxxxxxx INSTRUCTION MQS5783/0920 M0000/0016 SHEET Shop online at omega.com e-mail: info@omega.com For latest product manuals: www.omegamanual.info 800898...
- Page 2 OM-CP-PRTRANSIS-A2 Product Notes Getting Started To access the COM Port for the interface cable, unscrew the key-ring end cap. Ensure the end cap is screwed on tightly before deploying the data logger. Intrinsic Safety Approval The OM-CP-PRTRANSIS-A2 has been certified as Intrinsically Safe (IS) certification in accordance with the latest issue of FM3600 and FM3610.
- Page 3 OM-CP-PRTRANSIS-A2 Installation Guide Installing the software Insert the Omega Software Flash Drive in an open USB port. If the autorun does not appear, locate the drive on the computer and double click on Autorun.exe. Follow the instructions provided in the Installation Wizard. Installing the Interface cable - OM-CP-IFC200 (required, sold separately) Insert the device into a USB port.
- Page 4 OM-CP-PRTRANSIS-A2 Device Maintenance Battery Replacement Materials: 9/16 inch (15mm) wrench, small needle nose pliers and a replacement Battery (OM-CP-BAT102) 1. Move the device to a non-hazardous location before replacing battery. 2. Observe Operational Warnings when removing and replacing the battery. 3.
- Page 5 OM-CP-PRTRANSIS-A2 OM-CP-TRANSIS-A2 General Specifications Pressure Sensor Semiconductor (strain gauge) Pressure Range Calibrated Accuracy *See Table Below Pressure Resolution Memory 262,143 samples Reading Rate 1 reading every 10 milliseconds to 1 reading every 1 second Units PSIA(G), inches, altitude, Torr, mmHg, bar, Pascals Required Interface Package OM-CP-IFC200 (required, sold separately) Baud Rate 115,200 Typical Battery Life 3 days @ 10 milliseconds/sample...
- Page 6 OMEGA is a registered trademark of OMEGA ENGINEERING, INC. © Copyright 2016 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.
